ACSP2004-IG-GTF
20A Single-circuit Surge Suppressor with Ground Transient Filter
Description
Surge Suppressor / Ground Transient Filter Assembly
Model ACSP2004-IG-GTF is a compact, all-in-one device that
features Lowell’s UL Listed 20A surge suppressor Model
ACSP2004IG with a built-in ground transient filter (GTF). The
ETL listed assembly uses Lowell’s exclusive GTF filtering tech-
nology to eliminate potentially damaging electromagnetic tran-
sients / noise on the ground wire. The surge suppressor with
GTF is ideal for protecting sensitive equipment such as that
used in telecommunications, security, fire, audio/visual, broad-
cast, sound recording and reinforcement, DSP, data storage, test
& monitoring, process control, as well as business/retail PC’s
and point of sale terminals.
The surge suppressor/ground filter assembly is designed for rear
rack or wall installation. The compact 7”W x 8”H x 3”D device
features one GTF filter and two 20A isolated ground duplex out-
lets on rotating 900plates. Innovative plates (US Patent#
D535178S) allow for versatile front or side access to outlets
which can be a real benefit in crowded rack environments. Two
blank 900 plates are also provided for clean hardwire applica-
tions. Units include knockouts on all sides and LED status indi-
cators on the front.
Features & Benefits
All-in-one surge suppressor & ground transient filter.
ETL Listed 1449-2 Adjunct.
ANSI C62.41 Compliant.
GSA Grade A- Mode 1- Class 1Endurance tested.
Protects Line to Neutral - No ground wire contamination.
Defeats surges up to 72,000A using Lowell's TCR
(Triple Clamping RedundancyTM)technology.
Attenuates damaging high frequency transients.
Includes (2) duplex outlets (standard or isolated ground).
Outlets on patented 90Orotating plates for front or side access.
Easy rear rack installation.
ACSP2004-IG-GTF Surge Suppressor with Ground Transient Filter (GTF)
GTF is a RECOGNIZED COMPONENT
Electromagnetic Interference filters
(ANSI/UL 1283 - 4th Edition, 6/1998; rev 2/2004),
and (CSA C22.2 No. 8 - M1986).
Surge Suppressor
The 20A surge suppressor in assembly Model ACSP2004-IG-
GTF is UL Listed (1449-2) and endurance tested to meet
government GSA Grade A- Mode 1- Class 1requirements for
surge suppressors. It meets ANSI C62.41 and protect Line to
Neutral without ground wire contamination. It is ideal for pro-
tecting sensitive equipment from transient voltages, spikes
and surges. Far exceeding UL requirements, these suppres-
sors defeat surges up to 72,000 amps using Lowell’s Triple
Clamping RedundancyTM (TCR) technology and have a
response time of less than 5 nanoseconds. Additionally, the
surge suppressor ensures reliable performance of connected
analog or digital equipment through Transient Noise
Reduction (filtering) of 25dB@100kHz, 50dB@1MHz.
Ground Transient Filter (GTF)
Lowell’s 20A Ground Transient Filter (GTF) in assembly Model
ACSP2004-IG-GTF is a patented and ETL recognized technol-
ogy. The GTF installs in series with the ground line of electrical
circuits to attenuate high frequency transients without impeding
60Hz fault current (see Dia. 2 on page 2). It introduces less
than 0.1 ohm at 60Hz to the ground circuit thereby assuring
proper operation of any and all overcurrent protection devices
(circuit breakers, fuses, etc.).
At higher frequencies however, where the most damaging tran-
sients exist; the GTF provides significant attenuation. At 1MHz,
for example, the GTF attenuates ground noise by 25dB which
can be the difference between a sensitive system functioning
continuously or having an interruption or ‘reset/reboot’ occur-
rence. As illustrated in Dia. 2, Lowell’s ACSP2004-IG-GTF
Surge Suppressor with Ground Transient Filter (GTF) provides
a cost effective and easy-to-install 20A CleanPowerSolution for
sensitive equipment of all types.
Patented cover plate features
outlets that rotate 900for front
or side access.

ACSP2004-IG-GTF
20A Single-circuit Surge Suppressor with Ground Transient Filter
Lowell Manufacturing Company • 100 Integram Drive • Pacific, Missouri 63069 U.S.A.
Call 800.325.9660, 636.257.3400 • Fax [phone] • Click www.lowellmfg.com
Lowell makes every effort to provide accurate information and reserves the right to change specifications and/or improve manufacturing methods.
Download and print this spec from www.lowellmfg.com to insure that you have the most current information
1c-107
pg 2 of 4
Equipment
protected
from
surges
Equipment
protected
from
surges and
ground
transients
Diverts surges
to Neutral
Circuit
Breaker
Neutral
and
Ground
Bonded
Dia. 1: Power Flow - Normal Mode (L-N) Surge Suppressor WITHOUT GTF - (Typical)
Dia. 2: Power Flow - Normal Mode (L-N) Surge Suppressor WITH GTF (Lowell ACSP2004-IG-GTF)
Power Company
Transformer
7200VAC
(typ.)
120VAC
Neutral
Line (Hot)
Neutral*
Ground**
Diverts surges
to Neutral
Circuit
Breaker
Neutral
and
Ground
Bonded
Power Company
Transformer
7200VAC
(typ.)
120VAC
Neutral
Line (Hot)
Neutral*
Ground**
Lowell
ACSP2004-IG-GTF
normal mode (L-N) surge
suppressor with GTF
GTF
“Typical” normal mode (L-N)
surge suppressor
GTF attenuates and filters ground transients BEFORE they reach sensitive equipment
GTF technology attenuates high frequency transients without impeding 60Hz fault current.
*Neutral is a dedicated “current carrying, grounded conductor”. It is bonded directly to the center tap of the power company transformer which is bonded to the
grounded side of the supply line.
** Ground does not carry current except during a ‘fault’ condition. Ground connections inside a building may be made through metal conduit, junction boxes, building
structural steel, water pipes, etc. They are NOT always a direct connection to the service entrance, therefore the impedance of the ground can be much higher
than the neutral. Transients CAN be induced on ground circuits and CAN find their way into sensitive equipment.
ACSP2004-IG-GTF Block Diagram
Building Service
Entrance
Building Service
Entrance
POWER
AC
Rackmount
19” EIA
AC Strips
Rackmount
Vertical
AC
Loadcenters
(sequenced)
AC Surge
Protection
/ Filtering
AC
Remotely
Controlled
Low Voltage
Sequencers
Accessories
Single Circuit Surge

Lowell Manufacturing Company • 100 Integram Drive • Pacific, Missouri 63069 U.S.A.
Call 800.325.9660, 636.257.3400 • Fax [phone] • Click www.lowellmfg.com
Lowell makes every effort to provide accurate information and reserves the right to change specifications and/or improve manufacturing methods.
Download and print this spec from www.lowellmfg.com to insure that you have the most current information
1c-107
pg 3 of 4
ACSP2004-IG-GTF
20A Single-circuit Surge Suppressor with Ground Transient Filter
ACSP2004-IG-GTF Installation to Rack Mounting Rail Supports
1) Remove 1/4”
knockouts from
chassis base.
2) Loosely install
1/4-20 bolts
and slide nuts.
3) Attach to slide channel
in mounting rail support
and tighten bolts.
Specifications
Surge Suppressor
Operating Voltage 0-130 VAC nominal
Operating Current 20A hardwired, 16A w/receptacles(s) per NEC
210.21(B)(2), 210.23(A)(1).
Maximum Surge Current 72,000A (exceeds UL1449-2 6000V, 3000A).
Initial Clamping Voltage 205V, UL rating 330V
Endurance IEEE C62.41-1991, B3 (C1), Pulses (lifetime):
1kv≥1,000,000; 3kv≥100,000; 6kv≥5000
Transient Noise Reduction 25dB@100kHz, 50dB@1MHz
Response Time Less than 5 nanoseconds
Protection Mode Line to neutral, zero ground leakage
UL1449-2 Adjunct Results 1000 surges, 6000 volts, 3000A, C1 and B3
waveforms (IEEE C62.41), No failures
Federal GSA specs (1996) Grade A, Class 1, Mode 1
Diagnostic LED’s Top (Green): On = Ground verified,
Center (Green): On = Protection active,
Bottom (Red): On = Protection reduced*.
Applicable Standards IEEE standard 587-80 A & B, IEEE standard
C62.41-1991, IEC 1000-4-5-1995 (IEC 801-5).
Safety Agency Approvals Assembly is ETL Listed to UL1449 2nd
Edition; rev 2/2005 (US and Canada).
ACSP2004-IG-GTF Carton Contents
Blank Auxiliary
Cover IG Receptacle
(not installed)
Blank
Cover
Mounting
and
hook-up
hardware
IG Receptacle + GTF filter
(factory installed)
Ground Transient Filter (GTF)
Operating Voltage 125 VAC
Operating Current 20A
Frequency 60Hz
Impedance@60Hz 0.06 Ohms
Applicable Standards Electromagnetic Interference filters
(ANSI/UL 1283 - 4th Edition, 6/1998; rev 2/2004),
and (CSA C22.2 No. 8 - M1986).
Mechanical
Dimensions 7”W x 8”H x 3”D
Weight 7 lbs.
Input Connections Hardwired pigtail leads, 12 gauge minimum.
Output Connections (2) Duplex receptacles mounted on 90Orotatable
plates or hardwire pigtail leads ( 2) blank 90O
cover plates are included for hardwire use.
Chassis Steel with black powder epoxy paint finish.
Mounting Options Compact for rear rack installation to mounting
rail supports or solid surface using flanges.
*Lowell's Triple Clamping Redundancy is exactly that - triple clamping for triple protection. This
means that if one section of the suppressor has ‘reduced protection’, there are two additional
sections available to safeguard equipment. Device is endurance tested and verified: Grade A,
Class 1, Mode 1.
A & E Specifications
The 20A single circuit surge protection device shall be Lowell Model
ACSP2004IG-GTF with ground transient filter and (2) duplex isolated
ground outlets. The surge suppressor/ground filter assembly shall be ETL
listed (1449-2) and endurance tested to meet government GSA Grade A-
Mode 1- Class 1requirements for surge suppressors. It shall meet ANSI
C62.41 and protect line to neutral without ground wire contamination. It
shall be capable of protecting audio, video, broadcast, computer, DSP,
sound recording and reinforcement equipment from transient voltages,
spikes and surges. It shall include Lowell’s Triple Clamping RedundancyTM
(TCR) technology to defeat surges up to 72,000 amps and have a
response time of less than 5 nanoseconds. It shall include Transient Noise
Reduction (filtering) of 25dB@100kHz, 50dB@1MHz.
Additionally, it shall include Lowell’s patented GTF ground filter technology
to attenuate high frequency transients. The filter shall be compliant with
the Standards for Electromagnetic Interference filters (ANSI/UL 1283 - 4th
Edition, 6/1998; rev 2/2004) and Electromagnetic Interference filters (CSA
C22.2 No. 8 - M1986). The filter shall have a current rating of 20A and
impedance of 0.06 ohms at 60Hz.
The assembly shall rack mount and include (2) duplex isolated ground
outlets mounted on 90º plates that can be rotated for front or side access
plus blank plates for hardwire applications. The front shall include three
LED's for visual ground verification and diagnostics.

ACSP2004-IG-GTF
20A Single-circuit Surge Suppressor with Ground Transient Filter
Lowell Manufacturing Company • 100 Integram Drive • Pacific, Missouri 63069 U.S.A.
Call 800.325.9660, 636.257.3400 • Fax [phone] • Click www.lowellmfg.com
Lowell makes every effort to provide accurate information and reserves the right to change specifications and/or improve manufacturing methods.
Download and print this spec from www.lowellmfg.com to insure that you have the most current information
1c-107
pg 4 of 4
ACSP2004-IG-GTF wiring using only factory-installed receptacle
ACSP2004-IG-GTF wiring using factory-installed receptacle + aux. receptacle
ACSP2004-IG-GTF wiring for permanent (hardwire) installation (no receptacles)
ACSP2004-IG-GTF wiring using only factory-installed IG receptacle
ACSP2004-IG-GTF wiring using factory-installed IG receptacle + aux IG receptacle
ACSP2004-IG-GTF wiring for permanent (hardwire) installation (no receptacles)
Factory installed
duplex receptacle
1) Connect input (line)
to pigtails. Any knock-
out may be utilized.
2) Install blank cover.
1) Cut leads to factory
installed
receptacle. Splice
in leads from
auxiliary receptacle.
Alternate Method: Remove receptacle from plate. Connect auxiliary receptacle leads to
screw terminals. Re-install receptacle to plate.
Safety Ground (see *Note)
Neutral (white)
Line (black)
Typical Wiring ACSP2004IG-GTF (with safety ground only)
Auxiliary
Receptacle
(shown connected)
2) Cut or disconnect
wires to factory
installed receptacle.
4) Connect load
(output). Any
knockout may
be utilized.
5) Connect Green
wire from board
to isolated
ground.
6) Install blank
cover on each
side.
Factory installed
isolated-ground
duplex receptacle
Alternate Method: Remove receptacle from plate. Connect auxiliary receptacle leads to
screw terminals. Re-install receptacle to plate.
3) Connect safety
ground (green)
from load side.
4) Connect load
(output). Any
knockout may
be utilized.
4) Connect Green
wire from board
to isolated
ground.
6) Install blank
cover on each
side.
Typical Wiring ACSP2004IG-GTF (with independent isolated ground)
Ground Stud
2) Cut or disconnect
wires to factory
installed receptacle.
1) Connect input (line)
to pigtails. Any knock-
out may be utilized.
2) Install blank cover.
1) Cut leads to factory
installed
receptacle. Splice
in leads from
auxiliary receptacle.
Safety Ground (green)
Neutral (white)
Line (black)
Isolated Ground
(green/yellow stripe)
Auxiliary
Receptacle
(shown connected)
1) Connect input (line)
to pigtails. Any knock-
out may be utilized.
Safety Ground (see *Note)
Neutral (white)
Line (black)
1) Connect input (line)
to pigtails. Any knock-
out may be utilized.
Safety Ground (green)
Neutral (white)
Line (black)
Isolated Ground
(green/yellow stripe)
*Note: Connect bonding
jumper and green striped
wire from GTF.
*Note: Connect bonding
jumper and green striped
wire from GTF.
3) Connect safety
ground from load
side.
