Living Spaces 305-P156400 User manual

4Seat Cushion 1pc
3Centre Chair Leg 1pc
1Chair Back 1pc
2Chair Leg 2pcs
E10pcs
Flat Washer M6 x 19mm Ø
B4pcs
JCBC Screw M6 x 60mm
A
D11pcs
Spring Washer M6 x 12mm Ø
C4pcs
JCBC Screw M6 x 80mm
HARDWARE LIST
No. Description Sketch Quantity
F1pc
Allen Key M4 x 65mm
3pcs
JCBC Screw M6 x 35mm
Made In Malaysia
L I V I N G S P A C E S
ASSEMBLY INSTRUCTIONS
ITEM 305-P156400
Dining Bench
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
No. Description Sketch Quantity
PARTS LIST
Page 1 of 2

B
F
D
4x A
F
D
EC
F
D
4x
E
D
AF
2x
E
4
1
3
4
2
4
Made In Malaysia
L I V I N G S P A C E S
Page 2 of 2
COMPLETE
STEP 1 STEP 2
STEP 3
Turn the chair upright and place on level
surface.
Adjust the front legs so that chair is level
and does not wobble.
Tighten all the bolts and take care do not
over tighten.
Do not fully tighten
at this moment.
Do not fully tighten at this moment.
Do not fully tighten
at this moment.
