Logik LFC55B14 Parts list manual

Fridge Freezer
LFC55W13
LFC55S13
LFC55B14
Instruction / Installation Manual

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 5
Installation .................................................................................................................................... 6
Location ...................................................................................................................................................................... 6
Reversing the Door Swing.................................................................................................................................... 6
Door Space Requirements .................................................................................................................................10
Rear Spacer ..............................................................................................................................................................10
Levelling the Unit ..................................................................................................................................................10
Cleaning Before Use .............................................................................................................................................11
Before Using Your Unit.........................................................................................................................................11
Interior Accessories...............................................................................................................................................11
Product Overview.......................................................................................................................12
Operation ....................................................................................................................................13
Switching On Your Unit .......................................................................................................................................13
Adjusting the Temperature................................................................................................................................13
Noises Inside the Unit!.........................................................................................................................................13
Shopping for Chilled Foods...............................................................................................................................14
Tips for Keeping Food in the Unit....................................................................................................................14
Cleaning ......................................................................................................................................15
Defrosting ................................................................................................................................................................15
Cleaning the Interior and the Exterior of the Unit.....................................................................................15
Cleaning Tips...........................................................................................................................................................15
Maintenance ...............................................................................................................................16
Care When Handling / Moving Your Unit......................................................................................................16
Servicing...................................................................................................................................................................16
Switching O for Long Periods of Time.........................................................................................................16
Disposal.......................................................................................................................................16
Specications..............................................................................................................................17

4
Safety Warnings
For your continued safety and to reduce the risk of injury or electric shock,
please follow all the safety precautions listed below.
• Read all instructions carefully before using the unit and keep them for
future reference.
• Retain the manual. If you pass the unit onto a third party, make sure to
include this manual.
• This appliance is intended for indoor household use and similar
applications such as:
- farm houses and by clients in hotels, motels and other residential type
environment;
- bed and breakfast type environment;
- catering and similar non-retail applications.
• Ensure that the plug is easily accessible to enable disconnection from
the mains supply.
• If the mains cable is damaged, it must be replaced by the manufacturer,
its service agent or a qualied technician in order to avoid a hazard.
• Choose a location for your unit away from heat sources such as
radiators or res as refrigerant and vesicant are burnable.
• The unit must be manoeuvred by a minimum of 2 persons.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
• Children should be supervised to ensure that they do not play with the
unit.
• If your unit is tted with a lock to prevent children being trapped inside,
keep the key out of reach and not in the vicinity of the unit.
• Do not store explosive substances such as aerosol cans with a
ammable propellant in this appliance.

5
• Do not store bottles or glass containers in the freezer compartment.
Contents can expand when frozen (zzy drinks) which may break the
bottle and damage your freezer compartment. (If applicable)
WARNING
• Keep ventilation openings in the unit enclosure or in the built-in
structure clear of obstructions.
• Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
• Do not use electrical appliances inside the food storage
compartments of the unit, unless they are of the type
recommended by the manufacturer.
• Do not damage the refrigerant circuit (The refrigerant is a
very environmental-friendly gas but is also combustible. Take
care when transporting or moving the unit to ensure that the
refrigeration circuit is not damaged. In the event of damage
avoid naked ames or ignition sources and ventilate the room in
which the unit is placed for a few minutes.)
WARNING
IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORISED
SERVICE PERSONNEL TO CARRY OUT SERVICING OF REPAIRS WHICH
INVOLVE THE REMOVAL OF COVERS.
TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT ATTEMPT
REPAIRS YOURSELF.

6
The Main Unit
Upper balconies X2 Bottom balcony X1
Glass shelves X2 Salad Bin Cover X1
Upper drawers X3 Bottom drawer X1 Salad Bins X2
Egg Tray
Ice Tray Rear Spacers x 2
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Thank you for purchasing your new Logik Fridge Freezer.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Instruction Manual
Instruction
Manual

7
INSTALLATION
Installation
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
Levelling the Unit
To do this adjust the two levelling feet at the front of the unit.
If the unit is not level, the doors and magnetic seal alignments
will not be covered properly.
Max. 160°
Y mm
X mm
Installing the Spacers
Screw the spacers to the left and right side
of the unit’s rear part.
screw
Free Space Requirements
When installing the unit, ensure that 25 mm
of free space is left at both sides, 50 mm at
the rear of the unit and 25 mm at the top
of the unit. The door can be opened to the
right or the left, depending on which best
suits the location.
Please ensure there is more than twice the
width and depth distance space of the unit
to fully open the door to a maximum angle
of 160°.

8
INSTALLATION
1. Remove the 4 screws from top cover.
2. Lift the top cover away from the fridge.
3. Remove the three screws, then remove
the upper hinge that holds the door in
place. Lift the upper door and place it
on a padded surface to prevent it from
scratching.
Reversing the Door Swing
Tools required: Philips style screwdriver / Flat bladed screwdriver / Hexagonal spanner
• Ensure the unit is unplugged and empty.
• To take the door off it is necessary to tilt the unit backwards. You should rest the unit on
something solid, e.g. a chair just below the top panel.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
• If you want to have the door swing reversed, we recommend that you contact a qualified
technician. You should only try to reverse the door yourself if you believe that you are
qualified to do so.

9
INSTALLATION
4. Take off the middle hinge by removing
the screws. Lift the lower door and place
it on a padded surface to prevent it from
scratching.
5. Remove the lower screws, hinge bracket
and adjustable feet from the unit bottom.
Keep the matching bracket and foot
together.
unscrew
6. Remove the remaining screw-type
adjustable foot from the other side of
the unit bottom and transfer it to the
corresponding position on the opposite
side of the unit bottom.
7. Reattach the bottom door hinge, screws
and foot to the opposite side of the unit.
unscrew unscrew
unscrew screw
180˚

10
INSTALLATION
9. Remove and replace the pin on the
reverse side of the hinge.
10. Carefully set the upper door back into
place. Re-attach the re-assembled upper
door hinge on the opposite side of the
unit. Ensure the fridge door is aligned
horizontally and vertically so that the
seals are closed on all sides before finally
tightening the top hinge.
Middle hinge
Ensure the freezer door is aligned
horizontally and vertically, so that
the seals are closed on all sides
before finally tightening the hinge.
unscrew screw
180˚
11. On the top panel move the blanking
plate to the side opposite the hinge.
8. After replacing the freezer door, screw
the middle hinge back onto the opposite
side of the unit.
