Logik LFTG90B17 User manual

Instruction Manual
90cm Dual Fuel
Range Cooker
LFTG90B17, LFTG90X17
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 1 25/08/2017 16:14

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 7
Product Overview......................................................................................................................... 8
The Hob........................................................................................................................................................................8
Control Panel..............................................................................................................................................................8
Oven..............................................................................................................................................................................9
Before Using the Hob ................................................................................................................. 10
Lighting the Hob......................................................................................................................... 10
Flame Failure Safety Feature ..................................................................................................... 11
If the Burner Does Not Light...................................................................................................... 11
If the Flame is Irregular .............................................................................................................. 11
Electricity Failure........................................................................................................................ 11
Cookware Guidelines ................................................................................................................. 12
Oven Control............................................................................................................................... 13
Using the Oven ........................................................................................................................... 15
First Time Use of the Oven .................................................................................................................................15
Shelf Positions.........................................................................................................................................................15
Replacing the Anti-tilting Oven Shelf ............................................................................................................15
Preheating................................................................................................................................................................16
Cooking.....................................................................................................................................................................16
Baking Tips...............................................................................................................................................................16
Cooking with the Grill ................................................................................................................ 17
Using the Storage Compartment .............................................................................................. 19
Cleaning and Maintenance........................................................................................................ 20
Cleaning the Gas Hob................................................................................................................. 20
Burner Parts and Pan Supports ................................................................................................. 21
Replacing the Burners................................................................................................................ 21
Hob Controls ............................................................................................................................... 21
Cleaning Instructions ................................................................................................................. 22
Cleaning the Ceramic Hob.................................................................................................................................22
Cleaning the Outside of the Cooker...............................................................................................................22
Cleaning the Oven Door Glass.......................................................................................................................... 22
Cleaning the Inside of Your Cooker.................................................................................................................23
Removing the Oven Door .......................................................................................................... 23
Hints and Tips ............................................................................................................................. 24
Replacing the Oven Lamp.......................................................................................................... 25
Installation .................................................................................................................................. 26
Adjusting the Feet ...................................................................................................................... 27
Moving the Cooker ..................................................................................................................... 27
Stability Bracket ......................................................................................................................... 27
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 2 25/08/2017 16:14

Ventilation Requirements.......................................................................................................... 28
Gas Installation........................................................................................................................... 28
Installation and Service Regulations ........................................................................................ 28
Gas Connection........................................................................................................................... 29
Installation Relevant to Natural Gas ............................................................................................................... 29
Installation Relevant to Liquid Petroleum Gas (LPG)................................................................................ 29
To Connect the Gas Supply................................................................................................................................ 29
Replacement of Burner Injectors .............................................................................................. 30
To Replace the Hob Injectors ............................................................................................................................30
Adjusting the Reduced Flame Position ......................................................................................................... 30
Injector Size Table....................................................................................................................... 31
Electrical Connection ................................................................................................................. 32
Energy Saving Tips and Energy Label....................................................................................... 33
Product Fiche and Specications .............................................................................................. 34
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 3 25/08/2017 16:14

4
Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
• This appliance must be installed by a qualied Gas Safe registered
engineer. The manufacturer is not responsible for any damage caused
by incorrect installation.
• Check whether there is any damage to the appliance after you have
unpacked it. If any damage is found, do not use the appliance and
contact the store where you purchased it.
• This appliance is for indoor domestic use only.
• This appliance is for cooking purposes only. It must not be used for other
purposes, for example room heating.
• For disconnection from the mains supply you must have a switch with
a contact separation of at least 3.0 mm in all poles and rated 32 Amp that
provides full disconnection, this must be incorporated in the xed wiring
in accordance with the local wiring rules.
• If the mains cable gets damaged, it should be replaced by an authorized
service agent or qualied electrician in order to avoid a hazard.
• The cooker must be used in a well ventilated location and installed on
at / level surface.
• Only operate your appliance in a dry atmosphere.
• Keep the electrical cables of your other appliances away from hot areas;
do not let them touch the appliance.
• Ensure that the appliance is switched o at the mains supply switch
and allowed to completely cool down before cleaning, replacing the
oven lamp or performing any maintenance to avoid the possibility of an
electric shock or burns.
• The use of a gas cooking appliance results in the production of heat,
moisture and products of combustion in the room in which it is installed.
Ensure that the kitchen is well ventilated especially when the appliance
is in use. Keep natural ventilation holes open or install a mechanical
ventilation device (mechanical extractor hood).
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 4 25/08/2017 16:15

5
• Prolonged intensive use of the appliance may call for additional ventilation,
for example opening of a window, or more eective ventilation, for
example increasing the level of mechanical ventilation where present.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Cleaning and user maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure that they do not play with
the appliance.
• During use the appliance becomes hot. Care should be taken to avoid
touching the parts inside the oven or the hob burners/pan stands.
• The appliance and its accessible parts may become hot during use.
Young children should be kept away.
• Unattended cooking on a hob with fat or oil can be dangerous and may
result in re. NEVER try to extinguish a re with water, but switch o the
appliance and then cover the ame e.g. with a lid or a re blanket.
• Danger of re: Do not store items on the cooking surfaces.
• When the hob is hot never touch any parts that get hot. Allow the hob to
cool before touching these parts.
• When the oven is hot never touch the oven glass or any other parts that
get hot. Allow the oven to cool before touching these parts.
• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
the glass shattering.
• Before starting to use your appliance, keep curtains, tulle, paper or
ammable materials away from your appliance.
• Do not keep combustible or ammable things in, on or near the appliance.
• Do not use steam cleaners for cleaning the appliance.
• Do not rest any items on the open door and do not let children climb on
or stand on it.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 5 25/08/2017 16:15

6
• Take care when handling parts with glass, knocks, chips, heavy handling
and dropping could cause the glass to shatter.
• The glass doors use toughened glass and are designed to break into
many‘nugget’ size pieces if it breaks. These pieces will still have sharp
edges, please handle broken glass with care.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• This appliance is not designed to be used with hob guards. Use of
inappropriate hob guards can cause accidents.
• The inside surface of storage compartment may be hot during use. Care
should be taken to avoid touching inside surfaces.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 6 25/08/2017 16:15

7
Main Unit
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
Pan Support (Left/Middle/Right) × 3 Grill Pan Handle set x 1
100 mm Burner Ring × 1
100 mm Burner Cap × 1
Stability Bracket × 1 Stability Bracket Screws × 2
Stability Bracket Wall Plugs × 2 Shelf × 2
Baking Pan Shelf × 1
Splash Back × 1 Splash Back Screws × 2
75 mm Burner Ring × 2
75 mm Burner Cap × 2
55 mm Burner Ring × 1 Multi Ring Burner Ring × 1
55 mm Burner Cap × 1 60 mm & 130 mm Multi
Ring Burner Cap × 1
Thank you on the purchase of your new Logik Dual Fuel Range Cooker.
You must read this manual in order to fully understand how to operate it correctly.
This unit MUST be installed by a competent and registered engineer (Gas Safe in the UK).
Please allow the installer to view the installation section of this manual.
Read all the safety warnings carefully before use and keep this manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
* All images are for indication only; please refer to your individual unit for actual item.
LPG Replacement Rating
Plate Sticker × 1
LPG Conversion Kit:
LPG Nozzle × 5
Type of gas
3+ G30/31 28-30/37 mbar
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 7 25/08/2017 16:15

8
Product Overview
The Hob
Control Panel
1. Standard Burner (75 mm)
2. Large Burner (100 mm)
3. Small Burner (55 mm)
4. Multi Ring Burner (middle 60mm, outer 130mm)
1. Oven Timer Control
2. Oven Functions Control
3. Oven Temperature Control
4. Front Left Hob Control
5. Back Left Hob Control
6. Multi Ring Hob Control
7. Back Right Hob Control
8. Front Right Hob Control
2 3 4 5 6 7 81
1
3
4
2
* All images are for indication only; please refer to your individual unit for actual item.
1
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 8 25/08/2017 16:15

9
Oven
2
1
3
4
5
6
7
8
1. Splash Back
2. Oven Door Handle
3. Oven Door
4. Storage Flap
5. Adjustable Feet
6. Oven Light
7. Oven Shelves
8. Deep Baking Pan Shelf
The inside surface of storage compartment may be hot during use. Care should be taken to avoid
touching inside surfaces.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 9 25/08/2017 16:15

10
Lighting the Hob
1. Choose the control for the burner you want to use.
2. Press and hold the Burner control in. The spark ignition will
operate whilst you hold in the control. While pressing the
burner control down, turn it anti-clockwise to the large flame
symbol . Continue to hold the control in for approximately
5-10 seconds after the burner has lit. Releasing the control too
soon will extinguish the flame due to the flame failure safety
feature.
Manual Ignition (in case of electricity failure)
To ignite one of the burners, press and turn the control counter-clockwise so that the control is at the
position. Hold an ignition source (e.g. candle lighter) close to the upper circumference of the burner.
Move the ignition source away as soon as you see a stable flame. Continue holding the control in for
approximately 5-10 seconds after the burner has lit. Releasing the control too soon will extinguish the flame
due to the flame failure safety feature.
3. Adjust the flame anywhere between the and positions. Do not adjust the flame between the and Off
position.
4. After ignition, check the flames visually. If you see yellow tipped, lifted or unstable flames; turn the control
off. Allow the burners to cool before touching, then check the assembly of the burner rings and caps. Also,
make sure that no liquid has entered into the burner cups. If the burner flames go out accidentally, turn the
burners off, and do not try to light them again for at least 60 seconds (to allow the gas to disperse).
5. When turning the hob off, turn the control in a clockwise direction to the off mark, ‘O’.
Before Using the Hob
Before using your new hob, please:
• Read this manual fully taking special note of the ‘Safety Warnings’ section.
• Make sure the cooker is connected to the mains supply so that the ignition circuit will work.
O
High
Low
• If the burner does not light within 15 seconds, turn the control off and wait for at least 60 seconds
before trying again.
• To switch the burner off, turn the control clockwise to the off ‘O’ position.
• After use, always turn the controls to the off position.
This appliance is for cooking purposes only. It must not be used for other purposes, e.g. room
heating.
• This appliance is for cooking purposes only. It must not be used for other purposes, for example
room heating.
• The use of a gas cooking appliance results in the production of heat, moisture and products of
combustion in the room in which it is installed. Ensure that the kitchen is well ventilated especially
when the appliance is in use: keep natural ventilation holes open or install a mechanical ventilation
device (mechanical extractor hood). Prolonged intensive use of the appliance may call for
additional ventilation, e.g. opening of a window, or more effective ventilation, e.g. increasing the
level of mechanical ventilation where present.
* All images are for indication only; please refer to your individual unit for actual item.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 10 25/08/2017 16:15

11
Electricity Failure
If there is an electricity failure, you can still use your hob. Light the burners by holding an ignition source (e.g.
candle lighter) close to the side of the burner and turning the control to the High position to light the gas. The
controls must still be held down for 5 – 10 seconds after the burner has lit. Releasing the controls too soon will
extinguish the flame. Adjust the controls as required.
Flame Failure Safety Feature
The flame supervision device (FSD) probe cuts off the gas supply to the burner within one minute if the flame is
extinguished. Gas will flow out of the burner until the FSD cools down and activates, so you may notice the smell
of gas, this is normal.
If the flames are accidentally extinguished, turn off the burner and do not try to light it again for at least one
minute (to allow the gas to disperse).
When lighting the burner, hold down the control for approximately 5 – 10 seconds after the burner has lit.
Releasing the control too soon will extinguish the flame.
If the Burner Does Not Light
If the burner does not light, check that:
• The hob is connected to the electrical supply and the supply is switched on.
• The gas is turned on.
• You have held down the control for at least 5 – 10 seconds after the flame has been lit.
• The ignitors are sparking. If the ignitors are not sparking, they may be dirty or wet. Clean them gently with a
small nylon brush such as a toothbrush as shown below. Ensure the electrical supply has been disconnected
before cleaning.
If the Flame is Irregular
If the flame is yellow or irregular, check that the burner parts, including the burner cap (allow to cool before
touching), are:
• Clean and dry.
• Positioned correctly. See ‘Replacing the Burners’.
• Also see ‘Hints and Tips’.
Ignitor
Flame failure
probe
Burner Cap
Electrode Burner Ring
To avoid damage to
the ignition circuit
NEVER light the hob
when the burners are
not in place.
* All images are for indication only; please refer to your individual unit for actual item.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 11 25/08/2017 16:15

12
• Do not use large saucepans or frying pans that overlap the edges of your hob as this can deflect heat onto
your worktop and damage the surface, and may also cause a hazard.
• Always make sure saucepans are stable. Using very heavy saucepans may bend the trivet/pan support or
deflect the flame.
• Always lift the cookware when removing from the hob, do not drag.
• When you need to boil, simmer or fry food, first set the temperature to the High position.
Once the liquid is boiling, reduce the temperature to maintain a steady heat to cook your food thoroughly.
Doing this will reduce the cooking time and save energy.
• Pan sizes should be as per the table shown below.
Burners Minimum Diameter Maximum Diameter
Large (100mm) 20 cm 24 cm
Standard (75mm) 14 cm 22 cm
Small (55 mm) 12 cm 18 cm
Multi Ring
(middle 60mm, outer 130mm)
24 cm 28 cm
Cookware Guidelines
To get the best out of your hob, follow these simple suggestions:
• Use saucepans with thick flat bottoms. Food in a saucepan with an uneven bottom will take longer to cook.
• Using a lid will reduce cooking times and save energy.
• When liquid comes to a boil, reduce the temperature setting to maintain the desired level of boiling.
• Choose cookware of the proper size, material and construction.
• Minimise the amount of liquid or fat to reduce cooking times.
• Select the proper temperature setting for the cooking task.
Do not use cooking vessels on the hob that overlap its edges.
* All images are for indication only; please refer to your individual unit for actual item.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 12 25/08/2017 16:15

13
Function Description
Oven Light
Only the oven light will switch on.
Defrost Function
Defrost function can be started by placing the frozen food into your oven and turning the oven
control to the defrost sign. Ensure the thermostat light does NOT illuminate by making sure the
temperature dial is set to minimum ( ) DO NOT set a temperature. This function will not cook the
food as only the fan operates, this will help to defrost the food in a very short time. Put the food
to be defrosted on the shelf in the third guide slot position and place a tray onto a shelf on the
bottom guide slot position to collect the water during defrost.
Turbo Function
The oven’s light, ring heating element and fan will turn on.
The turbo function evenly disperses the heat in the oven. All food on the shelves will be cooked
evenly. Its recommended to pre-heat the oven for about 10 minutes.
Top and Bottom Heating Function
The oven’s light will turn on and the upper and lower elements will switch on.
This function emits heat, ensuring even cooking of the food from the top and bottom. This is ideal
for making pastries, cakes, baked pasta, lasagne and pizza. Preheating the oven for 10 minutes is
recommended and it is best to cook on only one shelf at a time.
Oven Control
Either a cooking time has to be set or the timer has to be set to ‘M’ (manual) before your oven will operate. The
oven will turn off when the timer reaches ‘O’. The ovens thermostat light will switch on if the temperature is
below the selected temperature on the dial, when you select any function other than the Oven Light function.
Grill element only switches onGrill
Grill & Top element switch onDouble grill
Grill & Top element and fan switch onDouble grill
with fan
1. Select a cooking
time or set the
timer to ‘M’
(manual)
2. Select your oven
function.
3. Set your oven
temperature.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 13 25/08/2017 16:15

14
Fan Function
The oven’s light will turn on and the upper and lower elements and the fan will switch on.
This function is very good for obtaining results in baking pastry. Cooking is carried out by the
lower and upper heating elements within the oven and by the fan providing air circulation, which
will give a slight grill effect to the food. Its recommended to pre-heat the oven for about 10
minutes.
Pizza Function
The oven’s light will turn on and the ring and lower elements and the fan will switch on.
Fan and lower heating function is ideal for baking food, such as pizzas, equally in a short time.
While the fan evenly disperses the heat of the oven, the lower heating element ensures the
baking of food dough.
Grill Function
The oven’s light and grill heating element will turn on.
The grill function is used for grilling and toasting foods, use the upper shelves of the oven. Its
recommended to pre-heat the grill for about 10 minutes.
• When using the grill the oven door must be closed and the oven temperature
should be adjusted to 190°C.
• You must leave a gap of at least 30mm between the grill element and the top of
the food that you are grilling when using the grill.
Double Grill
The oven’s light, grill and top heating element will turn on.
This function is used for faster grilling and for covering a larger surface area. Use the upper shelves
of the oven.
• When using the grill the oven door must be closed and the oven temperature
should be adjusted to 190°C.
• You must leave a gap of at least 30mm between the grill element and the top of
the food that you are grilling when using the grill.
Double Grill with Fan
The oven’s light, grill and top heating element and fan will turn on.
This function is used for faster grilling of thicker foods and for covering a larger surface area. The
grill element and top element will be switched on as well as the fan to ensure even cooking. Use
the upper shelves of the oven.
• When using the grill the oven door must be closed and the oven temperature
should be adjusted to 190°C.
• You must leave a gap of at least 30mm between the grill element and the top of
the food that you are grilling when using the grill.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 14 25/08/2017 16:15

15
Shelf Positions
1. On the wall of the inner cavity there are 5
different shelf guide slots in the oven. You
can place the shelf at different heights to
achieve the best cooking performance
depending on the heat of the heating
elements and the size of food. If only the
top heating element is on, we suggest
that you place the shelf on guide 5 (make
sure that there is a minimum distance of
30 mm between the food and the top
heating element).
2. Always monitor the food during
operation to ensure that you are not
overcooking it.
3. For heavy food, use a baking pan rather
than the oven shelf.
Using the Oven
First Time Use of the Oven
Ensure that nothing has been left in the oven and that the room is well ventilated. Remove any insert cards or
plastic bags. Before connecting the power, use a damp cloth to carefully wipe the inner cavity wall and housing.
Clean all the detachable parts in hot, soapy water before using.
Heat the appliance on maximum, making sure the room is well ventilated as there may be a little smoke and
odour. This is normal, and is due to the protective substance on the appliance which protects it during shipping
from the factory. Switch the appliance off once the smoke and odour has stopped. This can take
up to 30 minutes.
• Under no circumstances should the oven be lined with aluminium foil as overheating may occur.
• Do not place dishes or baking trays directly onto the base of the oven as it becomes very hot and
damage may occur.
• Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
• During use, this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g., oven door, heating elements.
• Accessible parts may become hot when in use. Children should be kept away.
• Do not leave the handle in position when grilling. If the handle is left in position when grilling,
it will get very hot.
Guide 5
Guide 4
Guide 3
Guide 2
Guide 1
Replacing the Anti-tilting Oven Shelf
• Insert the shelf at an angle with the vertical section to
the rear to clear the stops at either side of the guide slot.
Once past this stop the shelf can be placed level again.
• To remove, completely angle the shelf upward so the
shelf stop is cleared from the guide stop.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 15 25/08/2017 16:15

16
Preheating
When you need to preheat the oven, we recommend you do so for 10 minutes. For recipes needing high
temperatures, e.g. bread, pastries, scones, soufflés etc., best results are achieved if the oven is preheated first.
For best results when cooking frozen or cooked chilled ready meals always preheat the oven first, unless the
cooking instructions advise you otherwise.
Cooking
• Ensure that food is placed centrally on the shelf and that there is sufficient room around the baking tray/dish
to allow for maximum heat circulation.
• Stand dishes on a suitably sized baking tray on the shelf to prevent spillage onto the oven base and to help
reduce cleaning.
• The material and finish of the baking tray and dishes used affect browning of the bottom of the food.
Enamel-ware, dark, heavy or non-stick utensils increase browning of the bottom of the food. Shiny aluminium
or polished steel trays reflect the heat away and give less browning of the bottom of the food.
• When cooking more than one dish in the oven, place dishes centrally on different shelves rather than cluster
several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results.
• If you are cooking more than one tray of similar items, for example cakes or biscuits, swap the trays during
cooking or you can remove the top tray when the food is cooked and move the lower tray to the higher shelf
to finish cooking.
• Do not place baking trays directly on the oven base as it interferes with the oven air circulation and can lead to
burning of the food. Use the lower shelf position.
• During cooking, do not open the door unnecessarily as you will lose heat and your cooking results may
changed. Cooking times will be longer and energy use will be higher.
• At the end of cooking time, as in all other cooking processes; turn the control to the “0” position (off). Take the
cooking tray out and put it onto a safe place (NOT on the oven door) as it will be hot. Keep children away from
the hot oven during and after cooking, until it has completely cooled down.
Baking Tips
1. Always place baking tins in the centre of the wire shelf.
2. Make sure you use bakeware that is oven proof and suitable for your recipe.
3. Do not place bakeware too close to the rear of the oven wall.
4. You can influence the degree of browning by changing the temperature setting.
5. If a cake collapses after removing it from the oven:
• Use less liquid on your next attempt.
• Consider using a longer baking time or use a slightly lower temperature setting.
• During use, the outer and inner surfaces of the oven get hot. While opening the oven door,
step back to avoid the hot steam coming out of the oven. There may be a risk of burns.
• Always use oven gloves to remove and replace food in the oven.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 16 25/08/2017 16:15

17
Cooking with the Grill
Before using the grill for the first time, switch the grill on for 15 ~ 20 minutes. Ensure that the room is well
ventilated as there may be a little smoke and odour upon initial start up (for about 10 mins). This is normal.
It is due to the protective substance on the heating elements which protects the cooker from the effects
of corrosion during shipping from the factory.
Grill element only switches onGrill
Grill & Top element switch onDouble grill
Grill & Top element and fan switch onDouble grill
with fan
• The grill door must be kept closed when using the grill.
1. Select a time between 0-100 minutes or set the timer to ‘M’ (manual).
2. Select your desired grill option ( , or ).
3. Set the temperature to 190°.
4. Insert an oven shelf at your desired level, the closer to the
elements the more intense the heat with be. There must
be at least 30 mm between the food and the element.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 17 25/08/2017 16:15

18
6. The grill pan has a detachable handle. Ensure when using the grill pan handle that it is centralised
and secure as shown below.
7. At the end of grilling, as in all other cooking processes; turn the oven function control to the “ 0 ” position
(off). Take the grill pan out by using the supplied handle and put the pan onto a safe place.
• Never cover the grill pan or grill rack with foil as this can lead to grill fires.
• Bread may catch fire if the toasting time is too long. Close supervision is necessary during toasting.
• During use this appliance becomes hot. Care should be taken to avoid touching hot surfaces,
e.g. oven door.
• Accessible parts may become hot when in use. Children should be kept away.
• Do not leave the handle in position when grilling. If the handle is left in position when grilling,
it will get very hot.
5. Using the handle, insert the grill pan
and rack onto the shelf. Make sure you
leave at least 30mm of space between
the top of the food and the grill
element. You can position the grill pan
anywhere on the oven shelf. The food to
be cooked must be placed on the grill
rack in the grill pan. The handle must
be removed once the grill pan tray is
in position. Close the oven door. Check
the food regularly to ensure you do not
overcook it.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 18 25/08/2017 16:15

19
Using the Storage Compartment
Your oven has a convenient storage compartment for you to store your grill tray, shelves, small pots and pans.
The compartment may become hot so do not store any food in this compartment.
• The inside surface of storage compartment may be hot during use. Care should be taken to avoid
touching inside surfaces.
• The storage compartment is NOT a warming compartment.
1. Open the storage
compartment from
either side.
2. The compartment
door is sprung
loaded so take care
when opening and
closing the door. It
could snap closed
and trap your fingers.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 19 25/08/2017 16:15

20
Cleaning and Maintenance
Cooking Part Cleaning Important
Trivets/pan supports,
burner caps and enamel
surfaces
• Hot soapy water and nylon scourer.
• Mild abrasive cream cleaners.
• Fume-free or heavy-duty oven cleaners
(follow manufacturer’s instructions).
• Always allow hob parts to cool
completely before cleaning them.
• Always apply minimal pressure with
abrasive cleaners.
• Remove spills as soon as the hob is
cool to avoid the spills becoming
burnt on.
Burner parts • Hot soapy water.
• To clear the holes use a stiff nylon
brush.
• Mild abrasive cream cleaners.
• Ensure burner parts are dry before
refitting.
• Reassemble the burner parts correctly.
Controls • Hot soapy water and a soft cloth. • Care must be taken if removing the
controls from the shafts.
• If cleaning the controls whilst they are
attached to the shaft, ensure liquid
does not enter the appliance.
Hob surfaces • Soak stains under a hot soapy cloth,
rinse and dry thoroughly.
• Hard water spots can be removed with
household white vinegar.
• Non-abrasive hob surface cleaners.
• Never use harsh/abrasive cleaning
agents as they will damage the finish.
• Chlorine or chlorine compounds
in some cleaners are corrosive to
hob surface and may damage the
appearance of your hob. Check the
label on the cleaner before using.
Electrodes • Toothbrush. • A dirty or wet electrode will prevent
the burner lighting efficiently. Ensure
the appliance has been disconnected
from the electrical supply before
cleaning or drying.
Cleaning the Gas Hob
Maintenance Period Description
Daily • Clean gas hob as per the instructions.
Monthly • Remove all burner parts, and clean using a non-abrasive detergent. Rinse
in cold water, dry thoroughly, and replace.
• Clean the ignitor and probe carefully, using a toothbrush.
Every year • Contact your local authorized gas Service Agent to perform a thorough
check on all gas components on the gas hob.
Steam Cleaners must not be used to clean this product.
To avoid shock hazard, always disconnect the hob from the electrical supply.
Logik 90cm Dual Fuel Range Cooker LFTG90B17_X17 Manual.indd 20 25/08/2017 16:15
