ALWAYS PROTECTED
LIBERTYSAFE.COM
™
LIBERTY SAFE
QUICK START GUIDE
Congratulations on your purchase of your new high-quality
security safe designed and built by America’s #1 gun safe
company—Liberty Safe! To ensure proper set up and installation,
PLEASE READ THIS QUICK START GUIDE BEFORE OPENING YOUR SAFE.
Register your safe at www.LibertySafe.com. Online registration must
also be completed within (30) days of purchase. Failure to register the
product may void any warranty.
Place Serial Number
and Combination Here
INSPECTOR
QUALITY INSPECTION VERIFICATION
I have inspected this safe and found it to meet the high
standards set for this product including exterior, lock,
locking mechanism and interior.

2 3
SAFETY PRECAUTION
The safe door is heavy. Do not open the door with the safe on an uneven or unstable oor.
Hanging on an open door may cause the safe to tip forward when not lag-bolted to the oor,
resulting in serious injury or death to yourself or others. If a bolt down kit was included in
your safe, it is strongly recommended that you bolt the safe to the oor to prevent the safe
from tipping when the door is opened. If you have or have occasion to have small children in
your home, please make sure you never leave your safe unsecured. It is possible for small
children to climb inside your safe and become locked in. This could result in serious injury or death.
PACKAGING MATERIALS
After opening the safe, remove the plastic protectors or foam in the corners of the door.
INSPECT YOUR SAFE
Inspect your safe for shipping damage as soon as you receive it. If you nd any damage,
please contact the delivery company (or carrier) immediately. Any damage not noted upon
delivery must be reported within fteen (15) days or there will be no recourse. !PLEASE
NOTE: Record your safe’s serial number and combination and store in a secure location OTHER
THAN YOUR SAFE.
SERIAL NUMBER & MASTER COMBINATION (See opening instructions before proceeding)
!PLEASE NOTE: If your safe has been installed with an Electronic Lock, use the Electronic Lock
Opening Instructions before proceeding. Your safe’s serial number is in two (2) locations
on the safe. One is located on the top of the safe, back right side. The second is located
inside the opening edge of the door. Compare the serial number in this guide with the
serial number on the safe. All serial numbers should match. If they do not, contact your
local dealer or Liberty Safe immediately. You will need your safe serial number when
contacting customer service about your safe.
USING THE KEY-LOCK (DAY-LOCK) FEATURE
!PLEASE NOTE: The Key-lock will prevent the dial from being turned to open the safe.
However, to obtain the highest level of security it is recommended to lock the safe using
the combination and key-lock together rather than the key-lock alone.
Before using the key-lock feature you will need to close the door and rotate the handle
until the bolts extend into their locked position.
Step 1. Rotate the dial to the number 0.
Step 2. Insert the key and turn it 180 degrees counterclockwise until it stops (the jagged
edge of the key should be facing up).
Step 3. Remove the key and verify the safe is locked by trying to turn the handle.
NOTE: If the safe is NOT locked, try rotating the dial counterclockwise to the
number 4 and then back clockwise to 0, then repeat steps 2-3.
CHANGING COMBINATIONS ON MANUAL LOCKS
It is inadvisable for anyone other than a CERTIFIED LOCKSMITH to change the combination
on a manual lock. Changing the combination by anyone other than a certied technician
will void the lock portion of your warranty. Call your dealer or Customer Service at Liberty
Safe @ [phone] for help locating an approved locksmith. As part of our continuing
service, a record of your combination by serial number is kept on le at Liberty Safe. If
you lose your combination it can be restored to you for a $25.00 research fee provided
Liberty has been informed of any combination changes made and you have also met the
documentation requirements.
TO GET STARTED, nd the lock type below that resembles the one
installed on your safe. Then proceed to the instruction set marked
in yellow.
LOCK TYPE/MODEL
Model 6700
Dial Combination with & without Keylock
INSTRUCTION SET
Model Safelogic
TopLit & BackLit Electronic
Model Prologic
L01 Electronic
0
10
20
30
40
50
60
70
80
90
B
A
C

4 5
Step 1. Insert key, jagged edge down, into combination
dial like shown in gure 1.a. Then turn the key
clockwise 180 degrees so the jagged edge of the
key is up.
Step 2. Turn the combination dial clockwise about 45
degrees as shown in gure 1.b until the dial stops
turning. It will stop on or between the numbers ’87’
and ‘84’. (If the dial did not stop, advance to step
6.) Remove the key.
Step 3. As shown in gure 1.c, rotate the handle hub
clockwise (counterclockwise if the handle is set left
of door center) until the door comes open.
Step 4. Swing open door at least 90 degrees as shown in
gure 1.d.
Step 5. Rotate the handle hub counterclockwise as shown
in gure 1.d (clockwise if handle is set left of door
center). This will extend the locking bolts/bars so
you can test the lock while the door is open (some
models require the bolt detent (hinge side of the
door, see gure 1.e) be pressed and held in while
completing this step.)
Step 6. Locate safe combination on page 2 of this guide
and use the instructions in gure 1.f to verify the
combination works.
Step 7. If the combination dial stops between 84 – 87
you have veried your combination works.
Step 8. *Store combination OUTSIDE of safe!
Step 9. Continue to instruction set D “Remove Safe
from Pallet”.
A6700 DIAL
COMBINATION
*Skip to Step 6, if the dial on your safe
does not have a keylock in the center.
0
10
20
30
40
50
60
70
80
90
1.a
Figure 1.f
1.b
1.c
1.d
1.e
4 turns left
to 1st #
3 turns left
to 2nd #
2 turns left
to 3rd #
Turn right until
dial stops
between 84 - 87
1 2 3 4

6 7
3.c
3.d
Step 1. Enter factory set master code 1 2 3 4 5 6
Step 2. As shown in gure 2.c, rotate handle hub clockwise
(counterclockwise if handle is set left of door
center).
Step 3. Swing open door at least 90 degrees as shown
in gure 2.d.
Step 4. Rotate the handle hub counterclockwise as shown
in gure 2.c (clockwise if handle is set left of door
center). This will extend the locking bolts/bars so
you can test the lock with the door open. (Some
models require the bolt detent (underside bottom
edge of the door, see gure 2.e) be pressed and
held in while completing this step.)
Step 5. While the door is open, change the factory
set master code to something more secure by
completing the following 4 steps:
a) Enter: 000000
b) Enter: 1 2 3 4 5 6
c) Enter: New 6 digit code _ _ _ _ _ _
d) Enter: New 6 digit code again _ _ _ _ _ _
Step 6. With the door open, verify your new code opens
the lock. *Store combination OUTSIDE of safe!
Step 7. Continue to instruction set D “Remove Safe
from Pallet”.
Step 1. Enter factory set master code 1 2 3 4 5 6
Step 2. Then, within 6 seconds, rotate the handle
hub clockwise, as in shown in gure 3.b
(counterclockwise if handle is set left of door
center).
Step 3. Swing open door at least 90 degrees as shown
in gure 3.c.
Step 4. Rotate the handle hub counterclockwise as shown
in gure 3.c (clockwise if handle is set left of door
center). This will extend the locking bolts/bars so
you can test the lock with the door open. (Some
models require the bolt detent (underside bottom
edge of the door, see gure 3.d) be pressed and
held in while completing this step.)
Step 5. With the door open, change the factory set code
to something more secure by completing the
following these steps:
a) Press the Menu/OK button
b) Press “↑” or “↓” and choose System Menu
c) Press the Menu/OK button
d) Enter: 1 2 3 4 5 6
e) Press “↑” or “↓” and choose Change Code
f) Press the Menu/OK button
g) Enter: New 6 digit code _ _ _ _ _ _
h) Enter: New 6 digit code again _ _ _ _ _ _
Step 6. With the door open, verify your new code opens
the lock. *Store combination OUTSIDE of safe!
Step 7. Continue to instruction set D “Remove Safe
from Pallet”.
B C
SAFELOGIC TOPLIT &
BACKLIT ELECTRONIC
LOCKS
PROLOGIC L01
ELECTRONIC LOCK
2.a SafeLogic TopLit
3.a ProLogic L01 Lock
2.b SafeLogic BackLit
2.c
3.b
2.d
2.e

8 9
!PLEASE NOTE: Take precaution when completing these next steps. The safe is
extremely heavy! It is recommended that two or more adults work together when
removing the safe from the pallet.
Step 1. Remove side shelves and accessories from interior oor.
Step 2. Locate the lag screws that secure the safe to the pallet. Lag screws are located
in ONE of the following two areas (see next page for diagrams):
a. If the safe interior has plastic caps pressed into each corner of the carpeted
oor (see gure 4.a) remove these caps to access the lag screws.
b. If your safe interior has straps attached to the front center of the oor (see
gure 4.b), pull the straps up and lift out the oor boards. This will allow access
to the lag screws.
!PLEASE NOTE: While performing step 3, another adult must steady the safe to prevent
the safe from tipping o the pallet while removing the lag screws.
Step 3. Use a 9/16 inch socket wrench to unscrew each of the four lag screws.
Step 4. After removing all lag screws, close the door and turn the handle to prevent the
door from swinging open during step 5.
Step 5. With one person on each side of the safe as shown in gure 4.c, carefully slide
the safe o the pallet until one edge is resting on the oor. While the safe is
tilted on its edge, remove the pallet from under the safe. Carefully lower the
safe back to its upright position.
Step 6. Continue to the next instruction set “Interior and Handle Setup”.
!PLEASE NOTE: Prior to beginning this section, you should have already tested the lock.
If you experienced problems refer the troubleshooting guide in the back of the Use and
Care Manual.
Step 1. Locate the padded yellow envelope inside the safe on the oor. This package
contains the shelf clips and handle spokes. Remove the handle spokes and
screw each one into the hub as shown in gure 5.a. (If your safe has a solid
single-point handle you can skip this step. Handle may have up to 5 spokes.)
Step 2. Remove the shelf clips from envelope. Insert the top of each clip as shown in
gure 5.b at the desired shelf level. Firmly press down on the top (at side) of
the clip until the bottom of the clip snaps onto the track. Install 4 clips per shelf,
making sure each one is at the same level.
Step 3. Side shelves can be adjusted to meet your needed conguration. Locate the
shelves inside of the safe. Place each shelf on top of the previously installed
shelf clips. The style and quantity of the shelves will vary by model. See gure
5.c for examples of how your interior may look after setup.
D E
REMOVING SAFE
FROM PALLET
INTERIOR AND
HANDLE SETUP
Figure 4.a Lag Screw Cover
Figure 4.b Floor Board Removal
Figure 5.b Install shelf clips
Figure 5.a Install handle spokes
Figure 4.c Figure 5.c Interior setup
Before Setup After Setup

10 11
Step 1. Most safe models have two door adjustors for tightening or loosening the door.
These adjustors are located just inside the safe on the left doorjamb. After
removing all packaging material, close the door and extend the bolts. Pull out
on the door handle to check the tightness. If there is play in the door, you will
need to adjust the slide plate. Using the supplied hex wrench, loosen the two
(2) hex adjuster screws. Slide the adjuster left to loosen and right to tighten
the door. Retighten screws and check adjustment. When properly adjusted, you
should feel slight resistance when turning the handle to extend the door bolts.
Only slight movement should be felt with the door shut.
 Do not adjust door too tight. This may cause wear on both the door pins
and locking mechanism. If your door has a tendency to self-open (the bolts retract by
themselves) or the handle is hard to turn when extending the bolts, the door adjusters
may be too tight.
PLEASE NOTEConcrete anchor kits are sold separately and can be purchased
only at libertysafe.com or through your local Liberty Safe dealer.

– Hammer Drill
– ½"Socket Set
– Shop Vacuum
– Hammer
Step 1. Remove safe from pallet (refer to section D for instructions) and place safe in
desired location.
a. NOTE: leave oorboards/caps removed, as you will be using these four
anchor points
Step 2. Drill a hole in each of the four anchor points with a hammer drill using a ⅜"
concrete drill bit. Drill the holes approximately 3"deep.
Step 3. Use vacuum to clean up debris creating by drilling the holes.
Step 4. Hammer the anchor bolts into the holes and tighten using a ½"inch socket set.
Step 5. Replace oor caps/oor panels.
F G
DOOR
ADJUSTMENT
INSTALLING
CONCRETE ANCHORS
SLIDE-PLATE
ADJUSTER
PN 10915
 To achieve the highest level of security
and safety possible, anchor your safe securely to the
oor. We recommend placing a protective barrier
(such as a piece of carpet, treated wood or rubber
mat) between the safe and oor to prevent scratching
of the safe surface, which could lead to rust. Before
anchoring safe, make sure the safe is level. Use
appropriate hardware for the wood or cement surface
you are anchoring to. Securing it to the oor helps
secure and prevent removal of the safe by thieves.
PLEASE NOTE: If a bolt down kit was included in
your safe, it is strongly recomended that you bolt
the safe to the oor to prevent the safe from tipping
when the door is opened.

12 13
PLEASE NOTEWood anchor kits are sold separately and can be purchased
only at libertysafe.com or through your local Liberty Safe dealer.

– Drill
– 9/16"Socket Set
– Shop Vacuum
Step 1. Remove safe from pallet (refer to section D for instructions) and place safe in
desired location.
a. NOTE: leave oorboards/caps removed, as you will be using these four
anchor points
Step 2. Drill a hole in each of the four anchor points with a drill using a ¼"wood drill
bit. Drill holes approximately 3"deep.
Step 3. Use vacuum to clean up debris creating by drilling the holes.
Step 4. Place provided washers on provided wood bolts and secure them using a 9/16"
socket set or drill.
Step 5. Replace oor caps/oor panels.
MANUAL LOCKS
It is recommended that you have your manual lock serviced annually by a certied lock
technician to maintain trouble-free service. Electronic locks do not require this service.
LOCKING PINS/BARS – Once per year extend the bolts and wipe a small amount of
lubricating oil or Vaseline along the bottom of the middle most (2nd, 3rd, or 4th bolt
down) bolt on the hinge and open side of the door.
INTERNAL LOCKING MECHANISM – The advanced locking mechanism requires no
maintenance. Opening the door panel of your safe by anyone other than a certied lock
or safe technician may void your warranty.
EXTERIOR – Use a soft, non-abrasive cloth dampened with water to clean the surface
of a gloss, powder coat or textured nish safe. Other materials may cloud or scratch the
nish of your safe:
– Logos and other graphic images must be wiped gently. Never rub or polish
– The lock and handle have a protective coating to prevent tarnish. DO NOT use metal
polishes or solvents for cleaning. Simply wipe o with a soft cloth.
– Scratches and other blemishes may be touched up with a paint touch up kit
available from your dealer.
FIRE SEAL – The re seal does not need maintenance unless it is ripped or destroyed.
SAFETY PRECAUTIONSBefore moving you safe, make sure you have completely
tested the combination and lock to assure it will open properly prior to removing
the safe from the pallet and to its nal location. Safe doors are NOT designed to be
removed due to possible serious injury. Never move the safe with the door open. Do
not open the door with safe lying down. The safe’s door should never be removed.
Removing the safe door will void the warranty on your safe. Safes are very heavy and
awkward to handle. Only use of proper moving equipment by a trained professional
is recommended. Using a standard refrigerator dolly is very dangerous and can cause
injury or death.
H I
INSTALLING WOOD
ANCHORS
CLEANING AND
MAINTAINING YOUR SAFE
PN 10914
 To achieve the highest level of security
and safety possible, anchor your safe securely to the
oor. We recommend placing a protective barrier
(such as a piece of carpet, treated wood or rubber
mat) between the safe and oor to prevent scratching
of the safe surface, which could lead to rust. Before
anchoring safe, make sure the safe is level. Use
appropriate hardware for the wood or cement surface
you are anchoring to. Securing it to the oor helps
secure and prevent removal of the safe by thieves.
PLEASE NOTE: If a bolt down kit was included in
your safe, it is strongly recomended that you bolt
the safe to the oor to prevent the safe from tipping
when the door is opened.

14 15
LIBERTY SAFE AND SECURITYPRODUCTS, INC. LIMITED WARRANTY
Limited Lifetime Warranty: Liberty Safe and Security Products, Inc. (Liberty) is proud of the workmanship of the product you have just purchased.
Liberty warrants that each new safe will be free from defects in material and workmanship for the lifetime of the original purchaser (Purchaser). If
there is a defect in either materials or workmanship of a warranted safe during the lifetime of the original purchaser, Liberty will repair or replace the
safe. Liberty will also repair or replace any warranted safe that is damaged during a re (other than by arson committed by Purchaser, a member of
Purchaser’s family, or someone instructed or authorized by Purchaser or a member of Purchaser’s family), illegal and/or unauthorized break-in, or
an illegal and/or unauthorized attempted break-in, if a homeowner’s insurance policy will not cover the damage, during the lifetime of the original
purchaser. Liberty’s obligation under the limited lifetime warranty is limited to repair or replacement of the safe or product itself,
AND DOES
NOT EXTEND TO THE CONTENTS OF THE SAFE.
This limited lifetime warranty does not include the lock and painted surface, or electrical items (see
separate limited warranties below), and is subject to the following terms, conditions, and limitations:
Cost to Purchaser:
Inside United States: Liberty’s limited lifetime warranty is at no cost to the Purchaser, including labor and shipping.
Inside Canada: Liberty’s limited lifetime warranty is at no cost to the Purchaser, except that Purchaser is responsible for all freight charges if a
safe is replaced.
Outside of the United States & Canada: Liberty will provide replacement parts of like type and function for the safe at no cost to the purchaser.
However, any and all labor, repair, or service costs will be the responsibility of Purchaser, and Purchaser is responsible for all freight charges if
a safe is replaced.
Lock and Painted Surface Limited Warranty: Locks and painted surfaces are warranted to be free from defects in workmanship and materials
for a period of ve (5) years from the date of purchase. Within this ve year period Liberty will repair and/or replace parts of like kind and type
at no cost to the Purchaser, except that outside the United States and Canada, Liberty will provide replacement parts of like kind and type at no
cost to purchaser, but Purchaser will be responsible for any and all labor, repair, or service costs.
Electrical Items Limited Warranty: Light xtures, transformers, cords, and light switches are warranted to be free from defects in workmanship
and materials for a period of one (1) year from the date of purchase. Within this one-year period Liberty will replace parts of like kind and type
at no cost to the Purchaser. Purchaser will be responsible for any and all labor, repair, or service costs.
Proper Use for Intended Purpose: Liberty takes seriously its obligation to stand behind its product with this Limited Warranty as long as the
safe is properly installed and cared for as instructed in the Owner’s Use and Care Manual. This Limited Warranty does not apply to safes or parts
that have been misused, neglected or subjected to unusual or extreme conditions and/or environments, or to unreasonable wear and tear.
Changing or modifying the safe in ways that aect its intended use will void this Limited Warranty. FOR OPTIMAL SECURITYAND PROTECTION,
SAFES SHOULD BE BOLTED TO THE FLOOR. PLEASE REFER TO THE USE & CARE MANUAL FOR DETAILS ON ANCHORING YOUR SAFE TO THE FLOOR.
Warranty Registration: For this Limited Warranty to be valid, online registration MUST be completed within (30) days of purchase. Failure to
register the product shall void any warranty.
Warranty Claims: Claims shall be made under this Limited Warranty by calling 800-247-5625 or writing to Liberty Safe and Security Products,
1199 West Utah Avenue, Payson, Utah 84651. Any claims made for re, break-in or break-in attempts must be accompanied by a copy of your
homeowner’s insurance statement of coverage, and a report made by the police or re department. A claim must be made within six months of
the re, break-in, or attempted break-in.
Venue and Choice of Law: Any claims arising from this limited warranty shall be resolved in the State of Utah and Utah law will apply to any dispute.
No Other Warranties: This Limited Warranty is understood to be the complete and exclusive agreement between the parties, superseding all
prior warranties or agreements, oral or written, and all other communications between the parties relating to the subject matter of this Limited
Warranty. No employee of Liberty or any other party is authorized to make any warranty in addition to those made herein.
Limitation of Remedies: In no case shall Liberty be liable for any punitive, special, indirect, incidental, or consequential damages based upon
breach of warranty, breach of contract, negligence, strict tort, or any other legal theory relating to the subject matter of this Limited Warranty.
Such damages include, but are not limited to, loss of prots, loss of savings or revenue, loss of the contents of the safe or vault door, loss of
use of the safe or vault door, or any associated equipment, cost of capital, cost of any substitute equipment, facilities or services, downtime,
the claims of third parties including customers, and injury to property. Liberty’s maximum liability for any damages based upon breach of
warranty, contract, tort, statute, or otherwise relating to the subject matter of this Limited Warranty, shall be limited to the cost of the safe paid
by the Purchaser.
TO THE FULL EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY IS EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. ANYWARRANTIES IMPLIED BY LAW SHALL IN NO EVENT
EXTEND BEYOND DURATION OF THIS LIMITED WARRANTY. IN NO EVENT SHALL THIS LIMITED WARRANTYBE DEEMED TO COVER ANY PUNITIVE,
SPECIAL, INDIRECT, INCIDENTIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND ARISING OUT OF THE PURCHASE OR USE OF THIS PRODUCT, WHETHER
BASED UPON THIS WARRANTY, CONTRACT, TORT, STATUTE OR OTHERWISE. THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTYLASTS, SO THE ABOVE LIMITATION MAY NOTAPPLY TO YOU.
Your safe is now ready to protect your valuables. For additional
instructions a full Use & Care Manual can be downloaded from
our website www.libertysafe.com/ownersmanual.php. If you
experienced a problem, you can consult the troubleshooting guide
within the Use & Care Manual online. For additional online help visit
www.libertysafe.com/services.php or contact customer service by
phone [phone]. Support is available Mon-Fri, 8:00am to
5:00pm Mountain Standard Time. You will need your safe serial
number when contacting customer service about your safe.
LOST COMBINATION OR KEYS
The lock on your safe has been set with a randomly selected combination at the time
of manufacturing. As part of our continuing service, a record of your combination by
serial number is kept on le. To help us better serve you, please contact Customer
Support at [phone] when you change your combination or code. If you
lose your combination, you can retrieve a copy for a $25.00 research fee, provided
you have not changed it from the original combination. You must complete certain
security and documentation requirements. If you lose your keys you can obtain
duplicate for $5.00 each key, plus $5.00 shipping and handling.
Go to www.libertysafe.com to download a combination/duplicate key request form.
JLIBERTY SAFE
WARRANTY

16
ALWAYS PROTECTED
LIBERTYSAFE.COM
™
REV 7.15.19 LIBERTY SAFE & SECURITY PRODUCTS, INC. P/N: 16517
