Living Spaces 305-P139240 User manual

Table Top
Table Leg
Top Leaf
HARDWARE LIST
No. Description Sketch Quantity
Made In Malaysia
L I V I N G S P A C E S
ASSEMBLY INSTRUCTIONS
ITEM - 305-P139240 & 305-P139241
Dining Table
No. Description Sketch Quantity
PARTS LIST
Page 1 of 3
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and comparewith the hardwarelist below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
1
2
3
A
B
C
D
E
F
G
H
2 pcs
8 pcs
8 pcs
8 pcs
2 pcs
1 pc
1 pc
1 pc
1 pc
2 pcs
1 pc
JCBC Screw M6 x 70mm
JCBB Screw M8 x 70mm
Spring Washer M8 x 13mm Ø
Flat Washer M8 x 22mm Ø
Metal Plate 50 x 2mm
Metal Stretcher 1214 x 32mm Ø
Allen Key M4 x 65mm
Allen Key M5 x 65mm

Made In Malaysia
L I V I N G S P A C E S
Page 2 of 3
STEP 1
STEP 2
STEP 3
1
UNLOCK LOCK
1
1
3
2 2
- Attach Table leg (2) to Metal Stretcher (F),
Tighten all the bolts and take care do not over tighten.
F
2
F
GAE
1
- Place Table Top (1) on a clean flat surface
attach with Table Leg (2).
Do not fully tighten at this moment.
22
1
2
1
H
D
B
C

Made In Malaysia
L I V I N G S P A C E S
Page 3 of 3
COMPLETE
