Logik LFC60W16 Parts list manual

Instruction / Installation Manual
60cm Fridge Freezer
LFC60W16
LFC60W16_IB_RC_171121_grace.indd 1 21/11/17 3:20 pm

LFC60W16_IB_RC_171121_grace.indd 2 21/11/17 3:20 pm

Contents
Safety Warnings........................................................................................................................... 4
Unpacking.................................................................................................................................... 6
Installation ................................................................................................................................... 7
Location ..................................................................................................................................................................... 7
Levelling the Unit ................................................................................................................................................... 7
Free Space Requirements ................................................................................................................................... 7
Reversing the Door Swing................................................................................................................................... 8
Cleaning Before Use ............................................................................................................................................10
Before Using Your Unit........................................................................................................................................10
Product Overview...................................................................................................................... 11
Operation ................................................................................................................................... 12
Switching On Your Unit ......................................................................................................................................12
Adjusting the Temperature...............................................................................................................................12
Noises Inside the Unit!........................................................................................................................................13
Tips for Keeping Food in the Unit...................................................................................................................13
Preparations for Freezing...................................................................................................................................14
Defrosting Frozen Food......................................................................................................................................14
Cleaning ..................................................................................................................................... 15
Defrosting ...............................................................................................................................................................15
Cleaning the Interior and the Exterior of the Unit....................................................................................15
Maintenance .............................................................................................................................. 16
Changing the Internal Light .............................................................................................................................16
Care When Handling / Moving the Unit.......................................................................................................16
Servicing..................................................................................................................................................................16
Switching O for Long Periods of Time........................................................................................................16
Condensation.........................................................................................................................................................16
Disposal...................................................................................................................................... 16
Specications............................................................................................................................. 17
Product Fiche ............................................................................................................................. 17
LFC60W16_IB_RC_171121_grace.indd 3 21/11/17 3:20 pm

Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.
4
LFC60W16_IB_RC_171121_grace.indd 4 21/11/17 3:20 pm

• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked ames or ignition sources and ventilate the room in
which the unit is placed for a few minutes.)
• When positioning the appliance, ensure the supply cord is not
trapped or damaged.
• Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.
5
LFC60W16_IB_RC_171121_grace.indd 5 21/11/17 3:20 pm

Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Main Unit
Salad Bin Cover
Salad Bin
Fridge Glass Shelf x 3
Bottom Freezer Drawer
Upper Freezer Drawer x 2
Egg Tray Ice Tray
Instruction Manual
Upper Balcony Bottom Balcony
Thank you for purchasing your new Logik Fridge Freezer.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Instruction
Manual
Half Balcony x 3
Freezer Glass Shelf x 2
Door Block x 2
6
LFC60W16_IB_RC_171121_grace.indd 6 21/11/17 3:20 pm

Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 43°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Free Space Requirements
When installing the unit, ensure that 25
mm of free space is left at both sides, 50
mm at the rear and 25 mm at the top
of the unit. The door can be opened to
the right or the left, depending on what
better suits the location.
Please ensure there is more than twice
the width and depth distance space
of the unit to fully open the door to a
maximum angle.
Y mm
X mm
7
INSTALLATION
LFC60W16_IB_RC_171121_grace.indd 7 21/11/17 3:20 pm

3. Take off the middle hinge by removing
the screws. Lift the lower door and place
it on a padded surface to prevent it from
scratching.
Remove the screws’ covers and place
them to the opposite side.
Swap the position of the plastic tube and
hole cover on top of the lower door.
Remove the door block, screw and plastic
tube under the lower door and move
them to the opposite side. You may
need to replace the door block to fit the
opposite side.
unscrew
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
1. Take off the hinge cover.
2. Remove the the upper hinge. Lift the
upper door and place it on a padded
surface to prevent it from scratching.
Remove the door block, screw and plastic
tube under the upper door and move
them to the opposite side. You may
need to replace the door block to fit the
opposite side.
• Ensure the unit is unplugged and empty.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
8
INSTALLATION
LFC60W16_IB_RC_171121_grace.indd 8 21/11/17 3:20 pm

5. Reverse the middle hinge. Screw the
middle hinge onto the opposite side of
the unit.
6. Carefully set the upper door back into
place, inserting in onto the middle hinge.
7. Insert the upper hinge and screw it
tightly to the top of the unit.
Middle hinge
Ensure the lower door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before finally tightening the hinge.
Ensure the upper door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before finally tightening the hinge.
4. Remove the lower screws and lower
hinge from the unit bottom. Reverse the
lower hinge, move and secure it with
the lower screws to the opposite side of
the unit bottom. Carefully set the lower
door back into place, inserting it onto the
lower hinge.
8. Put the hinge cover back.
9
INSTALLATION
LFC60W16_IB_RC_171121_grace.indd 9 21/11/17 3:20 pm

• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time
to settle.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a sponge or cloth. Wipe completely dry before replacing the shelves, drawers
and salad bin. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
10
INSTALLATION
LFC60W16_IB_RC_171121_grace.indd 10 21/11/17 3:20 pm
