LNI SONIMIX 3030 Series User manual

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 1OMSX3030-PERM1T1PT.1oc 10.01.2003
SONIMIX 3030-PERM1T1PT
OPERATING MANUAL
1) INTRODUCTION
2) CHARACTERISTICS
2.1 GENERAL CHARACTERISTICS
2.2 PRESENTATION OF THE INSTRUMENT
2.3 INTERNAL STRUCTURES
2.4 ELECTRONICS
3) SOFTWARE DESCRIPTION AND ACCESSIBLE FUNCTIONS
3.1 INTRODUCTION
3.2 SOFTWARE EXPLORATION AND DEFINITION OF THE PRINCIPAL KEYS
3.3 DETAILS OF THE MENUS AND FUNCTIONS ACCESSIBLE
4) INSTALLATION
4.1 INSTALLATION
5) MAINTENANCE AND RECALIBRATION
5.1 MASS FLOW GENERATOR
5.2 PERMEATION TUBES
5.3 ON SITE VERIFICATIONS
5.4 REPAIR
5.5 FACTORY RECALIBRATION
6) TROUBLE SHOOTING
7) NOTES

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 2OMSX3030-PERM1T1PT.1oc 10.01.2003
1) INTRODUCTION
The SONIMIX 3030 is a modular calibration system, specially developed for the Air Pollution
Monitoring Network.
The different modules of the SONIMIX 3030 family answer all to the following philosophy :
1 gas àmeasured by 1 analyseràchecked by 1 calibration module.
With such family it is possible using the 5 appropriate modules to calibrate up to 5 Analysers
(NOx, O3, SO2, CO and HC or BTX) at the same time.
Different technologies and method are used : dilution (by MFC or sonic Nozzles), permeation, ozone generation
and GPT
The modularity of the SONIMIX 3030 able the user to cover all it’s needs : from the simple one to the most
complex one.
The SONIMIX 3030 has a RS 232 remote command, a key board and a 2x20 character VFD screen.
All used components (MFC, sonic Nozzles, pressure regulators, permeation oven and ozone generator) have
been developed by LN INDUSTRIES SA.
Following features have been in the centre of the development :
•High precision and stability
•Quick stabilisation time (by suppression of the dead volumes)
•Easy link to the national standards
The SONIMIX 3030-Perm can be used to generate different gases (SO2, NO2, NH3, HCl and BTEX) by
permeation. The SONIMIX 3030-perm is available in 2 different configurations : 1 point or multi-points
The use of permeation oven in stead of low concentrated gas cylinders (ppb) gives a much higher stability of the
generated gas as well as lower functioning costs. The microprocessor automatically calculate the concentration
of the gases and regulate the voltage of the MFC.
Fluidics
SX 3030-perm1T-1pt
SONIMIX
Module dilution
SONIMIX
Module Ozone
Inlet Air
Inlet Sample
To the Analyser
Option vanne 3/2
de sortie
Pressure
Regulator Sonic Nozzle
Permeation
Oven
MFC
Inlet Air
Inlet Sample
To the Analyser
Optional outlet
3/2 valve
Pressure
Regulator Sonic Nozzle
Permeation
Oven

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 3OMSX3030-PERM1T1PT.1oc 10.01.2003
Main technical data
Air : Dry air comingFrom a gas cylinder
From a Zero Air Generator LNI_SONIMIX
Concentration @ 5 Nl/min : to be choose between 10 ppb and 500 ppb
Concentration range : 10x by flow variation (0.5Nl/min à 5 Nl/min)
(only with SX 3030-perm1T-Mpt )
Maximal flow : 5000 Nml/min of mixture, (equivalent N2)
(other flow available)
Precision of the concentration : SX 3030-Perm-1pt better than 0.6% relative
(for SO2, NO2 and BTEX only) SX 3030-Perm-Mpts better than 1 % relative
Repeatability : SX 3030-Perm-1pt better than 0.3% relative
SX 3030-Perm-Mpts better than 0.5% relative
Stabilisation time of the mixture :< 1 minute
Inlet pressure : from 2.2 to 3.5 bar relative
Max outlet pressure : atmosphere
Alarms : inlet pressure, oven temperature, MFC voltage
Command : electrical, local or remote
* local with screen + key board : screen VFD 2x20 characters, key board 18 touches
* remote command : RS-232, 1200 à 9600 baud, other parameters 100% adjustable
communication Protocol : see options
Electrical consumption : 25W 220VAC/50Hz
Leak test : 316L < 10-7 mbar l/s, checked by He detector
Casing : ½ 19", 3U, 500mm
SX 3030-Perm-Mpt
No d’article Option Descriptif
670210300 SONIMIX 3030-Perm-Mpt Module à perméation multi-points avec 1 MFC / boîtier ½ 19’
670210302 SONIMIX 3030-Perm-Mpt-OP1 Outlet 3/2 valve to select Cal / Sample
670210311 SONIMIX 3030- Perm -Mpt-OP9.1 Remote command RS 232 : Protocol ASCII
670210312 SONIMIX 3030- Perm -Mpt-OP9.2 Remote command RS 232: Protocol Breitfuss
670210313 SONIMIX 3030- Perm -Mpt-OP9.3 Remote command RS 232: Protocol Bayer-Hess
670210397 SONIMIX 3030- Perm -Mpt OP97 Voltage 230 VAC / 50 Hz
670210399 SONIMIX 3030- Perm -Mpt OP99 Voltage 117 VAC / 60 Hz
SX 3030-Perm-1pt
No d’article Option Descriptif
670210600 SONIMIX 3030- Perm -1pt Module à perméation mono-point avec BS / boîtier ½ 19’
670210602 SONIMIX 3030- Perm -1pt -OP1 Outlet 3/2 valve to select Cal / Sample
670210611 SONIMIX 3030- Perm -1pt -OP9.1 Remote command RS 232 : Protocol ASCII
670210612 SONIMIX 3030- Perm -1pt -OP9.2 Remote command RS 232: Protocol Breitfuss
670210613 SONIMIX 3030- Perm -1pt -OP9.3 Remote command RS 232: Protocol Bayer-Hess
670210697 SONIMIX 3030- Perm -1pt OP97 Voltage 230 VAC / 50 Hz
670210699 SONIMIX 3030- Perm -1pt OP99 Voltage 117 VAC / 60 Hz No d’article Accessoires :
670210X72 Tube à permeation SO2
670210X74 Tube à permeation NO2
670210X76 Tube à permeation H2S
670210X78 Tube à permeation NH3

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 4OMSX3030-PERM1T1PT.1oc 10.01.2003
The SONIMIX 6000D1 is an instrument designed to calibrate manually or by remote control a BTX
monitor with upto 6 different gas sources. The six gas sources are generated by 6 different
permeation tubes located in the same permeation oven; Benzen, Toluen, O-xylene, M-xylene, P-
Xylene and Ethyl Benzene. When the CALibration or Zero functions are not activated, the sample
flows through the instrument without any modification.
The SONIMIX 6000D1 is equiped with an interface designed to be directly compatible with the BTX
monitor. That feature allows in Remote mode, to receive and to interpret, the instructions SAMPLE,
ZERO and CALibration. In Local mode, the interface allows to Configure the calibrator and to
perform the manual operations of calibrations necessary after the maintenance process on the
monitor. The major parameters, such as temperature, pressure,… are readable on the display.
The basic configuration of theSONIMIX 6000D1 is mainly composed of 3 parts :
** a mass flow generator, based on high precision pressure regulator and sonic nozzles. The Air
pressure is monitored by a pressure switch.
** a thermostated oven for upto 6 permeation tubes
** an interface, based on the 80537 microcontroler, able to receive and execute the instructions
emitted by the monitor, instructions materialised by two relays; the power supplies for the
valves, the keyboard and the 2 X 20 characters fluorescent display.
When the self regenerable internal Zero Air generator is installed, SONIMIX 6000D1 OP1, the
instrument is totally independant from the external source of compressed Air.

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 5OMSX3030-PERM1T1PT.1oc 10.01.2003
2) CHARACTERISTICS
2.1 GENERAL CHARACTERISTICS
Carrier gas : High grade ZERO Air from pressurized cylinders or
from the internal ZERO AIR GENERATOR (OP1)
Final concentrations generated by
the permeation tubes :30µg/m3 Benzen
30µg/m3 Toluen
30µg/m3 O-xylen
30µg/m3 M-xylen
30µg/m3 P-xylen
30µg/m3 Ethyl Benzen
Total outflow of mixture : 1000 Nml/min
Permeation tubes protection flow : 100 Nml/min
Stabilisation time of the mixtures (T99) : <2 to 3 minutes
Temperature of the permeation tube
oven : 45°C
Temp. stability of the permeation
tube oven : 0.05°C
Remote command signals : 2 dry relay as inputs
Alimenting pressures : 2.5+/- 0.3 bar ( 35 +/- 5 psig)
Operating temperature : 15 to 40°C
Operating altitude : from sea level to 4000m

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 6OMSX3030-PERM1T1PT.1oc 10.01.2003
Alarms :1 pressure switch on the Air line and one on the
permeation oven temperature
Electro-magnetic compatibility : According to CE recommandations
Power consumption : 110V/60Hz or 230V/50Hz/60Hz 150W
Gas connections : by 1/4″Swagelok fittings
Dimentions and weight : 19″3HE/84TE, 500mm deep. About 18 Kg.
2.2 PRESENTATION OF THE INSTRUMENT
2.2.1 Front face
The front face is composed of :
-1 : the vacuum fluorescent display with two rows of 20 characters
-2 : the 18 keys keyboard
-3-: the power switch
2.2.2 Rear face without Option1
The rear face is composed of :

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 7OMSX3030-PERM1T1PT.1oc 10.01.2003
-1 : the AIR Inlet. Swagelok 1/4″fitting with integrated filter
-2 : the Outlet of mixture , fitting Swagelok PVDF1/4″, to be connected to analyzers
-3 : the By-pass outlets, 1/4″Stainless teel
-4 : the Sample inlet port, 1/4″Stainless teel with integrated filter
-5 : DB9 Female remote command connector
-6 : the power line plug protected by two 1A fuses with a sticker indicating the voltage
2.2.3 Rear facewith Option1
The rear face is composed of :
-1 : the Outlet of mixture , fitting Swagelok PVDF1/4″, to be connected to analyzers
-2 : the By-pass outlets, 1/4″Stainless teel
-3 : the Sample inlet port, 1/4″Stainless teel with integrated filter
-4 : DB9 Female remote command connector
-5 : the power line plug protected by two 1A fuses with a sticker indicating the voltage
-6 : one fan with protections for ventilation of the compressor
2.3 INTERNAL STRUCTURES
2.3.1 FLUIDIC SCHEMA
The fluidic schema is represented with the self regenerable Zero Air generator.

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 8OMSX3030-PERM1T1PT.1oc 10.01.2003
EV11 EV12
EV13
c
no
nc
c
no
nc
INLET SAMPLE
Entrée Air
OUTLET
MIXTURE
PURGEBS 100 Ncc/min
BS 900 Ncc/min
TANK
PUMP
PURGE
(WATER)
EV1
EV2
EV3
EV4
EV5
EV6
EV7
EV8
EV9
FILTER
EV10
RES1
RES2
FILTER
FILTER
PS1 PS2
RP1 RP2
DRYER
2.3.2 FLUIDIC MODULES
The fluidic circuit of the SONIMIX 6000D1 shows four modules:
*** the mass flow generator based on a high precision pressure regulator with sonic orifices
*** the 6 tubes permeation oven with injection valves.
*** the sample / zero-span electrovalve
*** the self regenerable Zero Air generator (OP1)
PS3000
Power
supply
MB3000
Control
Board
Compressor Dryer with
coalescing filter

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 9OMSX3030-PERM1T1PT.1oc 10.01.2003
2.3.3 CONSTRUCTION
a) AIR line
* the filters and componants used on the circuit to purify the atmospheric Air are made of high
pressure resistant PVC and Delrin.
* all metallic parts in contact with the dry and pure AIR are made of anodized Aluminia,
passivated Brass and of stainless steel.
* the filter assembled in the Air inlet is made of sintered stainless steel with 30µabsolute level
of filtration
* elastomer seals are made of high grade Viton
b) Permeation oven module
* all metallic part in contact with the high concentration mixtures are made of non-reactive
corrosion free material such as pureTeflon, PFA and stainless steel. Seals are in Teflon or
high grade Viton.
2.4 ELECTRONICS
The SONIMIX 6000D1 electronics is composed of 5 different boards:
-1- the main board labelled MB3000 including
** the 80537 micro-controller with
64Kbyte of EPROM
8Kbyte of EEPROM
64Kbyte of RAM
** the remote command interfaces (dry relays and RS-232)
** 16 drivers and power-reducers circuits for the electro-valves with ECOPOWERsystem.
Mass flow
generator Permeation oven
Sample / Span
Zero Electrovalve Tank Filters

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 10 OMSX3030-PERM1T1PT.1oc 10.01.2003
-2- the power supply generating (PS3000/50VA)
+ 7VDC / 3.5 A
- 7VDC / 2.5 A
COMMON of +/- 7VDC
+ 5VDC / 1 A
GND of +5V (GND and COMMON not connected)
-3- one high precision temperature regulation system, labeled FOUR P6L2, with the valves
control and communication circuits with the MB3000 board for the permeation oven
-4- the 18-keys keyboard
-5- the 2X20 characters Vacuum Fluorescent Display module.
The boards 1, 2 and 3 are fixed together on an L-shape aluminia cooler located close to the
display. The boards 4 and 5 are fixed on the front face.
The three main boards, MB3000, PS3000 and FOUR P6L2 and eventual other options
communicate with the 2-wire bus I2C.
3) SOFTWARE DESCRIPTION AND ACCESSIBLE FUNCTIONS
3.1 INTRODUCTION
The SONIMIX 6000D1 is a sophisticated calibration system and the ideal companion of the BTX
monitors; the integrated software has been designed taking into account easy access, modularity,
adaptation to old or new installations, future evolutions of the needs and conviviality.
The remote command option is based on a very simple interface and generates three status :
SAMPLE

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 11 OMSX3030-PERM1T1PT.1oc 10.01.2003
ZERO
SPAN
This software is composed of three groups of functions or menus.
** 1st group : FEATURES and SETTINGS
** 2nd group : LOCAL or MANUAL instructions
** 3rd group : BOARD PANEL
3.2 SOFTWARE EXPLORATION AND DEFINITION OF THE PRINCIPAL KEYS
The software is composed of menus activated, visited, interrogated or where some data are
modified principally with four keys:
MENU, ENTER, ↑and ↓
After cold booting or a RESET (RST), the instrument identify it self during 5 seconds and shows
SONIMIX6 0 0 0 D1
BTXC A LIBRATOR
and jumps to the SAMPLE status.
SAMPLE↓
In order to visualise the different possibilities ( Remote Control, Manual Control, Settings, Features,
Board Panel ) press MENU and then the↑or ↓key. At that point it is possible to navigate through
the different menues and sub menues with the four above mentionned keys.
↑and ↓: allows to show menus, sub-menus, parameters or data
ENTER : allows to select menus, sub-menus, parameters or data
MENU : allows to jump back to the previous selection
3.3 DETAILS OF MENUES AND FUNCTIONS ACCESSIBLE
- - 4.3.1 FEATURES

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 12 OMSX3030-PERM1T1PT.1oc 10.01.2003
- - 4.3.2 SETTINGS
- - 4.3.3 MANUAL and REMOTE CONTROL
- - 4.3.4 BOARD PANEL
3.3.1 FEATURES
MAINMEN U ↓
FEATURE S
This menu includes the essential informations relative to the hardware composition and software
options. Those informations are stored during the last phases of the production cycle and can not
be modified by the user; they includes :
Model of instrument : SONIMIX 6000D1
Function of the instrument : BTX Calibrator
Serial Number : 1234
Software version : V1.0
Date of production (week/Year) : 19/1999
Next recalibration : 19/2001
Pressure regulator setting value : RP1 setting = 2500 mbar rel
Outflow CST1 : 900 Ncc
Outflow CST2 : 100 Ncc
The informations are accessible by selecting first the Features menu and after with the↑and ↓key
to read the data.
3.3.2 SETTINGS
The SETTINGS menu is intended to consult or modify the default values of the functioning
parameters, in order to adapt the intrument to the installation conditions or to the user habits.
The default values are stored in the EPROM and can not be modified, the modified values are
stored in the EEPROM. The active values (used by the micro-controler) are stored in the EEPROM.
WARNING: if for any reason a new EPROM is installed, the EEPROM must be resetted and
therefor the complete parametrisation process must be repeated.
The following points are sub-menues or specific points of the Settings
++ Permeation tube number and type of gas
++ Calibration value for each tube
++ Alarms
++ Languages
The complete definition of a permeation tube is realised when all the following parameters are
recorded :

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 13 OMSX3030-PERM1T1PT.1oc 10.01.2003
•Permeation tube number : 1 to 6
•selection of the gas
•PT Calibration
3.3.2.1 PERMEATION TUBE
Selection of the permeation tube from 1 to 6.
SET T INGS↓
P E RMEATI O NTUBE
(Press Enter)
SET T INGS↓
P E RMEATI O NTUBE:1
Press ENTER to select the right tube, 2 for example
SELECTI O NGAS↓
BENZENE
Press on ↓or ↑to chose the gas contained in the tube 2, and then Enter to select it.
SELECTI O NGAS↓
TOLUENE
SELECTI O NGAS↓
M -- X Y LENE
Enter
Continue to attribute gas types to the permeation tubes.
SET T INGS↓
P E RMEATI O NTUBE:3
SELECTI O NGAS↓
TOLUENE
SELECTI O NGAS↓
M -- X Y LENE
SELECTI O NGAS↓
O-- X Y LENE
(Enter)

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 14 OMSX3030-PERM1T1PT.1oc 10.01.2003
etc,….
3.3.2.2 CALIBRATION VALUE
This submenu is intended to calibrate, for example by comparison with a certified bottle, the
permeation devices. It starts with a ZERO phases, which could be stopped at any time by pressing
MENU
TPCALIBRATI O N↓
P.T.1:BENZENE
By pressing on ↓or ↑the right tube is selected .
TPCALIBRATI O N↓
P.T.2:TOLUENE
…..
TPCALIBRATI O N↓
P.T.6:ETHYLBENZENE
When a tube is selected, for example PT3, Press on ENTER
P.T.2:TOLUENE
AMOU N T:1 9 p p b
The stored value, in our example 19 ppb, is issued of a measurement made with a monitor and
compared with a reference mixture at a similar concentration.
The same procedure should be followed to qualify the other permeation tube
3.3.2.2 ALARMS ENABLE
This menu allows to activate (ON) or desactivate (OFF) all the alarms. See chapter 3.3.6 for details
on the SONIMIX 6000D1’set of alarms. The choice is achieved by selecting ON or OFF with the ←
or→key and then by ENTER.
ALARMS E NABLE
O F F ON
3.3.2.3 LANGUAGES
This menu allows to select the languages of the informations presented on the display. The choice
is achieved by selecting FRENCH or ENGLISH with the↓or ↑key and then by ENTER.

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 15 OMSX3030-PERM1T1PT.1oc 10.01.2003
LA N GU A GE S ↓
FREN C H
3.3.3 MANUAL CONTROL
It is by this menu that the three different major functions are accessible,
MAINMEN U ↓
MANUALCONTROL
Selection by ENTER
MANUALCONTROL↓
SAMPLE
MANUALCONTROL↓
ZERO
MANUALCONTROL↓
SPA N
When SAMPLE is selected,
SAMPLE↓
0 0 :2 3
The display shows the function executed and since when.
ZERO↓
0 0 :1 5
SPA N ↓
0 1 :3 1
As soon as the display shows such image, the corresponding valves are switched on and the
expected mixture starts to flow to the analyser. The instrument needs a few minutes to generate a
stable mixture.
3.3.4 REMOTE CONTROL

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 16 OMSX3030-PERM1T1PT.1oc 10.01.2003
When the instrument is under Remote control and no other function is selected, the instrument is
executing a SAMPLE function. It means that the monitor is pumping its sample through the
SONIMIX 6000D1 without chemical modification.
SAMPLE0 0 :2 3
As soon as the monitor is sending a ZERO or SPAN instruction, the instrument switches to the
corresponding status; as well for the display informations as for the fluidics.
ZERO0 0 :5 7
SPA N 0 2 :3 6
IMPORTANT NOTICE
At any time during a zero or span phase, the functioning parameters assembled in the BOARD
PANEL menu, could be monitored by pressing ENTER.
To exit from the BOARD PAEL menu, press on MENU two times
See BOARD PANEL Menu for a detailed description of the parameters.
3.3.5 BOARD PANEL
The visualisation of the active parameters is achieved with the↓or ↑keys
3.3.5.1 Pressure at the AIR inlet
BOA R D PA N EL
AIRPRE S S U R E
To read the actual AIR pressure status, press on ENTER
AIRPRE S S U R E
PRESENT
If the pressure is within the tolerances, or if the pressure is inferior to the lower limit.
AIRPRE S S U R E
A B S E NT
Press MENU to reach the next active parameter

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 17 OMSX3030-PERM1T1PT.1oc 10.01.2003
3.3.5.2 Temperature of the permeation oven
BOA R D PA N EL
TPHEAT T EMP E R A TU R E
To read the actual temperature in ovens, press on ENTER
TPHEAT T EMP E R A TU R E
T.A C TU A L:4 4 .9°C↓
To read the tolerances on the temperature , press on the↑↓ keys
TPHEAT T EMP E R A TU R E
T.MIN:4 4 .5°C↓
TPHEAT T EMP E R A TU R E
T.MAX:4 5 .5°C↓
Press MENU to reach the next active parameter
3.3.5.3 P.Tube calibration values
BOA R D PA N EL
STA N D A R D TP
P.T.1:BENZENE↓
AMOUNT:1 3 ppB
P.T.2:TOLUENE↓
AMOUNT:1 9 ppB
….
REMARK : Those values were stored during the SETTING menu.
Press MENU two times to come back to MAIN MENU
3.3.6 ALARMS
The SONIMIX 6000D1 is able to detect 3 sources of misfunction and it generates the
corresponding messages of alarm either in manual or remote modes.
AIR A LA R M

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 18 OMSX3030-PERM1T1PT.1oc 10.01.2003
The following articles are the list of the alarms, when such a case is arriving the calibrator is not
stopped but the user is supposed to identify and verify the source of alarm by pressing ENTER and
using the BOARD PANEL menu.
3.3.6.1 Hardware Alarm
One or several boards are not communicating with the MB3000. That could be due to an
interruption in the wiring or a damaged board.
3.3.6.2 AIR Alarm
The alimentation of Air pressure from the Zero Air Generator or from a gas cylinder is not setted at
a correct value. It is inferior to the minimum necessary pressure.
3.3.6.3 Heathing Alarm
This alarm is turned on when the oven’s temperature is inferior to the setted value, which is 44.5°C.
The Tolerance is +/- 0.5°C . This does not means that the stability is +/- 0.5°C, but that the mean
value was setted in the factory in a gap of 0.5°C around 45°C.
The stability is +/-0.05°C.
3.3.6.4 Overheath Alarm
The concept is similar to 3.3.6.3, but for temperature value over the maximal limits, which is 45.5°C.

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 19 OMSX3030-PERM1T1PT.1oc 10.01.2003
4) INSTALLATION
4.1 INSTALLATION
After carefull unpacking and verification that the instrument has not been damaged during the
transport, place it in the measuring installation.
Read this operating manual and be familiar with the chapters 3 and 4.
4.1.1 FLUIDIC CONNECTIONS
Connect the SONIMIX 6000D1 inlets to the AIR supply with a stainless steel tube, specially
processed for chromatography use. In addition, the pressure reducers fixed on the cylinders must
be of good quality and cleaned; made of stainless steel with sealings in Kalrez or Chemraz.
All pressure reducers are adjusted at about 2.5 bar relative.
In order to maintain the fast response time of this calibrator, we suggest the realise the flow
diagram as described
.
The tube and fittings between the calibrator and the monitor could be be in PTFE, PFA or stainless
steel.
BTX CALIBRATOR
AIR
INLET
BY-Pass
Outlet
BTX MONITOR
Sample /
Zero
Span
line
Remote
command
Sample INlet

OPERATING MANUAL SONIMIX3030-PERM
1T1PT
Edition 1.0E January 2003 Page 20 OMSX3030-PERM1T1PT.1oc 10.01.2003
The SONIMIX 6000D1 could be alimented by a cylinder of ZERO AIR or by the internal ZERO AIR
GENERATOR (OP1).
WARNING : If one or several permeation tubes are installed, a ZERO AIR flow will be continuously
consumed to stabilise them; in that case and for economical reason the ZERO AIR generator option
is expressly recommended.
The purge outflow must be evacuated to a safe area or to the atmosphere through a chemical
reduction filter.
Use only Swagelok double seal system for proper tightness.
Verify on each connection the absence of leak.
Recommended alimenting pressures : 2.5 bar relative; pressures superior to 5 bar ( even
temporarly) may damage definitively the internal pressure regulators.
4.1.2 REMOTE COMMAND CONNECTIONS
The remote control is made through a digital interface with only 3 signals ZERO, SPAN, and Alarm
on a DB9 female connector. The command mode could be either through dry relays or by voltages.
The Connector pinout is :
Remote control Mode DB9 Pins
ZERO Dry relay 1-6
SPAN Dry relay 1-7
ZERO +5Volt command 2-3
SPAN +5Volt command 2-4
ZERO +12Volt command 2-8
SPAN +12Volt command 2-9
ALARM Dry relay 2-5
GND (+5 and +12) 2
4.1.2.2. Remote commands and Alarm
Zero command:
Close contact between pin 1 and pin 6,
or apply +5V between pin 2 and pin 3,
or apply +12V between pin 2 and pin 8
Span command:
Close contact between pin 1 and pin 7,
or apply +5V between pin 2 and pin 4,
or apply +12V between pin 2 and pin 9
Internal signal:
Alarm: dry relay closed between pins 4 and 5, free of potential
