Logik L04TBSS11 User manual
4 Slice Black
Stainless Steel Toaster
Instruction Manual
L04TBSS11
Thank you for purchasing your new Logik Toaster.
We recommend that you spend some time reading this instruction manual
in order to fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
GB-4 GB-5
SAFETY FIRST!
For your continued safety and to reduce the risk of injury or electric shock, please follow
all the safety precautions listed below.
• Read all the instructions carefully before using the appliance and keep them for future
reference.
• Retain the manual. If you pass the appliance onto a third party, make sure to include this
manual.
• Check that the voltage marked on the rating label matches your mains voltage.
Damage
• Please inspect the appliance for damage after unpacking.
• Do not continue to operate the appliance if you are in any doubt about it working
normally, or if it is damaged in any way - switch off, withdraw the mains plug and
consult your dealer.
Location of Appliance
• The appliance must be placed on a at stable surface and should not be subjected to
vibrations.
• Do not place the appliance on sloped or unstable surfaces as the appliance may fall off
or tip over.
• The mains socket must be located near the appliance and should be easily accessible.
• This appliance is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature, either hot or cold. Place the appliance well away
from heat sources such as radiators or gas/electric res.
• Avoid exposure to direct sunlight and other sources of heat.
• Do not touch hot surfaces. Temperature of accessible surfaces may be very high when
the appliance is operating.
Naked Flames
• Never place any type of candle or naked ame on the top of or near the appliance.
Moisture
• To reduce the risk of re, electric shock or product damage, do not expose this appliance
to rain, moisture, dripping or splashing. No objects lled with liquids, such as vases,
should be placed on the appliance.
• If you spill any liquid into the appliance, it can cause serious damage. Switch it off at the
mains immediately and withdraw the mains plug.
Ventilation
• To prevent the risk of electric shock or re hazard due to overheating, ensure that
curtains and other materials do not obstruct the ventilation vents.
• Do not install or place this appliance in a bookcase, built-in cabinet or in another
conned space. Ensure the appliance is well ventilated.
Safety
• The appliance is not intended to be operated by means of an external timer or separate
remote-control system.
• Always disconnect the appliance from the mains supply before moving the appliance.
• In the interests of safety and to avoid unnecessary energy consumption, never leave the
appliance unattended for long periods of time, e.g. overnight, while on holiday or while
out of the house. Disconnect the mains plug from the mains socket.
• Bread may burn. Your appliance must not be used near or below curtains or other
combustible materials. It must be watched when in use.
• Only place toast bread in your appliance. Do not attempt to toast any pastry or bread
product which is lled with a fruit or sugary lling (pop tarts etc). The stuffings may leak
from the appliance and cause damage to your appliance with the possible risk of a re
occurring.
• Oversize food, metal foil packages or utensils must not be inserted in the appliance as
they may cause re or electric shock.
• Don’t attempt to dislodge food while the appliance is operating.
• Take the bread out carefully after toasting to avoid injuries.
• Do not use the appliance for uses other than its intended use.
Mains Cable
• Make sure the appliance is not resting on top of the mains cable, as the weight of the
appliance may damage the mains cable and create a safety hazard.
• Do not let the mains cable overhang the edge of the work surface or allow it to touch
hot surfaces or sources of heat or ame.
• If the mains cable is damaged it must be replaced by the manufacturer, its service agent,
or similarly qualied persons in order to avoid a hazard.
Supervision
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of the appliance by
a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Never let anyone especially children push anything into the holes, slots or any other
openings in the case - this could result in a fatal electric shock.
Service
• To reduce the risk of electric shock, do not remove screws. The appliance does not
contain any user-serviceable parts. Please leave all maintenance work to qualied
personnel.
• Do not open any xed covers as this may expose dangerous voltages.
Maintenance
• Ensure to unplug the appliance from the mains socket before cleaning.
• Allow the appliance to cool completely before cleaning or storing.
• Do not use any type of abrasive pad or abrasive cleaning solutions as these may damage
the appliance’s surface.
• Do not use liquids to clean the appliance.
SPECIFICATIONS
Mains supply: 230V ~50Hz
Power consumption: 1600W
We continually strive to improve our products. Specications may change without prior
notice.
DSG Retail Ltd • Maylands Avenue • Hemel Hempstead
Herts • HP2 7TG • England
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million spares
and accessories available we can deliver direct to your door
the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK customers only) Calls
charged at National Rate.
This symbol on the product or in the instructions means that your electrical
and electronic equipment should be disposed at the end of its life separately
from your household waste. There are separate collection systems for recycling
in the EU. For more information, please contact the local authority or your
retailer where you purchased the product.
(P.N. L04TBSS11-001)
L04TBSS11_IB_final110315.pdf 1 15/03/2011 5:55 PM
GB-1 GB-2 GB-3
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
UNPACKING
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
TOASTING BREAD
To prevent jamming, do not use your toaster with torn slices of
bread. Make sure the size and thickness of the slices of bread t
easily into the toast slots. Always watch your toaster when in
use. Never leave your toaster unattended.
1. Plug the mains plug into the mains socket.
2. Put bread slices into the bread slots.
Two sets of controls for defrost, reheat, cancel, browning
control and the toasting lever. Both sets of controls can work
together or separately. For four slice toasting and other
functional controls, both sets of control must be pressed.
OTHER FUNCTIONS
Reheat
Insert the cold slices of toast and lower the toasting lever
until it remains in a downward position. Press the REHEAT
button. The indicator will illuminate. In this mode, setting the
browning control will have no effect as the toasting time is
xed. When the time runs out, the toasting lever will
automatically pop up and nish the reheating process.
Defrost
Insert the frozen bread. Set the browning control to your
desired colour. Lower the toasting lever down until it remains
in a downward position, then press the DEFROST button. The
indicator will illuminate. In this mode, the frozen bread will be
toasted to your desired colour.
Cancel
If the toaster starts to smoke, press the CANCEL button to
stop toasting immediately. Remove all protective wrapping
prior to putting the bread into the toaster. Avoid toasting the
food with extremely runny ingredients such as butter. The
bread slot is only applicable for toasting regular bread slices.
Do not toast irregular sized bread.
REMOVING CRUMBS FROM THE TOASTER
1. First remove the mains plug from the mains
socket.
2. Slide the crumb tray out by holding the crumb
tray handle. (The metal part may be hot.)
3. Empty the crumbs into the bin and clean the
crumb tray.
HOW TO CLEAR A PIECE OF BLOCKED BREAD
1. Remove the mains plug from the mains socket.
2. Allow the toaster to completely cool down.
3. Push and hold the toasting lever down then release.
4. Gently dislodge the blockage with a non-metallic object, for example the handle of a
wooden spoon.
5. Lift the toasting lever to remove the blockage.
CLEANING AND MAINTENANCE
Remove the mains plug from the mains socket and allow the toaster to cool down
before cleaning.
Do not use harsh cleaners or solvents as they may damage the casing.
The body of the toaster should be cleaned using a cloth dampened with warm water.
Make sure you do not allow water to seep into the controls or heating elements.
When not in use, the mains cable may be wound under the bottom of the toaster.
FIRST TIME USE
Please note there may be manufacturing residue or oil remaining in the toaster or heating
element. Odour may be emitted the rst time you use it. This is normal and will not occur
after using your toaster for several times. The rst time you use your toaster we suggest
that you operate it without bread.
PRODUCT OVERVIEW
• The Main Unit
Toast Slots
• Instruction Manual
(P.N.: L04TBSS11-001)
1
2
7
8
3
5
6
4
1REHEAT Button
5
Toasting Lever
2Browning Control
6
CANCEL Button
3Crumb Tray
7
DEFROST Button
4Crumb Tray Handle
8
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
Let the crumb tray dry thoroughly before reinserting it back into the
toaster.
Ensure the crumb tray is completely inserted before using your toaster
again.
Ensure you don’t make contact with the heating elements, as you may
damage them.
•Select a lower position (i.e. 1 or 2) for light browning, especially for toasting
only one slice or for dry (old) bread. Note that the toasting colour for one slice
will be darker than that for two slices at the same level.
•If you have already toasted some bread, the toaster elements will be hot, so
when you put some more bread into the toaster it may become browner
faster than the rst slices that were toasted, even if the Browning Control is
set to the same level.
•Only when the toaster is connected to the
mains power, can the toasting lever be
locked in the downward position.
•During the toasting process, you may
observe the toasting colour. Press the
CANCEL button to cancel the operation at
any time if you are satised with the colour.
3. Select the level of browning by turning the Browning Control.
There are 6-setting levels:
(1) (6)
DarkestWhitest
4. Lower the toasting lever down vertically until it is positioned in place. The toaster will
begin at once.
5. Once the bread has been toasted to the preset browning
level, the toasting lever will automatically pop up.
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
1
2
34
5
6
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
CANCEL
1
2
34
5
6
1
2
34
5
6
REHEAT
DEFROST
4 Slice Black
Stainless Steel Toaster
Instruction Manual
L04TBSS11
Thank you for purc hasing your new Log ik Toaster.
We recommend that yo u spend some time read ing this instructi on manual
in order to fully un derstand all the op erational featur es it offers.
Read all the safe ty instructions ca refully before use a nd keep this
instruction m anual for future refe rence.
L04TBSS11_IB_final110315.pdf 2 15/03/2011 5:55 PM
Other Logik Toaster manuals
