Lorentz PS Commander Specification sheet

The Solar Water Pumping Company
EN
Photo may dier from actual product
Manual for Installation and Operation
PS Commander
Monitoring and managing systems remotely

EN
2 Introduction 3
EN
2 Content Introduction 3
1 Introduction
Thank you for purchasing a LORENTZ PS
Commander.
Pre-installation checklist
Check the item numbers of all the components of
your system, and verify that they are the items that
you ordered.
Read this manual in full. Store the manual and the
replacement parts near to the PS Commander. Install
any pump systems that the PS Commander will
connect to.
Subscribe to the LORENTZ Global service which
includes SIM card activation.
1.1 Product description
LORENTZ PS Commander connects pump controllers
securely to the IoT (internet of things).
LORENTZ CONNECTED
All LORENTZ pump systems have built-in data
logging. At each installation site, an installed
LORENTZ controller collects the performance data
from the pump system and stores it for periodic
collection. The controller uses Bluetooth™ to
communicate with the LORENTZ CONNECTED
apps allowing secure real-time data to be viewed
and historic data to be collected without physical
connections.
LORENTZ Assistant
To view real-time data or to collect historic data an
application called “Assistant” is used. Assistant runs
on the Android Operating System (smartphone or
tablet) and communicates with the controller via
Bluetooth. The communication distance is up to 10 m
(33 ft). Pump setting changes such as on/o timers
and speed control can also be made.
Table of Content
1 Introduction .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 3
1.1 Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.2 Product features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
2 Storage and Handling .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .5
3 Ambient and operating conditions .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 5
4 Installation.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. . 5
4.1 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
4.2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
4.3 Assembly of PV-Module bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
4.4 Placement of the PS Commander. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
5 Start-up and operation .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .9
6 Troubleshooting. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .9
6.1 Missing pump connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
6.2 No connection to telecommunication network . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.3 No connection to LORENTZ server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
6.4 Low Voltage Disconnect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6.5 SIM card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

EN EN
4 Introduction Storage and Handling 5
LORENTZ PS Commander
The Commander is used to control and read the
values and stored data of a pump system via remote
control comfortably from home, oce or on the
road. It is possible to handle several pump systems.
LORENTZ Global
This is a cloud-based water management system
which allows you to monitor and manage LORENTZ
devices anywhere in the world, whether that means
a service for one pump for a farmer or thousands
of pumps for a utility, corporate customer or
governments.
Using this service means you know exactly what is
happening in (very near) real-time. Benets include:
Reduced risk and losses from failed water delivery
Saves time and costs by reducing site visits
Allows you to plan ahead (e.g. forecast any
potential shortages)
With a LORENTZ solar pump system and Global you
can talk to your pump from anywhere.
1.2 Product features
The LORENTZ PS Commander has the following
features:
connection to a maximum of 8 PS2, PSk2 or PSk3
pump systems within Bluetooth range
grid-independent 24h power supply
connection to LORENTZ Global via mobile
communication networks:
 19-001900/19-001880: 2G/3G
 19-001860/19-001870: 2G/4G (LTE-M1 or
LTE-NB)
long life expectancy and proven in service record
designed for use in remote and harsh conditions
self-monitoring of battery voltage, signal strength,
temperature and irradiation
smart modular design for simple and cost
eective servicing and repair
fast and simple installation
engineered in Germany
4 Installation
Unscrew the lid to open the PS Commander for
battery and PV installation. The installation must
be done with great care and diligence. Close the lid
when all work has been done.
l WARNING: Never connect any other
power source to the "SOLAR IN" terminal
than a PV module as specied below.
The PS Commander will periodically
short-circuit the input to measure the
irradiation. Any other power source
would consequently damage the device
and/or the power source itself.
a Note: If an external power supply must
be used, do not connect the PV module.
Connect a 12V DC power supply to the
battery input instead of the battery.
Irradiation measurement will not be
possible in this conguration.
4.1 Power supply
The PS Commander gains its grid independent
power from a battery charged by a PV module. The
required battery and PV module must be ordered
separately.
2 Storage and Handling
On receipt of your product check that the packaging
is undamaged and complete. If any abnormality is
found, contact your distributor. It should remain in
the packaging until it is to be installed. Handle the
PS Commander with care and avoid unnecessary
impacts and shocks. The required battery and PV
module must be ordered separately.
Prolonged intermediate storage in an environment
of high humidity and uctuating temperatures must
be avoided. Moisture condensation may damage
electrical and metal parts. Non-compliance will void
any warranty. It is recommended to store the parts
in a closed and dry room. The PS Commander can be
stored in the range of -4 °F to 122 °F (–20 °C to 50 °C).
It should not be exposed to direct sunlight.
3 Ambient and operating
conditions
Operating temperature
The PS Commander should only be operated in a
temperature range of 5°F to 122°F (-15°C to +50°C).
Humidity and air salinity
The PS Commander must not be operated where the
day average humidity is above 80% or in saline air
with more than 2µg/m³.
Altitude
The PS Commander must not be installed at
altitudes above + 3000m m.s.l.

EN EN
6 Installation Installation 7
4 . 2 .1 Battery
Use the 2 pin battery plug with the pre-assembled
cables. The red cable is for plus (+), the black cable is
for minus (-).
Make sure the cables are securely mounted to the
battery. Ensure and check the correct polarity.
Slide in the battery. Ensure the battery is correctly
seated and secure it with the battery xation strap.
4.2.2 PV module
The PV module has a pre-wired cable. The
numbering of the phases is printed on the cable
jacket of the phases (1 is for plus (+), 2 is for minus
(-) ). Thread the cable through an appropriate cable
gland. Use the rubber seal (from the plug in the
cable-gland) to seal the cable entry. Connect the
cable to the Solar in terminal. The left terminal is for
plus, the terminal to the right is for minus. Use the
cable-gland in the bottom lid for strain relieve and
sealing.
Do not connect the plug at this point. The PS
Commander start-up is described in chapter 5.
PV-Module characteristics
Pmax Imp Vmp Isc Voc
unit [Wp] [A] [V] [A] [V]
value min. 20 1.2 17.2 1.3 21.6
value max. 150 7.9 8 18.8 8.5 22.7
If a PV module other than LORENTZ LC-20-12M
is used then the Isc must be congured via the
LORENTZ Assistant app accordingly.
4.2 Wiring
l WARNING – All electrical connections
should be performed by qualied experts
only!
The kit includes two green plugs, one is for the
battery and already pre assembled with a red (plus)
and black (minus) cable. The second plug is for
Solar In. The two plugs must be removed from the
board before wiring. The socket on the bottom right
lower edge of the board is for the PV-Module cables
(labeled with “ SOLAR IN”). The socket on the centre
right side of the board is for the battery cables
(labeled with “BATTERY”).
Battery
If a battery is not delivered by LORENTZ, it must
meet the following characteristics:
Genesis NP7-12 or similar. Sealed 12V AGM lead
acid battery
Min. capacity: 5Ah
Max. dimensions without connector:
151 x 70 x 95 mm (5.94 x 2.56 x 3.74 in)
Height overall max. 100mm (3.94 in)
Connector: 4.8 mm (0.189 in) faston tabs
It is possible to purchase a battery from LORENTZ.
Contact your distributor for further information.
PS Commanders delivered by LORENTZ, with
batteries included, must be re-charged every 6
months during storage.
PV module
The recommended PV-module is:
LORENTZ LC20-12M
The PV-Module is not only for battery charging.
It is also used as a measurement sensor for
irradiation detection. If a PV-module other than the
recommended is used,it must meet the following
characteristics:
4.2.3 Fuse
The fuse is switched in the red cable (plus) of the
battery cable. Pull out and replace the fuse if it is
broken. The fuse has no special orientation.
2A fast-acting ATO fuse
One fuse is pre-installed to the Battery cable,
another one fuse is delivered as replacement.
4.3 Assembly of PV-Module bracket
We recommend that you use the delivered PV
module bracket and to install it as mentioned in this
section.
Assemble the brackets to the pre-assembled PV
module braces. Use four M6x16 screws (with 1x
washer and 1x spring washer) as shown in „Figure 2:
Mounting of the brackets“. Fasten the screws with
10Nm.
Figure 1: PS Commander wiring slots
PV-
module
slot
Battery
slot

EN EN
8 Installation Start-up and operation 9
6 Troubleshooting
6.1 Missing pump connection
If a pump controller does not connect to the PS
Commander check that:
The pump controller is either a PS2, PSk2 or PSk3
controller. Other controllers are not supported by
the Commander.
a green system light is shown on the pump
controller
there is no active Assistant connection to the
pump system
there are not more than 8 PS Controllers within
range of the PS Commander. In this situation the
9th pump would not connect.
the Bluetooth signal strength is not impaired by
obstacles, walls or other interfering signals or
mounting the PS Commander in a metal box
5 Start-up and operation
Before installing the device it is advised to register
the system(s) in partnerNET Sites and to start the
monitoring service in partnerNET in order to activate
the SIM card.
The Commander is designed following "plug'n'play"
principles for ease of use.
Upon powering the device it will automatically
connect to the best network available
search for nearby Lorentz pump controllers and
forward their data to the remote management
platform LORENTZ Global
a NOTE: The Commander will regularly
search for new Lorentz controllers within
reach. If required, the Commander can
be congured to only connect to specic
pump controllers via the LORENTZ
Assistant app.
The PS Commander must be mounted vertically to a
wall or a pole using appropriate xings.
Mounting hole distances (Width x Height, Hole
Diameter):
Product Dimensions
PS Commander 270x150, Ø6mm
[10,63x5,9 Ø0,236in
Place the PV-Module holder at least 10cm (3.95 in)
above the PS Commander. The holes in the wall, for
the PV module holder, have to be 330mm (13.0 in)
away from each other. Use M8 screws.
4.4 Placement of the PS Commander
The Commander must be placed near to the pump
controller. The maximum Bluetooth range is up to
10m but depends on the surrounding conditions.
For example; walls, shelters or other signals may
weaken the signal strength. Keep the PV module free
of shadow and with a South (Northern Hemisphere)
or North (Southern Hemisphere) orientation. The PV
module must be kept clean from dirt and snow.
It is recommended to complete the wiring, SIM card
installation, battery installation and an established
pump connection before nally mounting the PS
Commander to a wall. See the Start-up section for
more information.
Figure 2: Mounting of the brackets

EN EN
10 Troubleshooting Troubleshooting 11
if the circumstances require, test the PS
Commander in an area with a known good signal
(within 1km of a radio mast)
the PS Commander is not installed in a location
where the signal will be impaired. Signal strength
will be reduced by walls, metal objects, obstacles,
being too distant from each other, interfering
signal, etc.)
if the circumstances require, test the PS
Commander in an open area directed to the radio
mast
the antenna cable is not broken
The PS commander will try to nd a network until it
is connected. If it does not nd a network there is a
risk of emptying the battery.
6.3 No connection to LORENTZ server
If the PS Commander is not able to establish a
connection to the LORENTZ server contact your
distributor for further information.
6.2 No connection to telecommunication
network
If the PS Commander does not connect to the
telecommunication network check that:
a supported network is available (19-001900/19-
001880: 2G/3G; 19-001860/19-001870: 2G/4G
(LTE-M1 or LTE-NB)
the SIM card is well seated
you are using the SIM card supplied by LORENTZ,
the PS Commander will not work with any other
SIM cards
the antenna cable is screwed tightly to the
terminal
there is a mobile phone signal at the site
the monitoring service for the system was started
in partnerNET Sites
a NOTE: You could use your smartphone
to roughly ascertain the signal strength
at the installation site.
6.4 Low Voltage Disconnect
The Low Voltage Disconnect (LVD) activates if the
battery`s voltage drops below a set amount of volts.
The Commander goes into a software LVD state at
11.9 volts and a hardware LVD at 11.8 volts. The LVD
is a protective feature to safe the battery from deep
discharge. During LVD there is no Bluetooth or 2G /
3G connection possible.
The PS Commander returns to normal mode after
the battery recovers to 12.2 volts. The voltage is
checked once per minute.
6.5 SIM card
To insert the SIM card into the 2G/3G terminal make
sure that the SIM card's contacts are facing left and
that the cut-o corner is pointing upwards as the
bottom gure shows.
Figure 3: Insert SIM card
The SIM card must “click” in and should be ush with
the outer case (of the terminal). Use a pen or small
screw driver to gently push it in (not much pressure
needed).
To remove the SIM card push the card in slightly
to release the lock and the card will be pop out
automatically. You can remove now the SIM card. Do
not pull the card while it is locked in the terminal.

Sun.Water. Life.
www.lorentz.de
v220729
