Logik L300CFW14 User manual

Instruction Manual
290L Chest Freezer
L300CFW14
L300CFW14_IB_RC_190404_grace.indd 1 4/4/2019 4:48 PM

Contents
Safety Warnings............................................................................................................................ 3
Unpacking..................................................................................................................................... 7
Installation .................................................................................................................................... 8
Location .......................................................................................................................................................................8
Free Space Requirements......................................................................................................................................8
Installing the Door Handle....................................................................................................................................8
Cleaning Before Use ................................................................................................................................................8
Before Using Your Unit............................................................................................................................................8
Product Overview......................................................................................................................... 9
Operation .................................................................................................................................... 10
Switching On Your Unit .......................................................................................................................................10
Adjusting the Temperature................................................................................................................................10
Fast Freezing............................................................................................................................................................10
Noises Inside the Unit!.........................................................................................................................................11
Tips for Keeping Food in the Unit.................................................................................................................... 11
Preparations for Freezing....................................................................................................................................11
Defrosting Frozen Food....................................................................................................................................... 11
Cleaning ...................................................................................................................................... 12
Defrosting ................................................................................................................................................................12
Cleaning the Interior and the Exterior of the Unit.....................................................................................12
Maintenance ............................................................................................................................... 13
Replacing the Light Bulb .................................................................................................................................... 13
Care When Handling / Moving the Unit........................................................................................................13
Servicing................................................................................................................................................................... 13
Switching O for Long Periods of Time......................................................................................................... 13
Disposal....................................................................................................................................... 13
Troubleshooting ......................................................................................................................... 14
Power Cut ................................................................................................................................................................14
The Freezer is Particularly Cold ........................................................................................................................ 14
The Freezer is Particularly Warm ..................................................................................................................... 14
The Freezer is Not Working ............................................................................................................................... 14
Condensation Appears on the Outside of the Freezer ............................................................................ 14
Specications.............................................................................................................................. 15
Product Fiche .............................................................................................................................. 15
L300CFW14_IB_RC_190404_grace.indd 2 4/4/2019 4:48 PM

3
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
L300CFW14_IB_RC_190404_grace.indd 3 4/4/2019 4:48 PM

4
• To avoid contamination of food, pay attention to the following:
-opening the door for long periods can cause a significant increase of
the temperature in the compartments of the appliance;
-clean regularly surfaces that can come in contact with food and
accessible drainage systems;
-clean water tanks if they have not been used for 48 hours; flush the
water system connected to a water supply if water has not been
drawn for 5 days;
-store raw meat and fish in suitable containers in the refrigerator so
that it is not in contact with or drip onto other food;
-two-star frozen-food compartments are suitable for storing pre-
frozen food, storing or making ice-cream and making ice cubes;
-one-, two- and three-star compartments are not suitable for the
freezing of fresh food;
-if the refrigerating appliance is left empty for long periods, switch
off, defrost, clean, dry and leave the door open to prevent mould
developing within the appliance.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
L300CFW14_IB_RC_190404_grace.indd 4 4/4/2019 4:48 PM

5
The table below contains general guidelines on the storage of food in the
refrigerator.
Refrigerator location Type of food
Fridge door • Foods with natural preservatives, such as
jams, juices, drinks, condiments.
• Do not store perishable foods.
Crisper bin (salad bin) • Fruits, herbs and vegetables should be
placed separately in the crisper bin.
• Do not store bananas, onions, potatoes,
garlic in the refrigerator.
• Fridge shelf – bottom
• Chiller bin
Raw meat, poultry, fish (for short-term
storage)
Fridge shelf – middle Dairy products, eggs
Fridge shelf – top Foods that do not need cooking, such as
ready-to-eat foods, deli meats, leftovers.
Freezer drawer/shelf • Foods for long-term storage.
• Bottom drawer/shelf for raw meat,
poultry, fish.
• Middle drawer/shelf for frozen
vegetables, chips.
• Top drawer/shelf for ice cream, frozen
fruit, frozen baked goods.
L300CFW14_IB_RC_190404_grace.indd 5 4/4/2019 4:48 PM

6
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked ames or ignition sources and ventilate the room in
which the unit is placed for a few minutes.)
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
WARNING: Risk of fire/flammable materials
L300CFW14_IB_RC_190404_grace.indd 6 4/4/2019 4:48 PM

7
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to local
regulations.
The following items are included:
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Main Unit
Freezer Basket x2Keys x2
Door Handle x1
Handle Cover x1 Screws x6
OFF
Power Run Alarm
5
6
4
3
2
1
Plastic Scraper Instruction Manual
Thank youfor purchasing your new Logik Chest Freezer.
We recommend that you spend some time reading this instruction manual in order that you
fully understand all the operational features it oers.
Read all the safety instructions carefully before use and keep this instruction manual for
future reference.
Instruction
Manual
Door Lock
L300CFW14_IB_RC_190404_grace.indd 7 4/4/2019 4:48 PM

INSTALLATION
8
Location
When selecting a position for your unit you should make sure the oor is at and rm and the room is well
ventilated. This unit can be used in a garage or outbuilding. For optimum energy eciency the unit should be
located within an average room temperature of between 10°C and 43°C. If the room temperature drops below
or rises above these temperatures the energy consumption and performance may be aected. Avoid locating
your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the
electrical consumption. Do not drape the unit with any covering.
Free Space Requirements
When installing the unit, ensure that 25 mm of free
space is left at both sides and 50 mm at the rear of
the unit. Please ensure there is adequate space for
the door to fully open.
• Make sure the door is always kept locked when not in use to prevent children from playing with
the unit.
• The door lock is specially designed to prevent the keys from being left inside the lock.
• The door keys should be kept out of reach of children.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant uid needs time to settle.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using a
sponge or cloth. Wipe completely dry before. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working properly and
to allow it time to fall to the correct temperature. Your unit should not be overlled.
Installing the Door Handle
1. Collect the door handle, door lock, screws and handle cover
from inside the unit.
2. Place and screw the the door lock.
3. Place and screw the door handle.
4. Place the handle cover to cover the screws, bending it
slightly and xing it at onto the door handle.
L300CFW14_IB_RC_190404_grace.indd 8 4/4/2019 4:48 PM

9
OFF
Power Run Alarm
56
4
3
2
1
Freezer Basket
Water Drain
Plug
Power
Indicator
Run
Indicator
Alarm
Indicator
Product Overview
OFF
Power Run Alarm
5
6
4
3
2
1
Light
Wheels
L300CFW14_IB_RC_190404_grace.indd 9 4/4/2019 4:48 PM

10
Operation
Switching On Your Unit
1. On rst connecting the mains cable to the mains socket, all
3 status indicators will light up. Once the unit reaches the
correct temperature:
• Power Indicator (green) : stays on
• Run Indicator (red) : switches on and o as the unit
maintains its internal temperature
• Alarm Indicator (amber) : lights up when the unit’s
internal temperature rises above -9°C.
2. The internal temperature of your freezer is controlled by
a thermostat. Adjust the thermostat control dial to the
desired position, 6makes the appliance colder and is
used for fast freezing. The ideal position is 4but should
be adjusted according to its environment. The appliance
may not operate correctly if it is in a particularly hot or
cold room or if the door is opened often or for prolonged
periods.
3. The unit may not operate at the correct temperature if it
is in a particularly hot or a particularly cold room, or if you
open the door often.
4. To ensure that the unit is cool enough to suciently chill
and freeze your food, wait 24 hours before lling it with
food.
5. If you are concerned that your unit is not being kept cold
enough and wish to check the temperature, you will need
a special fridge/freezer thermometer. These are available
from most supermarkets and hardware shops. Place the
thermometer in the freezer and leave overnight. The
correct temperature for the freezer should be -18°C or
lower.
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat. The recommended position is between 2 and 3
for colder working environments (i.e. during winter) and between 4 and 5 for hotter environments. Please adjust
according to the environment.
Fast Freezing
Fresh food should be frozen as quickly as possible. Turn the dial to 6so your freezer will operate at the coldest
temperature (approximately -28°C) continuously. It helps to quickly freeze and retain more of the goodness of
your food. Freezing will be completed after 24 hours. Then turn the dial back to its original position.
OFF
Power Run Alarm
SUPER
5
4
3
2
1
The Alarm indicator will light up if the unit’s internal temperature rises above -9°C .
OFF
Power Run Alarm
56
4
3
2
1
L300CFW14_IB_RC_190404_grace.indd 10 4/4/2019 4:48 PM
