CONTENTS:
Quick Start Guide
Digital Wireless Color
Camera with Stand
Wireless Antenna
for camera
Power Adaptor
for camera*
• Aim the Cameras to best optimize the viewing
area: Select a location for the camera that
provides a clear view of the area you want to
monitor, which is free from dust, and is not in
line-of-sight to a strong light source or direct
sunlight.
• Avoid installing the cameras where there are
thick walls, obstructions, or interference (i.e.
transformers, microwave ovens or other
electrical equipment) between the Cameras and
the Receiver.
• Select a location for the camera that has an
ambient temperature between 14°F~122°F
(-10°C~50°C)
• Before starting permanent installation, have
another person hold the camera for you while
you verify its performance by observing the
image on a monitor.
INSTALLING THE CAMERA
Before you install the camera, carefully plan where and how it will be
positioned, and where you will route the cable that connects the
camera to the power adaptor.
INSTALLATION WARNINGS
1. Carefully unpack the Camera.
2. Mount the stand to the wall:
• Mark the position of the
screw holes on the wall.
• Drill holes and insert the
drywall plugs as needed.
• Firmly attach the stand
to the wall using the
provided screws.
3. Attach the Antenna to the
Camera prior to mounting.
4. Place the camera in the
desired mounting position.
Tighten the thumbscrews
to secure the camera to the
Stand. Adjust the angle of
the camera until the
desired view is set.
*May not be exactly as shown
NOTE: AVOID INSTALLING IN A
LOCATION WHICH REQUIRES
THE WIRELESS SIGNAL TO PASS
THROUGH CEMENT, CONCRETE
AND METAL STRUCTURES. THIS
WILL REDUCE THE
TRANSMISSION RANGE.
Mounting
Screws
COLOR DIGITAL WIRELESS INDOOR/OUTDOOR
ACCESSORY CAMERA
LW2201AC1 SERIES - QUICK START GUIDE

www.lorexcctv.com LW2201AC1 SERIES QSG_EN_R1 Page 2
COLOR DIGITAL WIRELESS INDOOR/OUTDOOR
ACCESSORY CAMERA
LW2201AC1 SERIES - QUICK START GUIDE
CONNECTING CAMERA POWER ADAPTOR
Connect one end of the camera Power Adaptor to the camera and the other end to an electrical outlet.
It’s all on the Web
For detailed setup information,
please refer to your User’s Manual.
For additional information, please
visit our website
www.lorexcctv.com/support
1. Connect the power cable from the camera to the cable
from the Power Adaptor; plug the Power Adaptor into
an outlet or surge protector.
2. Press the Pair button repeatedly on the Wireless
Receiver to select an empty channel.
3. Press and hold the Pair button for 5 seconds to activate
pairing function. The on-screen displays informs you
that you have 30 seconds to press the pair button on
the camera*.
4. Press and hold the Yellow Pair button extending from
the camera. You must press the Yellow Pair button from
the camera within 30 seconds of pressing the Pair
button on the Wireless Receiver. If pairing is
successful, live video from the camera will immediately
appear on the monitor.
* These are instructions for pairing with the LW2201
receiver. To add this accessory camera to a different
Lorex Ultra Digital Wireless Receiver, check the
Owner’s manual for the receiver you have.
Pairing Button
ADDING THE ACCESSORY CAMERA TO YOUR SYSTEM
The Pairing Function assigns each camera to a different
channel on the wireless receiver (connect up to 4
Cameras), and is necessary for configuring additional
cameras. By default the camera that came with the
LW2201 system is assigned to channel no. 1.
NOTE: It is highly recommended to pair the Accessory
Camera to the Receiver before permanently mounting the
camera. For detailed information, please check the
owners manual for the LW2201 system available at
www.lorexcctv.com
Connect power adaptor to
local 120V AC power outlet
