Living Spaces AUSTEN D2101-227-F User manual

ASSEMBLY INSTRUCTIONS
AUSTEN - DINING CHAIR W/UPH SEAT
ITEM NO : D2101-227-F SKU: 318063
15 min
A
SPCES
LI V I NG
1

PART
A
B
C
SKU#
318063-A-B (BLACK)
Chair Leg
PART
1
2
3
SKU#
Hardware List of Dining Chair W / Uph Seat
318063-1(4)
1
1
2
IMAGE DESCRIPTION QTY
DESCRIPTION
Note: Screwdriver will be prepared by yourshelf.
THE HARDWARE IS LOCATED IN THE PACKING ITEM
NOTE: MUST TIGHTEN SCREWS PERIODIACLLY. WITH USE SCREW
MAY ENCOME LOOSE CHECK TIGHTNESS OF ALL SCREWS EVERY 6-8
WEEKS.
CLEANING INSTRUCTIONS:
After assembly, clean and polish the completed parts if necessary
with soft cloth and industrial recognized furniture polish.
2
QTY
4
4
2
318063-B-B (BLACK)
318063-C-B (BLACK)
318063-2(4)
318063-3(2)
Bolts M4*Ø1/4*60mm
1
318063-4(1) Allen key M4
4
Bolts M4*Ø1/4*80mm
Bolts M4*Ø1/4*38mm
Chair Back
Chair cushion

DETAIL VIEW
STEP 1:
*Use screw(1 and 3) to fix the chair frame (B）
on the chair back(A)
3
1
3
4
4
1= 4Pcs
3= 2Pcs
A
B
C
Assembly the chair frame
A
B
C

That's it ! You've finished
assembling your item. Thank you!
4
STEP 2:Assembly of the forefoot
2
4
2= 4Pcs
*Assemble the legs(C ) to chair frame(B) via the screw(2)
C
C
