Living Spaces 7030-00453 KIT User manual

MAS90: 5043-43240
SUMMIT BED FRAME HARDWARE
QTY: DESCRIPTION:
8100MM DECORATIVE HEAD LAG BOLTS
14MM ALLEN WRENCH
10 6 X 1 1/4" PHIL FLAT PARTICLE BOARD SCREW
1
4MM POWER DRILL DRIVER
7030-00453 KIT
ASSEMBLY: 1 PERSON AND 30 MINUTES
TOOLS:
1) 4 mm Allen Wrench (INCLUDED)
2) 4 mm Allen Drill Bit
(Be sure to FULLY SEAT bit into bolt head before turning)
3) Phillips Head Screwdriver
*We recommend using a power driver with the drill bit if available*
BE SURE THAT LAG BOLTS ARE STARTED INTO THE HOLES ON THE FRAME RAILS DURING ASSEMBLY.
DO NOT FULLY TIGHTEN UNTIL ASSEMBLY IS LOOSELY COMPLETE.

SUMMIT TWIN BOOKCASE BED
w/ DOUBLE 4 DRW STORAGE
4650/4653/4654
4695/4695
PARTS LIST
A) 8 – 100mm Decorative Head Lag Bolts
B) 1- Headboard Assembly
C) 1- Footboard Assembly
D) 2 -5 1/4" x 75" Mattress Rails w/Support Cleats.
E) 3 -3 1/2” x 38 3/4" (Twin) Individual slats
F) 10 -1 ¼” Wood Screws
G) 1 – 4mm Driver for power drill
H) 8 - Silver drawer pulls (box in drawer unit)
I) 16 - 1 1/2" Pan head machine screws (box in drawer unit)
J) 1 - Silver Knob (stapled to inside of Footboard Door)
K) 1 - 3/4" Pan head machine screw (packaged with knob)
NOTE:
Make sure you have all parts before beginning assembly. If you need a part, contact the dealer where
you purchased your bed.
1) Attach mattress rails (D), to headboard (B), and footboard (C) with eight lag bolts and tighten.
2) Spread Slat roll out across bed frame from end to end. Place wood screws in 4 outside corners with slat
pushed tightly up against the footboard/headboard. Place 3 loose slats into gaps in slat roll, an screw down
with wood screws. See Slat installation information on following pages.
3) Install pulls on drawer fronts and knob on footboard door with supplied machine screws, and slide 4Drw
Underdressers into position below mattress rail on both sides of bed.
4) Add the proper thickness innerspring bunk mattress. See Living Spaces for details.

Installation of individual slats for use with Slat Roll (Slat roll sold separately) See your retailer for purchase of Slat Roll
SCREW
SCREW
SCREW
SCREW SCREW SCREW SCREW
SCREW
SCREW
SCREW
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
Installation of individual slats for use with Bunkie Board (Bunkie Board sold separately) See your retailer for purchase of Bunkie Board
SCREWSSCREWSSCREWSSCREWSSCREWSSCREWS
INDIVIDUAL SLATS INDIVIDUAL SLATS INDIVIDUAL SLATS
When used with a slat roll, the three
individual slats should be placed evenly in the gaps and underneath the strapping before fastening.
Individual Slat
Individual Slat
Individual Slat
