Lloyd Pascal 3 Tier Shaker Caddy User manual

1
Customer Helpline
If you need help or have damaged or missing parts, call our customer
helpline 0121 776 5720
Assembly instructions- Please keep for future reference- 053.96.130M
3 Tier
Shaker
Caddy
Issue 1 - 07/01/2020

2
Thank you for
purchasing a
Lloyd Pascal
Product.
Why not take a picture of your
purchased LP product and post it
on one of our social media pages
tagging #Lloydpascal #LPfurniture
#LPhome.
To view our full terms and conditions
please visit our website.
www.Lloydpascal.com
Are you happy with your purchase?
Yes: That’s perfect, please leave us a review on our social media
channels or Trustpilot. Your feedback will help us to create future
products for the next generation.
No: if for any reason your enjoyment of our product is on Hold then
let the retailer that you purchased your item from know or contact
us and we will resolve your issue as quickly as possible.
www.lloydpascal.com

3
Safety and Care Advice
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY.
Care and maintenance
Additional Guidance
• Keep children and animals away
from the work area, small parts
could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• This product has been constructed
to be used in the domestic
environment only and not for
commercial purposes.
• Assemble the item as close to its
nal position (in the same room) as
possible.
• Assemble on a soft level surface
to avoid damaging the unit or your
oor.
• We do not
recommend the use
of power drill/drivers
for inserting screws
as this could damage
the unit. Only use
hand screwdrivers.
• Parts of the assembly will be
easier with 2 people.
• Dispose of all packaging carefully
and responsibly.
• Only clean using a damp cloth
and mild detergent. Do not use
abrasive cleaners.
• From time to time check that there
are no loose screws, nuts or bolts. If
there are please re-tighten.
• This product should not be
discarded with household waste.
Take to your local authority waste
disposal centre.
• Assemble all parts and bolts loosely during assembly, only once the product is complete should you fully tighten
the bolts.
• Regularly check and ensure that all bolts and ttings are tightened properly.
To help prevent product toppling over please follow the steps below:
• Must use the anti tip strap or wall xing method provided (whichever applies)
• Do not allow children to climb or hang on the furniture
•Do not open more than one drawer at a time
•Do not place heavy items in the top drawer
•Do not place heavy items on top of the furniture, unless the furniture has been designed for this purpose
Please note that only the anti tip strap is provided. You will need to supply wall plugs and screws applicable for
your wall type.
WARNING
In order to help prevent overturning- please follow these instructions

4
Bag 1
Fittings
Please check that you have all the ttings listed below:
NOTE: The quantities below are the correct amount to complete the assembly. In some cases
more ttings may be supplied than required.
Tools required
Phillips screwdriver
(small & medium)
Power drill
Male camlock x16 Female Camlock x16 Wooden dowel x20
Short screw x1 Safety Strap x1 Foot pad x4
Long screw x1 Washer x1 Wall plug x1

5
Panels
1 Top panel x1 2 Right side x1 3 Left side x1
4 Rail x4 5 Back rail x4 6 Shelf x3

6
Safety Strap x1
1
3
2
Male camlock x4
Wooden dowel x16 Short screw x1 Wooden dowel x4
Male camlock x16 Female Camlock x16 Wooden dowel x20
Short screw x1 Safety Strap x1 Foot pad x4
Long screw x1 Washer x1 Wall plug x1
REPEAT X4 REPEAT X4
1
4
5

7
Male camlock x6 Female Camlock
x2
REPEAT X3
5
4
6
Female Camlock x12 Male camlock x6 Female Camlock
x2
7
NOTE: Ensure the
wall strap attached
to back rail is at the
rear of the unit
^
_
6
2
3
4
4
4
4
5

8
c
Foot pad x4
4
4
4
5
4
3
6
6
6
8
9
Tighten camlocks
inside underside
of shelves using a
screwdriver.
6
6
6
2
Turn
Product

9
10
11Long screw x1 Washer x1 Wall plug x1
WARNING!
IN ORDER TO PREVENT OVERTURNING
THIS PRODUCT MUST BE USED WITH THE
WALL ATTACHMENT DEVICE PROVIDED
WARNING: Before
drilling, check wall
for hidden pipes and
cables
Tighten female
camlocks inside left
and right side using a
screwdriver.
1

10
Important note:
Types of walls
Important: when drilling into walls always check
that there are no hidden wires or pipes etc.
Care & Maintenance
You can use one of the following types of wall plug if your walls are
made of brick, breeze block, concrete, stone or wood.
Safety: Always check the fitting and
location to ensure your safety in and
around the home.
Fitting: From time to time check the
fitting to ensure the wall plugs or
screws do not become loose.
A Guide to Wall Mounting & Fixings
If plastic wall plugs (rawl plugs)
are supplied with your product,
eg:
No. 1 “General Purpose” wall plug
No. 2 “Plasterboard” wall plug
Generally aerated blocks should
not be used to support heavy loads,
use a specialist tting in this case.
For light loads, general purpose
wall plugs can be used.
For use when attaching light loads
onto plasterboard partitions.
For use when tting or supporting
heavy loads such as shelving, wall
cabinets and coat racks.
For use with heavier loads such as
TV and HiFi speakers and satelite
dishes etc.
For use with plasterboard partitions
or hollow wooden doors.
For use with walls stuck with
plasterboard. The hammer xing
allows it to be xed to the wall
rather than the plasterboard.
Always check the xing is secure to
the retaining wall.
No. 3 “Cavity Fixing” wall plug
No. 4 “Cavity Fixing - Heavy Duty”
wall plug
No. 5 “Hammer Fixing” wall plug
No. 6 “Shield Anchor” wall plug -
heavy loads
Make sure that the screws and wall plugs being used are suitable for
supporting your unit. Consult a qualied tradesperson if you are unsure.
Hints:
1. General rule: always use a larger screw and wall plug if you are not sure.
2. Ensure you use the recommended drill bit to match the wall plug and hole
size.
3. Ensure you drill the hole horizontally; do not force the drill or enlarge the
hole.
4. Take extra care when drilling high walls, ceilings and ceramic tiles. Ensure
wall plugs are inserted beyond the thickness of the ceramic tiles to avoid
the tiles splitting or cracking.
5. Ensure wall plugs are well tted and are a tight t in the drilled hole.
• these are suitable for use in
masonry walls
If you are in any doubt about the
correct wall plugs for your wall,
seek professional advice.
Failure of the product due to
using the incorrect xings is the
responsibility of the installer.

11
Using camlocks
Adjusting hinges
Step 1 Step 3
Step 2
Hinge adjustment
Step 4
1. 2. 3.
Connect the male
camlock as directed in
the assembly instructions
using a screwdriver.
Push the male camlock
into every hole.
Insert the female
camlock as shown in the
instructions.
Note: Ensure that the
arrow on the top of the
camlock points towards
the entry hole for the
male camlock.
STEP 1
To move the top panel
up or down, loosen
screws shown and
move top panel to suit.
STEP 2
To move the top panel
in or out, loosen screws
shown and move top
panel to suit.
Retighten screws
STEP 3
To move the top panel
left or right, adjust
screws shown.
Turn the female camlock
with a screwdriver.
You should feel a click
when the camlock is
locked in place.
The joint is now secure.
