LML Speedy 4-Stroke User manual

IMPORTANT INFORMATION
1. Name : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Address : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Licence No. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. YOUR DEALER . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Name : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Address : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tel. No. : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. YOUR VEHICLE
Model LML :
Colour : . . . . . . . . . . . . . . . . . . . . . . .
Engine No.
Chassis No.
Key No. : ................................................
Date of purchase : ................................................
Date of Registration: ................................................
Registration No. : ................................................
E
C
Es
2
9
4

CONTENTS
DESCRIPTION PAGE NO.
How to get maximum benefit out of your
LML 3
Vehicle Identification 6
Parts & Specifications 7
General specifications 9
Specifications - Auto start 14
Auto start Circuit Diagram 15
Technical Specifications 16
Control Functions 20
Locking System 20
Switches 23
Clutch 24
Gear 25
Brakes 26
Fuel supply 26
DESCRIPTION PAGE NO.
Operating the vehicle 28
Running-in Instructions 31
Care and Maintenance 32
Cowls 32
Changing the tyres 33
Engine oil 35
Spark plug cleaning 36
Battery 36
Air Cleaner 39
Cleaning & Polishing 40
Maintenance while not in use 40
Recommended Lubricants 41
Maintenance by Authorised Service Dealer 42
Exhaust Emission Control 45
Wiring Circuit Diagram 46
We thank you for choosing 4 stroke as your new scooter.
The comes to you from LML Limited - one of the fastest growing automobile companies in
India. A company that endeavours to redefine mobility everyday, the worldover by exceeding
customer expectations.
Born after years of understanding consumer needs, LML's comes to you with the promise
of an unmatched riding experience.
At it's heart lies a potent 4 stroke, 150cc Engine that delivers a phenomenal 8.0 BHP at 6250 RPM.
Giving you the power to leave everything behind in an instant. And while you do that, it's side
mounted stepny makes every ride a perfectly balanced one. Add to this, its two rear view mirrors,
give you the incomparable pleasure of watching the traffic you'll leave behind.
Besides giving you a smooth performance and extremely comfortable rides for years, the
also makes you the envy of others. All thanks to its breathtaking style and metallic colours that
people just can't ignore.
This owner's manual has been specially designed to help you understand your scooter better. It is
important for you to go through this manual to get the best performance out of your . It will
also help you to maintain it in the best condition.
So read this manual, ride out on your new and discover what world-class mobility is all
about.
2

HOW TO GET THE MAXIMUM
BENEFIT OUT OF YOUR LML
Given below are some important features of
your scooter and some useful tips on how to
maximize the benefits it offers.
1. LML's fuel saver engine : This engine gives
the best fuel consumption at a driving speed
of 35-45 kms/hr after running-in of 1000 kms.
Mileage may therefore vary depending upon
the variation due to road condition, traffic
intensity and driving habits and condition of
the scooter adherence to preventive
maintenance schedule.
Maximising the benefits from your LML
3
4
2. Safety features of LML : The safety
features inbuilt in your scooter take away
the worries from your driving. It is a perfectly
balanced scooter and its state of the art
braking system enables you to come to an
instant halt without skidding regardless of
the speed at which you are driving.
A powerful DC horn and indicators with a
buzzer enable you to negotiate busy and
noisy traffic conditions. In addition, the head
light retains its intensity even at low speed
that makes for safer night driving.
Some tips for even safer driving.
2.1. Always use a helmet while driving.
2.2. Make yourself familiar with the driving
signs and regulations.
2.3. Drive at a speed at which you are in
complete control of the scooter.
2.4. Never drive in neutral gear especially
when going down-hill or on a wet or
slippery road.
2.5. Use horn and indicators whenever
required.
Maximising the benefits from your LML
Tips to stretch each litre of petrol even longer.
1.1 Change gears as per the required
speed. Try to maintain the speed of
35-45 kms/hr to give you the best
mileage.
1.2 Use clutch, brakes and full throttle only
as and when required.
1.3 Maintain the air pressure of 1.2 kg/cm2
(17 PSI) in the front wheel and 2.5
kg/cm2 (35 PSI) in the rear wheel with
pillion rider.

Maximising the benefits from your LML
Vehicle Identification
6
3. Feel the power of the LML
engine : The engine power of your scooter
is not only the highest among all scooters
but also compares to some of the most
popular motorbikes in the same cubic
capacity. You can now surge ahead of other
vehicles, either from a stop position or while
negotiating busy traffic.
Some tips on how to keep power under control
3.1. Accelerate only to the extent you are in
complete control of the scooter.
3.2. Use its maximum power only when you
need to.
4. The driving pleasure that only the LML
gives you : Your scooter has been
designed so as to enable you to sit in a
correct posture to avoid strain. Its
comfortable and long seat, double acting
suspension and strong shock absorbers
better withstand uneven road conditions to
give you driving pleasure, unmatched by
any scooter.
Some tips on how to enhance your driving
pleasure.
4.1. Maintain the correct posture.
4.2. Sit in a relaxed and natural manner, not
stiffly.
4.3. Reduce speed on uneven and bumpy
roads.
Fig. 1
Fig. 2
Fig. 3
VEHICLE IDENTIFICATION
The vehicle is identified by a number on the
chassis and another number on the engine.
The chassis identification number is stamped
inside the glove compartment on upper chassis
as shown in (Fig. 1) Chassis number has the prefix
C9XX followed by 6 digit number.
The engine number is stamped on the crank
case (Fig. 2). The engine number has the prefix
E24XX followed by 6 digit number.
Each LML has one set of duplicate keys.
An identification number is punched on metallic
tag, which is provided alongwith the key ring
(Fig. 3).
Please keep your duplicate key carefully along
with the metallic tag.
5

Parts & Specifications
8
Parts & Specifications
Fig. 6
Fig. 7
1. Utility box
2. Back rest with cushion
3. Seat
4. RH side cowl
5. Hook for bag
6. Rear turn indicator (RH side)
19. Foot rest for pillion rider
20. Rear turn indicator (LH side)
21. Rear protection frame
22. Tail light
13. Glove compartment
14. Fuel cock lever
15. Choke knob
16. LH side cowl
17. Spare wheel cover
18. Spare wheel
7. Silencer
8. Kick starter
9. Foot brake pedal
10. Front suspension cover
11. Front suspension link cover
12. Wheel cover
1. Head light
2. Wind shield beading
3. Name plate
4. Front turn indicator
5. Front mudguard
6. 'Eco-friendly vehicle' emblem
7. Steering column cover
8. Name plate LML
9. Grill
10. Crest
11. Central stand
12. Rear view mirror
13. Utility tray
14. Glove compartment lock
15. Ignition-cum-steering lock
16. Instrument panel
17. Accelerator throttle twist grip
18. Front brake lever
7

Parts & Specifications
10
Parts & Specifications
GENERAL SPECIFICATIONS
1. ENGINE
1.1 Engine : Is pivoted to the link assembly
fitted on vehicle chassis through the
crankcase swinging arm on the clutch
side. The rear wheel (drive wheel) is
fitted on the outer side of the drive shaft.
1.2 Ignition : By means of an Electronic
Ignition Device (CDI) which feeds the
current to a high voltage transformer
(HT coil) to generate the spark.
1.3 Lubrication : Wet sump forced pressure
splash through a pump.
1.4 Clutch : Multiplate, oil bath type. The
unit is cable operated by a lever located
on the left hand side of the handlebar
and is adjustable.
9
2. FUEL
2.1 Fuel supply : Gravity fed from fuel tank
to carburettor. Carburettor is a side draft
carburettor and is having a vertical
moving throttle slide.
2.2 Fuel Gauge : In built with the
speedometer indicates the quantity of
petrol in the petrol tank by virtue of a
float unit located inside the tank.
2.3 Throttle Control : By twist grip on the
right hand side of the handlebar.
3. CHASSIS
3.1 Semi Monococque Chassis : Pressed
steel sheet and strong tubular structure.
A pressed steel sheet shell covers the
tubular structure.
3.2 Handlebar : Light alloy casting with
headlamp, instrument panel and
indicator lights. All transmission cables
are concealed therein.
3.3 Steering column and suspension :
The steering column is pivoted on the
front wheel swinging hub. Front and rear
suspensions are provided with helical
spring & hydraulic dampers.
3.4 Front suspension cover :Elegant
protection cover painted in vehicle shade
is mounted over front suspension
protects it from dust, water and foreign
elements. Also enhances the aesthetics.
3.5 Front suspension link cover :
Protection cover is mounted over front
suspension link protects it from dust,
water and foreign elements.
1.5 Gear Box : Four speed forward drive
with constant mesh gears immersed in
oil bath are operated by the twist grip
on the left hand side of the handlebar
which functions in conjunction with the
clutch control lever.
1.6 Cooling : Forced air provided by a
centrifugal fan.
1.7 Starting : With kick starter pedal located
on the right hand side of scooter. Push
button only in auto start model.

Parts & Specifications
11
Parts & Specifications
12
4.4 Rear Brake : Operated by pedal on the
right hand side foot board.
4.5 Wheel Cover : To enhance the look of
the scooter, wheels are provided with
covers. The front and rear wheel covers
are secured rigidly to the wheel rims.
There is also a protection cover for the
spare wheel.
5. TOOL KIT
Tool kit in a pouch containing
Box Spanner (13 x 16mm) with lever
Double sided screw driver
2 Double ended spanners
(7 x 8mm & 8 x 11mm)
Fig. 8
3.12 Utility Box : An elegantly designed
utility box with key operated lock for
keeping your personal belongings etc.
is secured rigidly to backrest.
3.13 Foot mat : Moulded center and side mat
which protects entire foot rest area.
4. WHEELS
4.1 Wheels : Interchangeable and made out
of pressed steel rim with 89 x 254 mm
(3.50 x 10) tyres.
4.2 Brakes : Cable operated drum brakes
with dual expanding shoes.
4.3 Front Brake : Operated by hand lever
placed on right hand side of handle bar.
3.6 Rear view mirror : Stylish moulded rear
view mirrors on both sides of handlebar.
3.7 Security Lock : On the steering column
and operated by a key.
3.8 Glove Compartment : A sleek & spacious
glove compartment for keeping personal
belongings, secured with a lock.
3.9 Utility Tray : Provided above glove
compartment for keeping utility articles.
3.10 Seat : Dual seat, tip up type with security
lock.
3.11 Backrest with cushion : For comfort of
pillion rider.

Fig. 9
Fig. 10
6.2 Engine Oil : Quantity of Engine oil in the
crank case is 850 ml. This is for lubrication
and cooling of the Engine. Always
maintain Oil level as per the marks
provided on the level gauge / dipstick as
shown in the figure for details of checking
see page no. 35.
Note : Take care that Engine Oil level is always
maintained between the upper and lower
level mark on the oil level gauge / dipstick.
Running engine with insufficient oil may
cause serious engine damage.
Parts & Specifications
13
14
Parts & Specifications
Fig. 13
SPECIFICATIONS - AUTO START
LML Es has the facility of a push button
for auto start below the headlight switch located
on right hand side of handle bar (Fig. 11) in
addition to a kick start option. The auto start circuit
is operated by a 12 volt - 9 Ah battery.
A PRD relay (prevention of restarting device) is
provided to avoid use of the self starter when the
engine is running.
A declutch switch has been provided to prevent
starting of scooter when the clutch is engaged.
An 8 Amp fuse (on spare wheel bracket, Fig. 12
& 13) is provided to avoid any damage due to short
circuiting in auto start system.
A powerful 12 volt-96 watt magneto charges
the battery through a regulator with a built in
charger.

16
Parts & Specifications
Technical Specifications
TECHNICAL SPECIFICATIONS
Dimensions
Overall length 1760 mm
Overall width 695 mm
Wheel base 1235 mm
Maximum road clearance 160 mm
Seat height 820 mm
Weights
Vehicle kerb weight (with 90% fuel) 110 kgs for kick start scooter and 114 kgs for
electric start
Maximum carrying capacity 2 Persons & 10 kgs of luggage - 275 kg.
Engine Single cylinder, four stroke, forced air cooled
Single over head cam and 2 valves
Displacement 147.55 cc
Bore 57.0 mm
Stroke 57.8 mm
Compression ratio 9:1
Maximum output/Power (8.0 ± 0.3 Bhp) at 6250 rpm
Maximum torque 1.1 kgm at 4250 rpm
Ignition system Capacitor Discharge Ignition (CDI) Electronic.
Ignition timing 110± 20before TDC
15

Technical Specifications
Technical Specifications
Fuel Petrol 87 Octane and above
Fuel tank capacity 5.5 Litres (inclusive of 1 litre in reserve)
Fuel cock Three way tap :
Open (ON), Close (OFF), Reserve (RES)
Carburettor KEIHIN PB18–side draft
Spark Plug RG4HC - Champion
C8EH9 - NGK
UHR3CC - BOSCH
Spark plug gap 0.7~0.8 mm
Starting Kick Start Push Button for Auto start
Clutch Multiplate, oil bath.
Transmission 4 Speed constant mesh
Overall Gear Ratio
1st Gear 17.07
2nd Gear 10.71
3rd Gear 7:89
4th Gear 5.83
18
Chassis Pressed steel sheet, and rear tubular framed
structure covered by sheet metal shell assy.
Steering column and suspension The steering column is pivoted at the front
wheel swinging hub
Front and rear suspension Front and rear suspension with hydraulic dampers
and helical spring
Brakes
Front brake Drum brake, mechanical expanding shoe type.
Rear brake Drum brake, mechanical expanding shoe type
Tyres
Front and rear tyres 89 x 254mm (3.50 x 10), 4 ply rating, interchangeable
Tyre pressure
Front wheel 1.2 kg/cm2 (17 psi)
Rear wheel 1.8 kg/cm2(25 psi)
2.5 kg/cm2(35 psi) with pillion rider
Controls
Steering Handle bar
Accelerator Twist grip type on right hand side of the handle bar
Gears By hand on left hand side of the handle bar
Clutch Lever operated on left hand side of the handle bar
Front brake Lever operated by right hand
Rear brake Pedal operated by right foot
17

20
Control Functions
Technical Specifications
Electricals
Generator system 12 Volt 96 Watt.
Head lamp 12 Volt 35/35 Watt
Tail light bulb 12 Volt 5 Watt
Stop light bulb 12 Volt 10 Watt
Speedolight bulb 12 Volt 1.2 Watt x 2
Turn signal light bulb 12 Volt 10 Watt
Tell tale lamp 12 Volt 1.2 Watt x 4
Horn 12 Volt DC Horn fitted with AC to DC convertor
Battery 12 Volt 9 Ah (for auto start model)
Fuse 8 Amp (for auto start model)
Maximum speed 90 kms/hr
CONTROL FUNCTIONS
1. LOCKING SYSTEM
The LML has a single key for
locking the steering column, glove
compartment, utility box and seat, as
well as for the ignition.
1.1 Steering lock-cum ignition switch.
Locking the Handlebar : First turn the
handlebar to the extreme left and then
turn the key anti-clockwise to lock
position. Pull out the key after locking
(Fig.14).
Un-locking the Handlebar : Insert the
key in ignition switch and turn it clock-
wise to unlock the handlebar. To switch
on the ignition turn the key further clock-
wise to "ON" position (Fig. 15).
19

Control Functions
Control Functions
INSTRUMENT PANEL
An elegantly designed instrument panel which
contains the following:
1. Fuel-Gauge
2. Fuel level indicator needle
3. Head light low beam indicator
4. LH turn signal indicator
5. Speed indicator needle
6. Odometer
7. RH Turn signal indicator
8. Head light high beam indicator.
1.2 Glove compartment lock : To open
the lock, insert the key into the lock
and rotate anti-clockwise till the end
and then press the lock downwards.
For closing, press the lid, turn the key
clockwise and then take out the key
(Fig. 16 & 17).
1.3 Seat Lock (Dual Seat) : Insert the key,
rotate it clockwise till the end then take
it out.
Push the lock with thumb (fig. 18) and
lift the saddle from the back (fig. 19).
Place the saddle in its normal position
& press it down.
To lock the saddle, follow the above
procedure in reverse order.
1.4 Utility Box Lock : To open the utility box
insert the key and rotate it clockwise till
end (Fig. 20). Open the lid (Fig. 21).
For closing, close the lid and rotate the
key anti-clockwise to lock and then take
out the key.
21
22

Control Functions
Control Functions
24
2. CONTROL SWITCHES : Control switches are
located on the right and left hand sides of the
handlebar.
2.1 Right hand side of the handlebar
(Fig. 23).
2.1.1 Headlight
l Press bottom end of (1) to activate
the headlight.
l Press top end of (2) for high beam
or bottom end of (2) for low beam.
l Headlight is switched off if (1) is
pressed at top end.
High and low beam positions are
indicated on the instrument panel.
2.1.2 Instrument Panel lights and tail lights.
Press bottom end of (1) for light. Press
top end of (1) to switch off light.
2.1.3 Stop Light - Becomes operative when
foot brake pedal or hand brake lever is
pressed.
2.1.4 Horn - Press button (3)
2.1.5 For Auto start model only : Press
push button switch (4) for auto start
only after pressing clutch lever and
disengaging clutch.
2.2 Left hand side of the handlebar
(Fig. 24).
2.2.1 Turn indicator switch : Press left hand
end of switch for turning left and right
hand end for turning right.
Left & right turn indicators are shown on the
instrument panel.
3. GEAR AND CLUTCH : Located on the left
hand side of the handlebar, consisting of
clutch lever for engaging the clutch and the
gear twist for changing gears.
3.1 Clutch lever : Press the clutch lever
towards the handlebar to disengage
the clutch. (Fig. 25).
23

Control Functions
3.2 Twist grip for gear change : There are
5 positions, one for neutral and the
other four for driving at different speeds
as given below;
Gear Speed band as
position given below
1 Upto 10 Kms/hour
0 Neutral
2 10-20 kms/hour
3 20-35 kms/hour
4 35 kms/hour & above
To change gear, press clutch lever and turn the
twist grip. (Fig. 26) to the required position.
4. ACCELERATOR THROTTLE : Located on
the right hand side of the handlebar. It
is a twist grip. For increasing acceleration
rotate the twist grip towards yourself. Do the
reverse for decreasing acceleration (Fig. 27).
5. BRAKES : There are two brakes one
operated by foot and the other operated
by hand. Both brakes should be applied
simultaneously for most effective braking.
5.1 Foot Brake : Operates on the rear
wheel. Press down brake pedal to
apply the brake. The distance in which
the scooter can be brought to a halt
will depend on the speed at which the
vehicle is travelling and the user's
driving habits. (Fig. 28).
5.2 Hand Brake : Operates on the front
wheel. Press hand brake lever towards
the twist grip (Fig. 29).
6. FUEL SUPPLY
6.1 The fuel tank is located under the seat
(Fig. 30) and is accessible only when
the seat is unlocked and lifted. For filling
in petrol unscrew the cap and close it
after refuelling.
26
Control Functions
25

Control Functions
1. Choke Knob 2. Fuel Cock lever 3. Hook for Bag
7. HOOK FOR BAG : There is a hook for
hanging a bag under the seat.
6.2 Control of flow of petrol (Fig. 31) : There
is a fuel cock below the seat which has
3 positions; (ON) for regular flow of petrol
from the tank to the engine; (OFF) for
stopping the petrol supply from the tank
to the engine; and (RES) to be activated
when the need arises.
If the vehicle stops on account of lack of
petrol, then turn the cock lever to (RES)
i.e. "RESERVE" position. There is one litre
of petrol kept in reserve in your tank for
any emergency.
There is a fuel gauge in the instrument panel
for indicating the quantity of fuel in the tank.
6.3 Choke knob (Fig. 32) : Located below
the fuel cock. To be used for starting the
engine when it is cold. Pull the choke
knob out-wards for operation. It should
be pressed back when the engine has
started running normally.
Caution :
If the choke knob remains pulled out, it will lead to
the flooding of petrol in the carburettor causing
erratic running and high fuel consumption.
28
Operating the vehicle
OPERATING THE VEHICLE
Warning : Before driving your scooter make
yourself thoroughly familiar with all
operating controls and their
functions.
1. BEFORE STARTING THE ENGINE:
1.1 Check if tyres are properly inflated.
1.2 Check for correct play in the clutch lever
(Fig. 25) and make sure that it operates
properly.
1.3 Check for correct play in the foot brake
pedal and hand brake lever.
1.4 Check if the accelerator throttle is
operating properly and the play is also
normal. A - Open fuel cock
B- Switch 'ON' ignition
C- Put gear in neutral
position
D- Pull the choke knob
(with cold engine only)
E - Bring accelerator throttle
to idling position
F - De-clutch
G - Kick starter pedal
Fig. 33
27

30
Operating the vehicle
3.4 Put the vehicle in motion by gradually
releasing the clutch and simultaneously
by rotating the accelerator throttle twist
grip towards yourself.
3.5 For changing gears, release the
accelerator throttle, press the clutch
lever and rotate the gear twist grip to
higher or lower gear as required.
3.6 Use indicator switch button for turning
and use horn whenever required.
3.7 For night driving use headlights.
Operating the vehicle
4. APPLICATION OF BRAKES:
4.1 Bring the accelerator throttle to its normal
position.
4.2 Press the clutch lever and change the
gear to the neutral position.
4.3 Use foot pedal brake and hand brake
simultaneously for the most efficient
braking.
2. STARTING THE ENGINE (Fig. 33).
2.1 Turn fuel cock lever to "ON" position.
2.2 Turn 'ON' the ignition switch.
2.3 Put gear control in neutral position.
2.4 Pull out the choke knob for cold engine
start only.
2.5 Bring the throttle to idling position.
2.6 If you are starting the engine for the first
time in the day, press the clutch lever
and, keeping it pressed, kick the starter
lever a couple of times.
2.7 Operate the kick pedal by pushing it
down with a kick for starting the engine.
For auto start models, in addition to the
kick start, they have push button start
switch. For starting the engine with auto
start, press clutch lever and then press
the push button start switch.
2.8 When the engine is running normally,
press the choke knob back to its
normal position.
Caution:
i. Do not use electric starter for more than 5
seconds at a time. Release the push button
start switch for approximately ten seconds
before pressing it again. If the engine fails
to start after repeated attempts hold the
throttle 1/8-1/4 open and push the button start
switch.
ii. Before using the auto start switch,
ensure that you press the clutch lever.
3. DRIVING THE SCOOTER:
3.1 Remove the vehicle from stand, by
pushing it forward.
3.2 Seat yourself on the scooter with feet on
the ground and hands on the handle
bar.
3.3 With the engine running at idling speed,
press the clutch lever with the left hand
and rotate the gear twist grip to 1st gear
position.
29

32
Running-in-Instructions
Care and Maintenance
CARE AND MAINTENANCE
1. REMOVAL AND REFITTING OF COWLS :
The right hand side cowl is to be removed for
checking of oil level and spark plug. The left hand
side cowl is to be removed for taking out or refitting
the spare wheel.
The levers for opening the cowls are placed
under the seat. To remove the cowls:
1.1 Lift the seat as explained on page 21.
1.2 Turn the cowl opening levers outwards
(Fig. 34).
1.3 Hold the cowl with both hands and pull
out the front end of the cowl by about
2". Then push the front end upwards by
about 10" and rotate it outwards i.e.
towards its rear side (Fig. 35 & 36).
1.4 Pull out the cowl by disengaging its rear
end. (Fig. 37).
1.5 Refit the cowl, by following above
procedure in reverse.
ENGINE RUNNING-IN
Operation : The most important period in the life
of your scooter is its first 1000 kms. The engine
is brand new and different moving parts of the
engine need to be set to their correct operating
tolerances. This ensures a longer life for your
vehicle. It is therefore necessary to take some
precautions so as not to overload the engine.
1. Keep to the following speed limits
1st Gear : 0 to 10 kms/hr.
2nd Gear : 10 to 20 kms/hr.
3rd Gear : 20 to 35 kms/hr.
4th Gear : 35 kms/hr and above.
2. Avoid running the scooter on full accelerator
(throttle) for long periods. Vary the speed from
time to time.
3. Do not drive with half (partially engaged)
clutch. This will not only damage the clutch
but will also cause overheating of the
engine.
4. Allow a cooling off period of 5-10 minutes
after each hour of use.
5. Ensure oil level in engine to recommended
level, by checking the level with the help of
dipstick.
31

34
Care and Maintenance
Care and Maintenance
2. CHANGING THE TYRES :
2.1 Removing and refixing the spare
wheel
2.1.1 Remove the left hand side cowl as
mentioned above.
2.1.2 Remove the protection cover of the
wheel by unscrewing the bolt with
the box spanner from your tool kit.
(Fig. 38).
2.1.3 The wheel is secured with two nuts.
Unscrew the nuts, remove the two
spring washers and take out the wheel.
2.1.4 For fixing the spare wheel follow the
above procedure in reverse order.
2.2 Changing of Front Wheel
2.2.1 Put the vehicle on its central stand.
2.2.2 Hold the wheel cover at its edges and
pull it out gently from its clamps.
2.2.3 Remove the five nuts securing the
wheel to the brake drum by using
the box spanner from your tool kit
(Fig. 39). While loosening the nuts, hold
the wheel with one hand.
2.2.4 Remove the spring washers and take
out the wheel from the brake drum.
2.2.5 For refitting, follow the above
procedure in reverse order.
2.3 Changing of Rear Wheel :
2.3.1 Put the vehicle on its central stand.
2.3.2 Remove side cowls as explained on
page 32.
2.3.3 In case of auto start model, remove the
battery. Follow the instructions given on
page 37 for removal and installation of
battery.
2.3.4 Bring the fuel knob to "close" position.
Start the engine to exhaust petrol in the
carburettor as well as in the fuel line.
The engine will stop automatically
when the fuel is exhausted.
2.3.5 Remove the spare wheel as explained
on page 33.
2.3.6 Lay the scooter gently on ground on its
right hand side with the handle bar
sleeve touching the ground at right
angle.
2.3.7 Hold the wheel cover at its edges and
pull it out gently from its clamps.
2.3.8 Bring the vehicle in first gear and hold
the wheel with one hand. Remove the
five nuts securing the wheel to the
brake drum by using the box spanner
(Fig. 40).
2.3.9 Remove the spring washers and take
out the wheel from the brake drum.
2.3.10 For refitting, follow the above
procedure in reverse order.
Precaution :
1. Tighten all wheel securing nuts alternately and
progressively. Re-check if all nuts are tightened
properly.
2. Get the tyre pressure checked to the
recommended level at the nearest service station.
Fig. 38 33

36
Care and Maintenance
Care and Maintenance
2.4 Tyre Rotation :
All the three wheels of your LML are
interchangeable with each other. However, the air
pressure in the tyre will depend on whether it is
fitted in the front or rear position. To ensure even
tyre tread wear, it is necessary to rotate the tyres
and change the face of the tyre (in relation to the
wheel rim) after every 6000 kms. Follow the
sequence for tyre rotation as explained in fig. 41.
3 CHECKING ENGINE OIL LEVEL AND
CLEANING SPARK PLUG
3.1 Park the vehicle on level surface.
3.1.1 Remove the right hand side cowl as
directed on page 32.
3.2 Checking oil level :
3.2.1 For checking the oil level, unscrew
dispstick as shown in fig. 42.
3.2.2 Clean dipstick by a dry cloth.
3.2.3 Dip the dipstick with out screwing.
3.2.4 Take out dip stick and check the level of oil, as
shown in fig. 9. Oil level should be above lower
level make and below upper level mark.
3.2.5 If level is less add Engine Oil to maintain correct
level.
3.2.6 Refix the dipstick
3.2.7 Wipe off any excess oil which may have been
spilled.
3.2.8 Refit the cowl.
3.3 Spark plug cleaning :
3.3.1 Remove the right hand cowl.
3.3.2 Disconnect the HT lead cable (Fig. 44).
3.3.3 Wipe & clean the area around the spark plug.
3.3.4 Using the box spanner, unscrew the spark plug
(Fig. 45).
3.3.5 Clean out any excessive carbon deposit.
3.3.6 Refix the spark plug back to its position.
3.3.7 Refit the cowl.
If you have a feeler gauge you can check the gap
between the electrodes in the spark plug. This gap
should be 0.7-0.8 mm (fig. 43). Resetting of the gap
should preferably be done at an authorised service
station.
Fig. 42
4. BATTERY CHECKING
(For Auto start Model Only)
Battery requires regular and thorough
maintenance as advised below:
4.1.1 The level of electrolyte must always be
in between the upper and lower levels
marked on the battery. Normally a
constant level in the specified range is
maintained for about two months or
approximately 2000 kms (Fig. 46).
35

38
Care and Maintenance
Care and Maintenance
4.1.2 The level of electrolyte should be
checked once in a month. In case of a
normal decrease (0.5 cm) put in distilled
water only so as to reach the upper level
indicated on the battery. In case of a
marked decrease (1 cm or more), please
get the battery checked at the nearest
service station.
Caution :
1. Battery should be removed if the vehicle is to be
washed lying on its side.
2. Use only 8 Amp fuse to prevent serious damage to
the wiring harness & battery. Ignition switch should
be in "off" position while replacing fuse.
4.2 Removal and refitting the battery
4.2.1 Turn the ignition key to "off" position.
4.2.2 Remove the left hand side cowl as
explained on page 32.
4.2.3 Remove the screw securing ground
cable (black) connected to the negative
(–) battery terminal by using the Philips
end of the screw driver from your tool
kit. (Fig. 44)
4.2.4 Similarly follow the procedure for
removing the red cable connected to the
positive (+) battery terminal.
4.2.5 Remove the battery and bleeder tube.
4.2.6 Detach the fastener belt and take out the
battery.
Precaution :
Keep the battery and bleeder tube away from the
vehicle to avoid any damage to the painted surface of
the scooter due to leakage or spillage of battery
electrolyte.
4.3 Installation :
4.3.1 Clean the battery box.
4.3.2 Clean the battery thoroughly from the
outside.
4.3.3 Put the battery in the battery box.
4.3.4 Connect the fastener belt first to the
lower hook, then hold the battery firmly
with one hand, stretch the belt and
fasten it in the upper hook. Re-check if
the battery is fastened firmly (Fig. 48).
4.3.5 Re-fix battery bleeder tube and ensure
that it is routed properly through its
clamp.
4.3.6 Fix the "Positive" (+) terminal first and
then the "Negative" (–) terminal.
4.3.7 Make sure the battery cable does not
touch any metallic surface during
fitment.
4.3.8 Apply petroleum jelly around the
terminals to prevent corrosion.
4.3.9 Ensure, Protection cap provided on
battery harness is fixed properly on
positive (+) terminal of battery.
Caution :
Always ensure that the bleeder tube is not clogged,
crimped or bent. The tube should be of proper length
i.e. 9". Replace the bleeder tube in case it is not of
correct length or it is clogged, or bent.
37
