Louroe Electronics TLSP-CM User manual

The Model TLSP Corner Mount is a two-way
talk/listen speaker/microphone with built-in electret
condenser microphone and a 3” speaker. It’s 18 gauge
vandal resistant housing is especially designed for
mounting in a corner or between wall and ceiling.
As part of a Louroe Audio Monitoring System, TLSP Corner
Mount provides 2-way listen and talkback capabilities
between the remote area and the Louroe Base
Station.
MODEL TLSP-CM
SPEAKER/MICROPHONE
(CORNER MOUNT)
TLSP-CM
SPEAKER/MICROPHONE
INSTALLATION AND OPERATING INSTRUCTIONS
6955 VALJEAN AVE, VAN NUYS, CA 91406
PH: [phone] / FAX: [phone]
/ www.louroe.com[email protected]
®
DESCRIPTION
Page 1 of 4
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
tlsp_cm_inst_3/15
Microphone:
Located behind the 3” speaker of TLSP-CM is a PC board with a small black terminal block marked
A, B, C. Using shielded portion of recommended wiring:
1) RED wire goes to terminal A (12 Vdc supply)
2) Black wire goes to terminal B (audio output)
3) Bare wire (drain) goes to terminal C (ground)
Speaker:
Mounted next to speaker is a 70V transformer with two lead wires, WHITE and GREEN. Using
wire nuts, connect these two wires to the unshielded WHITE and GREEN cables of recommended
wiring (West Penn 356 or equivalent), matching white with white and green with green.
MICROPHONE AND SPEAKER CONNECTION

CONNECTING MODEL TLSP CORNER MOUNT TO A LOUROE BASE STATION
The following procedure pertains to all Louroe Base Stations with
talkback
After wiring connections are made at Model TLSP-CM, run recommended 4 conductor
cable to the Louroe Base Station and connect as follows. Connections are located on
rear panel of the base station.
RED wire (12Vdc) goes to terminal “A” of Base Station (zone 1, 2, etc)
BLACK wire (Audio Output) goes to terminal “B” of Base Station
BARE wire (ground) goes to terminal “C” of Base Station
GREEN speaker wire goes to “TB” (talkback) terminal of Base Station
WHITE speaker wire goes to “G” (ground) terminal of Base Station
TLSP-CM
Page 2 of 4
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
tlsp_cm_inst_3/15
INSTALLATION AND OPERATING INSTRUCTIONS
Material
Weight
Shipping Weight
10” L x 6” W x 4 1/2” D
Steel
2 lb 13 oz
4 lbs
SPECIFICATIONS (Speaker)
Power rating
Input
Frequency response
Voice coil impedance
7W
70.7V constant
300 Hz to 4 kHz
8
Speaker size 3”
Dimensions
Sensitivity -45 dBV/Pa
1 Pa = 94 dB SPL
Frequency Response 50 Hz to 15 kHz
Output Line Level (0 dBV, 600W@ 1kHz)
Current Drain 10mA
Supply Voltage 12 Vdc
SPECIFICATIONS (MICROPHONE)

Terminal Block Identification
Microphone
C - Ground
B - Audio Output
A - 12Vdc Power
Green wire (positive)
White wire (negative)
are speaker connections
WIRING DIAGRAM FOR
MODEL TLSP-CM (CORNER MOUNT)
SPEAKER/MICROPHONE
70V
TRANSFORMER
MICROPHONE SENSITIVITY SWITCH
USED ONLY FOR LOWERING THE GAIN - 6dB
TO REDUCE BACKGROUND AND PICKUP
REDRED
BLACKBLACK
BAREBARE
REAR OF TLSP-CM
AA
BB
CC
GREEN
WHITE
WIRE NUT NOTE: IF USING CABLE
FROM OTHER
MANUFACTURERS,
COLOR CODE MAY VARY
RED (A)
BARE (C)
BLACK (B)
Refer to installation instructions
on page 1 or to the specific
Louroe Base Station
A B C
GREEN (+)
WHITE (-)
UNSHIELDED
SPEAKER
AND ALARM
CONNECTION
SHIELDED
MICROPHONE
CONNECTION
POSITIVE
NEGATIVE
}
}
MICROPHONE
CONNECTION
SPEAKER
WHITE
(-)
SPEAKER
GREEN
(+)
MICROPHONE TERMINAL
BLOCK IDENTIFIER
A = 12Vdc Power (red)
B = Audio Outputs (black)
C = Ground (bare)
WIRING REQUIREMENTS
4 Conductor consisting of:
+
2 Conductor shielded, 20 gauge
with 22 gauge drain (microphone
connection)
+
2 Conductor unshielded, 18 gauge
(speaker connection)
All in the same jacket
West Penn 356 or equivalent
ABC
Page 3 of 4
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
tlsp_cm_inst_3/15
INSTALLATION AND OPERATING INSTRUCTIONS

MANUFACTURED
IN THE
Page 4 of 4
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL [phone] FAX [phone]
website: www.louroe.com e-mail: [email protected]
(818)
®
tlsp_cm_inst_3/15
INSTALLATION AND OPERATING INSTRUCTIONS
IMPORTANT NOTICE
When this equipment is used as part of an
audio monitoring system, the law requires
that the public be given notice of AUDIO
MONITORING ON THE PREMISES. A
decal notice is included with each
microphone shipped.
Federal Law References:
Federal Regulations, US Code, Title 18.
Crime and Criminal Procedure, Sec 2510.
WARRANTY
LOUROE ELECTRONICS warrants that at the time of shipment products manufactured by LOUROE ELECTRONICS to be free of defects in material and workmanship.
Should a defect appear within one year (12 months) from date of shipment, LOUROE ELECTRONICS will, at its sole discretion, repair or replace the defective equipment.
This equipment shall not be accepted for repair or return without prior notification by LOUROE ELECTRONICS .
This warranty does not extend to any Louroe product that has been subjected to improper or incorrect installation, misuse, accident, or in violation of installation
instructions provided by LOUROE ELECTRONICS.
Returned shipments to LOUROE ELECTRONICS shall be at customer’s expense. LOUROE ELECTRONICS will return the equipment prepaid via best way.
®
®
®
®
®
®
AUDIO
MONITORING
On
These Premises
®
