Living Spaces 7030-00270 User manual

MAS90: 5043-43300
MIRROR KIT
QTY: DESCRIPTION:
6 8 X 1-1/4 PH PAN ZINC
7030-00270 KIT

MIRRORS
7030-00270
7030-01001
_____________________________________________________________________
PARTS LIST:
A) 1 -Mirror
B) 2 –Wooden Supports
C) 8 – Zinc Screws
TOOLS REQUIRED:
1) Phillips Head Screwdriver
ASSEMBLY INSTRUCTIONS:
NOTE:
Make sure you have all parts before beginning assembly. If you need a part, contact the dealer
where you purchased your bed.
1) Unattach and then reattach wooden brackets to the placement shown above using the pre-drilled
holes in the mirror support. Use the center hole on the mirror support as a reference; do not use a
screw in this hole. Use screws in holes 1 & 2 as shown in Detail B
2) Attach the assembled mirror and wooden brackets to case good using hole 3 and depending on
the case good purchased using 1 of the 3 holes for hole 4 (Dresser, Chest etc.). To determine the
hole to use push lightly on the case backing to feel the face frame horizontal behind it. When
putting in the screw if you don’t feel it pull together tightly then remove the screw and try a
different hole.
REVISED: 01/22/2013
Detail B Hole 1
Hole 2
Hole 3
Hole 4
