Logik LWC25S10 User manual

Wine Cooler
Instruction Manual
LWC25S10

GB-2
Contents
Unpacking.................................................................................................................................... 3
Product Overview........................................................................................................................ 4
Installation ................................................................................................................................... 4
Location .................................................................................................................................................................... 4
Handle Assembly ........................................................................................................................ 5
Levelling the Wine Cooler ................................................................................................................................... 5
Cleaning Before Use ............................................................................................................................................. 6
Before Using Your Wine Cooler ......................................................................................................................... 6
Operating Instructions................................................................................................................ 7
Switching on Your Wine Cooler......................................................................................................................... 7
Using the humidifer............................................................................................................................................... 8
Filling water in the humidifer............................................................................................................................. 8
Stacking the Wine Bottles.................................................................................................................................... 8
Noises Inside the Wine Cooler ........................................................................................................................... 9
Storing Wine in Your Wine Cooler..................................................................................................................... 9
Filling Your Wine Cooler .....................................................................................................................................10
Leave Space Around Wine Cooler...................................................................................................................10
Keep the Door Closed.........................................................................................................................................10
Cleaning ..................................................................................................................................... 11
Cleaning Inside the Wine Cooler.....................................................................................................................11
Cleaning the Outside of the Wine Cooler ....................................................................................................11
Cleaning Tips..........................................................................................................................................................11
Maintenance .............................................................................................................................. 12
Care When Handling ...........................................................................................................................................12
Installation ..............................................................................................................................................................12
Servicing..................................................................................................................................................................12
Switch O for Longer Periods of Time ..........................................................................................................12
Disposal....................................................................................................................................................................12
Disposal...................................................................................................................................... 12
Specication .............................................................................................................................. 13
Safety Warnings......................................................................................................................... 14

GB-3
Before UseOperation
Specification Cleaning and MaintenanceSafety Warnings
If items are missing or damaged, please contact Partmaster (UK only).
Tel: [phone] for assistance.
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Congratulations on the purchase of your new Logik Wine Cooler.
We recommend that you spend some time reading this instruction manual in
order that you fully understand how to install and operate it.
Read all the safety instructions carefully before use and keep this instruction
manual for future reference.
Door x 1
P.N.: 40052000000
Handle x 1
P.N.: RB80600000180
Screws x 2
P.N.: RX401000101168
Shelves x 3
P.N.: RB8060027200
Bottle Rack x 1
P.N.: RB80600027300
Instruction Manual
P.N.: RB30200200000
The Main Unit
2
3

GB-4
Before Use Operation SpecificationCleaning and Maintenance Safety Warnings
Product Overview
The metal bar is used to prevent the wine bottles having direct contact with the rear
evaporator.
Installation
Location
When selecting a position for your wine cooler you should make sure the oor is at and rm,
and the room is well ventilated with an average room temperature of between 16°C and 32°C.
Avoid locating your wine cooler near a heat source, eg. cooker, boiler or radiator. Also avoid
direct sunlight. If you are placing your wine cooler in an outbuilding such as a garage or annex
ensure that the wine cooler is placed above the damp course, otherwise condensation will occur
on the wine cooler cabinet. Never place the wine cooler in a wall recess or into tted cabinets or
furniture.
When your wine cooler is working, the sides may become warm. When installing, ensure that free
space is left at the sides. You may refer to the Overall Space Required in the Specication section.
Please ensure it is positioned at the correct distance from the wall.
2
3
Metal Bar
Shelves Glass Door
Thermostat
Control Dial
Humidier
Bottle Rack

GB-5
Before UseOperation
Specification Cleaning and MaintenanceSafety Warnings
Handle Assembly
1. Take out the handle and 2 screws.
2. Hold the handle onto the door edge and tightened
with the screws provided.
Levelling the Wine Cooler
To do this use the two levelling feet at the front of
the wine cooler.
If the wine cooler is not level, the door and
magnetic seal alignments will not be covered
properly.
Shelves and Bottle Rack Installation
Place the bottle rack at the bottom of the
compartment rst, and then place the shelves one
by one onto the side ribs inside the compartment.

GB-6
Before Use Operation SpecificationCleaning and Maintenance Safety Warnings
Cleaning Before Use
Wipe the inside of the wine cooler with a weak solution of bicarbonate soda. Then rinse with
warm water using a‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the
shelves and salad bin. Clean the exterior of the wine cooler with a damp cloth.
If you require more information refer to the CLEANING section.
•Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the wine
cooler.
•Before Turning On!
Do not turn on until two hours after moving the wine cooler. The coolant fluid needs time
to settle.
Before Using Your Wine Cooler
Before placing any wine in your wine cooler, turn it on and wait for 24 hours, to make sure it
is working properly and to allow the wine cooler to fall to the correct temperature. Your wine
cooler should not be overlled.

GB-7
Before UseOperationSpecification Cleaning and MaintenanceSafety Warnings
Operating Instructions
Switching On Your Wine Cooler
1. The internal temperature of your wine cooler is
controlled by a thermostat. There are 7 settings, of
which position 7 is the coldest and position 0 turns
the wine cooler o.
2. Make sure that the Thermostat Control Dial, located
inside the wine cooler on the right hand side is set
to 7.
3. After the wine cooler has been on for 20 minutes
adjust the Thermostat Control Dial to 5 – 6.
This is the recommended setting for the
wine cooler when operating at normal room
temperature (between 16°C and 32°C).
4. The wine cooler may not operate at the correct
temperature if it is in a particularly hot or a
particularly cold room, or if you open the wine
cooler door often.
5. If you are concerned that your wine cooler is not
being kept cold enough and wish to check the
temperature you will need a special wine cooler
thermometer. You may also need a hygrometer to
check the humidity of your wine cooler. These are
available from most supermarkets and hardware
shops.
Place the thermometer and hygrometer on the
middle shelf of the wine cooler, where they can be
read easily. Leave overnight, the temperature in the
wine cooler should be between 5°C and 20°C and
the humidity in the wine cooler should be between
50%-80% RH depending on the type of wine.
6. In the 0 position the wine cooler will not operate,
but the power supply remains connected.
2
3

GB-8
Before Use Operation Specification
Cleaning and Maintenance Safety Warnings
Using the humidifer
Using the humidier can protect wine from too much or too less humidity. If your wine cooler is
too dry (below 50% RH), the cork dries up. The air can get into the wine and alter its composition.
However the humidity of your wine cooler can’t be too high (above 80% RH), as the humidity
damages the cork and the smell of the cork will go into the wine.
Filling water in the humidifer
1. Take out the wine bottle from the bottle rack.
2. No need to remove the humidier.
3. Use a bottle which is narrow neck to ll water into the water tank to the level of 350ml.
•It is better to use cold soft water or distilled water.
•For keeping the best stock environment for your wine, please remember to add water
every ve days.
2
3
Max Capacity : 25 bottles
2
3
Stacking the Wine Bottles
The shelf system has been designed
so that a range of shelf heights can be
selected. All the shelves can be adjusted.
There is also a bottle rack at the bottom of
the wine cooler.

GB-9
Before UseOperationSpecification Cleaning and MaintenanceSafety Warnings
Noises Inside the Wine Cooler
If you have not owned a wine cooler before, you may notice that it makes some rather unusual
noises. Most of these are perfectly normal, but you should be aware of them!
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has
become more pronounced since the introduction of CFC free gases. This is not a fault and will
not aect the performance of your wine cooler.
This is the compressor motor working, as it pumps the refrigerant around the system.
Storing Wine in Your Wine Cooler
One benet of your new wine cooler is that you can simulate the conditions of a wine cellar.
By using a wine cooler thermometer you can ensure a constant temperature of around 5-20°C,
which is ideal for storing wine. Make sure the bottles are lying on their sides. This ensures the
wine inside is in contact with the cork, which stops the cork drying out, shrinking, letting air
in and spoiling the wine. After a bottle has been opened, the wine comes into contact with air
which will start to oxidise the wine. This generally occurs on the wine’s contact surface, leaving
the remaining wine in good condition. By leaving your bottle standing, you minimise the surface
area of the wine in contact with air.
If you’re serving white, rose or sparkling wine, chill it lightly for at least two hours in the wine
cooler before serving. Most reds should be served at room temperature, or in the case of lighter
reds like Beaujolais, very slightly chilled.
Opened wine will remain in good condition for up to two days (for delicate whites) or three days
(for rich reds) as long as the bottle is resealed and stored in your wine cooler. Special stoppers
that keep sparkling wine and Champagne bubbling for one or two days after opening can be
bought at most good wine shops. When storing leftover wine, attempt to minimise the oxidation
process of the wine. You can use a ‘vacuum’ which pumps out the air in the bottle leaving a semi-
vacuum. The wine should last for about two weeks.
However, if it is a good quality wine and you intend to nish it within one week, all you’ll need to
do is to replace the cork and leave it standing in your wine cooler.
Dierent wines are best kept at dierent temperatures. To choose the temperature at which to
store your wines please consult the table below.
Serving Temperatures
Wine Type °F °C
Rose Wine 48-54 9-12
White Wine 48-58 9-14
Sherry (Light) 48-58 9-14
Red Wine 57-68 13-20
Fortied Wine 57-68 13-20
Sherry (Dark) 57-68 13-20

GB-10
Before Use Operation Specification
Cleaning and Maintenance Safety Warnings
Filling Your Wine Cooler
When lling your wine cooler the greater the amount of wine placed inside the wine cooler
from room temperature, the longer it will take to cool them to the desired temperature. You may
wish to temporarily turn the Thermostat Control Dial to a higher setting to speed up the cooling
process. If you do this remember to return it to the previous setting once the wine have reached
the required temperature in order to conserve energy.
Leave Space Around Wine Cooler
Ensure 2.5 cm (1”) of free space at the sides should be left around wine bottles, this will allow
cold air to circulate around the wine cooler and improve the eciency of the cooling process.
Keep the Door Closed
To prevent cold air escaping, limit the number of times your open the door.
