LIVERYMAN CLASSIC 112053 User manual

PROFESSIONAL
HORSE TRIMMER
LIVERYMAN.CO.UK
INSTRUCTIONS FOR USE

2
INSTRUCTION MANUAL FOR CLASSIC TRIMMER
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance
Please Note: A copy of these instructions can be downloaded by visiting our
website at www.liveryman.co.uk
This appliance is designed to be used in commercial areas.
DANGER: To reduce the risk of electric shock: Do not reach for an appliance that
has fallen into water. Unplug immediately from receptacle. Unplug this appliance
before cleaning.
WARNING: To reduce the risks of burns, fire, electric shock, or injury to persons:
Close supervision is required when this appliance is used by, on, or near children,
or persons with limited physical, sensory, or mental capabilities or invalids. Use
this appliance only for its intended use as describe in this manual. Do not use
attachments not specified by the manufacturer. Never operate this appliance when
it has a damaged cord or plug, when it is not working properly, after it has been
dropped or damaged, or after it has been dropped into water. Return the appliance
to a service centre for examination and repair.
WARNING: This appliance is intended for animal clipping and trimming purposes
only. Use only on clean dry hair.
WARNING: During use, do not place or leave the appliance where it is expected to
be: subject to damage by an animal, or exposed to weather.
WARNING: Cutting blades may become hot after prolonged use.
WARNING: For the purposes of recharging the battery, only use the detachable
supply unit provided with this appliance. Charging must be carried out indoors and
in a dry place.
• The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
• Animal trimmer can be used by children aged from 3 years under supervision.
• Animal trimmers can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without
supervision.
Original Instructions

3
• Keep the cord away from heated surfaces. Do not pull, twist or wrap the cord.
• Do not use operate where aerosol (spray) products are being used or where
oxygen is being administered.
• Always attach plug to appliance first, then to outlet. To disconnect, turn all
controls to off position (e.g. “0”) then remove plug from outlet.
SAVE THESE INSTRUCTIONS
To ensure you achieve the best possible results from your trimmer, please read
the following instructions carefully before use.
TECHNICAL SPECIFICATION
Charging time: 2.5 hours
Operation time: 3.5 hours
Blade width: 46 mm
Dimensions: 16 (H) x 4.6 (B) x 4.1 (D) cm
Weight: 290 grams
Replacement blade: Adjustable Titanium and Ceramic blade
1. Trimmer Hand piece 6. Top Cutter Blade
2. On/Off switch 7. Blade set clip
3. Comb attachment recess 8. Oscillating bracket
4. Charging Indicator 9. 4/6/9/12mm combs attachment comb
5. DC In socket 10. Charging stand
1
2
8
4
3
7
6
9
10
5

4
SAFETY GUIDELINES AND OPERATOR RESPONSIBILITIES
1. Only use this appliance for its intended purpose. Use only on clean dry hair.
2. Close supervision is necessary when this appliance is by or near children.
3. Use only with accessories included in the package, or recommended by the
manufacturer.
4. Avoid contact with the eye area, and damaged or sensitive skin.
5. Except when charging, always unplug from the electrical socket after use.
6. Keep away from water or any detergent.
7. Do not pull, twist or wrap the cord.
8. Charging must be carried out indoors and in a dry place.
9. The charger adaptor must be kept dry at all times.
Should the following situations occur, unplug and switch off immediately, and
send for examination or repair:
1. The blade, main unit, power cord or attachment comb is damaged.
2. The trimmer or the adapter is dropped into water.
3. The trimmer is switched off, but the charging indicator does not light up when
plugged into the power source.
The trimmer and accessories must be checked regularly for damage.
If damage is detected, do not put the device into operation.
IMPORTANT NOTICE
BLADE
1. The blade must be lubricated before and after each use. This will maintain it in
good condition and will extend its service life.
2. Non-stop usage for hours may cause overheating of blades, reducing the
cutting performance and shortening their life. Should the blades overheat,
switch the unit off for a few minutes to let it cool down and lubricate the
blades.

5
3. Hair must be clean and dry before cutting. Foreign matter hidden in the hair
may damage the blade edge.
4. Hair may gather in the inside of the blade housing during use. Too
much stored hair will reduce the clipping ability of the blades and cause
malfunctioning. Always clean up hair in the blade housing before and after
each use.
5. Avoid impact of the blade with hard objects as this may cause damage to the
blade teeth.
BATTERY
1. Do not overcharge. It takes 2.5 hours to charge your trimmer. Charging over 36
hours may shorten the life of the battery.
2. The life of the battery will be shortened if the trimmer remains uncharged for
long periods. Charge every 3 months of non-use to activate the battery.
3. It is normal for the adapter and the internal parts to become warm when
charging.
OTHERS
1. Use or store the trimmer only at room temperature. Avoid direct sunlight,
moisture or heated surfaces. Operating range 0 - 40 °C.
2. Do not attempt to unscrew any part of the trimmer.
OPERATING INSTRUCTIONS
CHARGING
1. Switch off trimmer.
2. Connect the DC plug to the charging stand.
3. Place the trimmer into the charging stand.
4. Connect the adapter to the wall socket.
5. Check the charging indicator. When the indicator light of the trimmer unit is red,
the unit is charging.
6. When the trimmer is fully charged, the indicator will change to blue.

6
7. Simply unplug the charging stand.
Initial Charge: 24 hours (first charge only)
Recharge: 2.5 hours
Cordless Operation: 3.5 hours
BATTERY CONDITION INDICATOR
Fully charged: Blue
Less than 15 minutes use: Slow red flash
Less than 10 minutes use: Rapid red flash
BLADE ADJUSTMENT
The adjustment lever is located at the bottom of the blade set.
Select the desired length of cut by moving the adjustment lever sideways.
Cut Heights:
I: 0.8mm II: 1.2mm III: 1.6mm IIII: 2.0mm
COMB ATTACHMENTS
You may adjust the cutting length from 3-12mm by attaching the comb attachment.
1. The cutting length is marked on the of comb attachments.
2. Select a suitable size and slide the blade into the comb attachment.
CORD OPERATION
This trimmer can be operated by plugging it into the power source when the
battery is not fully charged.
1. Switch off.
2. Connect the adapter to the wall socket.
3. Connect the DC plug to the trimmer.
4. Check the charging indicator. The indictator will light up red.
5. Wait for 1 minute to activate the internal parts.
6. Switch on to operate. The indicator light will go off when operating.

7
CAUTION
• Except for the purpose of charging, always switch off and unplug the adapter
from the wall after use.
• Do not frequently use the trimmer plugged without having recharged the
battery, as this may reduce the life of the battery.
• Charge at room temperature between 5°C and 35°C.
MAINTENANCE
Always switch off before removing, replacing and cleaning the blade.
REMOVING AND CLEANING THE BLADE
1. Remove the blade set from the blade housing by pressing the top cutter blade
backwards with your thumb.
2. Brush off the stored hair thoroughly from between the teeth and the blade
housing.
3. Press down gentle on the oscillating bracket (see #8 on page 2) with your
thumb to separate the top cutter blade from the comb; brush out any hair
between the blades. Ensure that hair is not trapped between the blades before
releasing bracket.
LUBRICATING THE BLADE
Lubricate both friction surfaces of the front cutting teeth and the hind supporting
areas.
1. Hind supporting areas: Push the oscillating bracket (see #8 on page 2) to one
side; lubricate the visible friction surface on the other side. Drop a small amount
of oil on both sides.
2. Front cutting teeth: Drop a small amount of oil on the blade teeth and spread
evenly. Slightly move the oscillating bracket to spread the oil between the
blades.

8
REPLACE THE BLADE
1. To replace the blade set, put the bottom of the blade set clip (7) into the blade
set mount position (the little square part) on the blade housing.
2. Push gently but firmly inwards until it snaps into place.
CLEANING THE MAIN BODY AND ACCESSORIES
1. Switch off and unplug the trimmer before cleaning.
2. Wipe with a soft damped cloth.
3. Allow it to air-dry before use.
BLADE LIFE
The service life of the blade may be shortened in the following situations:
1. The blade has not been lubricated properly over a long period.
2. The blade cuts objects other than hair or unclean hair.
3. A foreign object damages the blade edge.
4. The blade is subjected to an impact.
If the cutting efficiency is reduced substantially despite proper maintenance, the
blade has exceeded its service life and should be re-sharpened or replaced.
MOTOR LIFE
• No maintenance is required for the motor.
• The service live expectancy if the motor is approximately 10000 under proper
usage.
The service life of the motor may be shortened in the following situations:
1. The trimmer is stored in humid surroundings for long periods.
2. The blade has not been lubricated properly.
3. Stored hair in the blade housing has not been cleaned properly.
4. An incorrect power source is used.

9
BATTERY LIFE
• The service life expectancy of the battery is approximately 1000 recharging
cycles. After that the charge will gradually drain and the power will be reduced.
The service life of the battery may be shortened in the following situations:
1. The battery is stored in humid surroundings for long periods.
2. The battery is over-charged.
3. The battery is over depleted (when the battery is out of power, the trimmer is
kept in the switched-on position for long periods).
4. The trimmer is always used plugged in.
5. The trimmer has not been charged for more than 6 months.
• When not in regular use, it is recommended to recharge the battery at least
every 3 months.
• If cordless operation lasts for less than 10 minutes, despite proper recharging,
the battery has exceeded its service life and should be replaced.
OPERATIONAL HINTS
• The Classic can be used to clip with or against the direction of the coat.
• For trimming longer hair use in conjunction with the combs and clip with the
direction of the hair.
• For a closer clip use against the hair.
• For the best finish, guide the trimmer through the coat. Do not force the trimmer
as this will cause an uneven cut, and the blades may jam.

10
EUROPEAN DIRECTIVES AND STANDARDS
The trimmers are manufactured to comply with the relevant European Directives
and Standards.
2006/95/EC LVD
2004/108/EC EMC EN60335-1 EN603355-2-8
2011/65/EU ROHS
ENVIRONMENTAL DISPOSAL
It is the owner’s responsibility to dispose of the trimmers in a reasonable manner
after their useful life. Do not dispose of in household waste.
The trimmer can be returned to the place of purchase or Liveryman (at Agrihealth)
for recycling, or taken to your local authority waste disposal site.
WARRANTY REGISTRATION
Please visit our website to register your warranty.
www.liveryman.co.uk
You will require the products serial number which can be located on the underside
of the trimmer and proof of purchase.
Agrihealth
TRUSTED SINCE 1966
Model No: 112053
Liveryman is part of the Agrihealth Group.
For more information visit www.agrihealth.ie

11
SPARE ITEMS
CODE DESCRIPTION
112483 Classic Mains Adapter
112473 Classic Charging Base
112273 Classic Blade Adjustable
112283 Classic Comb Set (4 piece: 3,6,9&12mm)
CLASSIC TRIMMER BLADE INFORMATION
Classic Trimmer Width Clip
mm Type of Clipping Combs
112273 CLASSIC
BLADE 46 0.8 - 2.0
Close to medium
adjustable. Use close
setting with combs.
3/6/9/12mm
MAINTENANCE
CODE DESCRIPTION
150073 Clipper Care Kit (Blade Wash & Oil)
150583 Clipper Oil Spray 200ml
150423 C&C Wash Spray 200ml
150563 Clipper Oil Liquid 100ml
150573 Clipper Oil Liquid 250ml
Liveryman is part of the Agrihealth Group.
For more information visit www.agrihealth.ie

LIVERYMAN.CO.UK
Liveryman Display Panel BETA 2021 1 19/12/2019 15:30:12
LIVERYMAN.CO.UK
Liveryman Display Panel BETA 2021 1 19/12/2019 15:30:12
LIVERYMAN.CO.UK
Find us on @LiverymanClippers @liveryman_
