LOFTNESS 51CCH User manual

Model Number:
Serial Number:
Date of Purchase:
Carbide Cutter
51CCH • 61CCH • 71CCH
Owner’s Manual and Parts Book
(Originating w / Serial Number 42-751)
N28364 09.26.14

LOFTNESS SPECIALIZED EQUIPMENT, INC.
WARRANTY POLICY
The warranty policy begins upon delivery of the unit to the original customer.
All Loftness products have a one (1) year warranty policy.
If any Loftness product is used as rental equipment, the warranty period extends for only 30 days from the
delivery date to the original customer.
Loftness Specialized Equipment, hereinafter referred to as LOFTNESS, a manufacturer of quality machinery since
1956, warrants new LOFTNESS machinery and/or attachments at the time of delivery to the original purchaser,
to be free from defects in material and workmanship when properly set up and operated in accordance with the
recommendations set forth in the LOFTNESS Operator’s Manual.
LOFTNESS’ liability for any defect with respect to accepted goods shall be limited to repairing the goods at an
authorized dealer or other LOFTNESS designated location, or replacing them as LOFTNESS shall elect. The above
shall be in accordance with LOFTNESS warranty adjustment policies. This warranty shall not apply to any machine
or attachment which shall have been repaired or altered outside the LOFTNESS factory or authorized LOFTNESS
dealership or in any way so as in LOFTNESS’ judgment, to affect its stability or reliability, nor which has been subject
to misuse, negligence or accident, nor to any machine or attachment which shall not have been operated in accordance
with LOFTNESS’ printed instructions or beyond the company recommended machine rated capacity.
WARRANTY REQUIREMENTS
Warranty registration form must be lled out and returned to Loftness Specialized Equipment to validate all
future warranty claims.
LIMITATIONS OF WARRANTY
LOFTNESS products are designed to provide years of dependable service when proper use and maintenance is
adhered to. The potential for misuse in many applications exists, therefore a limited warranty is provided as follows:
Auger wear is considered a maintenance item, and its life is dependant on the material being conveyed. Tires are
warranty of the manufacturer of the tire.
To receive a warranty claim, a return authorization from LOFTNESS must be obtained. The failed part may then be
returned in an untampered status. This warranty does not include freight or delivery charges incurred when returning
machinery for servicing. Dealer mileage, service calls and pick-up/delivery charges are the customer’s responsibility.
EXCLUSIONS OF WARRANTY
Except as otherwise expressly stated herein, LOFTNESS makes no representation or warranty of any kind, expressed
or implied, and makes no warranty of merchantability in respect to its machinery and/or attachments and makes no
warranty that its machinery and/or attachments are t for any particular purpose. LOFTNESS shall not be liable for
incidental or consequential damages for any breach of warranty, including but not limited to inconvenience, rental
or replacement equipment, loss of prots or other commercial loss. Upon purchase the buyer assumes all liability, all
personal injury and property damage resulting from the handling, possession or use of the goods by the buyer.
No agent, employee, or representative of LOFTNESS has any authority to bind LOFTNESS to any afrmation,
representation or warranty concerning its machinery and/or attachments except as specically set forth herein.
April 2009

650 South Main Street
Hector, MN 55342 USA
loftness.com 320-848-6266
US & Canada 800-828-7624 TM
International: 320-848-6266 Fax: [phone] Parts Fax: [phone] E-mail: inf[email protected] Web Address: www.loftness.com
WARRANTY REGISTRATION
Dealer No.:
Dealer Name:
Shipping Address:
Mailing Address:
City: State: Zip:
City:
County:
Phone: Month Day Year
Warranty (Delivered) Date
State: Zip:
Invoice No.:
Model No.: Serial No.:
Part No.:
Dealer Phone:
PLEASE
PRINT
FOLLOWING INFORMATION MUST BE FILLED IN COMPLETELY FOR WARRANTY:
DEALER PURCHASER
Customer:
Last Name:
The machine was properly set up, adjusted and inspected
before delivery. The following items were explained to the
purchaser.
* How to operate machine properly as shown in the owner’s
manual.
* The importance of safety precaution, safety equipment
and preventative maintenance.
* Loftness Warranty for this machine.
I have received and reviewed the operator’s manual for the
above machine and understand the proper and safe operation
as well as the applicable warranty outlined therein.
A customer’s manual is included with each machine.
The unit was delivered to me in satisfactory condition.
First
Mailing Address:
Middle Initial
Dealer’s Signature
Date
x
Purchaser’s Signature
Date
x
Customer Copy

650 South Main Street
Hector, MN 55342 USA
loftness.com 320-848-6266
US & Canada 800-828-7624 TM
International: 320-848-6266 Fax: [phone] Parts Fax: [phone] E-mail: inf[email protected] Web Address: www.loftness.com
WARRANTY REGISTRATION
Dealer No.:
Dealer Name:
Shipping Address:
Mailing Address:
City: State: Zip:
City:
County:
Phone: Month Day Year
Warranty (Delivered) Date
State: Zip:
Invoice No.:
Model No.: Serial No.:
Part No.:
Dealer Phone:
PLEASE
PRINT
FOLLOWING INFORMATION MUST BE FILLED IN COMPLETELY FOR WARRANTY:
DEALER PURCHASER
Customer:
Last Name:
The machine was properly set up, adjusted and inspected
before delivery. The following items were explained to the
purchaser.
* How to operate machine properly as shown in the owner’s
manual.
* The importance of safety precaution, safety equipment
and preventative maintenance.
* Loftness Warranty for this machine.
I have received and reviewed the operator’s manual for the
above machine and understand the proper and safe operation
as well as the applicable warranty outlined therein.
A customer’s manual is included with each machine.
The unit was delivered to me in satisfactory condition.
First
Mailing Address:
Middle Initial
Dealer’s Signature
Date
x
Purchaser’s Signature
Date
x
Loftness Copy

Carbide Cutter OM
Table of Contents
Warranty
Table of Contents
Ordering Code
Ordering Code ...............................................................1
Carbide Cutter (Example) ...................................................1
Introduction
Owner Information ............................................................3
Warranty Policy ..............................................................3
Serial Number Location ........................................................3
Manual Storage ..............................................................3
Carbide Cutter Features .......................................................4
Carbide Cutter Options ........................................................4
Safety Instructions
Safety First ..................................................................5
Owner’s Responsibility ........................................................5
Mandatory Shut-Down Procedure .............................................6
Safety Rules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Hydraulic Safety ...........................................................7
Carbide Cutter Identification ....................................................8
Safety Decal Locations ........................................................9
Set-up Instructions
Installing the Carbide Cutter to the Loader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Checking Rotor Rotation ......................................................14
Checking Rotor Speed ........................................................14
Pusher Bar Adjustment .......................................................15
Adjusting the Support Stands ..................................................15
Skid Adjustment .............................................................16
Rotor Locking Pin Installation ..................................................16
Operating Instructions
Getting Started ..............................................................17
Operation ..................................................................17
Log Moving ................................................................18
Maintenance
General Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Maintenance Schedule .......................................................19
Lubrication .................................................................20
Grease Point Location .....................................................20
Overhung Load Adapter ....................................................21
Belt Adjustment .............................................................22

Carbide Cutter OM
Table of Contents
Maintenance (Cont'd)
Tooth Removal and Installation .................................................23
Double Tooth & Double Planer ...............................................23
Quadco Teeth ............................................................23
Tooth Sharpening (Quadco Option Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Storage ...................................................................24
End of Season ...........................................................24
Beginning of the Season ...................................................24
Motor & Sheave Selection Chart ................................................25
Troubleshooting .............................................................26
Parts Identification
Carbide Cutter Drive Assembly .................................................28
Carbide Cutter Body Assembly .................................................30
Carbide Cutter Body Assembly (Cont'd) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Carbide Cutter Body Assembly (Cont'd) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Motor Assembly #530 Open (N28409). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Motor Assembly #630 Closed (N28410) ..........................................38
Motor Assembly #933 Open 15 Bar (N28472) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Motor Assembly #1033 Closed 15 Bar (N28500). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Motor Assembly, VOAC 60 (N20840) ............................................44
Overhung Load Adapter (N20901) ...............................................45
Variable Motor Assembly, 15 Bar (N28205) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Hydraulic Hose Assembly (N28471) .............................................47
Belt Tensioner (N28018) ......................................................48
Motor Shield W / Gauge (N15974). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Rotor (W / Double Carbide Teeth) 51" (N20083), 61" (N20077), 71" (N20080) . . . . . . . . . . . . .50
Rotor (W / Carbide Planer Teeth) (Optional) 51" (N20576), 61" (N20575), 71" (N21906) . . . . .51
Rotor (W / Quadco Planer Teeth) (Optional) 51" (N24689), 61" (N28165), 71" (N28168) . . . . .52
Tooth Assembly, Quadco Planer (N24281) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Rear Cutter Bar 51" (N20282), 61" (N20281), 71" (N21908) . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Machine Decals and Signs ....................................................55
Appendix
Specifications ...............................................................59
Dimensions ................................................................60
Torque Specifications .........................................................61
Inches Hardware and Lock Nuts .............................................61
Metric Hardware and Lock Nuts ..............................................62

1Carbide Cutter OM
SIZE
51 = 51" Cut
61 = 61" Cut
71 = 71" Cut
TYPE
CC = Carbide Cutter
H = Hydraulic
CUTTERS
S = Standard Double Carbide
P = Planer Double Carbide
Q = Quadco Planer
MOTOR SYSTEM
530 = Fixed Displacement Open
630 = Fixed Displacement Closed
933 = Variable Displacement 15 Bar Open
1033 = Variable Displacement 15 Bar Closed
SHEAVES / BELT COMBO
F = 8.5 / 9/75 63"
H = 8.0 / 10.3 63"
J = 9.0 / 9.75 63"
THRESHOLD SETTING
0 = Fixed Displacement
1 = 2175 PSI - Variable Displacement
2 = 2900 PSI - Variable Displacement
3 = 3400 PSI - Variable Displacement
Ordering Code
Ordering Code
Carbide Cutter (Example)
The ordering code will consist of two numbers (machine size), three letters (machine type), one letter (cutter type), three
numbers (motor system), one letter (sheaves / belt combo), one number (threshold setting), and two letters (options). An
example for a carbide cutter of this type would be as shown below.
61CCHS530H0

2 Carbide Cutter OM

3Carbide Cutter OM
Owner Information
Thank you for your decision to purchase a Carbide Cutter
from Loftness. To ensure maximum performance of your
machine, it is mandatory that you thoroughly study the
owner’s manual and follow its recommendations. Proper
operation and maintenance are essential to prevent injury
or damage and to maximize machine life.
The Loftness Carbide Cutter is an effective, reliable
machine used for maintaining grass, weeds, brush and
trees. Efficiently cuts and mulches up to 6" diameter
material. Intermittently cuts larger diameter material. For
best results, operate the machine as low to the ground
as possible without the teeth striking ground or other
obstructions. Lifting or tilting the shredder increases the
risk of flying debris. Because of the high speed of the
teeth, the life of the teeth will be reduced if it is operated
in rocky terrain or in areas where many obstacles are
present. Areas to be mowed should be free of debris
such as rocks, bottles, large branches etc. The teeth cut
and pulverize the grass, weeds and brush. The shredder
deposits cut material over the entire width-of cut, which
eliminates bunching or windrowing behind the machine.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws, and in compliance with
on-product labeling and these instructions.
Make sure that all personnel have read this owner’s
manual and thoroughly understand safe and correct
operating, installation and maintenance procedures.
Continuous improvement and advancement of Loftness
products may result in changes to your equipment that
may not be reflected in this publication. Loftness reserves
the right to make product improvements to the machine at
any time. Although great care has been taken to ensure
the accuracy of this publication, Loftness does not
assume any liability for errors or omissions.
Warranty Policy
Be sure to read and understand the Warranty Policy at
the beginning of this manual. It is also important that you
fill out the Warranty Registration form(s) completely with
your dealer so as not to void the warranty.
Serial Number Location
NOTE: Pusher bar arm has been removed for picture
clarity.
The arrows above indicate the location of the serial
number tag (1) and the location of the serial number
stamped into the frame (2).
Always use your model and serial number when
requesting information or when ordering parts.
Manual Storage
Keep the owner’s manual and the entire documentation
packet in the storage compartment provided on your
Carbide Cutter. The owner’s manual must be available
for all operators.
Introduction
1
2

4 Carbide Cutter OM
Introduction
Carbide Cutter Features
• Downward Rotation Design
• Premium Strength Steel Body & Rotor
• Front Mounted
• Hydraulic Driven
• Universal Skid-Steer Mount
• Adjustable Tree Pusher
• Claw Hooks On Tree Pusher
• 17 In. (43 cm) Diameter Rotor (1600 - 2150 RPM)
• 2 3/16 In. (56 mm) Rotor Bearings
• Anti Wrap Bearing Protection
• Heavy Duty Bearing Block
• Fixed Or Variable Displacement Piston Type Motor
• Dual Cross-Over Relief Protection
• Pressure Gauge
• Steel Chain Deflectors
• Four (4) - Groove Banded Belt
• Tapered-Lock Sheaves
• Spring-Loaded Belt Tensioner
• Skid Shoes - Adjustable 1 - 3 in. (25.4 - 76.2 mm)
• Hydraulic Hoses and Hose Holder
• Shear Bar
Carbide Cutter Options
• Carbide Planer Teeth
• Quadco Planer Teeth (Sharpenable)

5Carbide Cutter OM
Safety First
In the owner’s manual and on decals used on the
machine the words DANGER, WARNING, CAUTION,
IMPORTANT, and NOTE are used to indicate the
following:
DANGER: This word warns of immediate hazards which,
if not avoided, will result in severe personal injury or
death. The color associated with Danger is RED.
WARNING: This word refers to a potentially hazardous
situation which, if not avoided, could result in severe
personal injury or death. The color associated with
Warning is ORANGE.
CAUTION: This word refers to a potentially hazardous or
unsafe situation that, if not avoided, may result in minor
or moderate injury. It may also be used to alert against
unsafe practices. The color associated with Caution is
YELLOW.
IMPORTANT: Highlights information that must be heeded.
NOTE: A reminder of other related information that needs
to be considered.
If Safety Decals on this machine are ISO two panel
pictorial, decals are defined as follows:
• The first panel indicates the nature of the hazard.
• The second panel indicates the appropriate
avoidance of the hazard.
• Background color is YELLOW.
• Prohibition symbols such as and STOP if used,
are RED.
Be certain all machine operators are aware of the
dangers indicated by safety decals applied to the
machine, and be certain they follow all safety decal
instructions. Contact Loftness for safety decal
replacement.
Loftness cannot anticipate every possible
circumstance that may involve a potential hazard. The
warnings in this owner’s manual are not all inclusive.
Owner’s Responsibility
Due to the potential danger of flying debris, it is the owner’s
responsibility and is “ABSOLUTELY MANDATORY that
IMPACT-RESISTANT SHIELDING” be installed on the
machine to protect the operator.
It is ABSOLUTELY MANDATORY that all personnel read
and follow all safety precautions before operating the
machine and attachment.
Make sure that all personnel have read this owner’s
manual, and thoroughly understand safe and correct
installation, operation, and maintenance procedures.
Operate and maintain this machine in a safe manner and
in accordance with all applicable local, state, and federal
codes, regulations and/or laws; and in compliance with
on-product labeling and this owner’s manual instructions.
Make sure that all personnel know how to stop the
machine and attachment by disengaging all controls. See
“Mandatory Shut-Down Procedure” on page 6.
Make sure the attachment is installed on the machine
correctly before being placed in service. At regular
intervals thereafter, the attachment should be serviced
in accordance with procedures outlined in this owner’s
manual.
Safety Alert Symbol
This message alert symbol identifies
important safety messages on the machine
and in the owner’s manual. When you see
this symbol, be alert to the possibility
of personal injury and carefully read the
message that follows.
Safety Instructions

6 Carbide Cutter OM
Mandatory Shut-Down Procedure
• Stop the machine and attachment on a level surface
and lower the attachment to the ground.
• Move throttle to idle position.
• Disengage all power to the attachment.
• Shut off engine and remove the key.
Wait until the rotor has stopped completely before
inspecting the attachment.
Safety Rules
These are general safety considerations. Additional
precautions may be necessary to operate your
machine in a safe manner. Be certain you are operating
your machine in accordance with all safety codes,
OSHA rules and regulations, insurance requirements
and local, state, and federal laws.
• Read and observe all warnings decals on the machine
before attempting to operate the attachment. Do not
attempt to operate this attachment unless all factory
devices and decals are in place. Keep safety decals
clean of dirt and grime. Keep all guards, shields and
decals in place.
• Remove from area of operation all foreign objects
such as bottles, rocks, wire, etc., that might become
tangled in the rotor, causing damage to the machine
or be thrown striking other objects.
• Do not allow any people and animals within 300 feet
of the machine and attachment during operation.
• Do not allow anyone to operate the attachment
until he or she has read the owner’s manual and is
completely familiar with all safety precautions. Keep
the work area clear of all unauthorized personnel.
• Do not allow persons under the influence of alcohol,
medications, or other drugs that can impair judgment
or cause drowsiness to operate or maintain the
machine.
• Always use an approved roll bar and seat belt for
safe operation. Overturning a machine without a roll
bar and seat belt can result in injury or death.
• Use the handholds and step plates when getting on
and off the machine to prevent falls. Keep steps and
platform cleared of mud and debris.
• Always have an operator in the machine while the
attachment is in operation. Never leave the machine
and attachment running and unattended.
• Operate the attachment only from the operator’s
seat.
• Keep your feet on the pedals, (floor plates) seat belt
fastened snuggly and seat bar lowered, (if equipped),
when operating the attachment.
• The adjustable push bar could contact the machine
in some positions. Before starting the power unit, set
the push bar in the most forward position, then slowly
rotate the attachment back while an assistant checks
for clearance. Repeat this process in the other
settings to determine which positions are usable with
your machine.
• Never attempt to make any adjustments while
the attachment is running or the key is in the “ON”
position in the machine. Before leaving the operator’s
position, disengage power to the attachment, shut off
engine and remove ignition key.
• Disengage auxiliary hydraulics and place all machine
controls in neutral and engage the parking brake
before starting the engine.
• Become familiar with and know how to operate all
safety devices and controls on the machine and
attachment before attempting to operate. Know how
to stop the machine and attachment before starting it.
• Repeated impact of the knives with hard objects can
cause excessive wear and damage to the skid-steer
or attachment. Be sure to maintain recommended
ground clearance as specified in this manual.
• Should excessive vibration occur, disengage the
auxiliary hydraulics immediately and shut off engine.
Do not continue to operate the attachment until the
problem has been determined and corrected.
• Do not start, operate, or work on this attachment until
you have carefully read and thoroughly understand
the contents of this manual and the operator’s
manual for your machine.
Safety Instructions

7Carbide Cutter OM
• Keep children, bystanders and other workers off
and away from the machine and attachment during
operation. No riders allowed.
• Before inspecting, cleaning, lubricating, adjusting
or servicing any part of the attachment, always
exercise the Mandatory Shut-Down Procedure. See
“Mandatory Shut-Down Procedure” on page 6. After
service has been performed, be sure to restore all
guards, shields and covers to their original position.
• Make sure the operator’s area is clear of any
distracting objects. Keep work areas clean and free
of grease and oil to avoid slipping or falling.
• Make sure all controls, (levers, pedals and switches),
are in NEUTRAL position before starting the engine.
• Before leaving the operator’s position for ANY reason
or allowing anyone to approach the machine and
attachment, always perform the mandatory shutdown
procedure.
• Do not wear loose hanging clothes, neckties or jewelry
around rotating parts. Long hair is to be placed under
a cap or hat. These precautions will help prevent you
from becoming caught in any moving parts on the
machine and attachment.
• Before working under the attachment, be certain it is
securely blocked!
• Do wear safety glasses, ear protection, respirators,
gloves, hard hats, safety shoes and other protective
clothing when required.
• Periodically check all guards, shields and structural
members. Replace or repair anything that could
cause a potential hazard.
• Do not replace components or parts with other than
factory-recommended service parts. To do so may
decrease the effectiveness of the machine.
• It is the operator’s responsibility to be aware of
machine and attachment operation and work area
hazards at all times.
• Never operate the attachment without adequate light
and visibility.
• Keep hands and feet clear! Never step over or climb
over the attachment while the rotor is engaged or the
engine is running; entanglement could occur.
Safety Instructions
• Operators are responsible to know the location
and function of all guards and shields including but
not limited to belt drives and rotor. Operators are
responsible to make certain that all guards are in
place when operating the machine and attachment.
• Operators are responsible to be aware of safety
hazard areas and follow instructions on warning,
caution, or danger decals applied to the machine.
• Know the area before operating the machine. Be
aware of power lines or other equipment.
• Do not lubricate parts while the machine is running.
• Do not smoke while servicing the machine.
Hydraulic Safety
• The hydraulic system is under high pressure. Make
sure all lines and fittings are tight and in good
condition. These fluids escaping under high pressure
can have sufficient force to penetrate skin and cause
serious injury.
• Never check for leaks by using any part of your body
to feel for escaping fluid.

8 Carbide Cutter OM
Safety Instructions
Pusher Bar
Hydraulic Control Valve
Hydraulic Motor
Rotor
Cutting Teeth
Hydraulic Hoses
Hydraulic Hose Support
Rotor Locking Pin
(Storage Location)
Mounting Plate
Deflector Chain
Support Stand
Drive Belt
Pressure Gauge
Skid
Rotor Bearing Guard
Carbide Cutter Identification

9Carbide Cutter OM
Safety Decal Locations
Check and replace any worn, torn, hard to read or missing
safety decals on your machine.
13
2
4
1
2
3
4
5
5
Part No. N17013
Part No. N20661
Part No. N17014
Part No. N16759
Part No. 4334
Safety Instructions
WARNING
Due to the possible danger of flying debris,
it is absolutely MANDATORY that impact-resistant
shielding be provided on the power unit to
protect the operator.
The owner is responsible for providing the
operator protection devices on the power unit.
WARNING
Flying Debris can gather on the skid-loader and needs to
be cleaned off, especially around the radiator and oil cooler
screens, engine compartment and exhaust areas. Periodic
cleaning will help prevent the possibility of fire.
The adjustable push bar could contact the power
unit in some positions.
Before starting the power unit, set the push bar in the
most forward position, then slowly rotate the cutter
head back while an assistant checks for clearance.
Repeat this process in the other settings to determine
which positions are usable with your power unit.
WARNING
WARNING
Rotor must be stabilized with the rotor locking pin
to prevent accidental rotation any time the rotor is
exposed for service work.
Do Not Remove the locking pin for any reason
when one or more knives are missing from the
rotor assembly. The imbalance could cause the
rotor to turn without warning, causing serious
personal injury.

10 Carbide Cutter OM
Safety Decal Locations (Cont’d)
6
8
7
6
9
9
7
9
Part No. N22763
Part No. N13863
Part No. N28386
WARNING
Read and understand
operator’s manual before
using this machine.
Failure to follow operating
instructions could result
in death or serious injury.
STAY BACK
KEEP HANDS AND FEET
AWAY FROM ROTATING
KNIVES UNDER MACHINE
DO NOT LEAVE
OPERATORS POSITION
WHILE POWER UNIT IS
RUNNING
DANGER
Safety Instructions
8
Part No. N28385
WARNING
IMPROPER CONNECTION TO THE POWER UNIT’S HYDRAULIC SYSTEM
COULD CAUSE SERIOUS COMPONENT DAMAGE AND PERSONAL INJURY.
This attachment can be configured with different components to operate on a variety
of power units.
It is absolutely MANDATORY that you refer to your OPERATOR’S MANUAL for Set-up
Instructions and Pressure Ratings that apply to the components used on this unit.
The dealer/owner will be responsible for any damage caused by improper connection
to the power unit.
