LockNet Sur-Lock I/O 2000L Series User manual

HANDING of UNIT
IS
FIELD REVERSIBLE
Refer to both sides of this sheet or
Appendix A of the Installation
Instructions
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
1. Remove the Battery Bracket Assembly and the Lock Bolt Housing Assembly (both are held on
with 2 screws).
Battery Bracket
Assembly
Lock Bolt
Housing
Assembly

. . . Continued
2. Remove the Cotter Pin and Washers
that secure the Lock Bolt Rod to
the top post on the Pivot Plate.
3. Remove the Lock Bolt Rod and reinstall it through the opening on the opposite side, securing it
to the bottom post on the Pivot Plate using the
Washers and Cotter Pin.
4. Reinstall and secure the Battery Bracket Assembly and
the Lock Bolt Housing Assembly on the opposite side of
the unit from where they were originally installed.
5. Reposition the clip that secures the battery wires to the
unit, using caution so as to not pull the battery wires
out of the Alarm Board. The clip should be positioned
on the same side as the Battery Bracket Assembly. If
the Battery Bracket Assembly’s location is now on the
left of the unit, route the battery wires below the Alarm.
6. If the Battery Bracket Assembly is located on the left side of the unit,
route the battery wires through the metal channel and up to the battery.
Part # 14000003 (Revised 020819)
