Lorenz MAGNUM Pro HD User manual

WARNING AND INSTALLATION MANUAL
MMMC1LZAX022
ÑMMMC1LZAX022DÓ

1. Warranty and warnings
Faser Srl warrants every units to be free from defects in material and workmanship under normal use
and service for a period of 24 months from original retail purchase. During the warranty period, Faser
Srl will repair or replace any component which fails in normal use without charges for parts or labour.
Technological developments, modications and upgrades of software are not covered by warranty
(except commercial decision). To receive warranty service, contact your local authorized dealer for
shipping instructions. The device should be securely packed with its tracking code clearly written on
the outside of the package, shipping to be paid by the customer. Include a copy of the original sales
receipt as the proof of purchase. This limited warranty does not extend to any device which has been
subjected to misuse, neglect, accident, incorrect wiring or improper installation. Faser Srl reserves the
right to repair or replace the device at its sole discretion.
For more warranty information please see the web site: www.lorenzmarine.com
For technical advice or assistance contact:
Faser Srl
Via Maestri del Lavoro d’Italia 8, 17019 Varazze (SV), Italy
P.IVA 01252330095
Tel. +39-019-93-27-05
Electronic charts displayed by the device are believed to be accurate and reliable, but they
are not intended to replace ocial charts which should remain your main reference for all the
matters related to the execution of safe navigation. For this reason we would like to remind
you that you are required to carry on board and use the ocially published and approved
nautical charts.
Please be aware that the serial ports are not opto-isolated and therefore the peripherals are
electrically connected to the device. This allows the connection of high speed peripherals,
like Fish Finder. If you are connecting a NMEA0183 peripheral and you would like to isolate
it from the device, you have to add the opto-isolator externally.
If water leaks into the equipment, immediately turn o the power at the switchboard. Fire or
electrical shock can result.
If the equipment is giving o smoke or re, immediately turn o the power at the switchboard.
Fire or electrical shock can result.
Do not open the equipment. The equipment uses high voltage that can cause electrical
shock.
Keep the SD card slot’s door closed to avoid water intrusion into the device
Extensive exposure to heat may result in damage to the device.
Please read through the device manual before the rst operation. If you have any questions,
please contact the Company’s customer service or your local dealer.
C-MAP media is available from C-MAP Authorized Resellers.

1 2
2. Installation
2.1 Bracket Mount
2.2 Panel Mount
2.3 How to insert the MicroSD
134mm [5.3"]
12
Ø5mm [Ø0.2”] - 4 pos.

3. Keyboard
9 10 11 12
67
1
23
4
5
8
1
8
9
10
2
3
4
5
6
7
11
12
The joystick can move the cursor around the map or through menu items. Press [UP], [DOWN],
[LEFT] or [RIGHT].
[ZOOM OUT]
Change the scale of the map zooming out.
[ZOOM IN]
Change the scale of the map zooming in.
[ENTER]
Push it to conrm your choice. When on map page, it opens the contextual menu of a map object.
[CLEAR]
Short press: exits from the current menu (back).
Long press: allows to come on the main page or, if you are on map page and the cursor is away from
the boat position, centers the map on the boat position (home mode).
[MENU] – [PAGE]
Short press: Menu – opens the main menu if pressed on one of the main pages (Map, Fish Finder,
GPS status, Engine monitor). It selects the top bar control buttons if pressed on full menu pages such
as Marks, Routes, Tracks and others.
Long press: Page – shows the main pages, it is the quicker way to switch between pages.
[MOB]
Is a special key dedicated to man-over-board situation. Pressing MOB places a MOB mark on the
current boat position and starts navigation to that place.
[POWER] – [DAY / NIGHT]
Short press: allows switching Day/Night modes.
Long press: turns the device on/o when pressed and held in.
[F1 – F4] are special keys. Each key can perform two functions: a short press performs the xed function
labeled on the keys unit face and on icon in the key. A long press (hold) executes the second function which
can be customized. Read the software manual to learn how to customize the function keys.
[F1] – [EVENT]
Short press: Event – to add a new event.
[F2] – [TRACK]
Short press: Track – start and stop the track.
[F3] – [GOTO]
Short press: Go To – to navigate to a destination (desired position on map).
[F4] – [PAGE]
Short press: Page – shows the main pages, it is the quicker way to switch between pages.

4. Connections scheme
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red POWER INPUT + (10-35 Vdc)
4.1 Power supply connection only
FUSE 1A
Power & I/O Connector (Port A and C)
PIN FUNCTION
1 PWR-/GND
2 POWER INPUT + (10-35 Vdc)
3INPUT A
4 COMMON
5 OUTPUT C
6OUTPUT A
7 INPUT C
8 EXTERNAL ALARM OUTPUT +
GPS Connector (Port B)
PIN FUNCTION
1POWER OUTPUT + (10-35 Vdc)
2 OUTPUT B
3 INPUT B
4 NOT CONNECT
5 NOT CONNECT
6 GND / SIGNAL RETURN
HDMI OUT
NMEA 2000 Connector
PIN FUNCTION
1 NOT CONNECT
2 POWER +
3 POWER -
4 SIGNAL H
5 SIGNAL L
FUSE 1A

Autopilot on Port C
Autopilot on Port A
4.2 Autopilot Connections
Note: Current MAX 300 mA
Autopilot on Port A
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red POWER INPUT + (10-35 Vdc)
4 Green COMMON
6 Yellow OUTPUT A RX+
COMMON AUTOPILOT
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red POWER INPUT + (10-35 Vdc)
4 Green COMMON
5 Gray OUTPUT C RX+
COMMON AUTOPILOT
4.3 External alarm connection
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red PWR + (10-35 Vdc)
8 Blue OUTPUT EXTERNAL ALARM
(Open Collector)
Note: Current MAX 300 mA
FUSE 1A
FUSE 1A
FUSE 1A
FUSE 1A
FUSE 1A
FUSE 1A

●Dimensions: 172.5 x 106.5 x 84.4 mm
(6.8’’ x 4.2’’ x 3.3’’) with holder
●Weight: 350 g (12.3 oz)
●Back-lit keyboard
●Integrated remote control receiver
(radio IF 2.4 Ghz)
●External GPS connector
●NMEA 2000
●NMEA 0183: 2x Rx/Tx on power cable
●External alarm
●Built-in HDMI video input cable
(compatible with any HDMI display)
●Memory slot: MicroSD
●Wireless LAN connection compatibility*
●Mounting options: Bracket and flush mount
●Waterproof IPX6
●Supply Voltage: 10-35 Vdc
●Operating temperature: -10°C / +60°C
●Storage temperature: -20°C / +80°C
●Transmitting frequency range: 2400 - 2483 MHz
●Maximum transmitting power: 1mW (or 100mW*)
●Maximum power consumption: 4W (or 6.5W*)
*Wireless LAN version
4.4 NMEA0183 Connections
5. Technical specifications
External NMEA on Port A
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red POWER INPUT + (10-35 Vdc)
3 White INPUT A
4 Green COMMON
6 Yellow OUTPUT A RX+
COMMON
EXTERNAL
NMEA
DEVICE
TX+
External NMEA on Port C
POWER & I/O CABLE
PIN Wire Color Function
1 Black PWR-/GND
2 Red POWER INPUT + (10-35 Vdc)
4 Green COMMON
5 Gray OUTPUT C
7 Brown INPUT C
RX+
EXTERNAL
NMEA
DEVICE
TX+
COMMON
FUSE 1A
FUSE 1A
FUSE 1A
FUSE 1A

6. Product conformity information
6.1 FCC compliant
This equipment has been tested and found to comply with the limits for a class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interfer-
ence will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
●Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the AvMap Satellite Navigation could void the
user’s authority to operate the equipment.
Compliance information statement
Identication of the product
Name P/N
Magnum Pro HD
Magnum Pro HD Wireless LAN
version
P3MC1000LZ
P3MC100WLZ
Certied components
Remote control receiver: FCC ID: CU9- P3MC1000
Built-in WiFi and BT wireless module (Wireless LAN version only):
FCC ID: Z64-WL18SBMOD
Applicable compliance
statements
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) This device must accept any interference received, including interfer-
ence that may cause undesired operation.
Responsible party
Name AvMap Satellite Navigation Inc
Address 25 Enterprise Zone Drive,
Riverhead, NY 11901, USA
Phone +1-800-363-2627
Website www.avmap.us
6.2 Simplied EU declaration of conformity
Hereby,
Faser Srl, Via Maestri del Lavoro d’Italia 8, 17019 Varazze (SV), Italy declares that the radio
equipments in the following table are in compliance with Directive 2014/53/EU.
Magnum Pro HD P3MC1000LZ
Magnum Pro HD Wireless LAN version P3MC100WLZ
The full text of the EU declaration of conformity for every single product is available at the following
internet address: eudeclaration.avmap.it
