4 PORT PCI CARD DVR
WITH 4 DAY/NIGHT INDOOR OUTDOOR COLOR CAMERAS
PCI Card:
4 channel (camera) triplex DVR PC Card solution
(view, record, playback simultaneously)
Local and Remote Monitoring Capability
Digital Recording of live video to PC’s hard drive
View up to four locations simultaneously
Compatible with Windows operating system
Remote viewing options: Quad / Full Screen / Sequencing
Digital freeze and zoom-in
Easy search and playback of digitally recorded video
Password security protection
Cameras:
Durable Weather resistant metal Camera suitable
for Indoor or Outdoor installations*
11 high intensity IR LEDs provide illumination
in low light conditions**
Color video in standard lighting, automatically
changes to B&W video in low light conditions.
Easily Connects to any TV, VCR or monitor
with industry standard RCA connector.
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
ß
FEATURES
QLR0444
HOME & BUSINESS SECURITY
Lorex QLR 400 Series
PCI cards, cameras and video
management software turns
your Personal Computer (PC)
into a professional grade CCTV
system – with the ability to
view, record and control video
from any remote location via
the Internet.
* Weather resistant against dust and light rain - IP44 Rated
** IR illumination range of 13’ / 4m under ideal condition.
Objects at or beyond this range may be partially or completely obscured

SPECIFICATIONS:
©2008 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to modify product
design, specifications & prices without notice and without incurring any obligation. E&OE
3700 Koppers Street
Baltimore, Maryland 21227,
USA.
Lorex Technology Inc.
300 Alden Road, Markham,
Ontario L3R 4C1
Canada.
2-03072008
PACkAGE INFORMATION:
Weight: 12.5 lbs /5.66 kgs
Dimensions: 11.75 X 7.75” X 9.75” /
298mm X 197mm X 248mm (W x H x D)
UPC: 7-78597-01444-0
Cube: 0.013 CBM / 0.461 ft
Includes: PCI card, 4 cameras & 4 x 60ft. cables, QSG,
Serialized Application CD, 4 Power Adaptors for
cameras
Optional Accessories: Alarm Block (ACC-ALM)
4 PORT PCI CARD:
Video Input: 4 ch (RCA), NTSC/PAL
Display Speed: 30fps (4ch)
Split Screen: 1, 4
Recording Speed: 30fps (4ch) @ 320 x 240
Resolution: 320 x 240 / 640 x 480
Recording Modes: Motion Detection, Schedule,
Continuous
Playback Display: 1, 4
Search Modes: Date, Time, Channel, Event
Network Transmission Speed: Real-Time
Remote View: Via client software
Dynamic IP Support: Yes
Supported O/S: Windows 2000, XP, Vista
CAMERA:
Image Sensor: 1/4” Color CMOS
Resolution: 450 TV Lines
Minimum Illumination: 3.0 Lux
Built-in IR LED: 11 IR LED (850nm Type)
for Night Vision
Power Source: 7.5 V DC
Current Consumption: 180 mA
Operating Temp Range: -10°~50° C / 14° ~ 122° F
IP Rating: IP 44, weather resistant
DIMENSIONS:
Suitable for a variety of security surveillance applications:
Residential:
digitally record from cameras positioned at the
front door, garage, driveway or pool –
with the ability to view locally or remotely.
Manufacturing:
monitor and digitally record mechanical processes, or use for
security purposes.
Multiple business owner: cost effective solution for viewing
multiple locations from a remote computer.
ß
ß
ß
• Pentium III or higher processor
• Microsoft Windows operating system
• Optical drive
• 256 MB RAM
• Separate video card with 64MB minimum
(broadband internet connection required for remote connection)
MINIMUM SYSTEM REQUIREMENTS:
4in/
102mm
5in/
127mm
4in/
102mm
1in/
25mm
4.13in/
105mm
3.15in/
80mm
1.5in/
40mm
