Logik L04TPS13 User manual

GB-4
Thank you for purchasing your new Logik 4 Slice Stainless Steel Toaster.
We recommend that you spend some time reading this instruction manual in
order to fully understand all the operational features it oers.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
GB-4
GB-5
DSG Retail Ltd. (Registered in England no. 504877)
Maylands Avenue, Hemel Hempstead, Hertfordshine, HP2 7TG, UK
Visit Partmaster.co.uk today for the easiest way to buy
electrical spares and accessories. With over 1 million
spares and accessories available we can deliver direct
to your door the very next day. Visit www.partmaster.co.uk or call 0844 800 3456 (UK
customers only) Calls charged at National Rate.
This symbol on the product or in the instructions means that your
electrical and electronic equipment should be disposed at the end of its
life separately from your household waste. There are separate collection
systems for recycling in the EU. For more information, please contact the
local authority or your retailer where you purchased the product.
L04TPS13-130128V1
SPECIFICATIONS
Mains supply: 220-240V~50Hz
Power consumption: 1400W
We continually strive to improve our products. Specications may change without
prior notice.
CLEANING AND MAINTENANCE
Unplug the mains plug from the mains socket and allow the toaster to cool down
before cleaning.
Do not use harsh cleaners or solvents as they may damage the casing.
The body of the toaster should be cleaned using a cloth dampened with warm water.
Make sure you do not allow water to seep into the controls or heating elements.
When not in use, the mains cable may be wound under the bottom of the toaster.
• Only when the toaster is connected to
the mains power, can the toasting lever
be locked in the downward position.
•During the toasting process, you may
observe the toasting colour. Press the
CANCEL button to cancel the operation
at any time if you are satised with the
colour.
5. Once the bread has been toasted to the preset browning level, the toasting lever
will automatically pop up.
OTHER FUNCTIONS
Defrost
Insert the frozen bread. Set the browning control to your desired
colour. Push the toasting lever down until it locks into position,
then press the DEFROST button. The indicator will light up. In this
mode, the frozen bread will be toasted to your desired colour.
KEEPING THE MAINS CABLE TIDY
Extend the mains cable underneath the
toaster to the required length. For safety
it is recommended that the length of
exposed mains cable is kept as short as
possible.
TOASTING BREAD (Cont)
REMOVING CRUMBS FROM THE TOASTER
1. First unplug the mains plug from the mains socket.
2. Slide the crumb tray out by holding the crumb tray
handle. (The metal part may be hot.)
3. Empty the crumbs into the bin and clean the
crumb tray.
Let the crumb tray dry thoroughly before reinserting it back into the
toaster.
Ensure the crumb tray is completely inserted before using your toaster
again.
HOW TO CLEAR A PIECE OF BLOCKED BREAD
1. Remove the mains plug from the mains socket.
2. Allow the toaster to completely cool down.
3. Push and hold the toasting lever down then release.
4. Gently dislodge the blockage with a non-metallic object, for example the handle
of a wooden spoon.
5. Lift the toasting lever to remove the blockage.
Ensure you do not touch the heating elements, as you may damage
them.
Reheat
Insert the cold slices of toast and push the toasting lever down until it locks into
position. Press the REHEAT button. The indicator will light up. In this mode, setting
the browning control will have no eect as the toasting time is xed. When the
time runs out, the toasting lever will automatically pop up. The reheating process is
nished.
4. Lower the toasting lever down vertically until it is positioned in place.
The toaster will begin at once.
Instruction Manual
4 Slice Stainless Steel
Toaster
L04TPS13
• Select a lower position (i.e. 1 or 2) for light browning, especially for
toasting only one slice or for dry (old) bread. Note that the toasting
colour for one slice will be darker than that for two slices at the same
level.
• If you have already toasted some bread, the toaster elements will be
hot, so when you put some more bread into the toaster it may become
browner faster than the rst slices that were toasted, even if the
Browning Control is set to the same level.
3. Select the level of browning by turning the Browning Control.
There are 6-setting levels:
(1) (6)
DarkestLightest
2
2
3
3
1
1
Cancel
Reheat
Defrost
Cancel
If the toaster starts to smoke, press the CANCEL button to stop toasting
immediately. Remove all protective wrapping prior to putting the bread into the
toaster. Avoid toasting food with extremely runny ingredients such as butter. The
bread slot is only applicable for toasting regular bread slices. Do not toast
irregular-sized bread.
1
2
3 4
6
5
C
M
Y
CM
MY
CY
CMY
K
L04TPS13_IB_130130_chris.pdf 1 30/01/2013 11:05 PM

GB-3GB-1
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
• The Main Unit
• In the interests of safety and to avoid unnecessary energy
consumption, never leave the appliance unattended for long
periods of time, e.g. overnight, while on holiday or while out of the
house. Disconnect the mains plug from the mains socket.
• Bread may burn. Your appliance must not be used near or below
curtains or other combustible materials. It must be watched when
in use.
• Only place toast bread in your appliance. Do not attempt to toast
any pastry or bread product which is lled with a fruit or sugary
lling (pop tarts etc). The stungs may leak from the appliance and
cause damage to your appliance with the possible risk of a re
occurring.
• Oversize food, metal foil packages or utensils must not be inserted
in the appliance as they may cause re or electric shock.
• Don’t attempt to dislodge food while the appliance is operating.
• Take the bread out carefully after toasting to avoid injuries.
• Do not use the appliance for uses other than its intended use.
Mains Cable
•Make sure the appliance is not resting on top of the mains cable, as
the weight of the appliance may damage the mains cable and
create a safety hazard.
• Do not let the mains cable overhang the edge of the work surface
or allow it to touch hot surfaces or sources of heat or ame.
• If the mains cable is damaged it must be replaced by the
manufacturer, its service agent, or similarly qualied persons in
order to avoid a hazard.
Supervision
• This appliance can be used by persons aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge if they have been given
supervision or instructions concerning the use of the appliance in a
safe way and understand the hazards involved. Children should not
play with the appliance. Cleaning and user maintenance should not
be made by children unless they are older than 8 years and are
supervised.
Service
• To reduce the risk of electric shock, do not remove screws. The
appliance does not contain any user-serviceable parts. Please leave
all maintenance work to qualied personnel.
• Do not open any xed covers as this may expose dangerous voltages.
Maintenance
• Ensure to unplug the appliance from the mains socket before
cleaning.
• Allow the appliance to cool completely before cleaning or storing.
• Do not use any type of abrasive pad or abrasive cleaning solutions
as these may damage the appliance’s surface.
• Do not use liquids to clean the appliance.
SAFETY FIRST!
For your continued safety and to reduce the risk of injury or
electric shock, please follow all the safety precautions listed below.
• Read all the instructions carefully before using the appliance and
keep them for future reference.
• Retain the manual. If you pass the appliance onto a third party,
make sure to include this manual.
• Check that the voltage marked on the rating label matches your
mains voltage.
Damage
• Please inspect the appliance for damage after unpacking.
• Do not continue to operate the appliance if you are in any doubt
about it working normally, or if it is damaged in any way - switch
o, withdraw the mains plug and consult your dealer.
Location of Appliance
• The appliance must be placed on a at stable surface and should
not be subjected to vibrations.
• Do not place the appliance on sloped or unstable surfaces as the
appliance may fall o or tip over.
• The mains socket must be located near the appliance and should
be easily accessible.
• This appliance is designed for indoor use only.
Temperature
• Avoid extreme degrees of temperature, either hot or cold. Place
the appliance well away from heat sources such as radiators or
gas/electric res.
• Avoid exposure to direct sunlight and other sources of heat.
• Do not touch hot surfaces. Temperature of accessible surfaces
may be very high when the appliance is operating.
Naked Flames
• Never place any type of candle or naked ame on the top of or
near the appliance.
Moisture
• To reduce the risk of re, electric shock or product damage, do
not expose this appliance to rain, moisture, dripping or splashing.
No objects lled with liquids, such as vases, should be placed on
the appliance.
• If you spill any liquid into the appliance, it can cause serious
damage. Switch it o at the mains immediately and withdraw the
mains plug.
Ventilation
• To prevent the risk of electric shock or re hazard due to
overheating, ensure that curtains and other materials do not
obstruct the ventilation vents.
• Do not install or place this appliance in a bookcase, built-in
cabinet or in another conned space. Ensure the appliance is well
ventilated.
Safety
• The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
• Always disconnect the appliance from the mains supply before
moving the appliance.
SAFETY FIRST! (Cont)
FIRST TIME USE
Please note there may be manufacturing residue or oil remaining in the toaster or
heating element. Odour may be emitted the rst time you use it. This is normal and
will not occur after using your toaster for several times. The rst 2 times you use
your toaster we suggest that you operate it without bread.
TOASTING BREAD
To prevent jamming do not use your toaster with torn
slices of bread. Make sure the size and thickness of the
slices of bread t easily into the toast slots. Always watch
your toaster when in use. Never leave your toaster
unattended.
1. Plug the mains plug into the mains
socket.
2. Put 1-4 bread slices into the bread
slots.
PRODUCT OVERVIEW
• If toasting 2 or more slices, they should be similar in size, thickness and
freshness.
• For optimum browning, always place the bread as close as possible to
the centre of the slots.
• Make sure the crumb tray is completely inserted before use.
GB-2
Toast Slots
Toasting Lever
DEFROST Button
Crumb Tray
Crumb Tray Handle
Browning Dial
CANCEL Button
REHEAT Button
UNPACKING
Remove all packaging from the unit. Retain the packaging. If you dispose of it
please do so according to local regulations.
The following items are included:
C
M
Y
CM
MY
CY
CMY
K
L04TPS13_IB_130130_chris.pdf 2 30/01/2013 11:05 PM
