Lorex CVC6973HR User manual

LOREX Technology Inc.
Copyright © 2006 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Quick Set-up Guide
It’s all on the web
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
VISIT
www.lorexcctv.com
4. Camera Specifications H O M E & B U S I N E S S S E C U R I T Y
HI-RES COLOR DAY/NIGHT
IR CAMERA
Specifications:
Dimensions:
Horizontal Res. 480 TV lines
# Effective Pixels
Sync. System
S/N Ratio
Electronic Shutter
Illumination
IR Distance
Lens
Video Output
LED
Power Supply
Operating Temp
Storage Temp
Dimension
768 (H) x 492 (V) (380K)
Internal Sync.
45dB (AGC Off)
0 Lux (LED on)
35 ft. / 10 m.
6 mm / F2.0 (optional)
1.0Vp-p @ 75 ohms
12 LED
DC 12V ± 10% 300mA
14°F ~ 122°F
(-10°~ 50°C)
-4°F ~ 140°F
(-20°~ 60°C)
Model: CVC6973HR
Image Sensor 1/3” Color CCD
1/60 ~ 10,000 Sec.
3.9” (H) x 3.2” (D)
100mm (H) x 80mm (D)

1. Package Contents 2. Installing the Video Camera 3. Connecting the Camera
1 x 60 ft. extension cable
1 x BNC to RCA Adaptors
1 x AC Power Adaptor
1 x CVC6973HR Hi- Res
Color Day/Night IR
Camera
1 x Mounting Bracket /
Stand
1. Attach the camera to the supplied stand.
2. Mount the camera stand to the desired mounting
surface
3. Connect the 60ft Extension cable to the camera:
The mounting stand is designed to permanently
mount the camera to a surface.
BNC (VIDEO)
(Yellow Connector)
POWER
(Black Connector)
CAMERA
CONNECTIONS:
Connect the BNC
and Power cables to
the Camera
VIDEO INPUT
CONNECTIONS:
Connect the BNC cable to
the video input of the
monitor, and connect the
power adaptor to an
outlet.
4. Connect the BNC end of the 60ft Extension Cable
to the DVR / Observation System or to a TV/VCR.
5. Connect the A/C Power Adaptor to the 60ft Exten-
sion cable (Black connector). Plug the Power
adaptor to a wall outlet
Setup Diagram:
Connect the BNC to RCA Adaptor as needed to
allow for proper connectivity.
Features:
• Advanced 1/3” Color CCD Image Sensor with
380,000 effective pixels
• 12 IR LEDs provide illumination up to 35ft*
• Weatherproof** Design (IP67) with Removable
sunshade ideal for outdoor installations
• Color in the day, automatically switches to B/W at
night
* IR Illumination range of 35 ft. under ideal conditions. Objects at or
beyond this range may be partially or completely obscured,
depending on the camera application.
** Not recommended for submersion in water
