Logik L21CS10 User manual

Combination Microwave
Instruction Manual
L21CS10
L21CS10_IB_GB_100927_Zell.indd 1 27/09/2010 3:49 PM

Contents
Unpacking.................................................................................................................................... 3
Product Overview........................................................................................................................ 4
Using Aluminium Foil in Your Microwave .................................................................................. 5
Getting Ready ............................................................................................................................. 6
Introducing Microwave Cooking................................................................................................ 7
Cooking with a Microwave.................................................................................................................................. 7
Checking your cooking utensils........................................................................................................................8
Microwave Heating Categories ......................................................................................................................... 9
Steam........................................................................................................................................................................10
Condensation.........................................................................................................................................................10
Checking your Microwave.................................................................................................................................10
Setting the Child Lock ...............................................................................................................11
Clock Setting.............................................................................................................................. 12
Microwave Cooking................................................................................................................... 13
Grill Cooking .............................................................................................................................. 14
Combine Function ..................................................................................................................... 15
Convection Cooking (without Preheating).............................................................................. 16
Convection Cooking (with Preheating).................................................................................... 17
Auto Menu Cooking................................................................................................................... 18
Defrost By Time.......................................................................................................................... 20
Defrost By Weight...................................................................................................................... 21
Cleaning Your Microwave.......................................................................................................... 22
Frequently Asked Questions .................................................................................................... 23
Specication .............................................................................................................................. 24
Safety Warnings......................................................................................................................... 25
L21CS10_IB_GB_100927_Zell.indd 2 27/09/2010 3:49 PM

3
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
The Main Unit Glass Turntable x 1
P.N.: 262100500003
Turntable Ring x 1
P.N.: 252200200008
Grill Rack x 1
P.N.: 256511700941
Defrost Rack x 1
P.N.: 250900200006
Instruction Manual x 1
P.N.: 261800306333
Thank you for buying the new Logik Microwave.
These operating instructions will help you use it properly and safely.
We recommend that you spend some time reading this instruction manual in order
that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
L21CS10_IB_GB_100927_Zell.indd 3 27/09/2010 3:49 PM

4
Product Overview
The Main Unit
The Control Panel
Control Panel
LED Display
Shows the clock or
cooking time / setting.
MICROWAVE Button
Use this button to select the
microwave function.
CONVECTION Button
Use this button to select
the function of convection.
CLOCK Button
Use this button to set the
pre set function.
GRILL Button
Use this button to select the
function of grill.
COMBINE Button
Use this button to select
the function of combination.
START Button
To start cooking.
DEFROST BY W.T. Button
Use this button to set
defrost by weight.
DEFROST BY TIME Button
Use this button to set
defrost by time.
STOP/CLEAR Button
This button will stop
cooking and clear cooking
settings.
L21CS10_IB_GB_100927_Zell.indd 4 27/09/2010 3:49 PM

5
Using Aluminium Foil in Your Microwave
It is safe to use aluminium foil in your microwave as long as you follow these safety guidelines.
As with all metal, microwave energy cannot pass through foil, but provided that you keep the foil
away from the side of the microwave it will not cause sparks and there will not be any damage to your
microwave.
Using foil is a good way of shielding parts of food that you do not want to cook as quickly as others –
perhaps where the food is narrower and would otherwise overcook.
Place the foil over the area you want to shield, taking care that the foil will not touch the sides of the
microwave when the turntable rotates. Only use one piece of foil at a time so that you do not get sparks
between the separate pieces.
Follow these guidelines when using foil in your microwave:
• Remove foil lids from containers before using in the microwave. Some lids are made of card with a foil
covering – these should be removed too. Use a microwave safe transparent lid if possible.
• Stir food during cooking if the container has a lid or film cover.
• Always use the glass turntable.
• Use shallow containers with a large surface area. Do not use containers that are more than 1.25in
(3.5cm) deep.
• Use gloves when handling hot foil containers.
• Do not completely cover food with foil. The microwave energy cannot pass through the foil so the food
will not cook.
• Do not let aluminium foil touch the inside of the microwave.
• Do not use more than one piece of foil in the microwave at the same time.
L21CS10_IB_GB_100927_Zell.indd 5 27/09/2010 3:49 PM

6
2. Choose a flat work surface for your microwave
away from heat sources such as radiators or
fires and away from cold areas. You should
allow a 10cm space all around the microwave
and 30cm above so that warm air can
escape from the vents during cooking – This
microwave is not designed to be built in.
Getting Ready
This microwave is designed for home use. It should not be used for commercial catering.
1. After unpacking your microwave, check that it has not been damaged whilst in the box. Make sure
there are no dents, and the door closes properly. A damaged microwave could allow microwave energy
to escape. Make sure that you have taken out all of the packaging from the inside of the microwave.
Please dispose of the plastic wrappings/ bags safely and keep out of the reach of babies and young
children.
3. Plug your microwave into a standard
household electrical socket (230 - 240 volt,
13 amp rated). Avoid using a socket that also
has an adaptor and other equipment plugged
in. Do not use a multi adaptor.
4. Put the turntable ring inside the microwave
and place the glass turntable on top of the
ring. The turntable is shaped to sit securely on
the spindle. You must always use the turntable
and ring whenever you use the microwave.
30cm
10cm10cm
L21CS10_IB_GB_100927_Zell.indd 6 27/09/2010 3:49 PM

7
Introducing Microwave Cooking
Always remember the basic safeguards you would follow when using any cooking equipment or handling
hot food.
This page gives some of the basic guidelines for microwave cooking. If you are unfamiliar with using a
microwave, there is more information at the back of this instruction booklet.
Cooking with a Microwave
• Cooking with a microwave is much faster than conventional cooking and, whilst you should make sure
that food is fully cooked, you should be careful not to overcook it.
• If you are cooking a number of individual foods at the same time, such as baked potatoes or small
cakes, arrange them evenly on the turntable so that they cook evenly. Never stack food in your
microwave.
• Meat and poultry which is cooked for 15 minutes or more will brown lightly in its own fat. Anything
cooked for a shorter time can be brushed with a browning sauce to give an appetising colour.
• Microwave energy can heat unevenly so stirring to distribute heat is very important. Always stir from
the outside towards the centre.
• Turn larger foods such as meat roasts and poultry during cooking so that the top and bottom cook
evenly. It is also a good idea to turn chops and chicken pieces, especially if they contain the bone.
• Strips of aluminium foil can be used to cover the thinner pieces of food to stop them overcooking
before the thicker parts of the food have had a chance to cook. Use the foil sparingly and wrap around
the food or container carefully to stop it touching the inside of the oven which could cause sparks.
You should always have your microwave checked if it is dropped or damaged.
Microwave ovens cook food using microwave energy that is similar to naturally occurring radio waves.
Normally, these “waves” would fade as they disappeared into the atmosphere but in a microwave oven they
are concentrated onto food causing it to heat up.
Microwave energy can not pass through metal – so it can not
escape from inside your microwave oven – but it can pass through
materials like glass, porcelain, plastic, and paper.
These are the things used to make microwave-safe cooking
equipment.
Microwave-safe cooking equipment will still get hot as the food it
contains heats up.
L21CS10_IB_GB_100927_Zell.indd 7 27/09/2010 3:49 PM

8
Checking your cooking utensils
Most heat-resistant, non-metallic cooking utensils are safe to use in your microwave. If you are not sure you
can use a utensil in your microwave, follow this simple test:
1. Put the utensil into the microwave next to a cup of water – use a cup that you know is microwave safe.
Close the door.
2. Turn the microwave on for 30 seconds only.
3. After 30 seconds, carefully check to see if the water has warmed up.
4. If the water has not warmed up but the utensil has, the utensil is not microwave safe and should not be
used in the microwave.
5. Do not use your hands to touch the utensils as it may already be hot.
If the water has not warmed up but the utensil has, the utensil is not microwave-safe and should not be
used in the oven.
Never use equipment made of metal, except foil in your microwave oven.
The microwave energy can not pass through the metal so it bounces off and sparks against the
inside of the oven.
Stop the microwave straight away if any equipment does cause sparks.
Remember that some crockery has a metal trim around the edge. Even this trim can cause sparks.
Never use scratched, cracked or damaged glass in a microwave. Damaged glass can explode.
L21CS10_IB_GB_100927_Zell.indd 8 27/09/2010 3:49 PM

9
800W
E
800W is the output power of the microwave.
E is the heating category for your microwave.
Check the cooking times for category E on the
food’s packaging to see how long it should be
cooked for. Please see below example for reference.
To Microwave:
1. Remove outer packaging.
2. Pierce film lid SEVERAL TIMES.
3. Place on a microwaveable plate.
4. Heat on full power.
5. Turn halfway through heating.
Heating
Category
Wattage
(IEC705)
B D 650W 750W
Full power (in
minutes)
2222
Turn Turn Turn
Full power
(in minutes)
2 1.5 2 1.5
Standing time
(in minutes)
1111
To Microwave from frozen:
1. Remove outer packaging.
2. Pierce film lid SEVERAL TIMES.
3. Place on a microwaveable plate.
4. Heat on full power.
5. Turn halfway through heating.
Heating
Category
Wattage
(IEC705)
B D 650W 750W
Full power (in
minutes)
3 2.5 3 2.5
Turn Turn Turn
Full power
(in minutes)
4 3.5 4 3.5
Standing time
(in minutes)
1111
Microwave Heating Categories
Your microwave has been tested and labelled to meet the government’s voluntary agreement on the
reheating of pre-cooked food.
The heating characteristics and output power levels of microwave are usually calculated using a relatively
large portion of food (a 1000 gram load, IEC 705) but many packs of pre-cooked food are sold in smaller
packs, often about 350 grams.
The government, in partnership with food companies and microwave manufacturers, have set up a system
of heating categories to help you choose the reheating time for pre-cooked food.
L21CS10_IB_GB_100927_Zell.indd 9 27/09/2010 3:49 PM

10
Checking your Microwave
Check your microwave after unpacking and
whenever you think it might not be working
properly.
1. Push button to open the door.
Put the turntable ring inside the oven and
place the glass turntable on top of the ring.
The turntable is shaped to sit securely on the
spindle.
You must always use the turntable and ring
whenever you use the microwave.
Place a cup of water on the turntable. Make
sure the cup is microwave-safe - it should not
have any decorative metal trim.
2. Close the door.
3. Press the STOP/CLEAR button to clear any
settings that have already been made.
4. Press the MICROWAVE button once, then
press number keys to select cooking time.
Press the START button once.
The oven light comes on during cooking.
5. When cooking finishes, the water should be
hot - be careful when you take the cup out of
the oven.
Press the STOP/CLEAR button.
Steam
When you microwave food, steam is created as water in the food heats up and evaporates.
The steam formed during microwave cooking is entirely safe. It has to escape from the microwave to
prevent pressure from building up inside the microwave. It does this through the vents on the back of the
microwave and from around the door.
Condensation
As the steam cools, you may find the condensation
gathers in small pools inside your microwave and on the
work surface beneath the door and vents. Always dry
the microwave after cooking foods with a high moisture
content.
Your microwave is designed to let steam escape from the
vents and around the door without microwave energy
escaping. There is no danger of microwave energy
escaping with the steam.
3, 5
4
4
L21CS10_IB_GB_100927_Zell.indd 10 27/09/2010 3:49 PM

11
Setting the Child Lock
The child lock is a safety feature which when set will lock all of the buttons on your microwave. This
prevents your microwave being used accidentally though your microwave door will still open.
1. In waiting state, press and hold the STOP/
CLEAR button, there will be a long “beep”
denoting entering the children-lock state and
the locked indicator will display.
2. In locked state, press and hold the STOP/
CLEAR button, there will be a long “beep”
denoting that the lock is released, and the
locked indicator will disappear.
Your oven has a safety feature that
prevents children from using your oven.
Once the child lock is set, you will be
unable to use any functions, and no
cooking can take place. However, your
child can still open the oven door.
1, 2
L21CS10_IB_GB_100927_Zell.indd 11 27/09/2010 3:49 PM

12
Clock Setting
When the microwave oven is electrified,the oven will display “0:00”, buzzer will ring once and enter into the
waiting states.
1. When it is in waiting states, press the CLOCK
button, and “00:00” flashes.
2. Press the number buttons to input the time.
For example: to set the clock 12 : 12. You can
press “1”, ”2”, ”1”, ”2” in order.
3. Press the START button. Time begins to count
down, and “:” will flash.
4. How to modify the clock:
In waiting states, press the CLOCK button and
the current time is flashing. At the same time,
“:” will light.
5. Press number buttons to adjust the clock.
6. Press the START button. Time begins to count
down, and “:” will flash.
1, 4
3, 6
2, 5
L21CS10_IB_GB_100927_Zell.indd 12 27/09/2010 3:49 PM

13
Microwave Cooking
Select different microwave power level and set cooking time as you wish. There are five power levels
available for choosing. Keep on pressing “MICROWAVE” to choose the power.
Example: If you want to use 80% microwave power to cook for 10 minutes, you can operate the oven as the
following steps.
1. Press the MICROWAVE button once, the LED
will display “P100”, and “ “ indicator will
light.
If the STOP/CLEAR button is pressed, it will go
back to waiting state.
2. Press the MICROWAVE button twice to choose
80% power, the LED will display “P80”.
3. Input the time by pressing the number
buttons of “1”, ”0”, ”0”, ”0” in order, the LED will
display “10:00”. The maximum input time is 99
minutes and 99 seconds. If the STOP/CLEAR
button is pressed, it will go back to previous
state.
4. Press the START button to start cooking.
The “ “ indicator will flash. If you press the
STOP/CLEAR button, the unit stops working.
Press the MICROWAVE button can check the
microwave power for 3 seconds and then turn
back to the counting down states.
5. When the cooking is finished, the buzzer will
sound five times. And turn back to waiting
state.
Press the START button key in the cooking
state, it continue to work for 30 seconds.
The MICROWAVE button presses instructions.
Presses
Instructions LED Display Microwave Power
1100%
280%
350%
430%
510%
1, 3, 4
1, 2, 4
4, 5
3
L21CS10_IB_GB_100927_Zell.indd 13 27/09/2010 3:49 PM

14
Grill Cooking
1. Press the GRILL button repeatedly to choose
grill power. “G-1”, “C-1” and “C-2” will be
displayed in order. At this moment, either “
“ (for G-1) or “ “ “ “ (for C-1 and C-2) will
light.
If you press the STOP/CLEAR button now, the
unit will turn back to the waiting states.
2. Press number buttons to input the cooking
time.
3. Press the START button to begin cooking.
Either “ “ or “ “ “ “ will flash, and “:” will
stop flashing. Time counts down.
a. During this process, second gures counts
down too.
b. If you press the GRILL button again, the
display will show the status for 3 seconds,
for example: G-1. The unit will then
continue the cooking count down.
4. The buzzer sounds five times when the
cooking finish. If you press the START button
during cooking, it will increase the cooking
time for 30 seconds.
Example: If you want to use 100% grill power
to cook for 35 minutes, you can operate the
oven as per the following steps.
a. Press the GRILL button, the LED
will display “G-1“, at the same
time “ “ will light.
b. Press the number buttons of
“3”,”5”,”0”,”0” in order, the LED
will display “35:00”.
c. Press the START button to start cooking.
”GRILL” presses instructions.
Presses
Instructions LED Display Microwave Grill Cooking Cycle (every 30 sec.) Cavity
Temperature
1 G-1 √ 100% Grill Approximate
keep at
165°C ± 5°C
2 C-1 √ √ 55% Microwave+45% Grill
3 C-2 √ √ 36% Microwave+64% Grill
1, 3b,
4a
1
3, 4,
4c
2, 4b
L21CS10_IB_GB_100927_Zell.indd 14 27/09/2010 3:49 PM

15
Combine Function
1. Press the COMBINE button to choose the
temperature. “ “ , “ “ and “ �C “ will light.
“110”, “120”....”190” and “200” will be displayed
in cycle. It will go back to the waiting states by
pressing the STOP/CLEAR button.
2. Input the time by pressing the number
buttons. The maximum time is 99 minutes and
99 seconds.
3. Press the START button to start working. “ “
and “ “ will flash.
Time counts down. During this process,
second figures count down too.
4. If you press the STOP/CLEAR button, the unit
stops working.
5. Press the COMBINE button to check the
status and temperature will be displayed for 3
seconds.
6. The buzzer will sound five times when cooking
finish and turn back to the waiting states.
1, 4
1, 5
3
2
L21CS10_IB_GB_100927_Zell.indd 15 27/09/2010 3:49 PM

16
Convection Cooking (without Preheating)
1. Press the CONVECTION button to choose the
temperature of convection.
2. “ “ will light. “110”, ”120”....”190” and “200” will
be displayed in cycle.
3. Input the convection time by pressing the
number buttons. The maximum time can be
set is 99 minutes and 99 seconds.
4. Press the START button to work. “ “ will
flash. Time counts down. During this process,
second figures count down too. If you press
the STOP/CLEAR button, the unit stops
working. If you press the CONVECTION
button, you check the status and the
temperature will be displayed for 3 seconds,
then time counts down.
5. When work finish, the buzzer will sound five
times and turn back to the waiting states. 4
4
1, 4
3
L21CS10_IB_GB_100927_Zell.indd 16 27/09/2010 3:49 PM

17
Convection Cooking (with Preheating)
1. Press the CONVECTION button to choose the
temperature of convection.
2. “ “ will light. “110”, ”120”....”190” and “200” will
be displayed in cycle.
3. Press the START button to start preheating.
When the preset temperature is reached, the
buzzer will sound twice and the temperature
setting will flash.
4. At this stage press the STOP/CLEAR button
once, open the door and place your food
inside. Close the door.
The microwave will keep operating
preheat for 5 minutes. If you do not press
the STOP/CLEAR button within 5 minutes
the microwave will return to Standby
mode.
5. Input the convection time by pressing the
number buttons. The maximum time can be
set is 99 minutes and 99 seconds.
6. Press the START button to work. “ “ will
flash. Time counts down. During this process,
second figures count down too. If you press
the STOP/CLEAR button, the unit stops
working. If you press the CONVECTION
button, you check the status and the
temperature will be displayed for 3 seconds,
then time counts down.
7. When work finish, the buzzer will sound five
times and turn back to the waiting states.
4, 6
3, 6
1, 6
5
L21CS10_IB_GB_100927_Zell.indd 17 27/09/2010 3:49 PM

18
Auto Menu Cooking
1. When the unit is in waiting states, press the
number buttons to go into the auto menu
directly. Number 1-9 stand for Reheat, Potato,
Vegetable,.... Roast Chicken respectively.
2. The LED will display the weight. “g”and “Auto”
will light.
3. Press the START button to cook. The LED
will display the clock and time counts down.
“g” will go out. If you press the STOP/CLEAR
button, the unit stops working.
4. When finished, the buzzer sounds five times
and turn back to the waiting states.
3
3
1
L21CS10_IB_GB_100927_Zell.indd 18 27/09/2010 3:49 PM

19
The density and thickness of food can affect its cooking time. Ensure all food is piping hot
and cooked thoroughly before serving. It is essential that food is checked during and after the
recommended cooking time, even if Auto Menu was used.
Auto Menu Table
Menu Weight (g) Cook time Power Comments
Reheat
200 2’00” 100% (Mic.)
Thick pieces of food will take longer to heat than
thin pieces, liquids will heat faster than solids.
Ensure all the food has been properly cooked
before consumption.
300 3’00” 100% (Mic.)
400 4’00” 100% (Mic.)
500 5’00” 100% (Mic.)
Potato
230 5’00” 100% (Mic.) 1 regular size potato is approximately 200g. Leave
potato to stand for 5 minutes before consuming
(for best results wrap the potato in tin foil once
cooked and leave to stand for 5 minutes)
460 9’00” 100% (Mic.)
690 11’00” 100% (Mic.)
Vegetable
200 3’30” 100% (Mic.) Vegetables can be boiled or steamed. Cover
vegetables with boiling water before operation or
add 2 tablespoons of water per 100ml and cover
with microwave safe cling film and pierce the cling
film before operation. Caution - take care to avoid
steam burns when removing the cling film.
300 4’30” 100% (Mic.)
400 5’30” 100% (Mic.)
500 6’30” 100% (Mic.)
Pasta
50 18’00” 80% (Mic.)
- Add 450ml cold water
- Add 800ml cold water
- Add 1200ml cold water
100 21’00” 80% (Mic.)
150 24’00” 80% (Mic.)
Meat
200 2’40” 100% (Mic.) The times provided are guidelines only - make sure
meat is cooked through before consuming. Turn
meat over half way through the cooking cycle.
Thick pieces of food will require longer cooking
times than thin pieces.
Cut meat into small equally sized pieces and
place onto a microwave safe plate. Ensure meat is
thoroughly cooked before consuming.
300 4’20” 100% (Mic.)
400 5’30” 100% (Mic.)
500 6’30” 100% (Mic.)
Fish
200 4’00” 80% (Mic.)
The times provided are guidelines only - make sure
fish is cooked through before consuming. Turn fish
over half way through the cooking cycle.
Thick pieces of food will require longer cooking
times than thin pieces.
300 5’30” 80% (Mic.)
400 7’00” 80% (Mic.)
500 8’30” 80% (Mic.)
Pizza
300 9’00” 100% (Mic.) /
G -1 Place Pizza (recommend fresh thin base Pizza’s
only) onto the grill rack.
400 11’30” 100% (Mic.) /
G -1
Reheat Bread 50 3’30” G - 1 Place frozen bread piece(s) onto the grill rack for
reheat.
100 3’50” G - 1
Roast Chicken
750 35’00” C - 2 Remove any stuffing and other items not part
of the food load. Place chicken onto the glass
turntable. Ensure meat is fully cooked before
serving.
1000 40’00” C - 2
1250 45’00” C - 2
L21CS10_IB_GB_100927_Zell.indd 19 27/09/2010 3:49 PM

20
Defrost By Time
1. Press the DEFROST BY TIME buttons to
choose the function of defrost by time. “ “
and “ “ will light to indicate that you should
input the time.
If the STOP/CLEAR button is pressed now, the
unit will go back to the waiting states.
2. Press number buttons to input the time of
cooking. (the maximum cooking time is 99
minutes and 99 seconds.)
If the STOP/CLEAR button is pressed now, the
unit will go back to the previous states.
3. Press the START button to start defrosting.
“ “ and “ “ indicators will flash. Time
counts down. During this process, second
figures count down too.
If you press the STOP/CLEAR button, the unit
stops working.
At this time, press the STOP/CLEAR button
again or the time for pause is more than
5 minutes, it will turn back to the waiting
state. Press the START button within 5
minutes, the unit goes on working and
time counts down. If you press the the
START button during cooking process, the
unit starts working for 30 seconds.
The defrost rack must be used and the glass tray underneath.
It is recommended to turn the food to ensure even defrosting.
1, 2, 3
3
1
2
L21CS10_IB_GB_100927_Zell.indd 20 27/09/2010 3:49 PM
