Living Spaces Paige-Chaise Convertible 243787 User manual

2021-02-01
OPERATING YOUR UNIT
CONVERTING TO CHAISE / LOUNGER / BED
Standing at the side of the unit (from bed position), lift backrest to the desired position and
secure in place by releasing to the sound of a click.
LOUNGER
CHAISE
BED
PAGE-CHAISE CONVERTIBLE
ASSEMBLY INSTRUCTIONS
IMPORTANT,RETAINFORFUTUREREFERENCE: READ CAREFULLY
3

2
ASSEMBLY INSTRUCTIONS
1
2
3
A
B
C
D
E
4x
F
G
PARTS AND HARDWARE
IMPORTANT
Avoid using sharp objectsto open packaging as you may accidentally damage the product.
Please read complete instruction sheet prior to assembly.
Minimum 2 adults required to safely perform assembly process.
A 1
B 1
C 8
D 8
E8
M8 x 65mm
M5
M8 x 19mm
M8
13mm
F4
G 1
AK-M5
MS-M13
BLT-M8-65
FW-M8-19
NT-M8
WL-1011
N/A
QUANTITYPART # PART SKU# PART DESCRIPTION
How to Find Your Furniture Legs
Cómo encontrar las patas de su mueble
Hardware and legs was packed inside
carton box. Assembly instructions was
attached to the carton box.
Note: Bottom view of sofa’s body
