Lowe & Fletcher Gemini 2700 User manual

USER INSTRUCTIONS
2700 - Gemini
Mechanical

SELECT CURRENT USER CODE (DEFAULT 2 2 4 4 )
SET A NEW USER CODE
CLOSE DOOR, ROTATE HANDLE FULLY TO CLOSED
POSITION & SCRAMBLE CODE
OPEN SELECT USER CODE & TURN HANDLE (RH = CW, LH = CCW)
CLOSE TURN HANDLE & SCRAMBLE CODE (RH = CCW, LH = CW)
ROTATE INDIVIDUAL WHEELS TO SELECT
NEW USER CODE
PICTURE 1a
(LEFT-HAND)
USER INSTRUCTIONS
2700 - Gemini Mechanical
TURN HANDLE TO UNLOCKED POSITION TO
SET USER CODE
PICTURE 1b
(RIGHT-HAND)
TURN HANDLE TO CODE CHANGE POSITION
(OPEN POSITION + FURTHER 45˚)
SEE PICTURE 1a FOR LEFT-HAND VERSION = CCW
& 1b FOR RIGHT-HAND VERSION = CW

EMERGENCY KEY OVERRIDE
& CODE FINDER FUNCTION
2700 - Gemini Mechanical
INSERT MASTER KEY OVERRIDE & TURN
90° CLOCKWISE (SEE PICTURE 2)
LIGHTLY ROTATE INDIVIDUAL WHEELS (UPWARDS)
UNTIL EACH ONE LOCKS INTO POSITION
(USER CODE IDENTIFIED)
TURN KEY 90° ANTI-CLOCKWISE
& REMOVE FROM LOCK
REFER TO USER INSTRUCTIONS FOR
PROCEDURE TO SET NEW USER CODE
TURN HANDLE TO OPEN POSITION
PICTURE 2

Lowe & Fletcher Ltd
Moorcroft Drive
Wednesbury, West Midlands
WS10 7DE, England
T: + 44 (0) 121 505 0400
F: + 44 (0) 121 505 0420
E: sales@lowe-and-fletcher.co.uk
W: www.lowe-and-fletcher.co.uk
9224237 V2 May 2022 - 2700 User Instructions
