LockUP LockUp M User manual

Operate with an Assigned User Code
The ADA User Key is designed to be used by persons with disabilities and is 100% ADA Compliant.
Operate with an Assigned ADA User Key
OPERATING GUIDE
ASSIGNED USE FUNCTIONALITY with LATCH
M
FUNCTION
LOCK
Lock Interface Overview
1 2 3
4 5 6
7 8 9
C 0
C Button Key Symbol Button
Key Slot LED Indicator
Green
Numeric
Keypad
Integrated Pull Handle
• Provides management access
• Provides external power
• Up to 25 keys may be registered
to each lock
Manager Key (Black)
• ADA Compliant User Key
ADA User Key (Blue)
• Registers Manager Key(s)
• Provides external power
• 1 Required Per Location
Programming Key (Yellow)
1) Press: = (assigned 4-digit user code) `
2) Open the door.
To Unlock
The latch will
retract emitting a
double beep and
single LED ash.
1) Touch an assigned ADA User Key to key slot.
2) Open the door.
To Unlock
The latch will
retract emitting a
double beep and
single LED ash.
You may close the door at any point.
To Lock
After 5 seconds
the latch will
automatically
extend.
You may close the door at any point.
To Lock
After 5 seconds
the latch will
automatically
extend.
Note: After three consecutive incorrect user code entries, the lock will go into “Sleep State” for one minute or
until a registered Manager Key is used to operate the lock.

1) Press: =`2) Touch the Programming Key to key slot.
3) Open the door.
To Unlock
The latch will
retract emitting a
double beep and
single LED ash.
To Operate with a Manager Key
To Operate with a Programming Key
secu rity si mplif ied™
Digilock Lockup Celáre Numeris
security people
inc
Via email: [email protected]
Phone: [phone]
Fax: [phone]
For additional product information including instructional videos please visit us online at: www.lockup.com
LockUp ®
9 Willowbrook Court
Petaluma, CA 94954 1/31/13
To Unlock
1) Touch a registered Manager Key to key slot.
2) Open the door.
The latch will
retract emitting a
double beep and
single LED ash.
To Lock
You may close the door at any point.
After 5 seconds
the latch will
automatically
extend.
To Lock
You may close the door at any point.
After 5 seconds
the latch will
automatically
extend.

Lock Interface Overview
1 2 3
4 5 6
7 8 9
C 0
C Button Key Symbol Button
Key Slot LED Indicator
Green
Numeric
Keypad
Integrated Pull Handle
• Provides management access
• Provides external power
• Up to 25 keys can be registered per lock
Manager Key (Black)
• Registers Manager Key(s)
• Provides external power
• 1 Required Per Location
Programming Key (Yellow)
• 100% ADA Compliant
• Designed for persons with disabilities
ADA User Key (Blue)
PROGRAMMING GUIDE
ASSIGNED USE FUNCTIONALITY with LATCH
M
FUNCTION
LOCK
Note: The lock will accept only one ADA User Key at a time.
Assign or Change the User Code using Manager Key
Assign an ADA User Key
Assign or Change the User Code using Existing User Code
NOTE: Default user code is 1 2 3 4 once initialized.
2
a) Enter: [new 4-digit user code] `
b) Repeat: [enter the same 4-digit user code] `
Lock will emit a two
tone beep and the LED
will turn off.
2
a) Enter: [new 4-digit user code] `
b) Repeat: [enter the same 4-digit user code] `
Lock will emit a two
tone beep and the LED
will turn off.
1
a) Press: =` (the LED will turn solid)
b) Enter: [existing 4-digit user code]
The LED will turn solid.
1
a) Press: =`
b) Touch a registered Manager Key to key slot.
The LED will turn solid.
1
a) Press: =`
b) Touch a registered Manager Key to key slot.
The LED will turn solid. 2
Touch an ADA User Key to key slot.
Lock will emit a
two tone beep
and the LED will
turn off.

secu rity si mplif ied™
Digilock Lockup Celáre Numeris
security people
inc
Via email: [email protected]
Phone: [phone]
Fax: [phone]
For additional product information including instructional videos please visit us online at: www.lockup.com
LockUp ®
9 Willowbrook Court
Petaluma, CA 94954 1/31/13
Register Manager Key(s)
Press: = ` 55 `
LED will ash.
1
Touch each Manager Key to the lock one at a time.
(Up to 25 Manager Keys)
A single beep will be heard per key indicating acceptance.
3
Touch the Programming Key to key slot.
The LED will turn solid.
2
Touch the Programming Key to key slot until a two tone
beep is heard and the LED turns off.
4
Express Registration
Touch the Programming Key to key slot.
A two tone beep will be heard & the LED will turn off.
2
4
You must operate the lock with a Programming Key
once to end or exit out of the Express Registration
process.
Touch the Programming Key to the key slot of all locks to be
programmed.
At each lock, a two tone beep will be heard & the LED will ash
once to indicate successful programming.
3
Once you program one lock with Manager Key(s), you can transfer it to all the other locks with one touch.
Press: = ` 66 `
LED will ash.
1Go to the lock that has
been programmed with
Manager Key(s).
