Logik L24HED16 User manual

Instruction Manual
24” LED TV
with built-in DVD Player
L24HED16

Contents
Safety Warnings .................................................................................................................................................................................6
Preparation.........................................................................................................................................................................................8
Unpacking the TV ...............................................................................................................................................................................................................8
Installing / Removing the Base Stand .........................................................................................................................................................................9
− Installing the Base Stand......................................................................................................................................................................................9
− Mounting the TV to a Wall...................................................................................................................................................................................9
Front / Right Side View and Rear Controls...............................................................................................................................................................10
Rear View and Sockets....................................................................................................................................................................................................11
Installing Batteries in the Remote Control ..............................................................................................................................................................12
Remote Control Operation Range..............................................................................................................................................................................12
Remote Control .................................................................................................................................................................................................................13
Connections......................................................................................................................................................................................15
Making Video and Audio Connections.....................................................................................................................................................................15
Connecting an AV Device Using an HDMI Cable...................................................................................................................................................15
Connecting a Computer Using a VGA Cable ..........................................................................................................................................................16
Connecting an AV Device Using a Component (YPbPr) Cable ........................................................................................................................16
Connecting an AV Device Using a SCART Cable ...................................................................................................................................................17
Connecting an AV Device Using Composite Cable..............................................................................................................................................17
Connecting a Coaxial Audio Receiver.......................................................................................................................................................................18
Connecting Headphones...............................................................................................................................................................................................18
Initial Setup ......................................................................................................................................................................................19
Turning the TV On for the First Time .........................................................................................................................................................................19
− First Time Setup ....................................................................................................................................................................................................19
− Target Region Setting (UK Only) .................................................................................................................................................................... 20
− Selecting the Input Source................................................................................................................................................................................21
− Channel Selection ...............................................................................................................................................................................................21
− Listening to the Radio (Radio Mode).............................................................................................................................................................21
− Display Channel Information ...........................................................................................................................................................................21
− Volume Adjustment.............................................................................................................................................................................................21
Customising TV Settings .................................................................................................................................................................22
Picture Setting .................................................................................................................................................................................................................. 22
Sound Setting ................................................................................................................................................................................................................... 23
− Stereo / Dual Sound Reception (ATV Mode).............................................................................................................................................. 23
Channel Setting................................................................................................................................................................................................................ 24
− Auto Scan................................................................................................................................................................................................................ 24
− DTV Manual Scan (DTV Mode)........................................................................................................................................................................ 25
− ATV Manual Scan (ATV Mode)......................................................................................................................................................................... 26
− Auto Channel Update (DTV Mode)................................................................................................................................................................ 27
− Channel Edit (DTV Mode).................................................................................................................................................................................. 27
− Channel Edit (ATV Mode).................................................................................................................................................................................. 28
− Favourite Manager .............................................................................................................................................................................................. 29
− Common Interface (DTV Mode) ..................................................................................................................................................................... 30
− Signal Information (DTV Mode).......................................................................................................................................................................31
Lock Setting ....................................................................................................................................................................................................................... 32
− Lock System........................................................................................................................................................................................................... 32
− Channel Locks....................................................................................................................................................................................................... 32
− Parental Rating ..................................................................................................................................................................................................... 33
− Lock Keypad........................................................................................................................................................................................................... 34
− New Password....................................................................................................................................................................................................... 35
− Clear Lock ............................................................................................................................................................................................................... 35
Setup Setting..................................................................................................................................................................................................................... 36
− OSD Language...................................................................................................................................................................................................... 36
− Audio Languages (DTV Mode)........................................................................................................................................................................ 36
− Subtitle (DTV Mode) ........................................................................................................................................................................................... 37
− Teletext.................................................................................................................................................................................................................... 38

− Blue Screen ............................................................................................................................................................................................................ 39
− Mode Setting......................................................................................................................................................................................................... 39
− Time Settings ........................................................................................................................................................................................................ 40
− HDMI CEC Control.................................................................................................................................................................................................41
− PVR Settings (DTV Mode).................................................................................................................................................................................. 42
− OAD (Over Air Download) ................................................................................................................................................................................44
− Restore Factory Default.....................................................................................................................................................................................44
Using the Features ...........................................................................................................................................................................46
EPG (Electronic Programme Guide) (DTV Mode) ................................................................................................................................................. 46
− Switch On / O EPG............................................................................................................................................................................................. 46
− Select a Programme ........................................................................................................................................................................................... 46
Red Button (Interactive Services) (DTV Mode)...................................................................................................................................................... 47
− Accessing the Information ............................................................................................................................................................................... 47
Entertainment ..................................................................................................................................................................................48
Connecting a USB Storage Device............................................................................................................................................................................. 48
Viewing Photos................................................................................................................................................................................................................. 48
Listening to Music............................................................................................................................................................................................................ 49
Viewing Movies ................................................................................................................................................................................................................ 50
My Text................................................................................................................................................................................................................................. 50
PVR (Personal Video Recorder).......................................................................................................................................................52
Time Shift Function......................................................................................................................................................................................................... 52
Recording DTV Programme onto a USB Storage Device .................................................................................................................................. 53
Timer Programming (DTV Mode)............................................................................................................................................................................... 54
Play Recorded Programme .......................................................................................................................................................................................... 56
Using the DVD Features...................................................................................................................................................................58
Using the Built-in DVD Player...................................................................................................................................................................................... 58
Compatible Disc Types .................................................................................................................................................................................................. 58
− Supported Formats............................................................................................................................................................................................. 58
− Region Code.......................................................................................................................................................................................................... 58
Basic DVD Playback Functions.................................................................................................................................................................................... 59
− Playing the DVD ................................................................................................................................................................................................... 59
− Menu Playback (for DVD).................................................................................................................................................................................. 59
− Stopping Playback............................................................................................................................................................................................... 59
− Previous / Next (for DVD / CD / Multimedia discs) .................................................................................................................................. 59
− Forward / Backward (for DVD / CD / Multimedia discs)......................................................................................................................... 59
− Pause (for DVD / CD / Multimedia discs)..................................................................................................................................................... 59
− Repeat (for DVD / CD / Multimedia discs)................................................................................................................................................... 59
− Display (for DVD / Multimedia discs)............................................................................................................................................................ 60
− Angle (for DVD)..................................................................................................................................................................................................... 60
− Zoom (for DVD)..................................................................................................................................................................................................... 60
− Goto (for DVD / CD / Multimedia discs)....................................................................................................................................................... 60
− Audio (for DVD / CD)........................................................................................................................................................................................... 60
− Repeat A-B (for DVD / CD)................................................................................................................................................................................. 60
Program (for DVD) ............................................................................................................................................................................................................61
Using the DVD General Setup Page.......................................................................................................................................................................... 62
Using the DVD Audio Setup Page.............................................................................................................................................................................. 63
Using the DVD Preference Setup Page.................................................................................................................................................................... 63
Others Information..........................................................................................................................................................................65
Maintenance...................................................................................................................................................................................................................... 65
Hints and Tips.................................................................................................................................................................................................................... 66
Display Modes................................................................................................................................................................................................................... 68
Product Fiche and Specications .............................................................................................................................................................................. 69
Remote Control Code..................................................................................................................................................................................................... 71
− Sky Code ................................................................................................................................................................................................................. 71
Useful Information and Licences ............................................................................................................................................................................... 71

GB
Safety Warnings
6
Safety Warnings
• Read all the instructions carefully before using the unit
and keep them for future reference.
• Retain the manual. If you pass the unit onto a third
party make sure to include this manual.
• Check that the voltage marked on the rating label
matches your mains voltage.
Damage
• Please inspect the unit for damage after unpacking.
• Do not continue to operate the unit if you are in any
doubt about it working normally, or if it is damaged
in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Unit
• The unit must be placed on a flat stable surface and
should not be subjected to vibrations.
• Do not place the unit on sloped or unstable surfaces as
the unit may fall off or tip over.
• The mains socket must be located near the unit and
should be easily accessible.
• This unit is designed for indoor, domestic use only.
Temperature
• Avoid extreme degrees of temperature, either hot or
cold. Place the unit well away from heat sources such
as radiators or gas / electric fires.
• Avoid exposure to direct sunlight and other sources of
heat.
Naked Flames
• Never place any type of candle or naked flame on the
top of or near the unit.
Moisture
• To reduce the risk of fire, electric shock or product
damage, do not expose this unit to rain, moisture,
dripping or splashing. No objects filled with liquids,
such as vases, should be placed on the unit.
• If you spill any liquid into the unit, it can cause serious
damage. Switch it off at the mains immediately.
Withdraw the mains plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or fire hazard
due to overheating, ensure that curtains and other
materials do not obstruct the ventilation vents.
• Do not install or place this unit in a bookcase, built-in
cabinet or in another confined space. Ensure the unit is
well ventilated.
• Make sure that there is a gap of at least 10 cm on both
sides and a gap of 20 cm at the top.
Safety
• Always disconnect the unit from the mains supply
before connecting / disconnecting other devices or
moving the unit.
• Unplug the unit from the mains socket during a
lightning storm.
Mains Cable
• Make sure the unit or unit stand is not resting on top of
the mains cable, as the weight of the unit may damage
the mains cable and create a safety hazard.
• If the mains cable is damaged it must be replaced
by the manufacturer, its service agent, or similarly
qualified persons in order to avoid a hazard.
Interference
• Do not place the unit on or near appliances which may
cause electromagnetic interference. If you do, it may
adversely affect the operating performance of the unit,
and cause a distorted picture or sound.
Optimum viewing
• View the unit in moderate light to prevent eye strain. It
is recommended to watch the unit from a distance
3-7 times that of the screen height.
LCD screen
• The LCD screen is manufactured using high-precision
technology. However, some tiny black points and /
or bright points (red, blue or green in colour) may
constantly appear on the LCD screen. These points
are generated in the manufacturing process and are
normal.
Screen Burn
• A characteristic of Plasma and TV Panels is that
displaying the same image for a long time may cause
a permanent after-image to remain on the screen. This
is called screen burn. Most pictures shown on the unit
will be constantly moving and fill the screen.
• Examples of images that you need to watch out for are
as follows (this is not an all-inclusive list):
1. Black Bars: If black bars appear at the left / right or
top / bottom of the screen, it is recommended to
change the format so that the picture fills the entire
screen.
2. TV Channel Logos: e.g. Shopping channel logos
and pricing displays - especially if they are bright
and stationary. Moving or low-contrast graphics are
less likely to cause ageing of the screen.
3. Time Displays
4. Teletext: Do not view a stationary page for long
periods of time.
5. TV Menus
6. Pause Mode: Do not leave the screen in pause
mode for long periods of time, e.g. when watching
videos.
• To prevent screen burn if viewing any of the above for
long periods of time, reduce contrast and brightness
when viewing. Once burn-in occurs it will never
disappear completely.
Safety Warnings
10 cm 10 cm
20 cm
10 cm

GB
Safety Warnings
7
Earphones
• Listening to loud sounds for prolonged periods of time
may permanently damage your hearing.
• Before putting on earphones, turn the volume down
then put the earphones on and slowly increase the
volume until you reach a comfortable listening level.
Standby
• The button on the remote control does not switch
off the unit completely. The unit will continue to draw
electricity from the mains supply while in standby. In
the interests of safety and to avoid unnecessary energy
consumption, never leave the unit in standby while
unattended for long periods of time, e.g. overnight,
while on holiday or while out of the house. Disconnect
the mains plug from the mains socket.
Batteries
• Batteries used in the remote control for this unit
are easily swallowed by young children and this is
dangerous.
• Keep loose batteries away from young children and
make sure that the battery holder tray is secure in the
remote control. Seek medical advice if you believe a
cell has been swallowed.
• Please dispose of batteries correctly by following the
guidance in this manual.
• The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like.
Supervision
• Children should be supervised to ensure that they do
not play with the unit and the remote control.
• Never let anyone especially children push anything
into the holes, slots or any other openings in the case -
this could result in a fatal electric shock.
DVD
• Class 1 Laser Product
This unit utilises a laser. Use
of controls, adjustments or
performance of procedures other
than those specified herein may
result in hazardous radiation
exposure.
• Before moving the unit, ensure the disc tray is empty.
• Always remove the disc when the unit is not in use.
• Failure to do so will risk severely damaging the disc
and the unit.
• Do not stack devices, heat from other devices may
aect the performance of the unit.
CLASS 1
LASER PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the unit’s
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
manual accompanying the unit.
Service
• To reduce the risk of electric shock, do not remove
screws. The unit does not contain any user-serviceable
parts. Please leave all maintenance work to qualified
personnel.
• Do not open any fixed covers as this may expose
dangerous voltages.
Maintenance
• Ensure to unplug the unit from the mains socket before
cleaning.
• Do not use any type of abrasive pad or abrasive
cleaning solutions as these may damage the unit’s
surface.
• Do not use liquids to clean the unit.
• The wall socket plug is used as a disconnect device, the
disconnect device should be readily accessible.
• This equipment is a Class II or double insulated
electrical appliance. It has been designed in such
a way that it does not require a safety connection
to electrical earth.
To prevent the spread of fire,
keep candles or other open
flames away from this product
at all times.

GB
Preparation
8
Unpacking the TV
Remove all packaging from the TV. Retain the packaging. If you dispose of it please do so according to local regulations.
The following items are included:
Thank you for purchasing your new Logik TV.
Your new TV has many features and incorporates the latest technology to enhance your viewing
experience. We recommend that you spend some time reading this instruction manual so that you fully
understand these features. You will also find some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this instruction manual for future reference.
• If items are missing, or damaged please contact Partmaster (UK only). Tel: [phone] for assistance.
• If you require additional assistance:
for UK, please call our UK Call Centre on 0344 561 1234.
for Ireland, please call our Ireland Call Center on 1 890 818 575.
Preparation
Instruction Manual Quick Start Guide
TV Base
TV Stand Support
Remote Control / AAA Batteries x 2
AUDIO
TV
Screw (TA3 x 10mm) x 6 Component Adapter Cable Composite Adapter Cable
Quick Start Guide

GB
Preparation
9
1. To remove the stand assembly, untighten the screws
holding the stand assembly to the rear of the TV. Slide
the stand assembly out.
2. Mounting on the wall. This TV is designed to be
wall-mounted with a standard 200 mm x 100 mm
mounting kit (sold separately) designed for flat-panel
TVs. Mount this TV according to the instructions
included in the mounting kit. Due to space restrictions,
we recommend that you make all connections (refer to
page 15-18 and page 48 for details) before mounting
on to the wall.
1. Disconnect all cables connected to the TV.
2. Lay the TV down on a flat surface with the back side facing up, and ideally at the edge of a table so that the base of the TV
slightly overhangs on it. Please make sure a soft cushioned material (such as a pillow or thick piece of foam) is placed beneath
the screen.
Installing the Base Stand
1. To install the TV stand, first attach the stand support to the TV by using 3 screws. Align
with the screw holes then use 3 screws to fix the stand support to the TV.
2. To install the base stand,
align the screw holes, then
secure with a screw driver (not
included) using the 3 screws
provided.
Mounting the TV to a Wall
Installing / Removing the Base Stand
The screw holes will
only align if the front of
the base stand is at the
front of the TV.
The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be
sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it.
DO NOT exert pressure on the front of the TV at any time because the screen could crack.
Remove the stand assembly before mounting the TV onto the wall.
Screw x 3
TV Front Base Stand
Front
screw in
Screw x 3
unscrew
Screw x 3
screw in
Keep all the spare screws should you want
to use the stand assembly option.
200 mm
100 mm
Four mounting holes
(size M4 screw)
• Please read this instruction manual carefully while setting up your TV.
• If you require additional assistance:
for UK, please call our UK Call Centre on 0344 561 1234.
for Ireland, please call our Ireland Call Center on 1 890 818 575.

GB
Preparation
10
Front / Right Side View and Rear Controls
Item Description
1IR (Infrared Receiver) Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode. The LED will illuminate blue and then blink red and blue confirming that a timer
recording programme has started in the standby mode.
3 Disc Slot Insert a disc with the label side facing towards the front of the TV. (12 cm discs only.
Don't insert 8 cm discs.)
4 Press to eject disc. (DVD mode)
5 Press to start playback or pause. (DVD mode)
6 VOL + / – Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
7 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
8MENU Displays the OSD (on screen display) menu.
9 INPUT
Press to select among different input signal sources:
DTV / ATV / AV / SCART / YPbPr / HDMI / PC / USB / DVD.
Use the buttons on the remote control to select the input, and then press the OK
button to confirm.
10 Switches the TV on from standby mode.
Switches the TV back to standby mode.
3
1
2
4
5
6
7
8
9
10
INPUT
