Lorex SG6182SP User manual

INDOOR/OUTDOOR COLOR MINI CAMERA
wITh NIGhT VISION
FEATURES
www.lorexcctv.com
©2008 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex Technology & subsidiaries
reserve the right to modify product design, specifications & prices without notice and with-
out incurring any obligation. E&OE
3700 Koppers Street, Suite 504
Baltimore, Maryland 21227, USA.
Lorex Technology Inc.
300 Alden Road, Markham,
Ontario L3R 4C1 Canada.
SG6182SP
SPECIFICATIONS
PLUG AND PLAY SECURITY
1.8”in / 45mm
3-22082008
PACkAGE INFORMATION
4”in / 100 mm
Durable Metal Camera ideal for indoors or outdoors use*
Night Vision provides viewing in low light conditions*
Listen as well as view with camera’s built-in microphone
Includes 100ft Extension Cable
Convenient Camera Stand Allows for Wall Mounting
* Not recommended for direct exposure to rain or snow
* IR illumination range of 8ft. under ideal conditions. Objects at or beyond this range
may be partially or completely obscured, depending on the camera application.
ß
ß
ß
ß
ß
Image Sensor Type: 1/6” Color CMOS
Lens: 2.8mm F 2.0
IR LED’s: 8 LED’s with 1 CDS
Built-in Microphone: Yes, condenser type
Effective Pixels: H: 640, V: 480
Video format: PAL
Resolution: > 380 TV Lines
Minimum Illumination: 1.3 Lux
AES: 1/50~1/10000 sec
White Balance: Auto
FOV: 70 degrees diagonal
Power Requirement: 9.0Vdc
Current consumption: 180 mA
Operating Temp Range: -10 °C ~45°C ( 14°F ~ 113°F)
IP Rating: IP 44
UPC: SG6182SP (PAL version) - 7-78597-61820-4
Weight: 1.18 kgs / 2.6 lbs
Dimensions: (W x H x D) 10” x 11.6” x 3.9”
255 mm x 295 mm x 100 mm
Cube: 0.28cft / 0.008 cbm
Contents: Camera, Camera Stand, Power Adapter, 100ft
Extension Cable, Quick Start Guide, Warranty
Card, Decal, SCART Adapter
The SG6182SP compliments any décor and provides sharp
imaging over years of operation. Best of all, it is designed
to easily connect to any TV in minutes, which makes it the
perfect camera for the widest range of home and small busi-
ness applications.
DIMENSIONS
2.8”in / 70mm
