LITETRONICS LED Vapor Tight Slim Strip Light User manual
Installation Instructions
For 4’ and 8’ LED Vapor Tight Slim Strip Light (VT Series)
LED Vapor Tight Slim Strip Light
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLATION
WARNING:
READ CAREFULLY BEFORE INSTALLING STRIP LIGHT. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
CRITICAL SAFETY INSTRUCTIONS:
Installation should only be conducted by a qualified electrician in accordance with NEC and any relevant local
building codes.
Risk of fire or electric shock. Strip Light installation requires knowledge of luminaires electrical systems. If not qualified,
do not attempt installation. Contact a qualified electrician.
Be certain electrical power is OFF before and during installation and maintenance.
Strip Lights must be connected to a wiring system with an equipment–grounding conductor.
Make sure the supply voltage is the same as the rated Strip Lights voltage.
To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or sharp objects.
SAFETY INSTRUCTIONS AND WARNINGS
4’ Lamp
AC Line/Neutral/ Ground
Mounting Parts
Mounting Parts
3
TOOLS TYPICALLY USED FOR INSTALLATIONS
Wire Stripper
(optional)
Wire Cutter
(optional) Phillips Screwdriver
WHAT COMES IN THE BOX
LED Vapor Tight Slim Strip Light base product comes with following standard parts:
Before Installation, carefully remove all parts from the packaging.
Inspect product for defects due to shipping.
Drill
1312
Measuring Tape Step Ladder
IMAGE PART 4’ QT Y 8’ QT Y
ALED Vapor Tight Slim Strip Light 1 1
BMounting Brackets 2 3
CAnchors 2 3
DMounting Screws (#6 x 1 1/4”) 2 3
EAnti-spread Nuts 2 3
FAnti-spread Screws (M3 x 40) 2 3
GTooth Lock Washers (M3) 2 3
HTooth Lock Washers (M4) 2 3
IInstallation Instructions 1 1
B
A
C D E F G H
4
4’ & 8’ VAPOR TIGHT SLIM STRIP LIGHT
SURFACE MOUNT INSTALLATION
Section 1
1. Turn off power at electrical panel.
Note:
For 4’ Installation- 2 holes required. (Extreme ends)
For 8’ Installation- 3 holes required. (Extreme ends & center)
2. Determine mounting position and mark placement for
brackets. Drill pilot holes for anchors.
READ ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION
3. Insert the anchors into the surface by pressing firmly or
gently hammering until anchors are level with surface.
5
4’ & 8’ VAPOR TIGHT SLIM STRIP LIGHT
SURFACE MOUNT INSTALLATION
Section 1
6. Place Vapor Tight Slim Strip Light into both brackets. They
will snap into place. Slide into final position.
4. Place tooth lock washers (M4) over mounting screws
(#6 x 1 1/4”), then through center hole of brackets and
screw into anchors.
5. Tighten brackets down and be sure to align in same
direction.
6
4’ & 8’ VAPOR TIGHT SLIM STRIP LIGHT
SURFACE MOUNT INSTALLATION
Section 1
READ ALL INSTRUCTIONS BEFORE BEGINNING INSTALLATION
7. Use anti spread hardware to prevent fixture from
moving after installation. Slide anti spread screw (M3 x
40) through tooth lock washers (M3). Then slide screw
through holes in back of brackets.
8. Thread anti spread nuts onto screws and tighen.
9. The fixture will now be firmly in place.
7
12/20/2017
INPUT
CABLE WIRE
L (Black)
N (White)
Green GND
ACL (Black)
ACN (White)
GND (Green/Yellow)
LAMP
(VAPOR TIGHT)
4’ & 8’ VAPOR TIGHT SLIM STRIP LIGHT
SURFACE MOUNT INSTALLATION
Section 1
10. Using wire nuts (not included), connect incoming wires with fixture wires following wiring diagram below.
11. Turn on the power and you are done.
V4 (1-17-18)
WWW.LITETRONICS.COM
CustomerService@Litetronics.com or 1-800-860-3392
6969 W. 73rd Street
Bedford Park, IL 60638
