Living & Co DYD-S10A412 User manual

INSTRUCTION MANUAL
DYD-S10A412
DEHUMIDIFIER
NZ
SALES
AFTER
SUPPORT
0800 422 274

NZ
SALES
AFTER
SUPPORT
0800 422 274
1

Safety Instructions 3
5
7
8
Cleaning
11
Storage
12
Trouble Shooting 13
Technical Specifications 1 4
Product Overview
Prior to Operation
Operation Instructions
Display Error Codes 12
Contents
Page
NZ
SALES
AFTER
SUPPORT
0800 422 274
2

Safety Instructions
NZ
SALES
AFTER
SUPPORT
0800 422 274
3
Warning
Cautions Wet hands not allowed Warning
This appliance is intended for use in a domestic environment only. Any other use is not recommended
by the manufacturer and may cause fire, electrical shocks or other person injury and property damage.
Do not touch the plug with
wet hands in order to avoid
electric shock.
Do not put any heavy
objects on the power
cord in order to damage
and electric shock risk.
Ensure and extension cord
or power board used in
conjunction with this appliance
is appropriately rated and in
good working order.
Do not use the appliance
Do not attempt to change
the power cord yourself.
Contact an authorized
service centre for repair.
Only use a supply socket
outlet that has a reliable
earth connection.
Please pull out the plug
during lightning storms.
Power Cord
Hold the plug when
unplugging the device
from the socket. Do
not pull on the cord.
if the plug cannot be
held in the socket firmly.

Safety Instructions
NZ
SALES
AFTER
SUPPORT
0800 422 274
4
Placement
During Use
Please turn off the
power and unplug the
power cord before
moving it.
Children should be
supervised to ensure
that they do not place
any objects into the
appliance.
Do not put hands on the
air outlet in order to avoid
injury or malfunction.
Do not put any heavy objects
on the appliance in order
to avoid malfunction.
Do not use the appliance
at a swimming pool or similar
facilities in order to avoid
safety hazard.
Do not put flammable
and explosive objects
around the appliance in
order to avoid fire.
Do not use the
appliance in a
draughty place.
Place the appliance on a
stable, flat surface.
The appliance must not be
covered when being used.
Please install the air filter
before using it.
Do not let the appliance
topple over or let the
appliance be subjected to
strong impact in order to
avoid malfunction.

NZ
SALES
AFTER
SUPPORT
0800 422 274
5
Product Overview
Figure1
Figure2
Figure3
1
2
3
5
6
7
8
9
10
1112131415
16 17 18 19 21 22
24
4
(2S)
23
25
20

NZ
SALES
AFTER
SUPPORT
0800 422 274
6
Product Overview
Components
Control Panel
Drainage
1. Front Cover
2. Top Cover
3. Control Panel
4. Air Outlet
5. Cupped lift
6. Air Inlet Filter
7. Water Tank
8. Rear Cover
9. Drainage Outlet
10. Power Cord
11. Power Button
12. Timer button
13. Humidity control button
14. Fan Speed Button/Child Lock Button
15. Laundry Drying Button
16. Laundry Drying Indicator
17. High Fan Speed Indicator
18. Low Fan Speed Indicator
19. Humidity Reading Display
20. Timer Indicator
21. Tank Full Indicator
22. Running Indicator
23. Defrost Indicator
24. Drainage Outlet
25. Drainage Pipe

Prior to Operation
NZ
SALES
AFTER
SUPPORT
0800 422 274
7
Place the dehumidifier in an upright position on a stable, flat surface.
Ensure the dehumidifier is at a safe distance at least 50cm away from a wall or furniture.
Supply power should be in correspondence with the value on the nameplate, power outlet needs to be
grounded.
Ensure the tank is correctly fitted, if the tank is full or not in place, the tank full light comes on and
the dehumidifier will stop working.
Continuous Drainage
In general, water will be collected by the integrated tank, if you want continuous drainage, please follow
the steps in figure 3.
a.Take out the water tank.
b.Insert a drainage pipe with a 12mm inner diameter into the drainage outlet.
c.Replace the water tank.
Note: always ensure the drainage pipe is going downhill, and is not blocked or kinked.
Ensure that the air in/outlet is not blocked.
≥20cm
≥50cm
≥20cm
≥20cm
≥20cm
Turn on the power.
Select the relative humidity that you want, for most applications this will be 55%rh.

Operation Instructions
NZ
SALES
AFTER
SUPPORT
0800 422 274
8
Switch On / Switch Off The Unit [ Power button ]
When the machine is in standby mode, the on/off inicator will flash slowly.
Auto Shut-off Timer Function [ Timer button ]
Humidity Setting [ Up and Down buttons ]
Press the humidity setting buttons to select your preferred humidity from CO-30%-35%-40%-45%-
50%-55%-60%-65%-70%-75%-80%-CO. CO means continuous dehumidifying regardless of
ambient humidity.
(2S)
(2S)
(2S)
Connect to the power supply and press the power button once to turn on the unit, the unit runs by
default mode on manual continuous dehumidifying with low fan speed.
Press the power button to turn the unit off, the fan will continue to operate for a few seconds to
blow out the hot air inside the unit.
Press the timer button, then press up/down buttons to select your preferred number of hour from 00-24-00
The appliance will shut off automatically once the selected number of hours is reached.
Auto timer function will be canceled if the timer button is pressed twice in 5 seconds.
Auto timer function will be canceled if the appliance is switch off and on again.

Operation Instructions
NZ
SALES
AFTER
SUPPORT
0800 422 274
9
Fan Speed Option [ Fan Speed button ]
Press the fan speed button to select your preferred fan speed setting of low and high to meet the
different usage requirements.
Fan speed button is invalid at Laundry drying mode and Defrost mode.
Laundry Drying Function [ Laundry Drying button ]
Press the laundry drying button to Laundry Drying function, the unit runs in continuous
dehumidification with high fan speed for 6 hours then switch off
activate
automatically.
Fan speed button and timer button are invalid.
Press the for 2s to lock all buttons with a beeping sound, the same operation can
unlock it.
Fan speed button
Safety childlock function can be set at standby mode and working mode but can’t be activated
when the water tank is full.
Safety Childlock Function [ -2 seconds ]Fan Speed button
(2S)
(2S)
(2S)

Operation Instructions
NZ
SALES
AFTER
SUPPORT
0800 422 274
10
When the ambient temperature is too low, dehumidifier will enter into the defrost mode, the unit runs
with high fan speed without dehumidifying.
Low Temperature Defrost Indicator
(2S)
Memory Function:
Auto Shut off with Water Tank Full Indicator
(2S)
a.When the unit is unplugged or after a power cut, the dehumidifier will run in the mode prior to the
shutdown. The timer setting will be maintained.
b.Press the power button to switch off the dehumidifier, and then press the power button to switch it
back on. The dehumidifier will run in the mode prior to the shutdown. The timer setting will be
canceled.
The unit will enter into standby mode when the water tank is full or the water tank is not installed properly.
After emptying and re-installing the water tank, the unit will go on to the previous mode.
Except for the power button, all other buttons are invalid.
(2S)
c.Switch off the dehumidifier and unplug the power plug, then reconnect the power supply and switch on
the dehumidifier. It will run in the factory preset mode like the first time you received the dehumidifier.

Cleaning
NZ
SALES
AFTER
SUPPORT
0800 422 274
11
When used regularly , the filter may become clogged with dust and particles. Therefore the filter should
be cleaned at least every two weeks. Follow these steps:
1. Switch the device off and remove the plug from the socket before
cleaning.
2. Clean the housing with a soft, dry cloth. If the device is extremely dirty,
use a mild cleaning agent. Wipe the dehumidifier with a slightly damp
cloth. Never spray the device with water.
3. Remove the filter. Clean the filter with a vacuum cleaner or soapy
water
no hotter than 40℃.
4. Rinse and dry the filter completely before installing back on the
device.

Storage
Display Error Codes
NZ
SALES
AFTER
SUPPORT
0800 422 274
12
If the dehumidifier will not be used for a long period of time, take the following steps:
1. Remove the plug from the socket and empty the tank the tank and the dehumidifier to , dry
completely. This may take a couple of days.
2. Clean the air filter .
3. Check the dehumidifier for damge.
4. Pack the device with the suitable packaging.
5. Store the dehumidifier in a dust-free and out of direct sunlight location, preferably covered with a
sheet of plastic.
Display Code E1 E2
Error Temperature sensor error Humidity sensor error
Display Flash every 30 seconds Flash every 30 seconds
What is happening Device still dehumidifies but is
in defrost mode only.
Device still dehumidifies but is
in continuous dehumidifying
mode only.
Please contact local distributor if any of the error codes below appears.

Trouble Shooting
NZ
SALES
AFTER
SUPPORT
0800 422 274
13
Check the following before contacting technical support .
PROBLEM POSSIBLE CAUSE SOLUTION
The device does
not work
The power is not connected Insert the plug into the wall outlet
The water tank is full Empty the tank
The tank has not
been replaced correctly Replace the tank
Runtime is too short Be patient and leave the unit running for a longer
duration
Ambient temperature or
humidity is too low
It is normal that the device does not dehumidify in
these conditions
The room is too big We recommend using a dehumidifier with a
greater capacity
Water removal
capacity is too low
There is too much ventilation Reduce ventilation(e.g. close windows and shut
doors)
The air filter is clogged Clean the air filter
Set humidity is higher than
the ambient humidity Set the humidity lower than ambient humidity
Dehumidifier is
blowing out warm air This is normal, a dehumidifier is not an air cooler
The device works,
but reduces the
relative humidity
inadequately
The dried air is passed over
heating coils before it is blown
into the room as part of the
dehumidifying process
The display is not
showing the humidity
set point
The display shows the room
relative humidity not the set
point
Press the humidity control button once to see the
target relative humidity
Water on floor
There is residual water in tank,
and the device is lurched too
much by moving
Be careful when moving the tank
The dehumidifier is
noisy
The air filter is blocked or
the device is on an uneven
surface
Clean the filter or put the device on a flat surface

Power Supply
Dehumidifying Capacity
Power Consumption
Air flow
Water Tank Capacity
Noise Level
Operating Temperature
Refrigerant
Net Weight
Product Size (W×D×H)
Model
NZ
SALES
AFTER
SUPPORT
0800 422 274
14
DYD-S10A412
220-240V~ 50Hz
10L/day(30℃ RH80%)
5.0L/day(27℃ RH60%)
160W nominal / 225W maximum
100m³/h
2.6L
40dB(A)
5~35℃
R134a
10.5 kg
300 × 250 × 463 mm
At the end of its working life, make the appliance unserviceable by unplugging it
from the power outlet and cutting the power cord.
Do not throw this appliance out with your household rubbish. Electrical and electronic
products contain substances which can have a detrimental effect on the environment
and human health if disposal of inappropriately. Observe any local regulations
regarding the disposal of electrical consumer goods and dispose of it appropriately
for recycling. Contact your local authorities for advice on recycling facilities in your area.
The above technical data is indicative and for reference only. Some variation may exist between batches.
This appliance has been fully tested and meets all requirements as set out by standards
AS/NZS 60335.1 and AS/NZS 60335.2.40.
The RCM Mark(Regulatory Compliance Mark) indicates that the product
complies with relevant guidelines of the ACMA as well as corresponding
government requirements for the safety of electrical devices.
Responsible disposal
Technical Specifications
Compliance

NZ
SALES
AFTER
SUPPORT
0800 422 274
15
We pride ourselves on producing a range
of quality home appliances that are both packed with features
and completely reliable. We are so confident in our products,
we back them up with a 3 year warranty
Now you too can relax knowing that you are covered.
accompanied by proof of purchase.
Customer Helpline NZ:0800 422 274
This Product is covered by 3 year warranty when
IM Version 1.0 - Oct 2018
