Little Giant HWAB User manual

Applications
nLift pump chambers
nSump pump basins
nHolding tanks
nSewage and water removal systems
Features
nBattery backup feature to ensure that alarm
system continues to work if primary power fails
nLow battery chirp indicates when battery
should be replaced
nAutomatic alarm reset
nAlarm horn sounds at 87 decibels at 10'
nNEMA 1 enclosure, designed for ease of installation
nExternal terminal block for easy float installation
nFloat switch operates on low voltage and is
isolated from the 120V power line to reduce
the possibility of shock
nEntire unit UL listed and CSA certified
nTest switch to check proper operation of alarm
system
nSilence switch to turn off horn while alarm
condition is being remedied
Specifications
nVoltage:
Primary - 120VAC, 60Hz, 2.4 watts max.
(Alarm Condition)
Secondary - 9VDC
nBattery Backup Power: 9VDC
nAlarm Enclosure: NEMA 1 plastic
nAlarm Horn: 87 decibles at 10' (3m)
nPower Cord: 6' (1.8m)
nAlarm Float: Non-corrosive plastic float for use
in liquids up to 140°F (60°C) with 15' (4.6m)
18 guage, 2 conductor SJOW water resistant cord
The HWAB indoor high water alarm is designed to
warn of high water levels in lift chambers, sump basins,
holding tanks, sewage and water removal systems.
When a potentially threatening liquid level condition
occurs, the alarm horn will sound and the alarm light
will illuminate. The alarm light will remain illuminated
until the condition is remedied. Once the condition is
cleared, the alarm will automatically reset.
A green “power on” light indicates 120VAC primary
power is being applied to the alarm. The alarm is
equipped with a 9VDC battery backup to ensure the
alarm system continues to function if primary power
fails. If battery is low, a low battery chirp feature will
cause the horn to chirp approximately once per minute.
This indicates that the battery should be replaced.
Indoor High Water
Alarm System
HWAB – Indoor High Water Alarm

Form 995271 — 06/2004www.LittleGiantPump.com
HWAB – Indoor High Water Alarm
General Installation Instructions:
1. Determine indoor mounting location and insert screw in
desired location.
2. Hang alarm using keyhole on back of enclosure. Install
second screw in mounting flange at bottom of alarm.
3. Make sure power is disconnected.
4. Place the float switch cord into the clamp as shown in
Figure A.
5. Locate float at desired activation level and secure to the
discharge pipe as shown in Figure A. NOTE: do not install
cord under clamp band or over-tighten clamp band.
6. Make sure excess clamp band does not interfere with float
operation
7. Connect float switch cable to alarm according to Figure B.
8. Install 9 VDC for backup alarm function.
9. Plug the alarm power cord to primary power and verify the
green “power on” light is illuminated.
10. Use the provided cable clasp and secure the power cord
to the outlet as shown in Figure C. Use existing receptacle
faceplate screw and supplied washer.
11. Check installation by raising the alarm float. The horn will
sound and the “alarm” light will illuminate.
Figure A.
Figure B.
Figure C.
NOTE: Little Giant Pump Company cannot be responsible for damages
caused by faulty or negligent installation of this control. We recommend
that you engage the services of a competent plumber, electrician, or quali-
fied service person to install this product in accordance with national and
local electrical codes.
Item
Number
Model
Number
Primary
Voltage
Secondary
Voltage
513288 HWAB 120V, 60 Hz 9VDC
