Logitech Z906 User's Guide User manual

Logitech®
Surround Sound Speakers Z906
User’s Guide

2
Logitech®Surround Sound Speakers Z906
Contents
English 3
Español 15
Français 27
Português 39

English 3
Logitech®Surround Sound Speakers Z906
Thank you
Thank you for purchasing Logitech® Surround Sound Speakers Z906—designed to let you hear
every detail, all around you, with theater-quality 5.1 sound for your movies, games and music.
Dolby® Digital
Dolby Digital is the universal standard for 5.1
digital sound. Onboard 5.1 digital decoding
enables detailed surround sound—from the roar
of the crowd to the footsteps right behind you—
in your Dolby Digital soundtracks.
THX® Certified
THX certification is the seal of approval for
speaker quality. The Z906 speakers have
met strict performance standards to achieve
THX certification—so you can be sure that
your entertainment will sound the way it was
meant to.
DTS Digital Surround™
DTS is dedicated to making digital entertainment exciting, engaging and effortless by providing
state-of-the-art audio decoding. Blu-ray Disc technology adoption of DTS means you’ll get the
highest quality surround sound—in all of your DTS digital surround soundtracks.
For information about safety, compliance, and warranty,
please see the Important Information document.

4English
User’s guide
1. Four satellite speakers
2. Subwoofer
3. Center satellite speaker
4. Remote control
5. Control console
6. Five lengths of standard 18-guage speaker wire:
• Two 7.6-meter lengths for rear satellite
speakers
• Three 4.6-meter lengths for front and center
satellite speakers
7. 6-channel direct input cable
8. Three AAA alkaline batteries (remote control)
9. User documentation
Important information
Safety, compliance, and warranty
Logitech
®
Surround Sound Speakers Z906
User’s Guide

English 5
Logitech®Surround Sound Speakers Z906
Speaker placement
Before you position your speakers, take a look
around your room and figure out the best setup
(see diagram to the right). It’s easiest to place
all your speakers in the desired locations before
attaching any cables.
Satellite speakers – Place the two front
satellite speakers on either side of your
computer monitor or television, about the same
distance from each other as they are from your
listening position (e.g., the couch). Angle them
to face you. Place the two rear speakers behind
you and about the same distance apart as
the front speakers. You may want to mount
these speakers on the wall (see Wall mounting).
Center satellite speaker – Place your center
satellite speaker on your desk, or in front of
your monitor or television; you may also
wall-mount it.
Subwoofer – You can place the subwoofer
anywhere in relation to the other speakers.
To get the strongest bass, place your subwoofer
near a wall or corner, or under a desk. Make sure
that nothing is closer than 16 cm to the driver
or the bass port because it will affect your
sound. It’s also important to have adequate
ventilation around the subwoofer.
Control console –Place the control console
where it’s easy to reach. And make sure the IR
window is in plain view so the remote control
can communicate with it.
Subwoofer
Couch

6English
User’s guide
Subwoofer
Inputs
1. 6-channel direct
(PC sound card)
2. RCA (stereo)
3. Digital optical
4. Digital optical
5. Digital coaxial
Console
6. DB-15 pin connector
Speakers
7. Rear left
8. Rear right
9. Front left
10. Front right
11. Center
Power
12. Cable
Subwoofer back panel
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
2
34 5
1
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
1
34 5
2
12

English 7
Logitech®Surround Sound Speakers Z906
Connecting your speaker cables
The Z906 comes with five speaker cables: two 7.6-meter
cables for the rear satellites and three 4.6-meter cables
for the front and center satellites. When connecting
your speakers, the control console, and your audio source,
make sure the power to the system is off.
Connect the speaker cables –Connect your satellites
to the subwoofer using the speaker cables. Push the tab
on the spring clip, insert the wire into the connector,
and release the tab. Be sure that you match the wire
color (red or black) to the spring clip colors on both the
subwoofer and the satellite.
Connect the control console DB-15 cable – Connect
the control console DB-15 cable to the corresponding DB-
15 pin connector jack on the subwoofer.
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT

8English
User’s guide
1. Power On/Off
2. Input indicator
3. Decode indicator
4. Volume/Level indicator
5. Volume/Level adjust: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels.
6. Speaker indicator
7. IR remote window
8. Level select: Use this to select subwoofer, rear
satellites, center channel, or main volume levels.
9. Mute: Mutes the whole system.
10. Effect select: When a stereo source is present,
use this to select your desired sound effect:
• Stereo 3D – Provides a 3D surround sound
effect through all speakers
• Stereo 4.1 - Plays stereo through both front
and both rear satellites, plus the subwoofer
• Stereo 2.1 – Plays stereo through both the
front satellites and the subwoofer
11. Input select: Use this to select your audio source
(6-channel direct, stereo, optical, coax, and Aux).
12. Headphone jack (side of console): When you plug
your headphones in, all other outputs will be
automatically muted.
13. Aux input (side of console)
INPUT
1
2
3
3D
4.1
2.1
4
5
AUX
DECODE
STEREO
MUTE
INPUT EFFECT LEVEL
12
13
Control console

English 9
Logitech®Surround Sound Speakers Z906
1. Battery door: Install the three AAA batteries
2. Power On/Off
3. Input select: Use this to select your audio source
(6-channel direct, stereo, optical, coax, and Aux).
4. Mute: Mutes the whole system.
5. Level select: Use this to select subwoofer, rear
satellites, center channel, or main volume levels.
6. Volume/Level up: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels
7. Effect select: When a stereo source is present,
use this to select your desired sound effect:
Stereo 3D, Stereo 4.1, and Stereo 2.1.
8. Volume/Level down: Use this to adjust the main
volume, subwoofer, rear satellites, and center
channel levels
9. Test: See Testing your system for more information
about this mode.
Remote control
Control your listening experience without ever getting off the couch.
INPUT MUTE
LEVEL
EFFECT

10 English
User’s guide
Connect the subwoofer
power cable
Plug the subwoofer power cable into an
electrical outlet.
Adjust volume
Set volume to the nine o’clock position to test;
adjust thereafter as needed.
Turning on your system
Press the POWER ON/OFF button on the remote
control or control console to turn on your Z906.
Testing your system
To test whether you have correctly set up
your speakers, press and hold the INPUT button
on the remote control or control console for
5 seconds to put your system into test mode.
In test mode, the system cycles through each
speaker, playing an audible test signal. The test
signal comes from only one speaker at a time,
in 5-second intervals, in the following order:
left front, center, right front, right rear, left rear,
and subwoofer.
As a channel is tested, its corresponding LED
lights up on the front panel of the control
console. The test signal cycles through each
speaker one time and stops. To re-enter test
mode, press and hold the INPUT button on
the remote or control console for 5 seconds.
INPUTS
CONSOLE
2
34 5
1
INPUTS
CONSOLE
1
34 5
2
Subwoofer back panel
Connect the audio source cable
Turn off speakers
Connect your audio source (e.g., TV, DVD,
computer) to the appropriate input jack on
your subwoofer.
•For computer sound cards, use the 6-channel
input (cable included).
•For stereo devices, use the Stereo RCA input
(cable not included).
•For digital devices, use the digital inputs
(cable not included).

English 11
Logitech®Surround Sound Speakers Z906
Selecting your audio input
Use the remote control or the control console to select an input source. Pressing the INPUT
button cycles through the various audio input sources, which will always cycle in the same order.
Digital input
If you’re using a digital connection, follow the instructions on your audio source to make sure you’re
getting digital audio output.
For digital content, the control console automatically detects and displays the Digital stream as long
as the device is connected to a digital input. For example, if you have selected the DTS Digital Sound
or Dolby Digital 5.1 stream for a DVD you want to watch, it will be detected automatically when you
choose the applicable input.
Using the Effect select control with stereo sources
When playing stereo audio, you can use the Effect Select control on the remote control or the
control console to choose the type of sound you want to hear.
• Stereo 3D – Provides a 3D surround sound effect through all speakers
• Stereo 4.1 – Plays stereo through both front and both rear satellites, plus the subwoofer
• Stereo 2.1 – Plays stereo through both the front satellites and the subwoofer
• No Effect – Plays audio format of your computer’s sound card without applying any effects.
Available for 6 channel input only and is represented by having no Effect LEDs illuminated
Whenever you change the input, the last effect you selected is automatically restored. For example,
if you select Stereo 3D while listening to Input 2, the next time you select Input 2, Stereo 3D is
automatically selected.
Enjoy!
After you’ve made sure that you’ve set up your system correctly—and the selected input and effect
are correctly displayed on the control console—you’re ready to go. Just press play and get immersed
in your new Z906 speaker system.

12 English
User’s guide
Frequently asked questions
Q: I can’t hear any sound out of my Z906 speakers, and I see flashing lights on the front of the
control console. How can I resolve this?
A: a) The Z906 uses DTS Digital Sound/Dolby Digital decoding to process data into 5.1 surround
sound. If the Z906 receives neither DTS Digital Sound nor Dolby Digital decoding data, the Z906
will not be able to decode the signal. You can resolve this issue by making sure the Z906 receives
only a DTS Digital Sound or Dolby Digital signal from the host device (for example, DVD/Blu-ray
player, game console, or home computer). Please refer to your equipment manufacturer’s support
documentation for additional details.
A: b) Most DVD and Blu-ray Disc movies have audio encoded in both DTS Digital Sound and Dolby
Digital. Check the on-disc Audio menus to make sure the movie is playing either a DTS Digital Sound
or Dolby Digital signal.
Q: Where can I learn more about my speakers?
A: Visit the Logitech web site at www.logitech.com. If none of the above answers resolve the
problem, please contact Logitech Customer Support.
Error states
• No data – If you select a digital input and no digital stream exists for that input, the Effect and
Decode indicators on the control console will not be illuminated.
• Unknown data – The Decode and Effect LEDs will cycle continuously when you select a digital
input and its data stream cannot be decoded because the digital content is neither DTS Digital
Sound nor Dolby Digital.
Wall mounting
You can mount your satellite speakers with the appropriate hardware (not included). When attaching
a satellite speaker to a wall mount, make sure not to overtighten the mounting screw. Doing so may
damage the screw threads inside the speaker’s mounting lug.

English 13
Logitech®Surround Sound Speakers Z906
Performance specifications
•Total watts (RMS): 500 watts
- Subwoofer: 165 watts (6 ohms, at 52 Hz, at 10% THD)
- Satellites: 335 watts RMS (5 x 67 watts per channel {4 ohms at 3.85kHz, at 10% THD})
•Maximum SPL: >110 dBC
•Frequency response: 35 Hz – 20 KHz
•Amplifier: Ultra Efficient Class D
•Input Impedance: 8,000 ohms, min
•Signal to Noise ratio, A-weighted: >95dB
•Drivers:
- Satellites: 3” polished aluminum phase plug drivers
- Subwoofer: 8” high-excursion ported driver with 6th-order bass reflex enclosure
•Supported digital formats: Dolby Digital and DTS Digital Sound
•Source inputs:
- Digital Coaxial
- Digital Optical (2)
- 6-channel direct (3 x 3.5mm)
- Stereo (RCA)
- Analog stereo-mini (3.5mm)

14 English
User’s guide
What do you think?
Please take a minute to tell us.
Thank you for purchasing our product.*
www.logitech.com/ithink
* The sample customer survey shown here is in English. Logitech supports many languages on its Web site.

Español 15
Logitech®Surround Sound Speakers Z906
Gracias
Te agradecemos la adquisición de Logitech® Surround Sound Speakers Z906, un sistema
de altavoces diseñado para que puedas oír cada detalle de manera envolvente, con sonido 5.1
de calidad de cine para sus películas, juegos y música.
Dolby® Digital
Dolby Digital es el estándar universal para
sonido digital 5.1. La descodificación digital
5.1 integrada ofrece un sonido envolvente
detallado (desde el clamor de la multitud hasta
los pasos detrás de ti) en las bandas sonoras
Dolby Digital.
Certificación THX®
La certificación THX es el sello de garantía
de la calidad de un sistema de altavoces.
Los altavoces del sistema Z906 han cumplido
unas estrictas normas de rendimiento para
ganarse la certificación THX: puedes estar
seguro de que el material multimedia sonará
como debe sonar.
Para obtener información sobre seguridad, cumplimiento de normativas
y la garantía, consulta el documento de información importante.
DTS Digital Surround™
DTS está pensado para hacer el uso de material digital más ameno, interesante y sencillo,
mediante descodificación de audio avanzada. La tecnología Blu-ray usada en DTS aporta mayor
calidad de sonido envolvente en todas las bandas sonoras DTS digitales envolventes.

16 Español
Manual del usuario
1. Cuatro altavoces satélite
2. Subwoofer
3. Altavoz satélite central
4. Control remoto
5. Consola de control
6. Cable de altavoz estándar de calibre 18 (AWG)
de cinco longitudes:
• Dos cables de 7,6 metros para los altavoces
satélite posteriores
• Tres cables de 4,6 metros para los altavoces
satélite frontales y el altavoz satélite central
7. Cable de entrada directa para seis canales
8. Tres baterías alcalinas AAA (control remoto)
9. Documentación del usuario
Important information
Safety, compliance, and warranty
Logitech
®
Surround Sound Speakers Z906
User’s Guide

Español 17
Logitech®Surround Sound Speakers Z906
Colocación de los altavoces
Antes de colocar los altavoces, observa el
espacio para decidir la mejor ubicación
(consulta el diagrama de la derecha).
Resulta más fácil colocar todos los altavoces
en la ubicación deseada antes de conectar
los cables.
Altavoces satélite: coloca los dos altavoces
satélite frontales uno a cada lado del
monitor de la computadora o del televisor
y, aproximadamente, a la misma distancia
entre ellos que respecto al punto de escucha
(por ejemplo, el sofá). Oriéntalos dirigidos
al oyente. Coloca los dos altavoces posteriores
detrás del oyente y a la misma distancia entre
ellos que los altavoces frontales. Si lo deseas,
puedes montar los altavoces en la pared
(consulte Montaje en pared).
Altavoz satélite central: coloca el altavoz
satélite central en su escritorio o frente al
monitor de la computadora o del televisor;
también puedes
montarlo en la pared.
Subwoofer: el subwoofer puede colocarse
en cualquier ubicación con respecto al resto
de los altavoces. Para obtener graves más
potentes, coloca el subwoofer cerca de una
pared o una esquina o debajo de una mesa.
Asegúrate de que no haya nada a menos de
16 cm del transductor o el puerto de graves,
ya que esto afectaría al sonido. También es
importante que la ventilación sea adecuada
alrededor del subwoofer.
Consola de control: coloca la consola
de control en un lugar al que puedas acceder
fácilmente. Asegúrate también de que la
ventana de infrarrojos esté despejada para
que el control remoto pueda establecer
comunicación.
Subwoofer
Sofá

18 Español
Manual del usuario
Subwoofer
Entradas
1. Entrada directa para
6 canales (tarjeta de
sonido de PC)
2. RCA (estéreo)
3. Entrada óptica
digital
4. Entrada óptica
digital
5. Entrada coaxial
digital
Consola
6. Conector de patillas
DB-15
Altavoces
7. Posterior izquierdo
8. Posterior derecho
9. Frontal izquierdo
10. Frontal derecho
11. Central
Alimentación
12. Cable
Panel posterior del subwoofer
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
2
34 5
1
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
INPUTS
CONSOLE
1
34 5
2
12

Español 19
Logitech®Surround Sound Speakers Z906
Conexión de los cables de los altavoces
El sistema Z906 incluye cinco cables de altavoces:
dos cables de 7,6 metros para los altavoces satélite
posteriores y tres cables de 4,6 metros para los altavoces
satélite frontales y el altavoz satélite central. Al conectar
los altavoces, la consola de control y la fuente de audio,
asegúrate de que el sistema esté apagado.
Conexión de los cables de los altavoces:
conecta los altavoces satélite al subwoofer haciendo uso
de los cables incluidos. Presiona la lengüeta del terminal
de resorte, introduce el cable en el conector y suelta
la lengüeta. Ten cuidado de conectar los cables a las
lengüetas del mismo color (rojo o negro) del subwoofer
y el altavoz satélite.
Conexión del cable DB-15 de la consola
de control: conecta el cable DB-15 de la consola de
control al conector de patillas DB-15 correspondiente
del subwoofer.
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT
SPEAKERS
FRONT RIGHT
FRONT LEFT
CENTER
REAR RIGHT
REAR LEFT

20 Español
Manual del usuario
1. Encendido/apagado
2. Indicador de entrada
3. Indicador de descodificación
4. Indicador de volumen/nivel
5. Ajuste de volumen/nivel: utiliza este control
para ajustar el volumen principal y el nivel
del canal central, los altavoces satélite posteriores
y el subwoofer.
6. Indicador de altavoz
7. Ventana de control remoto por infrarrojos
8. Selección de nivel: utiliza este control para
seleccionar el nivel del volumen principal,
el subwoofer, los altavoces satélite posteriores
o el canal central.
9. Mute: silencia el sistema.
10. Selección de efecto: cuando haya una fuente
estéreo presente, utiliza este control para
seleccionar el efecto de sonido deseado:
• Estéreo 3D: proporciona un efecto de sonido
envolvente 3D haciendo uso de todos
los altavoces
• Estéreo 4.1: reproduce en estéreo haciendo
uso de los altavoces satélite frontales
y posteriores y el subwoofer
• Estéreo 2.1: reproduce en estéreo haciendo
uso de los altavoces satélite frontales
y el subwoofer
11. Selección de entrada: Utiliza este control
para seleccionar la fuente de audio (directa para
6 canales, estéreo, óptica, coaxial o auxiliar).
12. Toma de auriculares (lateral de consola):
al conectar los auriculares, las otras salidas
se silencian automáticamente.
13. Entrada auxiliar (lateral de consola)
INPUT
1
2
3
3D
4.1
2.1
4
5
AUX
DECODE
STEREO
MUTE
INPUT EFFECT LEVEL
12
13
Consola de control
