Locinox Valentino Instruction sheet

Valentino
CONFIGURATION MANUAL

22022-04-20 Rev 02 -Valentino
COPYRIGHT
Copyright©2022 Locinox. All rights reserved. This product incorporates copyright protected technology that is
protected by a number of EU patent method claims and other intellectual property rights owned by the Locinox
Corporation and other rightholders.
Use of this copyright protected technology must be authorized by the Locinox Corporation. Reverse engineering or
disassembly is prohibited.
No part of this publication can either be reproduced, communicated, transcribed, stored in a retrieval system or
be translated into any language in any form or by any means, whether electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, unless explicit written consent has been given by the copyright holder.
NOTICE
The contents of this publication are subject to change. The Locinox Corporation reserves the right to alter the contents
of this publication at any time and without notice. The contents of this publication may contain inaccuracies or
typographical errors and is supplied for informational use only.
TECHNICAL SUPPORT
If you require any additional information or assistance during the installation, please contact your dealer, who will be
able to provide the latest information. Alternatively, you can visit the Locinox website for more technical information or
e-mail us on [email protected]. Please keep the serial number at hand of your product for future support.

2022-04-20 Rev 02 - Valentino 3
Valentino
CONFIGURATION MANUAL

42022-04-20 Rev 02 -Valentino
Valentino
Up to 100
entry codes
Free exit
functioning
possible
Compatible
with push
handles
Extreme
weather
proof
IP 56
Easily
readable
digits by
LED lighting
PUSH
150K+ cycles
on same set
of batteries

2022-04-20 Rev 02 - Valentino 5
CONTENTS
EN 1. PRODUCT DESCRIPTION.................................................................................... 6
2. PROGRAMMING ................................................................................................ 6
3. FACTORY RESET UPON LOSS OF MASTER PIN................................................ 8
4. FUNCTIONING OF VALENTINO....................................................................... 8
5. MAINTENANCE .................................................................................................. 9
6. GENERAL INFORMATION ................................................................................. 9
7. WARRANTY.......................................................................................................... 9

Congratulations with the purchase
of your Valentino
1. PRODUCT DESCRIPTION
Valentino is a high quality battery operated
electronic code lock with aluminium housing.
Valentino’s energy efficient design makes it very
easy to equip any gate with access control, with a
minimal need for maintenance.
Both sides of the Valentino are equipped with a
weather protected illuminated electronic code
panel. Using these code panels, PIN codes can
be easily added, modified or removed. Up to 100
codes can be programmed. Different codes can
be used for entry and exit, and the system also
supports permanently open codes.
Valentino supports the use of a pushbar, free-exit
and code controlled handles.
2. PROGRAMMING
2.1 ACCESS PROGRAMMING MODE
Valentino offers 2 alternative methods to enter the
programming menu: by using the Master PIN code
(default value ‘12345’), or by using the key contact:
• Press [#] for 5 sec, [#] will start flashing
• Either enter the Master PIN code, and press [#],
or turn and hold the key contact in the locking
direction for a duration of 2 seconds
• If a wrong Master PIN is entered, the
programming mode ends and time out procedure
as described in 4.2 applies
For safety reasons we strongly recommend to
change the Master PIN upon first use
If only [#] is lit, you are in the main menu of the
programming mode
• Select a menu and confirm with [#]. The following
menus are available:
[9]  setup Master PIN
[1]  manage PIN codes
[2]  manage permanently open codes
[3]  setup switching duration
[4]  setup free exit mode
[5]  setup lighting mode
[0]  factory reset
See next paragraphs for detailed information
The programming mode ends automatically
when there is no activity for 60 seconds
• After selecting a menu, it’s possible to return to the
main menu by pressing the [C] key
• Press [C] for 5 seconds to exit the programming
mode
2.2 SETUP MASTER PIN [9]
• Access programming mode (see 2.1)
• Press [9] and confirm with [#]
• [9] and [#] are both lit
• The default Master PIN is 12345. It always has to
be a 5-digit code
• Enter a new 5-digit Master PIN and press [#]
• Repeat previous step to confirm the new
Master PIN
• If both codes are equal, all LEDs will light briefly
and you will return to the main menu of the
programming mode
EN
2022-04-20 Rev 02 - Valentino 6

2.3 MANAGE PIN CODES [1]
• Access programming mode (see 2.1)
A maximum of 100 different PIN codes can
be programmed (4-8 digits)
• Press [1] and confirm with [#]
• [1] and [#] are both lit
• Enter a new PIN code and confirm with [#]
• In case of a new code, the code will need to be
repeated and confirmed with [#]
• The lights below button [3] and [8] are indicating
on which side of the lock the code is valid. [8] is
used for the side the user is currently using, while
[3] is used for the other side
• Pressing [3] and [8] will select (permanently on) or
de-select (flashing) the corresponding side
• Press [#] to confirm
• You will return to the main menu of the
programming mode
When two different codes or a wrong code
length is entered, all keys will flash three times,
indicating the code setting hasn’t been saved.
Try again. [1] will remain lit
A code can be removed by de-selecting [3]
and [8] before confirmation
2.4 MANAGE PERMANENTLY OPEN
CODES [2]
PIN codes generated using menu [1] (manage PIN
codes) will unlock the lock for a predefined duration,
as configured in menu [3] (‘setup switching duration’).
In contrast, a ‘permanently open’ code has no
predefined duration to remain open, but will remain
open, until the same code (or another permanently
open code) is entered.
• Access programming mode (see 2.1)
• Press [2] and confirm with [#]
• [2] and [#] are both lit
• Enter a new PIN code and confirm with [#]
• In case of a new code, the code will need to be
repeated and confirmed with [#]
• The lights below button [3] and [8] are indicating
on which side of the lock the code is valid. [8] is
used for the side the user is currently using, while
[3] is used for the other side
• Pressing [3] and [8] will select (permanently on) or
de-select (flashing) the corresponding side
• Press [#] to confirm
• You will return to the main menu of the
programming mode
When two different codes or a wrong code
length is entered, all keys will flash three times,
indicating the code setting hasn’t been saved.
Try again. [2] will remain lit
A code can be removed by de-selecting [3]
and [8] before confirmation
2.5 SETUP SWITCHING DURATION [3]
• Access programming mode (see 2.1)
• Press [3] and confirm with [#]
• [3] and [#] are both lit
• Enter a value between 1 and 99, and confirm with
[#]. When all leds flash, your choice is saved
• You will return to the main menu
In case an invalid time is entered, all keys will
flash three times. Menu [3] remains activated
The default time is set at 8 seconds
2.6 SETUP FREE EXIT MODE [4]
The free-exit mode menu allows configuring a side
of the lock in ‘free exit mode’. On the free-exit side,
entering a PIN code is not required: just pressing any
key will unlock the lock for a predefined duration.
• Access programming mode (see 2.1)
• Press [4] and confirm with [#]
• [4] and [#] are both lit
• The lights below button [3] and [8] are indicating
which side of the lock is configured in free exit-
mode. [8] is used for the side the user is currently
using, while [3] is used for the other side
• Pressing [3] or [8] will select (permanently on) or
de-select (flashing) the corresponding side to be
configured in free-exit mode
• The selection is confirmed by pressing the [#] key
• You will return to the main menu of the
programming mode
The free-exit mode can be disabled by
de-selecting [3] and [8] before confirmation
EN
72022-04-20 Rev 02 -Valentino

2.7 SET LIGHTING MODE [5]
• Access programming mode (see 2.1)
• Press [5] and confirm with [#]
• [5] and [#] are both lit
• Choose the desired lighting mode:
[1] Auto dim (default):
During normal operation backlights are off.
As soon as a button is pressed, they go to full
brightness. After 5 seconds of inactivity the
lighting is switched off
[2] Backlight disabled:
The backlights will not light up upon pressing
a button
• Press [1] or [2] and confirm with [#]. When all
leds flash, your choice is saved
• You will return to the main menu
In case an invalid number is entered, all lights
flash three times. Try again. Menu [5] remains
activated
2.8 FACTORY RESET [0]
• Access programming mode (see 2.1)
• Press [0] and confirm with [#]
• [0] will flash rapidly to indicate an irreversible
action can be taken
• Enter the Master PIN and confirm by holding [#]
for 2 seconds
Instead of entering the Master PIN code, the
user can also confirm the reset by turning the
key contact in the locking direction for
a duration of 2 seconds
• When all LEDs flash, the factory reset is complete.
All settings are restored to default values
3. RESETTING THE MASTER PIN
UPON LOSS OF THE
MASTER PIN
Upon loss of the Master PIN code, it’s still possible to
enter the programming menu using the key contact,
as descibed in paragraph 2.1. After entering the
programming menu, the user can change the Master
PIN, as descibed in paragraph 2.2. Alternatively a
factory reset will also return the Master PIN to the
default value 12345.
4. FUNCTIONING OF VALENTINO
4.1 ENTER A CORRECT CODE
• Enter a PIN code (min. 4 - max. 8 digits)
• Press [#] to confirm
• A light sequence run from the left to the right across
the keypad, indicating that a correct code has
been entered
4.2 ENTER A WRONG CODE
• Enter a wrong PIN
• Press [#]to confirm
• All lights flash for 2 seconds, indicating a wrong
code has been entered
• If 5 or more wrong codes are entered
consecutively, you won’t be able to use the
Valentino for a certain period due to safety
reasons. The time out period is specified as
follows:
2[number of failed attempts] seconds
For example: 6 failed attempts result in a time out
period of 64 seconds (26seconds)
The time out period is reset when a correct
code is entered, or if no new code was entered
during 2 hours
4.3 LOW BATTERY WARNING
When the batteries start running out, the low battery
indicator on the keypad will start flashing when
entering a code, indicating that the time has come to
replace the batteries.
Once the batteries are further drained to a critical
level, no code can be entered anymore, and the low
battery light will light up when a button is pressed.
EN
2022-04-20 Rev 02 - Valentino 8

Federal Trade Commission rules restrict sending unwanted commercial email messages to
computers
A discarded device can either be returned to your dealer or be sent back to Locinox. This product’s
recycling fee is € 0,2.
The WEEE marking on the product indicates that it may not be thrown away together with normal
household waste and must be handed over to a designated collection point for the recycling of
electrical and electronic rejects.
As manufacturer of this product, we guarantee that we have taken all the necessary steps in order to
comply with the current safety requirements for this product.
5. MAINTENANCE
• Clean the housing and display using a soft cloth,
moistened with a neutral cleaning agent
• Never use fuel or chemicals on the device since
they might harm the housing
6. GENERAL INFORMATION
• Please observe the local regulations on the deposit
of packaging material and of appliances no longer
in use. Our packaging material is eco-friendly.
It can be divided into 2 materials: cardboard (box)
and expandable polyester (buffer)
• Your device is made of recyclable materials
7. WARRANTY
A 2 year warranty covers all electronics
4.4 REPLACE BATTERIES
• Open keyboard
• Pull the strap to remove batteries
We recommend the use of 6 AA (FR6)
Lithium Iron Disulfide (LiFeS2) batteries.
The use of other battery technologies will
influence its lifetime or even the functionality
of the Valentino
EN
Brand Locinox
Product Valentino
Model LOKQ4040Y2LZILVVSZC
Rating U = 4.5 VDC I = 5mA
Locinox HQ
Mannebeekstraat 21
8790 Waregem- Blegium
Locinox USA LLC
460-464 Windy Point Drive
Glendale Heights, IL 60319 - USA
92022-04-20 Rev 02 -Valentino
