Louroe Electronics TLI-CF User manual

TLI-CF
TLI-CS
TLI-VPSC
VPSC Housing
Surface Mount
TLI
SPEAKER/MICROPHONE Ceiling Mount - Flush
Ceiling Mount - Surface
WIRING REQUIREMENTS
4 Conductor consisting of:
+
2 Conductor shielded, 20 gauge
with 22 gauge drain (microphone
connection)
+
2 Conductor unshielded, 18 gauge
(speaker connection)
All in the same jacket
TLI SERIES
SPEAKER/MICROPHONES
INSTALLATION AND OPERATING INSTRUCTIONS
Page 1 of 8
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: [phone] / FAX: [phone]
/ www.louroe.com[email protected]
®
TLI_inst_4/11

WIRING REQUIREMENTS
4 Conductor consisting of:
+
2 Conductor shielded, 20 gauge
with 22 gauge drain (microphone
connection)
+
2 Conductor unshielded, 18 gauge
(speaker connection)
All in the same jacket
NOTE: If using cable from other
manufacturers, color code may vary.
The Model TLI is a two-way talk/listen remote station consisting of an electret
condenser microphone with pre-amp for line level output and 8” speaker. As a
system, the TLI provides both listen and talkback capabilities between the remote
zone and the Louroe™ base station. There are three configurations in which
Model TLI can be installed:
?
Using VPSC Housing for surface mounting to a wall or ceiling (industrial application)
Model TLI w/VPSC
?
Flush mounted to ceiling using ERD-8 Backbox and BR-8WS/BR-8VP Grill
(commercial application) Model TLI-CF
?
Surface mounted to ceiling using MR-8 Mounting Ring and BR-8WS Grill
(commercial application) TLI-CS. If a vandal resistant grill is required,
request model BR-8VP Grill instead of model BR-8WS.
DESCRIPTION
MICROPHONE CONNECTION (SEE DIAGRAM PAGE 4):
Terminal strip for microphone connection is located on an arm attached to outer rim of speaker and is labeled
A, B, C. Using West Penn 356 or equivalent four conductor cable, connect as follows:
1) Connect RED wire (shielded) to terminal block marked “A” (12 Vdc supply)
2) Connect BLACK wire (shielded) to terminal block marked “B” (audio)
3) Connect DRAIN wire (bare) to terminal block marked “C” (ground)
SPEAKER CONNECTION :
Using wire nuts, connect speaker wires as follows:
1) White wire of TLI connects to the White wire of West Penn356 (common)
2) Green wire of TLI connects to Green wire of West Penn 356
(SEE DIAGRAM PAGE 4)
Model TLI
without housing
INSTALLATION AND OPERATING INSTRUCTIONS
Page 2 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

If Model TLI is to be installed with Model VPSC Housing for mount to ceiling or wall, refer to
instructions on page 4.
If Model TLI is to be flush mounted to ceiling using ERD-8 back box and BR-8WS (or BR-8VP
vandal resistant grill), refer to drawing on page 5.
If Model TLI is to be surface mounted to ceiling using MR-8 Surface Mounting Ring and BR-8WS
(or BR-8VP vandal resistant grill), refer to drawing on page 6.
CONNECTING MODEL TLI TO LOUROE AUDIO BASE STATION
The audio inputs differ among the various Louroe base stations. Refer to the installation instructions
for the specific model base station.
NOTE: IF USING CABLE FROM OTHER MANUFACTURERS, COLOR CODE MAY VARY
SENSITIVITY SWITCH OF TLI
For special installations that require less microphone sensitivity, a sensitivity switch is located at the
top right corner of the PC board and has two positions, N (normal) and L (low). Factory set at “N”.
Use small screwdriver to move slide switch to L position (low sensitivity).
Model TLI w/VPSC
Model TLI-CF
Model TLI-CS
INSTALLATION AND OPERATING INSTRUCTIONS
Page 3 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

TO LOUROE AUDIO BASE STATION
OR OTHER AUDIO RECEIVING DEVICE
WIRING DIAGRAM FOR
MODEL TLI
SPEAKER/MICROPHONE
GREEN
(speaker
positive)
SAMPLE CABLE WEST PENN 356
+
2 Conductor shielded, 20 gauge with 22 gauge
drain (microphone connection)
+
2 Conductor unshielded, 18 gauge (speaker
connection)
West Penn 356 or equivalent
(all in the same jacket)
MOUNTING TLI TO VPSC HOUSING
Place TLI inside VPSC matching the 4 mounting screws
and secure with furnished nuts and washers.
No knockouts are provided on the VPSC. Bore a ¾”
opening at the desired side of VPSC for passing cable
through for connecting to TLI.
MICROPHONE
CONNECTIONS
WHITE SPEAKER WIRE (COMMON)
CONNECTS TO WHITE WIRE
(COMMON) USING WIRE NUT
1) Speaker Connection
White wire of West Penn 356
connects to White wire
(COMMON) from TLI
Transformer using a wire nut.
2) Green wire of West Penn 356
connects to Green wire from TLI
Transformer using a wire nut.
A B C
A B C
RED
BLACK
BARE
INSTALLATION AND OPERATING INSTRUCTIONS
Page 4 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

Ceiling Tile
Flexible Perforated
Steel Mounting Straps
(4)
8 x 32 Philips
(4 supplied)
Microphone Connection
or BR-8VP for vandal
resistant model
BR-8WS
Grill 12 7/8”dia
8” Speaker
Assy
70V Transformer
ERD-8 Backbox
MOUNTING ASSEMBLY
FOR
LOUROE MODEL TLI-CF SPEAKER/MICROPHONE
CEILING MOUNT - FLUSH
INSTALLATION AND OPERATING INSTRUCTIONS
Page 5 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

MOUNTING ASSEMBLY
FOR
LOUROE MODEL TLI-CS SPEAKER/MICROPHONE
CEILING MOUNT - SURFACE
5/32”
Pem
Nut
8 x 32
Phillips
(4 supplied)
BR8-WS
Grill 12 7/8”dia
8” Speaker
70V Transformer
Assy
Model MR-8
Surface
Mounting Ring
3”H x 12 3/8” dia
Mounting Bracket
to ceiling
NOTE
Install MR-8 mounting ring to
ceiling BEFORE attaching
BR-8-WS grill to mounting ring
Screws for securing mounting
ring to ceiling not supplied
Installation Steps
1 Make electrical connections to speaker/microphone terminal block
Refer to accompanying instruction manual for specific wiring
Connections for speaker/microphone
2 Install mounting ring to ceiling
3 Mount grill to mounting ring
Microphone
Connection
INSTALLATION AND OPERATING INSTRUCTIONS
Page 6 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

TLI Speaker/Microphone
Locator
Tabs (8)
Ceiling Tile
SSB-2 Suport
Bridge
ERD-8 Backbox
Snap-In tie off straps (2)
Horseshoe Tab (4)
backbox
bridge
MODEL SSB-2 SUPPORT BRIDGE
If Model SSB-2 Support is being used with Model TLI
Speaker/Microphone ceiling Installation, refer to drawing below for
positioning SSB-2 Support Bridge.
SSB-2 is optional and used to prevent tile sag caused by the weight of the
installation on suspended ceiling.
Bridge
INSTALLATION AND OPERATING INSTRUCTIONS
Page 7 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11

MANUFACTURED IN
THE
IMPORTANT NOTICE
When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
decal notice is included with each
microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
Page 8 of 8
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
TLI_inst_4/11
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
AUDIO
MONITORING
On
These Premises
®
