Lloyd Pascal 056.50.341M User manual

we love home
lloydEst
1919
.
pascal
Hi there,
Meet your new
Lloyd Pascal
Under Basin
Unit
1
Customer Helpline
If you need help or have damaged or missing parts, call our customer helpline
0121 776 5720
Assembly instructions- Please keep for future reference
Issue 2- 10/02/2022
056.50.341M
056.94.341M

Lloyd
Pascal
tak a p of your LP
product and
#Lloydpascal
#LPfurniture #LPhome
Are you your purchase?
Yes:
No:
we love home
lloydEst
1919
.
pascal
2

Safety and Care Advice
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Care and maintenance
Additional Guidance
• Keep children and animals away
from the work area, small parts
could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• This product has been constructed
to be used in the domestic
environment only and not for
commercial purposes.
• Assemble the item as close to its
final position (in the same room) a
possible.
• Assemble on a soft level surface
to avoid damaging the unit or your
floo .
• We do not
recommend the use
of power drill/drivers
for inserting screws
as this could damage
the unit. Only use
hand screwdrivers.
• Parts of the assembly will be
easier with 2 people.
• Dispose of all packaging carefully
and responsibly.
• Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
• From time to time check that there
are no loose screws, nuts or bolts. If
there are please re-tighten.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
• Assemble all parts and bolts loosely during assembly, only once the product is complete should you fully tighten
the bolts.
• Regularly check and ensure that all bolts and fittings are tightened properly.
3
we love home
lloydEst
1919
.
pascal
Serious or fatal crushing injuries can occur from furniture tipping over.
To help prevent this item of furniture tipping over:
WARNING!
IN ORDER TO PREVENT OVERTURNING THIS PRODUCT MUST BE
USED WITH THE WALL ATTACHMENT DEVICE PROVIDED
An attachment device is provided with your product, however you will need to source suitable
fixings for your wall type. If in doubt, please consult a qualified tradesperson.
Always ensure the wall to be drilled is free from hidden electrical wires, water and gas pipes.
• Use the wall attachment device provided.
• Do not let children climb or hang on drawers, doors or shelves.
• Place the heaviest items in the lower drawers or shelves.
• Do not place TV’s or other heavy objects on top of this product, unless it has been specifically
designed to support them.
• Never open more than one drawer at a time.

Fittings
Please check that you have all the fit ings listed below:
NOTE: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may need to supplied than required.
ABC
DEF
HI
JKL
MNO
PQ
Male camlock x8 Female camlock x8 dowel x8
Screw x4 Screw x6 Push to open
mechanism x2
G
catch plate x2 Hinges x4 Screw x16
Screw x4 Long screw x1 Wall plug x1
Short screw x1 Washer x2 Wall strap x1
Hexagonal key x1 Screw x15
we love home
lloydEst
1919
.
pascal
4
Tools required
Crosshead screwdriver
Ruler/tape
measure
Eye protection
Mallet Power drill

Panels
Top panel Shelf Side panel x1
Side Panel x1 Legs x4 Bottom panel
Hardboard back x2 Left door x1 Right door x1
123
4 5 6
78 9
we love home
lloydEst
1919
.
pascal
5

F
Push to open
mechanism x2
ABC
DEF
G HI
JKL
MNO
PQ
Male camlock x8 Female camlock x8 Wooden dowel x8
Screw x4 Screw x6 Push to open
mechanism x2
catch plate x2 Hinges x4 Screw x16
Screw x4 Long screw x1 Wall plug x1
Short screw x1 Washer x2 Wall strap x1
Hexagonal key x1 Screw x15
1
E
Screw x2
2J
Screw x4
P
Hexagonal key x1
J
2
P
J
J
REPEAT
FOR EACH LEG
J
11
we love home
lloydEst
1919
.
pascal
6

3
4
3
4
2
A
Male camlock x4
B
C
Female camlock
x4
Wooden dowel x4
WARNING: Please
refer to page 10
for details on
fitting camlocks.
D
Screw x4
C
Wooden dowel
x4
A
A
C
C
6
we love home
lloydEst
1919
.
pascal
7

1
WARNING: Please
refer to page 10
for details on
fitting camlocks.
B
Female camlock x4
5
6
C
Wooden dowel x4
A
Male camlock x4
7
Q
7
Q
Q
Q
Q
Q
Q
QQ
Q
Q
QQ
Q
Q
Q
Screw x15
Turn
Product
C
C
A
we love home
lloydEst
1919
.
pascal
8

9
7G
catch plate x2
E
Screw x4
H
Hinges x4
I
Screw x16
8
K
L
M
N
O
N
O
WARNING: Before
driling, check wall
for hidden pipes
and cables.
L
Wall plug x1
O
Wall strap x1
N
Washer x2
M
Short screw x1
K
Long screw x1
I
WARNING!
IN ORDER TO PREVENT OVERTURNING
THIS PRODUCT MUST BE USED WITH THE
WALL ATTACHMENT DEVICE PROVIDED
REPEAT
FOR DOOR 8
we love home
lloydEst
1919
.
pascal
9
ASSEMBLY
COMPLETE
Refer to page 10
for further details
on fitting hinges

Step 1 Step 3
Step 2
Hinge adjustment
Step 4
a: b: c:
Connect the male
camlock as directed in
the assembly instructions
using a screwdriver.
Push the male camlock
into every hole.
Insert the female
camlock as shown in the
instructions.
Note: Ensure that the
arrow on the top of the
camlock points towards
the entry hole for the
male camlock.
a: To move the top panel up
or down, loosen screws
shown and move top panel
to suit.
b: To move the top panel in or
out, loosen screws shown
and move top panel to suit.
Retighten screws
c: To move the top panel
left or right, adjust screws
shown.
Turn the female camlock
with a screwdriver.
You should feel a click
when the camlock is
locked in place.
The joint is now secure.
Using camlocks
Adjusting hinges
we love home
lloydEst
1919
.
pascal
10
For how to use
camlocks watch
our video
https:// vimeo.com/
340876871

Important note:
Types of walls
Important: when drilling into walls always check
that there are no hidden wires or pipes etc.
Care & Maintenance
You can use one of the following types of wall plug if your walls are
made of brick, breeze block, concrete, stone or wood.
Safety: Always check the fitting and
location to ensure your safety in and
around the home.
Fitting: From time to time check the
fitting to ensure the wall plugs or
screws do not become loose.
A Guide to Wall Mounting & Fixings
If plastic wall plugs (rawl plugs)
are supplied with your product,
eg:
No. 1 “General Purpose” wall plug
No. 2 “Plasterboard” wall plug
Generally aerated blocks should
not be used to support heavy loads,
use a specialist fitting in this case.
For light loads, general purpose
wall plugs can be used.
For use when attaching light loads
onto plasterboard partitions.
For use when fitting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with heavier loads such as
TV and HiFi speakers and satelite
dishes etc.
For use with plasterboard partitions
or hollow wooden doors.
For use with walls stuck with
plasterboard. The hammer fixing
allows it to be fixed to the wall
rather than the plasterboard.
Always check the fixing is secure to
the retaining wall.
No. 3 “Cavity Fixing” wall plug
No. 4 “Cavity Fixing - Heavy Duty”
wall plug
No. 5 “Hammer Fixing” wall plug
No. 6 “Shield Anchor” wall plug -
heavy loads
Make sure that the screws and wall plugs being used are suitable for
supporting your unit. Consult a qualified tradesperson if you are unsure
Hints:
1. General rule: always use a larger screw and wall plug if you are not sure.
2. Ensure you use the recommended drill bit to match the wall plug and hole
size.
3. Ensure you drill the hole horizontally; do not force the drill or enlarge the
hole.
4. Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure
wall plugs are inserted beyond the thickness of the ceramic tiles to avoid
the tiles splitting or cracking.
5. Ensure wall plugs are well fitted and are a tight fit in the drilled hol
• these are suitable for use in
masonry walls
If you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using the incorrect fixings is the
responsibility of the installer.
