Loki Plugin User manual

2022.08.17

PLUGIN LOKI

KEY FOB PAIRING

FOR TESLA MODEL X FEATURE

USER GUIDE

UNIQUENESS

TRAINING

SERVICE

INNOVATION

WARRANTY

QUALITY

English

User guide

3

CONTENTS

INTRODUCTION....................................................................................................................................................4

1. CONNECTION TO THE VEHICLE .....................................................................................................................5

2. KEY PAIRING.....................................................................................................................................................6

3. PREPARING THE PAIRING KEY (PROVISION) ............................................................................................ 8

4. PAIRING THE KEY (PAIRING).........................................................................................................................9

CONTACTS...........................................................................................................................................................12

English

Plugin Key Fob Pairing for Model X Feature

4

INTRODUCTION

To key for pairing for Model X , the LOKI module, the LC003-CX cable, the clean key (or several)

and BLE dongle with the activated plugin are used.

Before turning on the module, you must connect BLE dongle to any port of the USB module.

The module itself is connected by LC003-CX cable to the diagnostic CAN port of the vehicle under

the monitor.

To work plugin you need to connect to the Internet.

WARNING!The plugin cannot untie an existing key or pairing the being in the use key.

The theoretical number of keys that can be pairing to a car is 20.

In general, the pairing process is as follows:

1. Connecting the module to the vehicle, reading the existing list of keys;

2. Connect the module to the clean key;

3. Provision procedure for entering data into the key;

4. Pairing procedure for directly pairing the key to the vehicle.

English

User guide

5

1. CONNECTION TO THE VEHICLE

The vehicle must be switched on, ignition is not necessary.

After connecting the module with the LC003-CX cable, you must go to the key pairing window.

If the connection is successful, a list of keys in the BCCEN module and data about the vehicle

and dongle will be displayed.

English

Plugin Key Fob Pairing for Model X Feature

6

2. KEY PAIRING

To connect to the key it is necessary to bring it to the module at a distance of up to 70cm (closer

- better), and start a key search by the button "Start Key Discovery", after the dongle initialization,

you need to double-click the front trunk button to wake the key.

After discovery, the key will appear in the list.

English

User guide

7

After the key is discovered, you need to connect to it, just click on the "Connect" of the desired

key in the table. As soon as the corresponding inscription appears in the log - press three times

on the front trunk button to confirm the connection.

After reading the data from the key, it is considered connected.

The status of the key can be seen in the SE State field where:

– Personalization - Clean Key, ready for Provision procedure;

– Active - A key that has passed the Provision procedure, is waiting to execute the Pairing

procedure;

– Paired - Paired key after Pairing procedure.

WARNING!The key transition from the Personalization state to all subsequent states is

irreversible.

English

Plugin Key Fob Pairing for Model X Feature

8

3. PREPARING THE PAIRING KEY (PROVISION)

WARNING!Once this procedure is started, the key cannot be used to paired to another car.

To perform the Provision procedure, just click on the corresponding menu item, the program will

automatically configure the key for the connected vehicle and prepare it for pairing.

Information about the end of the procedure will appear in the log.

If the key was not clean, the log will look like this.

English

User guide

9

After successfully completing the Provision procedure, you can proceed with the Pairing

procedure.

4. PAIRING THE KEY (PAIRING)

To perform the Pairing procedure, just click on the corresponding menu item, the program will

automatically attach the key to the connected vehicle.

English

Plugin Key Fob Pairing for Model X Feature

10

After you complete the pairing procedure, you need to restart the BCCEN block and read the key

list to ensure that the pairing succeeds.

English

User guide

11

The pairing procedure of the first and all subsequent keys is not different, so if necessary, pairing

several keys procedure should be repeated for each of them, the old keys will not be disconnected

and will continue to work.

English

Contacts

12

MSG Equipment

HEADQUARTERS AND PRODUCTION

MSG equipment

18 Biolohichna st.,

61030 Kharkiv

Ukraine

+38 057 728 49 64

+38 063 745 19 68

E-mail: [email protected]

Website: servicems.eu

REPRESENTATIVE OFFICE IN POLAND

STS Sp. z o.o.

ul. Modlińska, 209,

Warszawa 03-120

+48 833 13 19 70

+48 886 89 30 56

E-mail: [email protected]

Website: msgequipment.pl

TECHNICAL SUPPORT

+38 067 434 42 94

E-mail: [email protected]
