Logik L17MSS14 User manual

Instruction Manual
17 Litre Stainless Steel
Microwave
L17MSS14
L17MSS14_IB_131223_grace.indd 1 23/12/2013 10:55 AM

L17MSS14_IB_131223_grace.indd 2 23/12/2013 10:55 AM

Contents
Safety Warnings............................................................................................................................ 4
Unpacking..................................................................................................................................... 9
Getting Ready ............................................................................................................................. 10
Introducing Microwave Cooking............................................................................................... 11
Cooking with a Microwave.................................................................................................................................11
Checking Your Cooking Utensils......................................................................................................................12
Using Aluminium Foil in Your Microwave..................................................................................................... 12
Microwave Heating Categories ........................................................................................................................13
Steam......................................................................................................................................................................... 14
Condensation..........................................................................................................................................................14
Product Overview....................................................................................................................... 15
The Main Unit..........................................................................................................................................................15
The Control Panel ..................................................................................................................................................15
Checking Your Microwave.......................................................................................................... 16
Microwave Cooking.................................................................................................................... 17
Cooking Table .........................................................................................................................................................17
Defrosting ................................................................................................................................... 18
Defrosting Table.....................................................................................................................................................18
Cleaning Your Microwave........................................................................................................... 19
Frequently Asked Questions ..................................................................................................... 20
Specications.............................................................................................................................. 21
L17MSS14_IB_131223_grace.indd 3 23/12/2013 10:55 AM

Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
General Safety
• Switch o and unplug before tting or removing parts/attachments,
after use and before cleaning.
• Keep your ngers away from moving parts and tted attachments.
• Never use a damaged appliance.
• Never operate the appliance when it is empty.
• Keep the mains cord out of reach from children.
• Keep the unit, mains cord and plug away from water.
• Never exceed the maximum capacities.
• When using an attachment, read the accompanying safety instructions.
• Take care when lifting this appliance as it is heavy.
• You should always have your appliance checked by a qualied service
agent if it has been dropped or damaged to ensure it is safe to use.
• This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance.
• Keep the appliance and its cord out of reach of children less than 8
years.
• Only use the appliance for its intended indoor, household, domestic
use.
Maintenance of Your Microwave
Warning: It is hazardous for anyone other than a qualied service agent to
carry out any service or repair operation which involves the removal of a
cover that gives protection against exposure to microwave energy.
Warning: If the door or door seals are damaged, the microwave must not
be operated until it has been repaired by a qualied service agent.
• If smoke is observed, switch o and unplug the microwave and keep
the door closed in order to stie any ames.
• If the mains cord is damaged, it must be replaced by a qualied service
agent.
4
L17MSS14_IB_131223_grace.indd 4 23/12/2013 10:55 AM

• If you have a pacemaker, please contact your doctor before using a
microwave.
Microwave Use
• This microwave is not intended for commercial use.
• It should never be used for drying clothes or for other non-food
purposes, including any type of storage, which may lead to risk of injury,
ignition or re.
• This microwave can only be used indoors in a dry, well-ventilated,
domestic, indoor area.
• Do not place the microwave in a cabinet.
• Install or locate this oven only in accordance with the installation
instructions provided.
• The appliance is not intended to be operated by means of an external
timer or separate remote-control system.
• The microwave should not be left unattended when in use.
• The temperature of accessible surfaces may be high when the
microwave is operating.
• To prevent high moisture content gathering inside the microwave
cavity, open the door immediately after the cooking function has
stopped to allow steam to escape.
• Only use utensils that are suitable for microwave use.
• Care should be taken when using paper, plastic, wooden or other
combustible materials in the microwave as they can catch re.
• Oil & fat for deep frying should not be heated in the microwave.
• Only use cling lm designed for microwave use and take extra care
when removing the lm to avoid steam burns.
• Only heat popcorn that has been designed for microwave use.
• Do not operate the microwave empty as this could damage the
product.
• Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
• Do not obstruct the unit’s front or door, or allow soiling or cleaner
residue to accumulate on sealing surfaces.
Cooking Use
• As the power of dierent microwaves can vary considerably, care must
be taken when rst using this microwave as it may cook faster than
expected.
5
L17MSS14_IB_131223_grace.indd 5 23/12/2013 10:55 AM

• Do not leave the microwave unattended during use.
• Take care when cooking food with a high sugar or fat content, such as
Christmas pudding or fruitcake. The sugar or fat can overheat and in
some cases catch re.
• Do not overcook food.
• Remove wire twist-ties and metal handles from paper or plastic
containers/bags before placing them in the oven.
Warning: Only allow children to use the microwave without supervision
when adequate instructions have given so that the child is able to use the
microwave in a safe way and understands the hazards of improper use; DO
NOT assume that because a child has mastered one cooking skill he/ she
can cook everything without close supervision. The microwave MUST NOT
be treated nor used like a toy.
Fire!
In the event of re:
• Keep the microwave door closed.
Turn o the power.
• Unplug the microwave from the mains power.
First Aid
Treat scalding by:
• Quickly placing the scald under cold running water for at least 10
minutes.
• Cover with a clean dry dressing. Do not use creams, oils or lotions.
Cleaning Your Microwave
• The microwave should be cleaned regularly and food deposits removed.
Failure to maintain the microwave in a clean condition can aect the
life of the microwave and possibly result in a hazardous situation. (See
cleaning your microwave.)
• Do not use a steam cleaner to clean the unit.
Do Not Use These in Your Microwave
• Metal objects are not to be used in the microwave. These include:
- Metal cooking utensils
- Metal plates or trays
- Wine twist ties
- Crockery with metal trims
6
L17MSS14_IB_131223_grace.indd 6 23/12/2013 10:55 AM

- Meat thermometer
• Never use equipment made of metal, except aluminium foil in your
microwave. The microwave energy cannot pass through the metal so it
bounces o and sparks against the inside of the microwave.
• Stop the microwave straight away if any equipment is causing sparks.
• Remember that some crockery has a metal trim around the edge. Even
this trim can cause sparks.
Containers
WARNING: Pressure will build up in sealed containers and can cause them
to explode. Therefore, do not use the following in your microwave:
- Sealed containers
- Capped bottles
- Vacuum containers
- Sealed jars
- Hard-boiled eggs
- Eggs in their shells
• Always pierce the skin of fruit and vegetables, such as potatoes.
• Never use scratched, cracked or damaged glass in a microwave.
Damaged glass can explode.
• When heating food in plastic or paper containers, keep an eye on the
microwave due to the possibility of ignition.
Delayed Boiling
Liquids heated in a microwave can boil up when removing them from the
microwave.
Take the following precautions:
• Always stir liquids, before and after cooking.
• Allow them to stand.
• Use containers that are wider at the top than at the bottom.
Preparing Food for Babies
• Extra care must be taken when preparing food or drink for babies and
small children.
• Always test the food or liquid temperature before feeding it to the baby.
• When using a baby bottle, ensure the teat is removed before heating.
• When warming baby food or milk, ensure that it is thoroughly stirred
and at a safe consumable temperature.
7
L17MSS14_IB_131223_grace.indd 7 23/12/2013 10:55 AM

Caution!
Hot Surface
During cooking, accessible surfaces will become hot. Do not touch
these surfaces or the outer casing of the microwave. Care should
be taken not to store any items on top of your microwave.
Earthing Instructions
WARNING: THIS APPLIANCE MUST BE EARTHED.
This appliance is equipped with a mains cable having an earthed
plug.
The plug must be plugged into an appropriate mains socket that
is installed and earthed in accordance with all local standards and
requirements.
WARNING!
• Improper connection of the appliance-earthing conductor can result in
a risk of an electric shock.
• Check with a qualied service agent if you doubt the appliance is
properly earthed.
• Never modify the plug provided with the appliance.
• If the plug does not t properly in the mains socket, contact a qualied
service agent to install a proper mains socket.
• This appliance is not intended to be operated by means of an external
timer or separate remote-control system.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the unit’s enclosure that
may be of sucient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and
maintenance (servicing) instructions in the manual accompanying
the unit.
8
L17MSS14_IB_131223_grace.indd 8 23/12/2013 10:55 AM

Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
The Main Unit Turntable Plate x 1
Turntable Support x 1 Instruction Manual
Thank you for purchasing your new Logik Microwave.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction manual in
order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
* All images in this document are for indication only; please see your individual product for details.
Instruction
Manual
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
9
L17MSS14_IB_131223_grace.indd 9 23/12/2013 10:55 AM

2. Choose a flat, stable work surface for
your microwave away from heat sources
such as radiators or fires and away from
cold areas. The surface should be at least
85cm above the floor. You should allow
a 20 cm space all around the microwave
and 30 cm above so that warm air can
escape from the vents during cooking.
This microwave is not designed to be
built in. Do not block any intake or outlet
openings as this can damage the unit.
Getting Ready
This microwave is designed for home use. It should not be used for commercial catering.
1. After unpacking your microwave, check that it has not been damaged whilst in the box.
Make sure there are no dents, and the door closes properly. A damaged microwave could
allow microwave energy to escape. Make sure that you have taken out all of the packaging
from the inside of the microwave. Please dispose of the plastic wrappings/ bags safely and
keep out of the reach of babies and young children.
3. Plug your microwave into a standard
household electrical socket (AC 240 volt,
13 amp rated). Avoid using a socket that
also has an adaptor and other equipment
plugged in. Do not use a multi-adapter.
4. Put the turntable support inside the
microwave and place the glass turntable
plate on top of the support. The turntable
support is shaped to sit securely on
the spindle. You must always use the
turntable plate and support whenever
you use the microwave.
30cm
20cm20cm
Underside View
5. To protect your work surface, we
recommend that you fix some non-slip
cushion buttons (not included) to the
underside of the microwave.
Remove the turntable plate and
turntable support before turning the
microwave upside down.
10
L17MSS14_IB_131223_grace.indd 10 23/12/2013 10:55 AM
