Logic LIFE 20 User manual

SMARTWATCH
User Manual
Please refer to this manual before using your
LOGIC LIFE 20 SmartWatch.

ENGLISH
OVERVIEW
CHARGING
USABILITY
PAIRING
FUNCTIONS
TECHNICAL SPECIFICATIONS
3
4
5
6-7
8-12
13
Pages
2

1. OVERVIEW
Information
LOGIC LIFE 20 is resistant to water splashes or rain. LOGIC LIFE 20
MUST NOT be submerged in water.
Information
Camera
Heart rate
monitor
Charging
connectors
On/Off
Microphone
Speaker
Micro SD
3

Plug in the larger side of the USB cable to a USB
power source.
Connect the 4 pin magnetic connector to the back of
your LOGIC LIFE 20.
Make sure the 4 pin connectors are making contact
with the charging terminal on your LOGIC LIFE 20.
An indicator bar will light up on the watch showing you
the charging progress. Once fully charged the
indicator bar will be filled completely.
2. CHARGING
2.1
2.2
2.3
2.4
For the watch to be completely charged it takes about 2-3 hours.
When your watch gets a low battery, an indicator will alert you.
Charge your LOGIC LIFE 20 for no less than 2 hours before using it for
the fist time. For a safe charging we recommend placing your watch
in a straight and horizontal surface.
To install the expandable memory card Use the screwdriver
(Included) to detach the back cover of the watch. Do not remove the
battery. Carefully insert the memory card, put on the back cover of
the watch and secure the screws tightly.
Information
Information
MicroSD
MICRO SD LOCATION
4

3.1
3.2
3.3
3.4
3. USABILITY
Press the on/off button for about 3 seconds to turn
it on or off.
Once its on, slide to the left to get to the main menu.
Slide downwards to see all the functions.
Slide right to go back a screen.
Interact and explore with your new LOGIC LIFE 20 to get used to it.
For more information visit our website at www.logicmobility.com/log-
iclife-20.
Information
4. PAIRING
To enjoy your LOGIC LIFE 20 to the fullest, download and
install the following app to your smartphone.
5

4.1 For Android devices
For an easy and safe
installation please scan
the QR code from your
phone and follow the
steps down below.
*Make sure you have a QR reader
app in your smartphone. If you don’t,
you can download one in the Google
Play Store.
4.1.1.
4.1.2.
4.1.3.
4.1.4.
Configure your mobile device to accept the
installation of apps from unknown sources. Go to
the option “settings”, then “security”, locate
“unknown sources” and check to activate.
Scan the QR Code and this will open up a web page
on your browser. Confirm you would like to open
the web page http://c3.cli.im/BdF06M
It will load a screen with 5 app choices. You must
download FunDo SmartDevice.
Next it will start downloading the app installer, once
it is done, click on the installer and wait for the
installation. Keep the app running in the
background.
4.1.2 4.1.3 4.1.4
6

The pairing process is only done for the first time for each new
device. If the pairing fails repeat the same steps. If you want to pair
the LOGIC LIFE 20 with another device, first you must un-pair it from
the previous device. Logic Mobility recommends that you use the
suggested apps to fully control your watch. Logic Mobility isn’t
responsible for third-party apps. Logic Mobility does not own the
Fundo Smart Device and Fundo Wear applications. For more
information please go to: www.logicmobility.com/logiclife-20.
Information
For system requirements visit: www.logicmobility.com to get the
updated version of the list with the compatible devices.
Information
4.2. Pairing your device
4.2.1.
4.2.2.
4.2.3.
4.2.4.
Go to the main menu and find the Bluetooth icon.
Click “Search device”.
In your smartphone accept the pairing request.
When both devices are successfully paired you will
see an icon next to your device’s name.
4.1.2 For IOS
Open the Apple App Store and search for FUNDO
WEAR. Download and install the app. Keep the app
running in the background.
7

5. FUNCTIONS
Contacts
Call log
Bluetooth
QR Code
Messaging
Calculator
Dialer
Calendar
Music
Video
Themes
Video recorder
Settings
Image viewer
Camera
Audio recorder
Notifications
Sleeping
Remote camera
File manager
Heart rate
Alarm
Pedometer
Anti-theft
Stopwatch
Clock
Info
Sedentary
Sound
Voice assistant
Energy-saving
Motion
8

1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
Contacts: Pair your LOGIC LIFE 20 and access your
contacts.
Call log: Access your call log from your LOGIC LIFE 20.
Bluetooth: Activate, search and pair your watch with
other mobile devices.
QR code: Scan the barcode to install suggested apps.
Messaging: Send and receive text messages from
your LOGIC LIFE 20.
Calculator: The LOGIC LIFE 20 has a calculator to
solve everyday calculations.
Dialer: Make calls from your LOGIC LIFE 20.
Calendar: Get acces to your daily schedule.
For a better understanding of your LOGIC LIFE 20 enter our website
at www.logicmobility.com/logiclife-20.
Information
SCREEN 1
9

2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
Music: Pair your mobile device and listen to your
music in your watch. You can also store songs on your
SD card and access those from the watch.
Video: LOGIC LIFE 20 plays video stored in your Micro
SD card.
Themes: You can choose between 4 watch faces for
your LOGIC LIFE 20.
Video recorder: Shoot video with the VGA camera in
your LOGIC LIFE 20.
Settings: Set up the time, sound, volume, screens and
other general settings.
Image viewer: Look at pictures taken with the LOGIC
LIFE 20 and send them to your mobile device.
Camera: Take pictures with the VGA camera in your
LOGIC LIFE 20.
Audio recorder: Your LOGIC LIFE 20 lets you record
audio and play it later.
For a better understanding of your LOGIC LIFE 20 enter our website
at www.logicmobility.com/logiclife-20.
Information
SCREEN 2
10

3.1
3.2
3.3
3.4
3.5
3.6
3.7
3.8
Notifications: Pair your LOGIC LIFE 20 and get
notifications from the apps you have selected in the
FunDo app.
Sleeping: Monitor your sleep quality and hours of
sleep with your LOGIC LIFE 20.
Remote camera: Pair your smartphone and control
your phone camera from your LOGIC LIFE 20.
File manager: Store and access files in your
SmartWatch or your Micro SD card.
Heart rate: Your LOGIC LIFE 20 measures your heart
beats per minute and stores it.
Alarm: Set up alarms.
Pedometer: LOGIC LIFE 20 keeps track of your daily
steps, distance and calories burned.
Anti-theft: Always together. Get the location of your
mobile device from your watch or vice versa.
For a better understanding of your LOGIC LIFE 20 enter our website
at www.logicmobility.com/logiclife-20.
Information
SCREEN 3
11

For a better understanding of your LOGIC LIFE 20 enter our website
at www.logicmobility.com/logiclife-20.
4.1
4.2
4.3
4.4
4.5
4.6
4.7
Stopwatch: Stopwatch function.
Clock: Set up the date and time. Choose your favorite
watch face for your LOGIC LIFE 20.
Info: LOGIC LIFE 20 information.
Sedentary: Stay active with your LOGIC LIFE 20 and
get an alarm when you have been seated for a long
period of time.
Sound: Choose a ringtone for your notifications and
set the audio level.
Voice assistance: Do things quicker on your smart
phone via voice commands.
Power saving: Activate this function to save energy
on your LOGIC LIFE 20.
Information
SCREEN 4
12

Interact and explore your new LOGIC LIFE 20 to get used to it. For
more information visit our website at www.logicmobility.com/logi-
clife-20
Information
Charging time
Processor
Characteristics
Touch screen
Bluetooth
Camera
MicroSD
Battery capacity 320 mAh
2-3 hours
Mediatek 2502C
1.54 inches IPS LCD,
Resolution 240*240 pixels
Yes
Version 4.0
Microphone / Speaker Yes
0.3 MP VGA, remote camera.
Memory ( ROM/RAM ) 128Mbit + 64Mbit
Up to 16 GB
Mp3/Mp4 player Yes
4.8.1 Turn
>Mute incoming calls
>Mute alarms
4.8.2 Rise
>Turn on the screen
4.8.3 Shake
>Change menu
>Answer calls
13
For the full list of technical specifications of your LOGIC LIFE 20 enter
our website at www.logicmobility.com/logiclife-20.
Information
4.8 Motion
6. TECHNICAL SPECIFICATIONS
