Living 043-5877-2 User manual

Ceramic Heater
Product No. 043-5877-2
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Before beginning assembly of product, make sure all parts are present.
Questions? If you have any questions or need replacement parts, please call our toll-free helpline at
1-877-483-6759.
Keep this manual for future reference.
Installation and User Manual

2Product No. 043-5877-2
Imported for Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
Table of Contents
Technical Data 2
Important Safety Instructions 3
Key Parts Diagram 5
Important Information 6
Operation 7
Care and Maintenance 10
Warranty 11
Table of ContentsTechnical Data
Operating voltage 120 V
Operating frequency 60 Hz
Power 1500 W (high), 750 W (low)
Maximum current 12.5 A

3
Important Safety Instructions
• Read all the instructions carefully and use the heater only as directed in the manual. Use of the heater in other
ways may cause electric shock, fire, or damage to persons or property.
• Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3' (0.9 m)
from the front, top, side and rear portions of the heater.
• Keep children away from the work area. Do not allow children to handle the heater. Extreme supervision is
necessary when using the heater near children, differently-abled or pets.
• Ensure the heater is placed on a stable, secure surface to avoid risk of tipping it over. Never place the heater in
such a way that it may fall into a bathtub or into another water container.
• DO NOT place or run the power cord under carpeting. Do not cover the cord with throw rugs or runners.
Make sure that the cord is away from any obstructions so that it will not be tripped over.
• DO NOT leave the heater unattended.
• DO NOT place the heater on a small, non-level, uneven surfaces or any other surface where the heater could
easily tip over.
• DO NOT insert or allow foreign objects to enter any ventilation or exhaust opening of the heater, as these may
cause electric shock, fire or damage to the heater.
• DO NOT use the heater on a rug, carpet, or any other soft surface, such as a bed, where the ventilation openings
may become blocked.
• DO NOT touch the heater when in use to avoid skin burns.
• DO NOT use the heater outdoors. This heater is not intended for use in any area containing still or stagnant water.
• DO NOT use this heater in areas where gasoline, paint or flammable liquids are used or stored. This heater may
have hot, arcing or sparking parts inside.
• DO NOT operate the heater if there is damage in the power cord or if the heater has been dropped, damaged
or has malfunctioned. Return the heater to an authorized service facility for examination, or electrical or
mechanical adjustment or repair.
• DO NOT plug the heater into a worn AC outlet. Doing so may cause the power cord to become hot or distorted,
resulting in overheating of the cord and could cause a fire. Always replace the worn outlets prior to further use
of the heater.
• DO NOT operate the heater with its ventilation obstructed or its air intake blocked to prevent a fire hazard.
• DO NOT operate the heater with its grille or any of its safety features removed or disabled.
• DO NOT use an extension cord or any other relocatable power tap to operate the heater. Always plug the heater
into a grounded wall outlet.
• DO NOT use the heater in damp environments such as flooded basements, near sinks, washing machines,
swimming pools, etc.
• DO NOT place the heater on soft surfaces, like beds or pillows, as the heater could tip over and ignite the
materials.
• DO NOT use the heater with a broken heating element or a damaged ceramic cone.
• The heater should be placed on a smooth, non-combustible surface for smooth and trouble-free operation.
• This heater is not intended for use in a bathroom, laundry areas and similar moist indoor locations.
• Use carry handle when moving the heater. Never pull the heater using the power cord.
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.
Warning! When using electrical appliances, basic precautions should always be followed to
reduce the risk of fire, electric shock, and injury to persons, including the following:

4Product No. 043-5877-2
Important Safety Instructions
• This heater draws 12.5 A during operation. To prevent overload and blown fuses, always plug the heater into a
dedicated electrical circuit. Do not plug in any other electrical appliance into the same outlet or another outlet
on the same electrical circuit.
• Always connect the heater to a properly polarized AC outlet only.
• Make sure that the connection is tight between the AC outlet and plug, as a loose connection may cause
overheating and distortion of the plug. Contact a qualified electrician to replace a loose or worn outlet.
• Use of this heater is not recommended for persons with reduced sensitivity to heat or an inability to react to
burns. The output of this heater may vary and its temperature may become intense enough to burn exposed skin.
• When not in use, always disconnect the heater by turning the power setting control to the OFF position, then
remove the power cord from the outlet.
IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY.

5
11
22
3344
Tip-over switch
11
Power cord
22
Thermostat control
33
Power indicator
44
Power level switch
55
Key Parts Diagram
E
55
MIN
MAX

6Product No. 043-5877-2
Important Information
1. Features
1.1. Power indicator
This indicator glows to indicate that the heater/fan is in the ON setting.
1.2. Power level switch
The power level switch is used to turn the heater on or off. The heater will operate at different power ratings
when the power level switch is set at fan, low, high and energy save positions.
At “ ”, the heater is OFF.
At “ ”, only the fan operates.
At “ ”, the heater operates at 750 W (low).
At “ ”, the heater operates at 1500 W (high).
At “ ”,the heater operates in Energy Save mode, providing a comfortable setting while saving you
money on energy costs.
1.3. Thermostat control
This knob is used to set the desired temperature and maintains that temperature by sensing the surrounding
temperature and turning the heater on and off automatically. The thermostat control is designed in a way to
adjust the temperature gradually from the minimum position to maximum position and not with discrete values.
2. Safety features
2.1. Polarized plug
The heater power cord is equipped with a polarized plug to prevent electric shock. In a polarized plug one of
the blades is wider than the other. The wider blade can be plugged into a socket with a wider slot in only one
way, thus preventing an electric shock. Contact a qualified electrician if the plug does not fit into the socket.
2.2. Thermal overheat protection
This feature shuts down the heater if it gets overheated due to an obstructed heater grille or other abnormal
condition. If this happens, turn off and unplug the heater for 10 minutes until it cools down. Inspect and
remove any objects blocking the grille and then plug it back into the outlet to resume its normal operation.
2.3. Tip-over switch
The tip-over switch is located on the bottom of the heater. This feature will automatically shut off the heater if
it is lifted or if the heater tips over. To resume operation, place it in an upright position.
E

Operation — Heater Mode
Warning!
• Read each step carefully before beginning any installation and make sure you understand
each step.
• Keep children and pets away during heater operation.
• Do not use the heater without the grille in place.
Warning!
• Make sure the plug fits tightly in the outlet. A loose connection may cause overheating and
damage to the plug or heater.
• Disconnect the heater from the power supply when the heater is not in use.
NOTE:
The heater may emit a foul odour or smoke during its initial use, owing to the “burning off” of the heating element
lubricant. This is normal and will go away after a few minutes of use.
NOTE:
It is recommended to not use the heater around birds and pets until the manufacturing corrosion coating burns off
as those creatures tend to be sensitive to the fumes.
E
MIN
MAX
7
1. Locating the heater
• Place the heater (1) on a firm, level surface free from
obstructions, and at least 3' (0.9 m) away from any wall
(2) and any other combustible materials such as furniture,
pillows, papers, clothes and curtains. Also place it in an
upright position before turning on (fig. 1).
NOTE:
Make sure that the heater is placed in the coldest region/area
of the room.
2. Connecting the heater to the power supply
• Make sure the power level switch (1) is in (OFF) position.
Connect the power cord (2) of the heater into a grounded
120 V AC, 60 Hz outlet (3) (fig. 2).
11
11
22
33
22
3' (0.9 m)

8Product No. 043-5877-2
Operation — Heater Mode
3. Turning on the heater
• Turn the power level switch (1) from the (OFF)
position to (LOW), (HIGH), or (Energy Save),
whichever is desired. The power indicator (2) glows
when the power level switch is turned on (fig. 3).
4. Using the thermostat control
• Turn the thermostat control (1) clockwise to the
maximum position (fig. 4).
5. Maintaining the room temperature
• Once the room temperature has risen to the desired
temperature, slowly turn the thermostat control (1)
counter-clockwise until a "click" is heard. At this
setting, the thermostat will automatically turn the
heater on when the room temperature is lower than
the desired temperature and turn it off when the
temperature is higher than the desired temperature
(fig. 5).
• Turn the thermostat control counter-clockwise
to lower the temperature
6. Turning OFF the heater
• Turn the power level switch (1) to the (OFF) position
and unplug the power cord (2) from the outlet after
using the heater (fig. 6).
22
11
11
1122
E
E
MIN
MAX
11
E
MIN
MAX
E
MIN
MAX
E
MIN
MAX

Warning!
• Disconnect the heater from the power supply when the heater is not in use.
9
1. Turning on the fan
• Turn the power level switch (1) to the (fan) setting. The
power indicator (2) glows when the power level switch is
turned on (fig. 7).
2. Turning on the continuous fan mode
• Turn the thermostat control (1) clockwise to the maximum
position to let the fan run continuously (fig. 8).
Operation — Fan Mode
11
11
E
MIN
MAX
22
E
MIN
MAX

10 Product No. 043-5877-2
It is recommended to clean the heater at least once a month and also before off-season storage.
• After use, always turn off the heater and allow the heater to cool.
• Use a soft, damp cloth to clean the air inlet on the heater. Do not use any detergents or abrasives.
• Never immerse the heater in water.
• If the heater is not in use for an extended period, store the heater in a dry place.
Storage
Store the heater in the original carton. Coil and tie the power cord to avoid damage during storage.
Cleaning and Maintenance
Warning!
• Before cleaning the heater, always turn off the power switch and unplug the heater.
• Do not use the heater without the grille in place.
Warning!
• Please do not attempt to open or repair the heater by yourself. Doing so may void the
warranty and could cause damage or personal injury.

11
This product is guaranteed for 12 months from the date of original retail purchase against defects in materials and
workmanship.
Subject to the conditions and limitations described below, this product, if returned to us with proof of purchase
within the stated warranty period and if covered under this warranty, will be repaired or replaced (with the same
model, or one of equal value or specification), at our option. We will bear the cost of any repair or replacement and
any costs of labour relating thereto.
This warranty is subject to the following conditions and limitations:
• a bill of sale verifying the purchase and purchase date must be provided;
• this warranty will not apply to any product or part thereof which is worn or broken or which has become
inoperative due to abuse, misuse, accidental damage, neglect, or lack of proper installation, operation, or
maintenance (as outlined in the applicable owner's manual or operating instructions) or which is being used for
industrial, professional, commercial, or rental purposes;
• this warranty will not apply to normal wear and tear or to expendable parts or accessories that may be supplied
with the product which are expected to become inoperative or unusable after a reasonable period of use,
including but not limited to finish, glass coverings, and remote controls;
• this warranty will not apply to routine maintenance;
• this warranty will not apply where damage is caused by repairs made or attempted by others (i.e., persons not
authorized by the manufacturer);
• this warranty will not apply to any product that was sold to the original purchaser as a reconditioned or
refurbished product (unless otherwise specified in writing);
• this warranty will not apply to any product or part thereof if any part from another manufacturer is installed
therein or any repairs or alternations have been made or attempted by unauthorized persons;
• this warranty will not apply to normal deterioration of the exterior finish, such as, but not limited to scratches,
dents, paint chips, or to any corrosion or discolouring by heat, abrasive and chemical cleaners; and
• this warranty will not apply to any component part sold by and identified as the product of another company,
which shall be covered under the product manufacturer's warranty, if applicable.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer nor the
manufacturer shall be liable for any expense, loss, or damage, including, without limitation, any indirect, incidental,
consequential, or exemplary damages arising in connection with the sale, use, or inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other rights, which may vary from province to
province. The provisions contained in this warranty are not intended to limit, modify, take away from, disclaim or
exclude any statutory warranties set forth in any applicable provincial or federal legislation.
Imported by
Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
For any help, please contact the customer service at:
1-877-483-6759
(Monday-Friday 8:00-7:00pm EST, Saturday 9:00-7:00pm EST)
Warranty
