Logik LFTC50W16 User manual

Instruction Manual
Free-Standing Twin Cavity
Electric Cooker
LFTC50W16
LFTC50W16_IB.indd 1 20/05/2016 15:03

LFTC50W16_IB.indd 2 20/05/2016 15:03

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 6
Product Overview......................................................................................................................... 7
Front View ...................................................................................................................................................................7
Top View.......................................................................................................................................................................7
Control Panel..............................................................................................................................................................8
Before Using Your Cooker ............................................................................................................ 8
First Time Use of the Hob ............................................................................................................. 8
Choosing the Right Cookware..................................................................................................... 8
Using Your Hob ............................................................................................................................. 9
First Time Use of the Oven ......................................................................................................... 10
Using the Oven ........................................................................................................................... 10
Replacing the Anti-tilting Oven Shelf....................................................................................... 10
Using the Oven Control.............................................................................................................. 11
Baking Tips.................................................................................................................................. 11
Energy Saving ............................................................................................................................. 11
Using the Grill ............................................................................................................................. 12
General Advice............................................................................................................................ 13
Cleaning the Outside of the Cooker.......................................................................................... 13
Cleaning the Ceramic Hob ......................................................................................................... 13
Cleaning the Cooker Door Glass................................................................................................ 14
Cleaning the Inside of Your Cooker........................................................................................... 14
Removing the Grill Door ............................................................................................................ 14
Replacing the Oven Lamp.......................................................................................................... 15
Hints and Tips ............................................................................................................................. 16
Product Fiche and Specications .............................................................................................. 17
Energy Saving Tips and Energy Label....................................................................................... 18
- Main Oven..................................................................................................................................................... 18
- Hob ..................................................................................................................................................................18
Installation .................................................................................................................................. 19
Adjusting the Feet ...................................................................................................................... 20
Moving the Cooker ..................................................................................................................... 20
Stability Bracket ......................................................................................................................... 20
Electrical Connection ................................................................................................................. 21
LFTC50W16_IB.indd 3 20/05/2016 15:03

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• It is recommended that this appliance is installed by a qualied electrical
engineer. The manufacturer is not responsible for any damage caused by
incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• For disconnection from the mains supply you must have a switch with a
contact separation of at least 3.0 mm in all poles and rated 32 Amp that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The oven must be used in a well ventilated location and installed on at /
level ground.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• Use of your appliance creates moisture in the room in which it is placed,
make sure that your kitchen is well ventilated. Maintain the natural
ventilation ducts properly.
• Cleaning and user maintenance shall not be made by children without
supervision.
LFTC50W16_IB.indd 4 20/05/2016 15:03

5
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Cleaning and user maintenance shall
not be made by children without supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
• During use the appliance becomes hot. Care should be taken to avoid
touching the heating elements inside the oven or the hotplates.
• The appliance and its accessible parts become hot during use. Young
children should be kept away.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• Danger of re: Do not store items on the cooking surfaces.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper
or ammable materials away from your appliance. Do not keep
combustible or ammable things in or on the appliance.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on or stand on the open door.
• If the hob surface is cracked, switch o the appliance to avoid possibility
of electric shock.
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass oven door uses toughened glass and is designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
LFTC50W16_IB.indd 5 20/05/2016 15:03

6
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according
to local regulations.
The following items are included:
Oven Shelf x 2
The Main Unit
Thank you for purchasing your new Logik Free Standing Twin Cavity Electric Cooker.
You must read this manual in order to fully understand how to operate it correctly.
This cooker must be installed by a competent engineer. Please allow the installer to view the
installation section of this manual.
Read all the safety instructions carefully before use and keep this manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Stability Bracket x 1
* All images are for indication only; please refer to your individual unit for actual item.
Grill Rack x 1
Grill Pan x 1
Grill Pan Handle x 1
LFTC50W16_IB.indd 6 20/05/2016 15:03

7
Product Overview
Front View
Top View
1
2
3
7
5
6
4
8
1
2
3
2
1
1. Large Ceramic Heater 1700W
2. Small Ceramic Heater 1200W
1. Hob
2. Control Panel
3. Grill Tray
4. Top Oven Door
3. Hot Hob Warming Light
5. Top Oven Door Handle
6. Oven Shelf
7. Main Oven Door
8. Adjustable Feet
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 7 20/05/2016 15:03

8
Control Panel
1. Grill Control
2. Oven Control
3. Ceramic Heater Controls
4. Grill Indicator Lamp
5. Oven Indicator Lamp
6. Hob Indicator Lamp
Before Using Your Cooker
Before using your new cooker, please:
• Make sure all the controls are turned off.
• Read this Instruction/Installation Manual, taking special note of the 'Safety Warnings' section.
• Turn the mains power on.
First Time Use of the Hob
Operate your vitro ceramic hobs at level 6 for 5 minutes. This will remove any manufacturing residues there may
be a small amount of smoke and a slight odour. This is normal and will stop after a few minutes.
Choosing the Right Cookware
Do not use cookware with jagged edges or a curved base.
1
4 5 6
2 3
Make sure that the base of your pan is smooth, sits flat against the glass, and is the same size as the cooking
zone. Always centre your pan on the cooking zone.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 8 20/05/2016 15:03

9
Using Your Hob
1. Rotate the control to the heat level you wish to use for the selected cooking zone.
LEVEL 0 LEVEL 1 LEVEL 2 LEVEL 3 LEVEL 4 LEVEL 5 LEVEL 6
OFF Simmering
(Low)
Cooking at
medium temperature
Cooking, frying and boiling
(High)
2. When the hob indicator lamp illuminates above the controls, this means that one or more of the hobs
are switched on.
3. When you are finished cooking rotate the control back to the “0” position, the hob indicator lamp will
turn off. The cooking zones will remain hot for some time and the hot hob warning light will illuminate.
Do not touch the hobs until they have completely cooled down.
Always lift pans off the ceramic hob – do not slide, or they may scratch the glass.
• The heated areas will be seen to switch on and off even when higher heat settings are used. This is
due to a safety device, which prevents the glass from overheating. Some switching on and off when
cooking at high temperatures is quite normal, causes no damage to the hob and little delay in
cooking times. Excessive switching may however be caused by the use of an unsuitable cookware
or a saucepan which is smaller than the heated area. If excessive switching occurs, discontinue the
use of the cookware.
• To improve performance, and reduce energy, always use pans with close fitting lids.
• If the ceramic hob glass surface is cracked, switch of the appliance to avoid the possibility of electric
shock. Contact an authorised repair agent.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 9 20/05/2016 15:03

10
1. On the wall of the inner cavity there are 5 different
rack guide slots. You can place the rack at different
heights to achieve the best cooking performance
depending on the heat of the heating element and
the size of the food. It is recommended to preheat
the oven for 10 minutes.
2. Always monitor the food during operation to ensure
that you are not overcooking it.
3. For heavy food, use a baking pan rather than the
oven shelf.
4. During cooking, do not open the door unnecessarily
as you will lose heat and your cooking results may
cooking times will be longer and energy use will
be higher.
5. Using cake tins when cooking cakes will give
better results.
6. The grill pan has a detachable handle. Ensure the
grill pan handle is centralised and secure as shown
below when in use.
Replacing the Anti-tilting Oven Shelf
• Insert the shelf at an angle with the vertical section to the rear to clear the
stops at either side of the guide slot. Once past this stop the shelf can be
placed level again.
• To remove, completely angle the shelf upward so the shelf stop is cleared
from the guide stop.
First Time Use of the Oven
Ensure that nothing has been left in the oven. Remove any insert cards or plastic bags. Before connecting the
power, use a damp cloth to carefully wipe the inner cavity wall and housing. Clean all the detachable parts in hot,
soapy water before using.
Heat the oven on maximum for 45 minutes. There may be a little smoke and odour upon initial start up (for about
15 mins). This is normal. It is due to the protective substance on the heating elements which protects the cooker
from the effects of corrosion during shipping from the factory.
Using the Oven
Oven Shelf
Guide 5
Guide 4
Guide 3
Guide 2
Guide 1
Accessible parts may become hot during use. Young children
should be kept away.
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and
damage may occur.
• Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.
• Do not leave the handle in position when grilling. If the handle is left in position when grilling,
it will get very hot.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 10 20/05/2016 15:03

11
Using the Oven Control
Function Description
Defrost Function
Defrost function can be started by placing the frozen food into
your oven and turning the oven control to the defrost sign or
below. Ensure the oven light does not illuminate as this will activate
the elements and start the cooking process. This function will not
cook the food as only the fan operates, this will help to defrost the
food in a very short time. Put the food to be defrosted on the shelf
in the third guide slot position and place a tray onto a shelf on
the bottom guide slot position to collect the water during defrost.
50
100
150
200
250
Adjusting the temperature
This design spreads the heated air equally in the oven and it is
suitable for cooking with one or more trays.
Turn the oven control to the desired temperature. It is recommended
to preheat the oven for 10 minutes. Place the tray on the shelf.
At the end of cooking time, as in all other cooking processes;
turn the oven control to off. Take the cooking tray out and put it
onto a safe place as it will be hot. Keep children away from the hot
oven during and after cooking, until it has completely cooled down.
Baking Tips
1. Always place baking tins in the centre of the wire shelf.
2. Make sure you use bakeware that is oven proof.
3. Do not place bakeware too close to the rear of the oven wall.
4. You can influence the degree of browning by changing the temperature setting.
5. If a cake collapses after removing it from the oven:
• Use less liquid on your next attempt.
• Consider using a longer baking time or use a slightly lower temperature setting.
Energy Saving
To save energy and to help protect the environment, we recommend these hints:
• Preheat the oven only if expressly required by the recipe or guidelines.
• Dark baking tins have a higher degree of heat absorption.
• In the case of longer baking times, you can switch off the oven 5–10 minutes before the full
baking time and use the residual heat. This will reduce energy usage.
• Use the oven efficiently, by cooking many trays of food at the same time.
• Select the correct shelf location for the food being cooked.
• Do not open the oven door more than necessary.
100
150
200
250
50
0
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 11 20/05/2016 15:03

12
Using the Grill
Before using the Grill for the first time, heat the grill on maximum for 15 ~ 20 minutes. There may be a little
smoke and odour upon initial start up (for about 10 mins). This is normal. It is due to the protective substance on
the heating elements which protects the cooker from the effects of corrosion during shipping from the factory.
Function Description
Grill Function
This function is used for grilling. In order to grill, please use the
grill pan supplied with your product. Turn your grill’s control to
the required setting.
At the end of grilling, as in all other cooking processes; turn the
control to the “0” position (off ). Take the grill pan out by using the
supplied handle and put the pan onto a safe place. Keep children
away from the hot oven during and after grilling, until it has
completely cooled down.
Place an oven shelf in either guide slot 1 or 2 position.
There must be at least 30 mm between the food and
the element.
Using the handle, insert the grill rack and tray onto the
shelf in guide slot 1 or 2. The food to be cooked must be
placed on the grill rack in the grill tray. The handle can be
removed once the grill rack tray is in position. Check the
food regularly to ensure you do not overcook it.
The grill pan has a detachable handle. Ensure when using
the grill pan handle that it is centralised and secure as
shown below.
Preheat the grill element for approximately 5-10 minutes before cooking the food.
Ensure a minimum distance of 30 mm exists between the food and the elements. If necessary use a lower guide slot.
Check the food regularly to ensure you do not overcook the food. If slower cooking is required use a lower guide
slot or lower grill setting.
Guide 2
Grill Tray
Oven shelf
Guide 1
0
1
2
3
4
5
6
• The Grill door must be kept open during this function. The door has a position in which the door
is open at 30°. This is the minimum the door can be closed during use.
• During use the appliance becomes hot. Care should be taken to avoid touching the heating
elements inside the grill.
Do not leave the handle in position when
grilling. If the handle is left in position when
grilling, it will get very hot.
Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 12 20/05/2016 15:03

13
General Advice
• Wipe the oven clean after every use.
• Wipe up spills. Avoid leaving alkaline or acidic substances (such as lemon juice or vinegar) on the oven surfaces.
• Do not use cleaning products with a chlorine or acidic base.
• Never clean the interior, panel, lid, trays and all other parts of the oven with tools like a hard brush, cleaning
mesh or knife. Do not use abrasive, scratching agents and detergents.
• After cleaning the interior parts of the oven with a soapy cloth, rinse it and then dry thoroughly with a soft
cloth. Leave the doors open to allow the cavities to completely dry
• Never use flammable agents like acid, thinner and petrol when cleaning your oven.
• Do not wash any part of your oven in a dishwasher.
• If you choose to use a commercial stainless steel cleaner, please read the label to make sure it does not contain
chlorine compounds as these are corrosive and may damage the appearance of your cooker.
• Do not use abrasive cleaners, cloths or pads on the outside surfaces. Immediately wipe off any caustic cleaners
if they are spilled onto the oven door handles.
Cleaning the Outside of the Cooker
Wipe the outside surfaces often, using warm water and a mild household detergent. Any stainless steel parts may
also be cleaned with a suitable cleaner.
Cleaning the Ceramic Hob
• Ensure the cleaning material is designed for cleaning ceramic hobs and does not contain any particles which
may cause it to scratch the glass.
• Spilt food must be cleaned right after the hob glass has cooled.
• Do not use steel cleaning material as it may damage the ceramic hob glass.
• Dust on the surface must be cleaned with a damp cloth allow to completely dry before use.
• The glass may discolour if the incorrect cleaning materials are used.
Before you start cleaning your cooker, please:
• Read the cleaning instructions and the ‘Safety Warnings’ sections.
• Turn the cooker off at the mains socket.
• Allow the cooker to completely cool down before cleaning and disconnect the appliance
from the electrical supply.
• Do not use a steam cleaner.
• Do not keep flammable substances in, on or near the cooker.
LFTC50W16_IB.indd 13 20/05/2016 15:03

14
Removing the Grill Door
The grill door can easily be removed as follows:
1. Open the door completely.
Cleaning the Inside of Your Cooker
• Do not use abrasive cleaners, cloths or pads to clean the enamel.
• Clean the enamel on the inside of the cooker when it has cooled down, using household detergents or an
ammonia-based cleaner. You may use an ‘off the shelf’ oven cleaner, if you carefully follow the manufacturers’
instructions.
• The grill door can be removed to allow easier access to the inside of your grill cavity. (See “Removing the Grill
Door” section)
• Wipe the cooker after every use with a soft cloth that has been dampened in soapy water. Wipe it again with
a wet cloth and then dry it. Do not clean with dry or powder cleansers.
• Do not clean the cooker while the glass panels are hot.
• Clean the cooker with a glass cleaner which is designed to be used with cookers. Then rinse and then dry
it with a dry cloth.
Cleaning the Cooker Door Glass
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they may scratch the surface, which could result in
the glass shattering.
2. The swivel retainers of the right hand and left hand hinges are
hooked onto the metal bar above them. Lift the retainers as shown.
Take care when handling parts with glass, knocks, chips,
heavy handling and dropping could cause the glass to shatter.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 14 20/05/2016 15:03

15
3. Lift the door slightly. The notch on the bottom of the hinge
will disengage.
4. Now pull the oven door forwards off the appliance. Releasing both
hinge sections from the slots.
Let the oven cavity and the heating element cool down.
• Remove the protective cover by unscrewing.
• Unscrew and replace the bulb with a new one suitable for high
temperatures (300°C).
• Refit the protective cover.
To replace the door, repeat the above steps in reverse order.
Replacing the Oven Lamp
Ensure that the cooker is switched off before replacing
the lamp to avoid the possibility of an electric shock.
Bulb specifications
230V~ 50 Hz, 25W, E14
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 15 20/05/2016 15:03

16
Hints and Tips
Problem Possible Causes What To Do
The cooker cannot be
turned on.
No power. Make sure the cooker is connected
to the mains socket and the socket
is switched on. Check whether
there is a power outage in your
home or area. If you’ve checked
everything and the problem
persists, call a qualified technician.
The glass has been scratched. Unsuitable, abrasive scourer or
cleaning products being used.
Do not use harsh abrasive cleaners
or sharp metal scrapers to clean
the glass.
Some pans make crackling or
clicking noises.
This may be caused by the
construction of your cookware
(layers of different metals
expanding/shrinking differently).
This is normal for cookware and
does not indicate a fault.
The oven temperature is too high
or too low.
Wrong temperature selected / or
the wrong shelf position was used.
Check that the recommended
temperatures and shelf position are
being used. Be prepared to adjust
the temperature up or down. If the
temperature needed is critical use
an oven thermometer.
The interior lighting lamp does
not light.
The oven must be on for the lamp
to light. If the lamp is defective you
can change it. (See "Replacing the
Oven Lamp" section.)
LFTC50W16_IB.indd 16 20/05/2016 15:03

17
Product Fiche and Specications
Brand Logik
Model LFTC50W16
Product Type Electric Cooker
Mass of the appliance 42 Kg
Grill ( upper cavity)
Heat Source Electric
Volume 31 litres
Main Oven ( lower cavity)
Energy Eciency Index - Conventional 103.7
Enegy Class A
Energy Consumption (electricity) -
Conventional 0.81 kWh/cycle
Heat Source Electric
Volume 55 litres
Number of Cavities 2
This product complies with EN 60350-1
Overall Dimension (W x D X H) 500(W) x 600(D) HOB [640(D) MAX] x 900(H) mm
(Not including Controls or Handles)
Oven Lamp 25W
Thermostat 50 - 265°C
Oven Heating Element 2000 - 2250 W
Grill Heating Element 1500 - 1600 W
Supply Voltage 230V ~ 50 Hz
Vitroceramic Heater 145 mm 1200 W at 230V
1300W at 240V
Vitroceramic Heater 180 mm 1700 W at 230V
1850W at 240V
Type of Hob Electric
Number of Cooking Zones 4
Heating Zone(s) Small
Heating Technology Radiant - Ceramic
Size 14.5 cm diameter
Energy Consumption 192 Wh/Kg
Heating Zone(s) Large
Heating Technology Radiant - Ceramic
Size 18 cm diameter
Energy Consumption 192 Wh/Kg
Energy Consumption of Hob 192 Wh/Kg
The Hob complies with EN 60350-2
Features and specifications are subject to change without prior notice.
LFTC50W16_IB.indd 17 20/05/2016 15:03

18
Energy Saving Tips and Energy Label
Main Oven
• Cook the meals togeter, if possible.
• Keep the pre-heating time short.
• Do not elongate cooking time.
• Do not forget to turn off the oven at the end of cooking.
• Do not open the oven door during cooking.
Hob
• Use cookware that has a flat base.
• Use the correct sized cookware for the cooking zone being used.
• Use a lid on your cookware.
• Minimize the amount of liquid or fat used.
• When liquids start boiling reduce the heat.
LFTC50W16_IB.indd 18 20/05/2016 15:03

19
Installation
• The cooker must be installed by a competent person, if in doubt consult a qualified technician, and in
compliance with local electrical, safety and building regulation standards.
• If the cooker is installed adjacent to furniture which is higher than the hob, a gap of at least 100 mm must be
left between the side of the cooker and the furniture unless non-combustible materials (e.g., ceramic tiles,
metal splashback, etc.) are used which then allows this distance to be reduced to 20 mm.
• The furniture walls adjacent to the cooker must be made of heat resistant material (check with your furniture
supplier). The veneered synthetic material and the glue used must be resistant to a temperature of 100°C in
order to avoid ungluing or deformations.
• The cooker may be located in a kitchen, a kitchen/diner or bed-sitting room but not in a room containing
a bath or shower.
• Flammable materials such as curtains, wood, wallpaper, etc. must not be fitted immediately behind the
appliance or within 500 mm of the sides.
• Do not place next to a refrigerator.
• This cooker must NOT be placed on a pedestal or base.
• It is essential that the cooker is positioned as stated or freestanding taking into account the distances of any
combustible materials detailed above.
• Any cooker hoods must be installed according to the requirements of the cooker hood instruction/installation
manual but no less than 650 mm.
• Any cupboards placed directly above the cooker must be no less than 700 mm.
500 mm
X
500 mm
900 mm
420 mm
700 mm
640 mm
Cupboard
500 mm
X
500 mm
900 mm
420 mm
650 mm
640 mm
Cooker HoodCupboard
For all dimensions marked “X”, please
refer to the information below:
X : 100mm for combustible materials
20mm for non-combustible materials.
* All images are for indication only; please refer to your individual unit for actual item.
LFTC50W16_IB.indd 19 20/05/2016 15:03

20
Adjusting the Feet
The cooker stands on 4 levelling legs. As the levelling legs are
adjusted at lower position, it is required to control whether
the product is levelled before operating it. This adjustment
can be made by turning the levelling leg clockwise to raise
the cooker, if required. It is possible to raise the product a
maximum of 30mm via the levelling leg. If the levelling legs
are adjusted appropriately, the product must NOT be moved
by dragging. The cooker must always be moved by lifting it
up. The levelling leg can be adjusted by hand or a metal plate
of the correct size to fit the slot.
Level the cooker by screwing the bottom of the feet in or out,
as shown.
Moving the Cooker
Using the fitted adjustable feet is MANDATORY. For safety reasons and to ensure adequate
ventilation, the cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface.
• Two people must always raise the cooker, as shown,
to prevent damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the floor.
* All images are for indication only; please refer to your individual unit for actual item.
Stability Bracket
The supplied stability bracket or a recognized cooker stability device MUST be fitted.
50x60 : 420mm
Plastic Foot
Stability Bracket
Washer
Screw
You can connect a stability
chain (not supplied) to the
screws shown here.
LFTC50W16_IB.indd 20 20/05/2016 15:03
