Logik L22FED13 User manual

• Do not connect the TV to the mains supply until you have completed all the connections.
• If you watch TV using a set-top box, simply connect your TV and set-top box via a HDMI cable and select HDMI in the Input Source menu.
Connecting the Aerial and the Mains Socket
4
Operating Your Remote Control
2
Unpacking
1
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Installing the Base Stand
3
Remove all packaging from the TV. Retain the packaging. If you
dispose of it please do so according to any local regulations.
1. Lay the TV down on a flat surface with the back side facing up, and ideally at the edge of a table so that the base of the TV slightly overhangs on it. Please
make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed beneath the screen.
2. To install the TV stand, first attach the stand support to the TV by using screw A. Align with the screw hole then use screws to fix the stand support to the TV.
3. To install the base stand, align the screw holes, then secure with a screw driver (not included) using the 3 screw B provided.
Installing Batteries
1. Press and lift the back
cover to open the
battery compartment of
the remote control.
2. Insert two AAA size
batteries. Close the
battery compartment
cover.
Operation Range
Point the remote control
at the TV no more than 5
metres from the remote
control sensor on the TV and
within 60° in front of the
TV. The operating distance
may vary depending on the
brightness of the room.
1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the RF (75Ω) socket at the rear right side of your
TV.
2. Connect the mains cable to the mains socket after you have completed all the connections.
3. At this stage, the TV switches to standby mode. The red LED indicator will illuminate on the front panel of the TV.
4. In standby mode, press the button on the right side panel or on the remote control to turn the TV on. The red LED indicator will turn off.
For Help and Support Call
UK: 0344 561 1234
Ireland: 1890 818 575
1
2
USB HDMI2 HDMI1 PC IN RF
COMMON INTERFACE (CI)
HEADPHONE PC AUDIO
RF coaxial cable
(not included)
OR
To the mains socket
AUDIO
TV
Remote Control
Screw A x 1
(4 x 20PWB)
Quick Start Guide
TV Stand Support
AAA Batteries x 2
Screw B x 3
(4 x 10PWB)
TV Base
Rear Spacers x 4
Instruction Manual
AUDIO
30° 30°
5M
Screw A x 1
(4 x 20PWB)
screw in
Screw B x 3
(4 x 10PWB)
TV Front
Base Stand
Front
screw in
22” LED TV with DVD Player
L22FED13 / L22FEDW15
Quick Start Guide
Thank you for purchasing your new Logik TV.
Your new TV incorporates the latest technology to enhance your viewing
experience. We would suggest that you allow about 20 mins for initial setup.
Please follow this guide for a successful first time installation.
The latest eco-friendly power-saving technology will switch off the TV if
device is left on and idle for 4 hours. Please refer to “Auto Standby” under
the “Time Settings” section of the instruction manual for more detail.
Install the batteries correctly by following the polarity (+ and –)
indications in the battery compartment.

Turning the TV On for the First Time
5
Target Region Setting (UK only)
During tuning your TV may have received signals from more than one transmitter. If this has occurred
the Target Region Setting screen will be displayed. This will enable you to select the correct regional
transmission for the local news service that you require.
Press the buttons to select each option’s setting and then press the OK button to confirm.
Country Code This will be shown as GBR for the UK.
Primary Region This will show the regional country (e.g. England, Wales, Scotland, NI).
Secondary
Region
This will allow you to set the region for your local news service on BBC and ITV (e.g.
London, Beds and Cambs etc).
Tertiary Region You may receive signals from more than one transmitter within the Secondary
Region, (e.g Beds and Cambs may have Luton or Sandy Heath).
The first time you turn the TV on, it will go straight into the First Time Installation menu.
TV : 0 Channel(s)
Channel Tuning
DTV : 3 Channel(s)
Radio : 0 Channel(s)
Data : 0 Channel(s)
36%... 668.75MHz (DTV)
Press MENU to skip.
Target Region Setting
Country Code GBR
Primary Region England
Secondary Region
Tertiary Region
London
1. Please ensure the aerial is plugged in and then press the OK button.
5. DTV Channel tuning will commence. This operation may take a few minutes. The display will show
the progress of the tuning and the number of channels found.
2. Press the buttons to select your desired language to be displayed on the menu. The
default on-screen menu language is set as English. Press the OK button to confirm.
3. Press the buttons to select your desired mode and then press the OK button. Press the
button to select Yes to confirm or the button to select No to cancel and return to the Mode
Select menu.
Home Mode Intended for use in home environment.
Shop Mode Intended for use in shop environment.
If you select Ireland as the country where you will operate the TV, a pop-up screen will be display. You will
need a 4-digit activation code for Irish tuning. This code can be found in-store, on the back of your receipt
(if bought in Ireland), or call the customer service team / KNOWHOW.
If you are going to watch TV using a set-top box, press the EXIT button on the remote control then skip
this section. Then press the INPUT button on the remote control to select HDMI mode.
4. In the Tune Type menu, press the buttons to select DTV / ATV / DTV+ATV. Press the
button and then press the buttons to select the country where you will operate the TV.
Press the OK button to confirm.
First Time Installation
Please ensure aerial is plugged in!
Then press OK button.
OK
English
Svenska
Dansk
Česky
Slovak
Norsk
Suomi
Please select an OSD Language
OK
Home Mode
Shop Mode
Mode Select
Tune Type DTV
MENU
UK
Sweden
France
Ireland
Finland
Spain
Denmark
Portugal
Norway
Well done, your new TV is now ready to use. You will find that there are many exciting features available. To get to know all these features, please
take some time to read the instruction manual provided with your TV.
If after reading the instruction manual you have additional questions related to the use of your TV please call:
• UK Call Centre on 0344 561 1234. • Ireland Call Center on 1 890 818 575.
(QSG-L22FED13(F)_W15-150824V3)
