Lockly PL45E1UQ User manual

USER MANUAL
SMART SAFE
ERP机型： PL45E1UQ-US-SMT00010A-V1
Designed：Walter Date：2022-08-08
描述: 说明书:PL45E1UQ/PGV528,SMT000,REV.A(UMPGV528W20220808),196×196MM,
封面&底面:128g双粉纸双面过哑油,单黑印刷,内页80g书纸,双面印单黑,22页44面装订本,
RoHS2.0,REACH,Prop65,POPs,PAHs
ERP P/N：
REV：1.1
KYMC
R
6
4 3
0
7 2
8
1 4
5
3 9

TABLE OF CONTENTS
Section 1 - Product Highlights
Section 2 - Product Overview
Section 3 - Using Your Smart Safe
3.1 Configuring Access
3.2 Entering Programming Mode
3.3 Adding an Access Code
3.4 Deleting an Access Code
3.5 Checking the Access Codes
3.6 Adding a Fingerprint
3.7 Fingerprint Scanning Directions
3.8 Fingerprint Scanning Tips &
Troubleshoot
3.9 Deleting Stored Fingerprints
1.1 Product Features
Section 5 - Advanced Features
Section 7 - Important Notes
Section 8 - Maintenance and Cleaning
Section 9 - Safety Precautions
9.1 Safety Precautions
1
2
3
4
6
7
5
8
9
10
12
14
15
18
20
21
24
25
27
33
34
29
30
32
35
36
37
2.1 Product Overview - Exterior
2.2 Product Overview - Interior
2.3 Understanding Your Smart Safe
2.4 Rebooting Your Smart Safe
2.5 Low Battery
2.6 Changing The Battery
4.3 Unlocking Lockly with App
4.4 Setting Up the Secure Link Wi-Fi Hub
4.5 Connecting Your Lockly Smart Safe
4.6 Unlocking with Physical Key
4.7 Safe Mode
4.8 Shine Mode
Section 4 - Unlocking
22
23
4.1 Unlocking with Access Codes
4.2 Unlocking with Fingerprint
5.1 Offline Access Code™(OAC)
5.2 Sub-Admin Access
7.1 Important Notes
Section 6 - Re-keying
34
6.1 Re-keying
8.1 Cleaning
Table of Contents
For additional support, visit http://Lockly.com/help
or email [email protected]

1.1 Product Features
1 SECTION 1.1
Patented Hack-Proof PIN Genie Keypad
Digits are randomly displayed on the key pad ensuring access codes to be undetectable to intruders
after repeated use. Numbers are randomly distributed across 4 buttons, with 3 numbers in each button.
Users can press any button showing their number. Location of the numbers are always different every
time someone uses the keypad, making it hard for prying eyes to guess the correct code.
Advanced 3D Fingerprint Recognition
Biometric Fingerprint Recognition protocol allows up to 99 registered fingerprints to be used and accepts
only actual fingerprints - preventing lifted prints from being used.
Tamper-proof / Premium Build
Made of 2.5mm alloy steel with corrosion resistant coating, magnet resistant, laser-cut 3D keyway and
fireproof interior inlays. With included safety metal wires and screws to prevent the Smart Safe from being
moved or stolen.
Air Transfer compatible
Quickly transfer fingerprint and trusted user profiles from your Lockly smart locks to you Smart Safe.
Hydraulic Easy-Lift Unlocking
Unlocks Safe quietly and syncs with LED lights which allows users to unlock, grab valuables with a single hand.
Backup Keys and TYPE-C Socket
Lockly Smart Safe can be opened with physical backup keys. There is also TYPE-C connection socket for
emergency power backup to access the keypad in case your Safe runs out of battery.
Offline Access Code™(OAC)
The offline access code can allow owners to issue access codes, set the allowed access duration, all
without Lockly ever connecting to the internet, so in case of power outage, you can still magically and
remotely issue Access Codes without any connection to the web.
Live Monitoring
Through your smartphone, monitor Smart Safe access from anywhere in the world and securely control
who comes and goes.
Multiple Access Codes & Monitoring
Store up to 100 Access Codes for family, friends and guests, as well as monitor entry and exit records.

2.1 Product Overview - Exterior
2
SECTION 2.1
Fingerprint
Reboot Button
Bluetooth light
OK Button
Keypad Buttons
Touchscreen
Key Hole

Battery
Compartment
Flashlight
Type-C Port
SECTION 2.23
2.2 Product Overview - Interior
Program Button
When the Safe opens, the light automatically
turns ON and OFF after 2 minutes. Touch the
keypad to turn ON the lights again.

2.3 Understanding Your Smart Safe
Understanding some key functions of operating your Smart Safe is important. The following guides
will walk you through setting the Safe, adding Access Codes, deleting Access Codes, adding and
deleting fingerprints, and how to configure your OAC (Offline Access Code™).
For any questions you can always visit https://Lockly.com/help for assistance.
Don’t forget that Lockly works best with our iOS and Android™app. Please download the app by visiting
the link below.
Scan or visit Lockly.com/app
4SECTION 2.3

SECTION 2.45
2.4 Rebooting Your Smart Safe
Reboot
NOTICE
Reboot Lockly in case of dead battery or malfunction. No settings
will be changed and all Access Codes will still be stored within
Lockly.
Press and release the reboot button when you want to reboot the Safe. Your Lockly will beep once
after reboot. Only reboot when necessary.
You will need something small such as a paperclip, to press the reboot button located on the exterior
of the safe, left of the fingerprint reader. Insert the paperclip and press down firmly and let go. Your
screen should restart and the safe should reboot automatically.

6SECTION 2.5
Type-C
2.5 Low Battery
When the battery is in seriously low condition, Lockly will make continuous beeping sounds in addition
to the flashing low battery icon on the touch screen. You should replace batteries immediately
to avoid your Smart Safe from shutting down.
When your Safe low-battery warning alert finally dies, you will have 3 chances to unlock your Safe
either by a password, APP or fingerprint. If the unlock was successful, the low-battery
warning
alert will be on for 1 minute. After which, the Safe will go to dead-battery mode and
will auto lock
in 5 seconds and the screen will display a low-battery icon.
Dead Battery
Condition Indicator Solution
Low Battery
Battery Icon on the display
keypad will light up to indicate
low battery.
Replace batteries immediately to
avoid battery failure. Lockly can still
operate up to 300 cycles in low
battery condition.
When there is no display
and sounds; and screen is
non-functional.
Your Lockly has a TYPE C USB port located at the right
exterior of the Smart Safe. Use a power bank or DC
5V USB to temporarily power up your Safe. Once the
screen lights up, enter your Access Code or scan a
registered fingerprint to unlock Safe. Once unlocked,
batteries should be replaced immediately.
Replace batteries immediately.
Supplied physical backup keys
can be used to unlock the safe.
Alternatively, use TYPE-C as shown
below to temporarily activate
the safe.

7 SECTION 2.6
2.6 Changing The Battery
Under normal use, the Lockly battery will last up to a year. Please check battery levels regularly and
change your batteries when the low battery notification is issued. For best practice, always use new
batteries by a major brand.
Open the battery compartment cover and insert four (4) new AA alkaline batteries as shown. Be sure
to unscrew the screw located on the top of the cover first by unscrewing counterclockwise before
sliding the cover up.
- Make sure the batteries are oriented correctly by matching the orientation displayed.
- Replacing the batteries do not reset stored Access Codes.
- To see a list of recommended brands, please visit http://Lockly.com/battery
NOTICE
Press the snap to remove the battery cover.
Carefully take out the battery holder and disconnect from the terminal.
Make sure you DO NOT PULL the connection cable.
Remove and/or install new 4 x AA batteries according to +/- direction.
Connect the battery holder to the terminal cable and return inside the battery box.
Return the battery cover.
1
2
3
4
- AA +
3
1 2 4
Whenever batteries are replaced, reconnecting Smart Safe to your smartphone
app is required.
If you have not yet downloaded the app, visit: Lockly.com/app

8
SECTION 3.1
3.1 Configuring Access
The Default Access Code is
NOTICE 1 2 3 4 5 6
How to Use the Keypad
There are a total of five (5) buttons on the keypad as shown in the example image above. The numbers
in each button may differ from what is shown on your device than what is displayed here.
To enter your required digit, just simply press the circle where your number is shown. You do not need
to press the actual number as anywhere within the circle will suffice.
The last button on the right is the OK button. You will be pressing this button when you are done
entering your Access Code.
We recommend pairing the Safe to your smart phone to manage your access
codes. Section 3.1 - 3.9 refers to locks not paired with a smart phone. Once paired
with a smart phone, the Program button will be disabled.
Your new Lockly Access Code can be any combination of 6 to 8 digits. Once a new Access Code
is entered, the Default Access Code of 123456 would be deleted. A maximum of 100 sets of Access
Codes can be stored for use at any given time. To add more than 100 sets of Access Codes, you
must delete an existing Access Code before adding a new code.
OK Button
NOTICE

SECTION 3.29
1 2 3 4 5 6
3.2 Entering Programming Mode
Add Access Code
and Fingerprint
ModeNumber
Delete Access Code
and Fingerprint
Bluetooth Pairing Profile
Restore Factory Settings
Check Access Code
Program Button
To enter Programming Mode, open the
Smart Safe. The programming button is
located on the rear left interior.
Quickly press the Program Button twice
to enter programming mode.
Note: Once the smartphone is connected,
1 PG Programming mode will be disabled,
Configure all settings via synced smart
phone. Access Codes previously added by
1 PG Programming mode will be cleared.
To end Programming Mode, press the Program button anytime. Programming Mode will automatically
exit if the keypad is inactive for more than thirty (30) seconds.
After entering Programming Mode, you should
see the screen as displayed to the right on
your Lockly keypad. Follow the following steps
to add, delete, or check your Access Codes.

10SECTION 3.3
3.3 Adding an Access Code
While in Programming Mode, select
“1AD” to add an Access Code. If
you are not in Programming Mode,
please see Section 3.2 to enter
Programming Mode.
After pressing “1AD” press “Pd” to
add an Access Code.
Enter your new 6 - 8 digit Access Code and press when you are finished. You will then re-enter
the code to confirm your new Access Code.
Remember, just touch the digit you need within the circle around each 3 numbers. There is no need to
touch the exact location of the number. For example, based on the example image to the left, if
you need “1”, you can touch the first button on the left. For “6”, you would touch the second
button from the left.

SECTION 3.311
3.3 Adding an Access Code (Continued)
If you have successfully entered your new Access Code twice, you will see the new code displayed
here. In this example, we chose 123456. Press to Confirm or to cancel.
To exit or cancel, you can always press or
If the two (2) Access Codes you entered does not match, an error message will appear on the
screen. Press OK to return to the Programming Screen and try again.
OK Button

12
SECTION 3.4
3.4 Deleting an Access Code
While in Programming Mode, select
“2DE” to delete an Access Code.
If you are not in Programming Mode,
please see Section 3.2 to enter
Programming Mode.
After pressing “2DE” press “Pd” to
delete an Access Code.
OK Button
Example Only
Active Access Codes will then be displayed on the screen in sequence from left to right.As shown on
the above example, the Access Code displayed is 1 2 3 4 5 6.
Scan through different Access Codes shown by touching any number on the screen. If you
find the Access Code you want to delete, simply hold the OK button for 2 seconds. (Continue on
next page)

13 SECTION 3.4
NOTICE
3.4 Deleting an Access Code (Continued)
Once you have selected the Access Code you want to delete, Lockly will ask you to confirm deletion
by showing you the Access Code you are deleting, in this example, 1 2 3 4 5 6.
Press to delete, or to cancel.
There are two incidents where your Access Code cannot be deleted.
Only one Active Access Code
No Access Codes Set
(1) There There are no Access Codes set. (2) The factory default Access Code
cannot be deleted.
There is only one (1) Access Code saved in the Safe
. At least one code must be registered. Please add
another Access Code before attempting to delete the existing code.

14SECTION 3.5
3.5 Checking the Access Codes
OK Button
While in Programming Mode, select “3CH”
to check registered Access Codes. If
you are not in Programming Mode, please
see Section 3.2 to enter Programming
Mode.
Active Access Codes will then be displayed
on the screen in sequence from left to
right. In the example shown on the
left, the Access Code displayed is 1
2 3 4 5 6 .
Scan through the different Access Codes by touching any number on the screen. To exit Check
Access Code screen, simply press the OK button.
If there are no Access Codes registered in your Smart Safe, Check Access Code mode will be invalid.
The default Access Code will not be shown on the display keypad, and you will see the screen above
instead.

SECTION 3.615
3.6 Adding a Fingerprint
Fingerprint Pattern with
Cross Intersection Lines
Concentric or Parallel Pattern
with no Cross Intersection Lines
Fingerprint with Scars or
Worn Out Ridges
OK Not OK Not OK
In this section, you will learn how to register a fingerprint to your new safe.
We are using an advanced biometric sensor, providing the most secure fingerprint authentication. For
security reasons, Lockly will only accept fingerprint patterns that consist of cross intersection points.
Patterns with no cross intersection points will not be acceptable.
Please check your fingers before registration to make sure the finger you want to register will be
acceptable by our system. Otherwise, use an alternative finger to ensure successful registration.
The following examples show which types of fingerprint patterns will be acceptable. It is highly
recommended to enroll at least one finger from each hand in case the hand you are using is
unavailable, such as, in instances like if you are holding items in that hand or have sustained an
injury.
Your Lockly Smart Safe can register up to ninety-nine (99) fingerprints. Please read the following
sections if you want to add or delete fingerprints. We recommend using your app to add fingerprints,
however, the following section can show you how to add and remove fingerprints if you did not pair
your safe with a smart phone.

16SECTION 3.6
3.6 Adding a Fingerprint (Continued)
While in Programming Mode, select
“1AD” to add an Access Code. If you
are not in Programming Mode, please
see Section 3.2 to enter Programming
Mode.
After pressing “1AD” press “FP” to
register a Fingerprint.
Upon pressing “FP”, you will enter Fingerprint Registration Mode and you will see a green LED ring light
up on the fingerprint panel on the exterior side of Lockly Smart Safe.
Once you’re in Fingerprint Registration Mode you will see two numbers displayed on keypad. The top
number is your Fingerprint Registration number, in this example above, “1”. The bottom number will always
start with a “6”.
You must successfully scan your fingerprint six (6) times for it to properly register. Every time you scan
your fingerprint, the number on the bottom will change, starting from 6 - then 5, 4, 3, 2, 1, until
the fingerprint is successfully registered.
NOTICE
For reference, please keep a record of your fingerprint registration number
to distinguish whom it was registered to.

SECTION 3.617
3.6 Adding a Fingerprint (Continued)
NOTICE
Please make sure your fingers are clean from dirt and oils before
scanning your fingerprint. Make sure the sensor is also clean by
taking a soft cloth and wiping the surface.
Scan your finger by lightly placing your designated finger on the sensor until you hear a beep. Lift
your
finger and repeat the process slowly until the digit “6” shown on the screen becomes “1”. If you have
successfully scanned and registered your fingerprint, you will hear a long beep, and the Bluetooth icon will
flash green.
PASS will show on the keypad and press OK to exit. If you did not successfully register your fingerprint,
FAIL will show on the keypad. If FAIL is displayed, press OK to return to the previous screen to rescan
your finger.
For instructions on scanning an optimal fingerprint, please proceed to Section 3.7.
OK Button
