Lorex SG7221 Series User manual

LOREX Technology Inc.
Copyright © 2008 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Quick Set-up Guide
It’s all on the web
Product Information
User Manuals
Quick Start Guides
Specification Sheets
Software Upgrades
Firmware Upgrades
VISIT
www.lorexcctv.com
BUSINESS AND HOME
INDOOR/OUTDOOR
DAY/NIGHT
COLOR CAMERA
Model: SG7221 Series
English Version 1.0
4. Camera Specifications
Specifications:
H: 512, V: 492
2:1 Interlace NTSC
On 1/60~1/ 15,000Sec
14°F ~ 122°F
(-10°~ 50°C)
3.0 LUX
1/4” Color CCD Image
420 TV Lines
3.6mm Fixed F 2.0
Image Sensor
Effective Pixels
Scanning System
Resolution
AES
Sync. System
Min. Illumination
White Balance
Lens
Video Output
Power Supply
Power Consumption
Operating Temp
2:1 Interlace NTSC
AWB
1.0 Vpp @ 75 OHM
12 V DC
180mA
Viewing Angle 70 Degree
Operating Humidity Less than 90%
Dimensions:

1. Package Contents 2. Installing the Video Camera 3. Connecting the Camera
60 ft. (18m) 4PIN DIN Exten-
sion Cable
NOTE: Both ends are male
*Available with SG7221R
only. AC Power Adaptor,
and 4PIN to RCA Coupler
(ACC425)
Color Bullet Camera with
Sunshade Housing, Stand,
and Mounting Hardware
1. Mount the camera stand to the desired mounting
surface. Attach the camera to the supplied stand.
2. Connect the Extension cable to the camera:
3. Connect the Yellow RCA Connector (on the
4PIN to RCA Coupler) to the System.
Before starting permanent installation,
have another person hold the camera for
you while you verify its performance by
observing the image on a monitor.
SG7221R
Extension Cable to
4PIN-RCA Coupler
SG7221B
Extension Cable to
4PIN-6PIN Coupler
1. Connect the A/C Power Adaptor to the 4PIN
to RCA Coupler (Black Connector). Plug the
Power adaptor into a wall outlet
Setup Diagram:
BLACK: Connect to the Power Adaptor
YELLOW: Connect to the VIDEO port
Features:
• Durable Weather resistant metal Camera suitable
for Indoor or Outdoor installations*
• 11 high intensity IR LEDs provide illumination in
low light conditions. **
• Color video in standard lighting, automatically
changes to B&W video in low light conditions.
• SG7221B connects to Lorex Observation Sys-
tems with 6 PIN DIN connectors (There is no
need for a power adaptor as the camera is pow-
ered by the system).
• SG7221R connects to any TV or Lorex PCI cards
(QLR Series) with RCA connector. A coupler:
RCA (female) to BNC (male) is required in order
to connect to DVRs and Observations Systems
with BNC connectors (BNCA sold separately).
* Weather resistant against dust and light rain - IP44 Rated
** IR illumination range of 16’ / 5m under ideal condition.
Objects at or beyond this range may be partially or completely ob-
scured
*Available with SG7221B
only. 4PIN to 6PIN
Coupler (ACC426)
SG7221B
SG7221R
