Logik L612WM11 User manual

6KG Washing Machine
Installation Guide / Instruction Manual
L612WM11
L612WM11_IB_final110406_running change.indd 1 06/04/2011 6:12 PM

L612WM11_IB_final110406_running change.indd 2 06/04/2011 6:12 PM

Contents
Unpacking.................................................................................................................................... 4
Installing Your Washing Machine ............................................................................................... 5
Choosing the Right Location for Your Washing Machine ........................................................................5
Moving and Installing ................................................................................................................. 6
Removing the Transit Bolts ................................................................................................... 6
Moving the Washing Machine from One Location to Another........................................... 6
Hose and Cable Lengths ........................................................................................................ 7
Levelling the Washing Machine ............................................................................................ 7
Water Supply Hose................................................................................................................. 7
Water Drain Hose.................................................................................................................................................... 8
Connecting to the Mains Supply ......................................................................................................................8
Product Overview........................................................................................................................ 9
The unit...................................................................................................................................................................... 9
The Control Panel ................................................................................................................................................10
Preparation ................................................................................................................................ 11
Organising Laundry.............................................................................................................................................11
Preparing Laundry ...............................................................................................................................................11
Adding Detergent and Softener .....................................................................................................................11
Selecting the Programme..................................................................................................................................12
Wash Setting .............................................................................................................................. 13
Standard Washing ................................................................................................................................................13
Manual Soaking ....................................................................................................................................................13
Individual Washing Functions (Process Selection) ...................................................................................13
Optional Functions ..............................................................................................................................................14
Removing Laundry...............................................................................................................................................14
Turn O the Tap (optional)................................................................................................................................14
Important Information.............................................................................................................. 15
Washing Delicates (Wool and Silk Programmes) ......................................................................................15
Adding Delicate Laundry Items to the Drum.............................................................................................15
Which Detergent to Use.....................................................................................................................................15
Tips for Hanging Delicate Items to Dry.........................................................................................................15
If Clothing Shrinks in the Wash........................................................................................................................15
How to Use Laundry Starch ..............................................................................................................................16
How to Use a Water Softener ...........................................................................................................................16
How to Set the Key Lock ...................................................................................................................................16
Maintenance - Cleaning the Washing Machine ....................................................................... 17
Cleaning the Drum...............................................................................................................................................17
Cleaning the Exterior of your Washing Machine.......................................................................................17
Cleaning the Detergent Drawer......................................................................................................................17
Cleaning the Door Seal and Window ............................................................................................................17
Cleaning the Drain Filter....................................................................................................................................18
Preventing a Frozen Water Supply Hose......................................................................................................18
Cleaning the Filter Net of the Water Supply Hose ....................................................................................18
Hints and Tips ............................................................................................................................ 19
Troubleshooting ........................................................................................................................ 21
Error Code ...............................................................................................................................................................21
Specication .............................................................................................................................. 22
Safety Warnings......................................................................................................................... 23
L612WM11_IB_final110406_running change.indd 3 06/04/2011 6:12 PM

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
The Main Unit
Thank you for purchasing your new Logik Washing Machine.
We recommend that you spend some time reading this installation/instruction manual
in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Cover Cap x 4
P.N.: 301130650057
Water Supply Hose x 1
P.N.: 301130600020
U-Shape Holder x 1
P.N.: 301130600276
For xing the water drain hose.
Instruction Manual
P.N.: 3020306A0903-V2
Drain
Off
Cold
Cold
Cold
Synthetic
Rinse
Cotton
Delicate
Wool
Spin
30 Quick Wash
Intensive Rinse
L612WM11
Spin
Speed
Programme
Selection1
Programme
Selection2
Prewash
Start/Pause
Baby Care
Reduced
Creases
ECO Wash
Intensive
6KG Washing Ma chine
Installation Guide / Instruction Manual
L612WM11
L612WM11_IB_final110406_running change.indd 4 06/04/2011 6:12 PM

Installing Your Washing Machine
Please read and follow the instructions carefully.
• In addition to the instructions mentioned here, special regulations of the relevant water and power
supply companies may apply. If in doubt, have the washing machine connected by a qualified
technician.
• The washing machine is heavy - caution when lifting it. Do not lift by projecting components (e.g.
washing machine door).
• Warning: Frozen hoses may tear/burst. Do not install washing machine in outdoor areas or where
there is a risk of frost.
• Lay hoses and cables in such a way that there is no risk of tripping over them.
Choosing the Right Location for Your Washing Machine
• Make sure there’s enough space for your washing machine.
• Install your washing machine on a flat, stable surface to avoid excessive vibrations and noise.
• Don’t install your washing machine in direct sunlight or in a place where temperatures reach
freezing.

Sloping
surface
Unstable Bumpy
surface
Two or more people are required to carry
the washing machine.
• Start by tilting the washing machine backwards.
• One person should stand behind it, holding the rear of the top panel. The other person should grip
the bottom feet at the front.
• Don’t touch the door opening button while holding.
• Check that you have all the required accessories for installation.
• Entrust the installation of the washing machine to a qualified technician.
An additional space of (240mm) is required at the rear of the washing machine. This is to
allow enough space for the water hose and drain hose.
INSTALLATION
5
L612WM11_IB_final110406_running change.indd 5 06/04/2011 6:12 PM

Moving and Installing
Removing the Transit Bolts
Four transit bolts keep the interior of the washing machine in place while it’s being moved.
They need to be removed before installation. Use a spanner (not supplied) and follow the instructions
detailed below.
Moving the Washing Machine from One Location to Another
Before you move the washing machine:
• Shut off the tap and run the washing machine to drain the water. Drain any remaining water from
the pump hose.
• Disconnect the mains cable.
• Attach the transit bolts.
To remove the transit bolts:
1. Use a spanner to loosen the four bolts. They are located at the rear side of the washing machine.
2. Pull the bolts out horizontally. Make sure the entire bolt is removed.
3. Push the four cover caps (included with your accessories) into the respective bolt holes.
Don’t run the washing machine without removing the transit bolts, as this can cause
excessive vibrations.
You’ll need the transit bolts again if you move the washing machine, so make sure you keep
them in a safe place.
1 2 3
Make sure to fix the transit bolts prior to moving the washing machine.
INSTALLATION
6
L612WM11_IB_final110406_running change.indd 6 06/04/2011 6:12 PM

Levelling the Washing Machine
There are 4 levelling feet on the underside. They must be adjusted to make sure the washing machine
is level.
1. On each stand, loosen the lock nut by turning it clockwise with a spanner.
2. Adjust all four feet in this way.
3. Use a spirit level to ensure the washing machine is level.
4. Tighten each lock nut by turning them anti-clockwise (towards the
washing machine body), again using a spanner.
Ensure all four lock nuts are tightened securely. Check the feet are still bolted to
the washing machine - if they’re unbolted, the washing machine will move around.
Water Supply Hose
Points to remember
• Follow the instructions in this section to avoid water leaks.
• Don’t connect the hose to a combination tap.
• Don’t twist, squash, modify or cut the hose.
• Optimum water pressure in the main pipe is 0.05 MPa - 1.0 MPa. If the water pressure is set higher
than this, you will need to install a depressurising valve. Water-flow from the tap should be more
than 5 litres per minute. If you’re unsure, ask a qualified technician to connect the hose.
• This unit must only be connected to cold water mains using the new water inlet hose provided.
Connecting the Water Supply Hose
1. Attach the hose to a tap, and tighten the
plastic joint by hand.
2. Open the tap slowly and check that there
are no leaks around the joint.
Hose and Cable Lengths
Drain
Off
Cold
Cold
Cold
Synthetic
Rinse
Cotton
Delicate
Wool
IntensiveRinse
Spin
30 QuickWash
BabyCare
Reduced
ECOWash
Intensive
Spin
Speed
Programme
Selection 1
Programme
Selection 1
Prewash
Start/Pause
The joint is subject to water pressure.
How to connect from the left side
~80cm
~90cm
~85cm ~135cm
min. 60cm
max. 100cm
~40cm
~130cm
How to connect from the right side
Lock nut
3/4”
min. 10 mm
3/4”
min. 10 mm Plastic joint
INSTALLATION
7
L612WM11_IB_final110406_running change.indd 7 06/04/2011 6:12 PM

Water Drain Hose
Points to remember:
• Don’t twist, pull out or bend the drain hose.
• Your washing machine should be no more than 85cm from the drain outlet.
Draining to a sink or wash-basin
• Secure the drain hose in position, so it can’t drop out of the basin.
• Don’t block the basin’s drain outlet, and make sure that the drainage through it is sufficient.
• Don’t let the tip of the drain hose dip into the drained water, as this can cause the water to flow
back into the washing machine.
U-Shape Holder
Draining to a wash-basin Draining to a drain hose
Connecting to the Mains Supply
For your safety:
• Do not use a mains plug adapter or extension cable.
• If the mains cable or mains plug are damaged, stop using them and call a qualified technician for
assistance.
Installation Check List
By now, you should have installed the washing machine.
Let’s go through the checklist to ensure that the installation has been done correctly!
Questions Checkbox
Transit bolts - Have you removed them and attached the cover caps properly?
4 levelling feet Four Adjustable Stands - Are they bolted securely to the washing
machine?
Four Stand cushions - Are they standing flat?
Power supply - Is the household dedicated mains socket, fully rated at AC220V to
240V independently?
Location - Is your washing machine on a flat, stable surface? Does it run without
vibrating?
Water Supply Hose - Is it free from leaks and is the water supply normal?
Water Drain Hose - Is it free from leaks and is it draining normally?
INSTALLATION
8
L612WM11_IB_final110406_running change.indd 8 06/04/2011 6:12 PM

9
Product Overview
The unit
Drain
Off
Cold
Cold
Cold
Synthetic
Rinse
Cotton
Delicate
Wool
Spin
30 Quick Wash
Intensive Rinse
L612WM11
Spin
Speed
Programme
Selection1
Programme
Selection2
Prewash
Start/Pause
Baby Care
Reduced
Creases
ECO Wash
Intensive
The Detergent
Compartment
The Control Panel
Door Handle
Filter Door
Window
L612WM11_IB_final110406_running change.indd 9 06/04/2011 6:12 PM

10
The Control Panel
Spin Programme
Selection 1
Programme
Selection 2
Prewash Start/Pause
Drain
Off
Cold
Cold
Cold
Synthetic
Rinse
Cotton
Delicate
Wool
Intensive Rinse
Spin
30 Quick Wash
Baby Care
Reduced
ECO Wash
Intensive
Speed
Programme Dial
Different wash
programmes can be
selected according to
your wash requirements.
Start / Pause
Press to start your wash.
Press while in operation
to pause your wash.
Display Window
Only the relevant cycle
function currently in
operation (wash, rinse,
spin) will be lit during the
washing process.
Spin Speed Selection
This button is used to
adjust the spin speed
during the drying stage.
You can change the spin
speed by pressing this
button repeatedly.
Prewash
One washing
procedure added
before the main
wash to increase
the washing
eects.
Programme
Selection 2
This button is
used to choose
ECO Wash
or Intensive
functions.
Programme
Selection 1
You can select from
two functions. Baby
Care or Reduced
Creases to get a
better wash for your
clothes.
L612WM11_IB_final110406_running change.indd 10 06/04/2011 6:12 PM
