Logik LTFFFS12 User manual

Tall Silver Frost Free Freezer
Instruction Manual
LTFFFS12

Contents
Unpacking.................................................................................................................................... 4
Installation ................................................................................................................................... 5
Location ..................................................................................................................................................................... 5
Reversing the Door Swing................................................................................................................................... 5
Levelling the Unit ................................................................................................................................................... 7
Cleaning Before Use .............................................................................................................................................. 8
Before Using Your Unit.......................................................................................................................................... 8
Product Overview........................................................................................................................ 9
Main Unit................................................................................................................................................................... 9
Control Panel............................................................................................................................................................ 9
Operation ................................................................................................................................... 10
Adjusting the Temperature...............................................................................................................................10
Fast Freezing...........................................................................................................................................................10
Alarm for Freezer ..................................................................................................................................................11
Noises Inside the Unit!........................................................................................................................................11
Shopping for Frozen Foods ..............................................................................................................................11
Preparations for Freezing...................................................................................................................................11
Defrosting Frozen Food......................................................................................................................................12
Cleaning ..................................................................................................................................... 13
Defrosting ...............................................................................................................................................................13
Cleaning the Interior and the Exterior of the Unit....................................................................................13
Cleaning Tips..........................................................................................................................................................13
Maintenance .............................................................................................................................. 14
Care When Handling / Moving the Unit.......................................................................................................14
Servicing..................................................................................................................................................................14
Switching O for Long Periods of Time........................................................................................................14
Disposal...................................................................................................................................... 14
Specications............................................................................................................................. 15
Safety Warnings......................................................................................................................... 16

Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit
Upper Freezer Frame x 3
P.N.: 1118674
Lower Freezer Frame
P.N.: 1118675
Lower & Bottom
Freezer Panel x 2
P.N.: 1403902
Upper Freezer Panel x 3
P.N.: 1403904
Bottom Freezer Frame
P.N.: 1118679
Freezer Slip
P.N.: 1403905
Ice Tray
P.N.: 1051965
Instruction Manual
P.N.: DSGLTFFFS12-001
Thank you for purchasing your new Logik Freezer.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
4

Location
When selecting a position for your unit you should make sure the floor is flat and firm, and
the room is well ventilated with an average room temperature of between 16°C and 38°C.
Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct
sunlight as it may increase the electrical consumption. Extreme cold ambient temperatures
may also cause the unit not to perform properly. This unit is not designed for use in a garage
or outdoor installation. Do not drape the unit with any covering.
When installing the unit, ensure that 100 mm of free space is left at both sides, 100 mm at
the rear and 75 mm at the top of the unit. The door can be opened to the right or the left,
depending on what better suits the location. Please ensure there is adequate space for the
door to fully open.
• Ensure the unit is unplugged and empty.
• Adjust the two levelling feet to their highest position.
• To take the door off it is necessary to tilt the unit backwards. You should rest the
unit on something solid so that it will not slip during the door reversing process.
• All parts removed must be saved to do the reinstallation of the door.
• Do not lay the unit flat as this may damage the coolant system.
• We recommend that 2 people handle the unit during assembly.
1. Tilt the unit slightly towards the rear and
prop it securely. Two people are required
to tilt the unit during the door reversal
process.
• If you want to have the door swing reversed, we recommend that you contact a
qualified technician. You should only try to reverse the door yourself if you believe
that you are qualified to do so.
• All parts removed must be saved to do the reinstallation of the door. You should
rest the unit on something solid so that it will not slip during the door change
process. Do not lay the unit flat as this may damage the coolant system. Ensure
the unit is unplugged and empty. .
Reversing the Door Swing
Tools required: Phillips style screwdriver / Flat bladed screwdriver / Hexagonal spanner.
Installation
INSTALLATION
5

2. Remove the four blanking plates
from the top of the freezer with a flat
bladed screwdriver. Remove the screws
underneath with a Phillips screwdriver.
3. Use the 8mm socket or spanner to
remove the three bolts above the door
hinge. Lift off the bracket. Remove the
freezer door.
4. Remove the pin from the bracket and
replace it into the same hole from the
other side.
5. Remove the hinge insert plate from the
bottom of the freezer door. Replace the
plate on the opposite side.
6. Tilt the freezer back, no more than 45°,
to access the bottom hinge and feet.
Remove the feet and the bolts securing
the right hand hinge plate and left hand
fixing plate.
7. Remove the pin and reattach it to where
the hinge bracket was located on the
opposite side (right to left). Place the
hinge on the opposite side of the cabinet,
secure it with three bolts, screw the foot
into position.
* All images are for reference only; please refer to your individual unit for actual item.
INSTALLATION
6

8. Place the fixing plate on the opposite
side of the appliance, secure it with three
bolts, and screw the foot into position.
9. Remove the handle covers and screws
which fix the handle on the right side of
door, then remove the handle and rotate
180 degree, position on the right side, fix
it by screws and cover the handle cover.
10. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
Levelling the Unit
To do this adjust two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal
alignments will not be covered properly.
* All images are for reference only; please refer to your individual unit for actual item.
INSTALLATION
7

Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm
water using a ‘wrung-out’ sponge or cloth. Wash the drawers in warm soapy water and dry
completely before replacing in the unit. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the
unit.
• Before Turning On!
Do not turn on until two hours after moving the unit. The coolant fluid needs time
to settle.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is
working properly and to allow it time to fall to the correct temperature. Your unit should not
be overfilled.
INSTALLATION
8

Product Overview
Main Unit
Upper
Freezer
Drawers
Lower
Freezer
Drawers
Bottom
Freezer
Drawers
Freezer
Flap
Control Panel
Levelling Feet
Ice Tray
Control Panel
Normal
Min Max
Alarm Power Super Super Freeze
1 2 3 4 5
1. Thermostat Control Dial
2. Alarm Indicator
3. Power Indicator
4. Super Indicator
5. Super Freeze Button
9

Operation
1. Connect the mains cable to the mains socket.
The power indicator will turn on. The internal
temperature of your unit is controlled by a
thermostat. There are three setting Min, Normal
and Max.
2. After the unit has been on for 20 minutes adjust
the thermostat control dial to Normal. This is the
recommended setting when operating at normal
room temperature (between 16°C and 38°C).
3. The unit may not operate at the correct
temperature if it is in a particularly hot or a
particularly cold room, or if you open the door
often.
4. To ensure that the unit is cool enough to
sufficiently chill your food, wait 24 hours before
filling it with food.
5. If you are concerned that your unit is not
being kept cold enough and wish to check the
temperature, you will need a special fridge/freezer
thermometer. These are available from most
supermarkets and hardware shops.
Place the thermometer in the centre of the unit,
where it can be read easily. Leave overnight, the
temperature in the unit should be between -18°C
or lower.
Adjusting the Temperature
The internal temperature of the unit is controlled by a thermostat. Max position is the coldest
setting and it is used for fast freezing. The recommended position is Normal, but it should be
adjusted according to the environment.
Fast Freezing
Fresh food should be frozen as quickly as possible. Press the Super Freeze button to makes your
unit operate at its coldest temperatures (approximately -28°C ) continuously. The Super indicator
will turn on. It helps to quickly freeze and retain more of the goodness of your food. Freezing
will be completed after 24 hours. After freezing your food, press the Super Freeze button. The
Super indicator will turn off. Never freeze large quantities of fresh food at one time.
Normal
Min Max
When the Super Freeze button is set on, the compressor works continuously to fast
freeze much hot food quickly. So you must turn off the Super Freeze button to normal
mode in 24 hours.
