LS tractor J2020H User manual

LS TRACTOR
OPERATOR'S MANUAL
LS TRACTOR
OPERATOR'S MANUAL
INNOVATIVE
TECHNOLOGY
PARTNER
J2020H J2030H
OPERATOR'S MANUAL
PO Box 70, Battleboro, NC 27809
Tel : [phone]
Fax : [phone]
www.lstractor.co
www.lstractorusa.co
J-SERIES
P/NO 52105107
DATE 20110501

Contents
1. General Notices for Safety
1-1. Before using the tractor ······································1-1
1-2. Safety Precautions (Read this for safety before using)
(1)Noticesbeforeusing·········································1-3
(2) Notices when starting Engine · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-
(3) Notices while operating/using the tractor · · · · · · · · · · · · · · · · · · · · · · · · · · 1-6
(4) Notices when connecting Implement · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-8
( ) Notices when towing the tractor · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-8
(6) Notices when transporting the tractor · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-9
(7) Notices when parking tractor · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-9
2. The Name of Each Part
(1)HSTType················································2-1
(8) Notices when checking tractor after work · · · · · · · · · · · · · · · · · · · · · · · · 1-10
(9) Notices when handling Diesel Fuel · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-11
(10) Operator Protective Structure (OPS) · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-11
1-3. Long-term storage
(1) Preparation for storage · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-12
(2) Check & Maintenance during storage · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-13
(3) Preparation for Reuse · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-13
1-4. otices for “Use & Disposal” related to Environment Preservation ···
1-14
1-5. Symbols ··················································1-1
1-6. Safety Decals
(1) Handling and Maintenance of Safety Decals · · · · · · · · · · · · · · · · · · · · · · 1-16
(2) Safety Decals and attaching position · · · · · · · · · · · · · · · · · · · · · · · · · · · · 1-16
3. Instruments and Controls
3-1. Instrument Panel and Switches
(1)Thenameofeachpart········································3-1
(2) Key switch · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-1
(3) Cold start aid indicator · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-1
(4) Tachometer and Hour meter · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-2
( ) Engine coolant temperature gauge· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-2
(6)Fuellevelgauge·············································3-2
(7)Turnsignallightswitch········································3-3
(8) Engine oil pressure indicator · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-3

Contents
(9) Battery charging indicator · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-3
(10)Lightswitch················································3-4
(11)Hornswitch················································3-4
(12) Hazard warning light switch · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-
(13) Work light switch · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-
(14) PTO operation indicator · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-6
(1 )PTOswitch················································3-6
(16) Parking brake indicator · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-6
3-2. Operating Levers and Pedals
(
1
)
Throttle
lever
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
3
-
7
(
1
)
Throttle
lever
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
3
-
7
(2)Brakepedal ···············································3-8
(3) Parking brake lever· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-8
(4) Range gear shift lever · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-8
( )PTOgearlever(iffitted)······································3-9
(6)4WDlever··················································3-9
(7)Differentiallockpedal········································3-10
(8) HST forward/ reverse pedal (HST type) · · · · · · · · · · · · · · · · · · · · · · · · · · 3-10
(9)HSTneutralswitch··········································3-11
(11) Cruise control lever (HST type) · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-11
(10)Driver’sseat(HSTtype)·····································3-12
(12) Seat adjustment · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-12
3-3. Hydraulic System
(1) Steering system · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-13
(2) Hydraulic lift Control · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-14
(3) Down speed control knob · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-14
(4) Remote control lever and Quick coupler · · · · · · · · · · · · · · · · · · · · · · · · · 3-1
( ) Hydraulic System Diagram · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-16
3-4. Safety Device
(1) Seat belt · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3-17
(2) Foldable Safety frame (R.O.P.S. type) · · · · · · · · · · · · · · · · · · · · · · · · · 3-17
4. Operation and Work
4-1. Engine start and stop
(1) Engine start · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-1
(2)Startincoldweather········································4-2
(3) Engine stop · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-2

Contents
4-2. How to Drive and how to Stop
(1) How to drive · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-3
(2)Changingspeed·············································4-4
(3)EmergencyStop·············································4-4
(4) Stopping tractor · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-
( ) Driving tractor on the road · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-6
(6)Parking····················································4-7
4-3. How to handle new tractor
(1)Checkpoints················································4-8
(
2
)
Notices
in
handling
new
Tractor
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
4
-
8
(
2
)
Notices
in
handling
new
Tractor
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
4
-
8
4-4. Attaching Implement
(1) 3-point linkage · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-9
(2) Upper link installation and adjustment · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-10
(3) Adjustment of Lift rod’s length · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-10
(4) Adjustment of Stabilizer’s length · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-10
( ) Reference of Implement installation part · · · · · · · · · · · · · · · · · · · · · · · · 4-11
(6) Reference of PTO shaft · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-11
(7) PTO Safety cover and protection cap · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-12
(8) Hitch and Drawbar · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-13
(9)7-Poleconnector(option)·····································4-14
(10) Technically maximum permissible mass · · · · · · · · · · · · · · · · · · · · · · · · 4-1
(11) Adjusting Wheel tracks and tire replacement · · · · · · · · · · · · · · · · · · · · · 4-16
(12) Tires and Load capacity · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-16
(13) Adjusting Steering angle · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 4-17
4-5. Driving Speed·············································4-18
. Lubrication and Maintenance
5-1. Checking of Each Part
(1)CheckingParts·············································· -1
(2)MaintenanceTable··········································· -2
5-2. Lubricants and Capacity · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -3
5-3. Access for maintenance ····································· -4
5-4. First 50 hour check ····································· -4
5-5. Checking Before Staring (Daily check)
(1)Engineoil··················· ······························· -
(2)Fueltank··················································· -6

Contents
(3) Instrument panel & Indicators · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -6
(4) Turn signal lights, Lights, Horn · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -7
( ) Engine coolant · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -7
(6) Air cleaner (Dry type) · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -8
(7) Cleaning of Radiator and Radiator screen · · · · · · · · · · · · · · · · · · · · · · -9
(8) Tires air pressure and damage · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -9
(9) Tightening state of Bolts and Nuts of each part · · · · · · · · · · · · · · · · · · -10
(10) Adjustment of Brake pedal play · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -10
(11) Adjusting HST control linkage (HST type) · · · · · · · · · · · · · · · · · · · · · · · -11
5
-
6. Every 50 hour check
5
-
6. Every 50 hour check
(1) Lubricating grease · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -12
(2) Checking Transmission oil · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -12
(3) Checking Front axle oil · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -13
(4) Battery check · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -13
( ) Air cleaner (Dry type) · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -13
(6) Cleaning of Radiator and Radiator screen · · · · · · · · · · · · · · · · · · · · · · · -13
5-7. Every 300 hour check
(1) Replacing Engine oil and Filter · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -14
(2) Replacing Hydraulic oil Filter · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -1
(3) Replacing Fuel filter cartridge· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -16
(4) Replacing Air cleaner element (Dry type) · · · · · · · · · · · · · · · · · · · · · · · · · -16
( ) Tension adjustment of Fan belt · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -17
(6)Toe-in···················································· -17
5-8. Every 600 hour check
(1) Changing Front axle oil · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -18
(2) Changing Transmission oil · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -18
(3) Replacement of Engine Coolant · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -19
(4) Adjusting Engine Valve clearance · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -20
( ) Checking Nozzle injection pressure · · · · · · · · · · · · · · · · · · · · · · · · · · · · -20
5-9. General maintenance (When required)
(1) Air-bleeding from Fuel system · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -21
(2)Fuse&Mainfuse··········································· -23
(3) Battery handling and Notices · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -2
5-10. Troubleshooting ······ · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · -29
6. Dimension and Specification · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6-1

1. General Notices for Safety
1-1. Before using the tractor
※
※※
※Read this Operator’s manual carefully, before using the tractor,
to understand fully.
◆
◆◆
◆General information for right use
Your tractor is designed and manufactured to be used for agriculture. Do not use the product for
improper purpose out of the intention of manufacturer, and follow the safety instructions pro ided by
this Operator’s manual.
Especially, read Chapter 1 “General Notices for Safety” thoroughly and never modify or change
the dri er’s protection de ice or safety de ice without permission, never use tractor without safety
de ices or operate in iolation of traffic rules, etc. (Do not remo e seat belt or safety frame (Roll bar)
or PTO shield)
After using first 50hours, perform “First 0 hour check” and periodic regular check. (See page 5-4)
The manufacturer will not be responsible for the damage or safety problems caused by maintenance
or repair with non-genuine parts. It must be requested to use the genuine parts.
When cleaning the tractor by using high pressurized water, do not inject water directly to the
electronic parts, wiring, air intake pipe, hot engine or muffler inside bonnet.
1
11
1 - 1
◆
◆◆
◆Safety Mark Description
- In the places where the cautions in usage are required, the marks such as “DANGER”, “WARNING”,
“CAUTION” are found.
- You should comply with the description marked on the decals attached on the product or the contents
marked with safety mark in this Operator's Manual..
Warning – This indicates a potential dangerous situation that may cause a serious
injury or death if not a oided.
Caution – This indicates a potential dangerous situation that may cause a light
injury or damage to the properties if not a oided.
Notice – This indicates the instructions for right use for the safety of persons or
products.
Danger – This indicates a fatal dangerous situation that may cause a serious injury
or death if not a oided.
Notice
Caution
Warning
Danger
Maintenance and repair of the tractor is performed by skilled technical experts with the proper
tools authorized by the manufacturer.
For damage or accidents caused by the miss use or operation in iolation of these rules, the
manufacturer will not ha e any responsibility and warranty.
Keep this Operator’s manual for future reference at hand (on the tractor).

Fig.1-1
Fig.1-2
Engine No.
◆
◆◆
◆Product Identification
Your tractor has a exclusi e chassis number and
engine number marked with product serial number
tag to identify the product. (See Fig.1-1)
In case of requesting ser ice or parts from your
dealer
Dealer will need chassis serial number, engine
serial number, and also running hours displayed on
the instrument panel. (See Fig. 1-3)
Chassis No.
1
11
1 - 2
Front
Rear
RightLeft
Fig.1-3
◆
◆◆
◆Terminology
When reading this Operator's Manual, refer to
the right figure for the discrimination of the front/
rear/ left/ right direction.
Running hour

1-2. Safety Precautions - read this for safety before using.
(1) Notices before using
For Safety Instruction : Before using the tractor,
read this Operator's Manual carefully and
understand the instructions fully for the safety
pre ention and right usage of the tractor and then
use the tractor safely according to the instructions.
Refer to Operator’s
Manual.
Operator’s condition : The persons such as
patients, drunks, people on drugs etc. are ne er
allowed to operate this tractor.
Only educated operators can use the tractor after
learning the usage of controls for mo ing, stopping,
turning and other operating.
Safety Decals : For right use and personal safety of the operator, the safety decals are attached to
the parts related with safety operation. Before using the tractor, comply with the safety instructions.
(For further information, refer to “1-6 Safety Decals”, See page 1-16)
Especially, special cares must be taken for using the tractor in the places where the safety
signs such as Danger, Warning, Caution etc. are marked. For further information, See page 1-1)
1
11
1 - 3
▶ Additional seat (if fitted) is used for dri er training or instruction. Do not permit
anyone to ride on the tractor.
Warning
Suitable Clothes & Protect Entanglement :
When checking or operating the tractor, wear tight
fitting clothes and safety equipment instead of
loose or long clothes. Also, slippers, high heel
shoes are not suitable for operation. Wear the low
shoes or work shoes or boots.
Warning
▶ Do not approach the rotating shaft such as PTO shaft or cooling fan, especially,
with loose clothing and long clothes. The entanglement in rotating shaft can cause
serious injury or death.
▶ Stop the engine and be sure PTO shaft is stopped before getting near it.
Keep Riders off : Riders on the tractor or implements obstruct the operator’s iew and can be
thrown off the tractor. It can cause a serious injury or death. Riders should not be carried on the
tractor at any time.

Protect Children : Pay special attention to children (or a child) while using the tractor or during
storage.
- Make sure children keep a safe distance from the tractor and all implements before using the
tractor. Be alert to the presence of children.
- Do not let children or an untrained person operate the tractor.
- Do not allow children to approach the tractor while the engine is running.
- When parking the tractor, remo e the ignition key and lower implements to the ground for
children’s safety.
▶ As children are ery curious, they may do unexpected mo ements or actions.
Special care must be taken, when operating tractor or equipment.
Warning
Periodical Check : “Lubrication and Maintenance” must be performed periodically. If necessary,
do it immediately and if not, it may cause the failure, reduction of product life or physical injury.
* Periodic Lubrication and Maintenance
Fuel, Oil, Filter, Air cleaner, Battery, Belt, Cable, Grease, Pedals such as clutch and brake pedal,
Tire air pressure, Wheel bolts, Toe-in, Electrical wirings, other items related to safety.
Genuine Parts : When replacing parts, you must use “Genuine Parts” of LS tractor. Contact your
authorized dealer. If not, it may cause a reduction of product life, failure and serious injury.
Restrict Maintenance : If you repair or change some components and settings arbitrary, the
performance of the tractor can NOT be guaranteed and may oid the warranty, And also,
1
11
1 - 4
performance of the tractor can NOT be guaranteed and may oid the warranty, And also,
maintenance of the hea y weighted parts without special tools can cause serious injury.
If it is required to check or repair the tractor due to trouble, or if you ha e any questions for the
usage or operation of the tractor, contact your authorized dealer.
* The items that are not allowed to be modified or changed or remo ed arbitrarily by user are
below :
- Protection structures such as PTO co er, Guards, Safety frame (Roll Bar), Cabin, etc.
- Engine components, Fuel injection control and setting, etc.
- Automatic control equipment, Lamps, Transmission, Hydraulic al e and pressure settings.
- Other parts that detail and where complicated adjustments are needed.
▶ Skilled professional technology is needed for the repair.
▶ For detail maintenance or repair, contact your authorized dealer.
Warning
Lamps : Do not modify the lamps or change the bulb capacity arbitrarily.
▶ Modified lamps or change bulb capacity may cause the traffic accident by disturbing
approaching dri er’s iews.
▶ If the lamp is blown out, replace it immediately with a genuine part. In case of
dri ing at night, it may cause a traffic accident.
Warning

(2) Notices when starting Engine
Check each part with reference of “5. Lubrication
and Maintenance” in this manual. If necessary,
repair or replace it immediately. Especially,
check if safety protection structures or covers
are attached originally and the bolts are
tightened well.
Before starting, check again if there are other
workers or children around the tractor and
implements and keep a safe distance.

Start engine and operate the tractor
after sitting
Safety Structure : For the safety of the dri er, arious protection structures are attached on the
tractor. If these structures are changed or detached by user arbitrarily, it may cause serious
accident. Such beha iors are prohibited strictly.
▶ Do not disassemble or drill the Bonnet (Hood), Fan co er, PTO co er, PTO shaft
co er, Safety frame (Roll Bar) or Cabin etc. or do not modify other structures by
welding arbitrarily. It may cause the loss of original function of the structures and
serious injury may occur, and may oid warranty.
▶ If the protections or safety de ices are broken, replace them immediately. If not, it
can cause a accident or serious injury.
Warning
1
11
1 - 5

Start engine and operate the tractor
after sitting
on the driver’s seat correctly with seat belt
fastened.
Place the shuttle le er, transmission gear le er in
NEUTRAL and especially check if parking brake
is applied.
Lower the implements on the ground.
Ensure that rear iew mirrors and the other
mirrors (if fitted) are adjusted correctly, and check
the operation of the headlights and other lights
Put PTO switch to “OFF” position. If the PTO
switch is “INDEP” or “MANUAL”, the engine can
NOT be started. (See Fig.1-4 )
Depress the clutch pedal fully (if fitted). If not, the
start safety switch is not contacted enough and
the engine can NOT start.
Warning
▶ Do not start the engine in a closed area. The poisonous exhaust gas can cause fatal
damage to the dri er or persons around.
Fig.1-4
PTO Switch

Connect left and right brake pedals while dri ing
on the road. (if fitted)
DO NOT use differential lock de ice while dri ing
on the road or turning in the field.
DO NOT ride your foot on the brake pedal or
(3) Notices while operating/using the tractor
Ventilation
Warning
▶ It is ery dangerous to work in a
closed area. The poisonous
exhaust gas may cause serious
damage to the human body. If
you should work in this area,
make sure to entilate well and
put on the protecti e mask.
Noise and Vibration : When working between buildings or in confined spaces, the sound pressure
le el can be increased. Wear suitable ear protectors in high noise le el conditions. When working
with equipment in the field, Vibration may intensity from the equipment may be increased. To reduce
the harm to the body, take a rest periodically.
1
11
1 - 6
clutch pedal.
Lower the dri ing speed enough before turning a
sharp cur e. Especially, when you dri e the tractor
with implements, make the turning radius wider.
DO NOT start or stop the tractor suddenly. Engage
the clutch and brake softly. If not, front wheels can
be lifted up and it is ery dangerous.
Do not jump up and down while tractor is mo ing.
When getting off or on the tractor, use the grip or
handrail and sub step to pre ent falls.
When dri ing the tractor in re erse, lower the
engine speed. Make sure to check if there is any
obstacle or person in the rear.
DO NOT permit other people and especially
children approach within working area while
operating tractor and equipment.

When crossing a high ridge, let down the
implement and go straight across the ridge at low
speed.
When connecting the implements to the front/rear
of the tractor, install the proper additional weights
in the rear/front of the tractor to keep the balance
of the tractor.
Obey the traffic rules while dri ing on public roads.
Do not exceed the local legal speed limit.
Use a sign beacon or slow mo ing ehicle (SMV)
to indicate that the ehicle is slow mo ing.
If you can not dri e the tractor due to a failure,
mo e the tractor to a safe place and install
troubled ehicle (safety tripod).
(Day : backward 100m ( 328 ft )
Night : backward 200m ( 656 ft))
Do not o eruse the fuel, oil, etc and pay attention not to contact the skin directly. Generally, these
materials contain harmful materials to the human body. When you work in a area where hazardous
chemicals are sprayed, check the cabin filter (if fitted) and replace the filter with suitable one for the
purpose being used. To protect the body completely from these harmful materials, wear a safe
protection equipment such as mask, and clean the body after working.
1
11
1 - 7
When working at the edge of steep slope, take
special care about a turn-o er.
When working, wear the protection equipment and
tighten the seat belt.
If the authorized passenger seat are not installed,
keep riders off.
On a downhill, operate the throttle pedal and brake
pedal slowly and DO NOT dri e while the
transmission gear is in NEUTRAL.
To climb a steep slope, dri e tractor slowly in
re erse up the slope rather than forward. It is
much safer.
When turning the tractor on a slope, pay attention
to safety especially.
of the tractor.

Attach or detach the implement on wide and le el
ground.
Do not stand between tractor and implement.
Use hitch or drawbar for towing. Do not tow by
connecting with any other structures.
When connecting hea y implements, apply the
parking brake and use the wheel chock.
Do not attach o er-weighted implement.
▶ Before connecting or checking the implement, put PTO switch to “OFF” and place
PTO gear le er in Neutral position.
▶ When attaching or detaching the implement, make sure to fix the implement and
tighten the three point hitch pins correctly. If not, the serious troubles and injury can
occur during the operation.
Warning
(4) Notices when connecting Implement
▶ When connecting or disconnecting hydraulic coupler, lower implement on the
ground, turn off engine and check if the pressure of hydraulic line is released.
▶ When installing the implement ha ing big hydraulic cylinders or lines, check oil le el
in tractor transmission housing after installing the implements.
Caution
1
11
1 - 8
Check the horizontal and ertical permissible load of the hitch (or drawbar) before towing. The load
is different with trailer brake, and stopping distance increases with speed and weight of towed loads
and slope. Make sure you consider the total weight of the equipment and its load. (See page 4-13 )
( ) Notices when towing the tractor
▶ If hea y loaded trailer is connected to 3-point linkage or any structure, it can cause
turno er or failure and serious injury. Make sure to use towing hitch or authorized
draw bar.
If tractor needs to be towed for a short distance,
Use the hitch (or drawbar) or front towing hook.
Do not connect to other structures such as rear
axle, ROPS, front axle, steering components for
towing.
Tractor can be steered for a short distance
without engine running, but it will be hard to turn
the steering wheel. If possible, run the engine for
steering and lubrication.
When being towed, disengage the 4WD,
differential lock, parking brake and place all gear
shift le ers in neutral position. Refer to “3-2.
Operating le ers and pedals”. See page 3-7)

(6) Notices when transporting the tractor
When transporting the tractor by truck, trailer,
etc, use suitable equipment or facilities to
load or unload the tractor.
Fix the tractor tightly to the ehicle with hea y-
duty straps or chains.
When fixing the rear of the tractor, use the hitch
or hitch support.
When fixing the front of the tractor, use the
towing hook.
When dri ing on public roads, the transporting
ehicle must ha e signs and lights required by
local regulation to a oid collision with a ehicle.
▶ When fixing the tractor, Do not hook or connect chains to the 4WD shaft, steering
cylinder, tie-rod or front axle. These can be damaged by the chain or excessi e
strain.
▶ In case of turbocharger engine (if fitted), co er the exhaust outlet to protect that the
turbocharger does not rotate by air without lubrication.
Caution
1
11
1 - 9
(7) Notices when parking tractor
Stop the tractor on le el ground. Place the
transmission gear in neutral.
Put PTO switch to “OFF” and lower implements to
the ground.
Stop the engine and remo e the ignition key.
Apply the parking brake.
Ha e to apply the wheel chock on a slope.
▶ When parking on a slope while attaching the loaded equipment, the tractor may
mo e e en if the parking brake is applied. Apply the wheel chock and low speed
transmission gear as follow.
-. Mechanical : downhill ⇒ Re erse 1gear / uphill ⇒ Forward 1gear
-. HST type : Lowest gear
Caution

(8) Notices when checking tractor after work
The check and maintenance must be performed after stopping the engine and cooling down the
engine sufficiently.
Warning
▶ When opening the radiator cap,
hot cooling water or steam may
explode. Remo e the cap using
a thick rag or glo e to pre ent
serious burns.
DO NOT pour water into the radiator or engine
when the engine is hot. The engine or radiator
may crack.
▶ Before remo ing hydraulic pipe or hose and other parts, check if the system
pressure is remo ed. The leakage of pressurized oil can cause a fatal physical injury.
Use the proper protection equipment.
▶ When connecting or disconnecting the hydraulic quick coupler, lower the
implements to the ground after checking that hydraulic pressure is released.
When checking or repairing the hydraulic system or fuel system, high pressurized oil or fuel may
cause a se ere injury.
Make sure the engine is stopped, and all the transmission gears are in NEUTRAL, and lower the
implements to the ground, and mo e once the remote control le er to each direction to release the
hydraulic system pressure.
Warning
1
11
1 - 10
Ne er fill the fuel tank while the engine is running or the engine is hot. And ne er smoke or ha e
flames around fuel tank.
Keep the fire distinguisher near.
When maintaining the electric system, remo e the ground clamp of battery (“-” terminal). To pre ent
fire or explosion, keep flames or sparks away from battery.
▶ Always remo e grounded (-) battery clamp first and assemble it last. If not, It can
cause an explosion by spark. (for further information, see page 5-25)
Caution
implements to the ground after checking that hydraulic pressure is released.
Do not attempt to remo e or unfasten the air conditioning components arbitrary. There is a possible
to be se erely frostbitten or injured by escaping refrigerant. Contact your authorized dealer to work
air conditioning systems.

(9) Notices when handling Diesel Fuel
Do not mix gasoline, alcohol or blended fuels to diesel fuel. These mixtures are explosi e in fuel
tank.
Ne er remo e the fuel cap or refuel with the engine running or hot.
Do not smoke while refueling the tractor or when standing near fuel. Keep any type of flame away.
Maintain control of the fuel filler nozzle when filling the fuel tank.
Do not fill the fuel tank to capacity. Fill only to the bottom of the filler neck to allow room for
expansion.
Wipe up spilled fuel immediately and always tighten the fuel tank cap securely.
If the original fuel tank cap is lost, replace it with an appro ed one.
Ne er use fuel for cleaning purposes.
Arrange fuel purchases so that summer grade fuels are not held o er and used in the winter.
Warning
▶ Your tractor is equipped with an Operator Protecti e Structure (OPS), such as ;
Safety frame (Roll O er Protecti e Structure (ROPS)) or Falling object Protecti e
Structure (FOPS) or Cabin with ROPS (Roll Bar).
▶ This structure is a special safety structure for agricultural tractor that used for the
protection of the operator to minimize the possibility of serious injury.
This structure
(10) Operator Protective Structure (OPS)
1
11
1 - 11
protection of the operator to minimize the possibility of serious injury.
This structure
does not guarantee full protection against all working conditions, i.e. falling
objects, low hanging wires and branches in the forest, orchard or construction
area, etc. NEVER enter or operate these hazardous area without certified
Operator Protective Structure installed.
▶ The Protecti e Structure and interconnecting components are a certified system.
Any damage, Fire, corrosion or modification will weaken the structure and reduce
your protection. If this occurs, the Protecti e Structure MUST be replaced with a new
one. Contact your authorized dealer for Protecti e Structure inspection and
replacement.
▶ In case of an accident, fire, tip or roll o er, the following MUST be performed by a
qualified technician before operating the tractor again.
- The Protecti e Structure MUST be replaced.
- The mounting or suspension for the Protecti e Structure , operator seat and
suspension, seat belt and mounting components and wiring within the operator’s
protecti e system MUST be carefully inspected for damage.
- All damaged parts MUST be replaced.
▶ DO NOT attach any device to the Protective Structure for pulling purposes.
▶ DO NOT weld, drill holes, attempt to straighten or repair the protective
structure. The modification can reduce the structural integrity of the structure
which can cause death or serious injury in the event of fire, tip, roll over,
collision or accident and void the warranty.

1-3. Long-term storage
(1) Preparation for storage
※ Wash the tractor cleanly and follow the procedure
as below.
Apply grease or lubricant oil or spray paint to the
non-painted metal to a oid corrosion. Keep the
tractor in a co ered, dry and well- entilated place.
Temperature : 10 ℃ ~ 35 ℃ (50 ℉ ~ 95 ℉ )
Humidity : 45% ~ 70%
Place all controls, including electrical switches, in
neutral position and apply the wheel chock to the
tires and disengage the parking brake.
Check the lubricant capacity of each part and if the
engine oil has exceeded 100 hours of work,
change the oil and run the engine for 5 minutes at
idle rpm.
Drain the engine coolant completely. If the engine
coolant is anti-freeze solution, it is not necessary
to drain but check its concentration.
Lift arm
1
11
1 - 12
to drain but check its concentration.
Fill the fuel tank full with fuel.
Loosen all dri e belts and clean the air cleaner.
Loosen the rubber plug (if fitted) under the clutch
chamber to drain water.
Remo e the battery, clean the co er and smear the
terminals with grease. Place the battery in a
entilated place not less than 10°C (50°F) and
away from direct sunlight.
Warning
▶ When restarting the engine at the end of long-term storage, follow the instructions
of “Preparation for Reuse”. (See next page)
Lift rod
If possible, fit stands or other suitable supports under the axles to raise the wheel off the ground.
And let the air out of the tires. If not, check the tire pressure from time to time.
Remo e the lift rod and place the lift arm to the highest position to protect the cylinder.
Remo e the ignition key.
Co er the tractor with a non-water-proof co er.
If the implements are attached, lower the implements on a support off the ground.

(2) Check & Maintenance during storage
Apply grease or lubricant oil to non-painted metal to a oid corrosion.
Check the leakage of fuel, oil and coolant. If necessary, repair the damaged part.
The battery should be charged about once a month not to be discharged entirely.
Check the tire air pressure and maintain the proper pressure.
▶ As the electrolyte of battery is sulfuric acid, it is emits the explosi e and poisonous
gas. It is strong enough to burn skin, clothing and can cause blindness if splashed
into eyes.
- Keep the sparks and flames and cigarettes away from the battery.
- When handling the battery, wear safety glasses to protect the eyes.
- If the electrolyte contacts the eyes and skin, wash with water immediately and go
to see a doctor. ( ※ For further information, refer to the section of “Battery handling
and Notices”, See page 5-25)
▶ When remo ing and storing battery, select dry and cool place out of reach of
children.
Caution
(3) Preparation for Reuse
※
When using first after long
-
term storage, check each part as below.
1
11
1 - 13
※
When using first after long
-
term storage, check each part as below.
Check the damaged part or loosen part
Check the leakage of fuel, coolant, engine oil, transmission and front axle oil.
Check the le el and density of the engine coolant.
Check the le el of engine, transmission, rear and front axle oil, and fuel.
(For further information, refer to the section “5. Lubrication and Maintenance” in this manual.)
Check all dri e belts carefully, paying particular attention to the point where the straight run of the belt
starts to bend around the pulley. Check the ee groo e in the pulley for corrosion.
Electric system check
- Is there any open circuit or any other problem in the wiring?
- Is there any problem of the instruments?
- Is the charging state of the battery sufficient?
Start engine and then check the engine oil pressure indicator and battery charging indicator. Run the
engine at a fast idling speed (suggest 1000/1500 rpm) until normal operating temperature is
resistered, and check for oil, fuel and coolant leakage. (For further information, See page 4-1)

Soil, Air and Water are essential elements for human life. To contribute to en ironment
preser ation of the Earth, we are trying to minimize the en ironment pollution necessitated by
general business acti ity such as product design, manufacturing, distribution, etc.
Se eral substances and products deri ed from chemical and petrochemical products are major
portion of en ironment pollution and must be disposed of according to en ironment laws or
related regulations, and common sense.
We’d like to notify the following items for “Use & Disposal” related to en ironment preser ation.
1. A oid the o erload work after reading the Operator's Manual.
O erload work may reduce the life of the product as well as the unburned exhaust gas
occurred during o erload work becomes the major cause of air pollution.
2. When you replace arious oils (engine, transmission, anti-freeze solution) directly, do not
1-4. Notices for ”Use & Disposal” related to En ironment
preser ation
1
11
1 - 14
throw the exhausted waste oil to any place.
This may pollute the soil and water seriously and also is prohibited legally. If iolating, you
would be responsible for that by ci il or criminal case. The waste oil must be disposed
according to the en ironment laws.
3. Use the product according to the Operator's Manual and if the life of product ended, do not
throw away (or dispose) to any place. The rust water or oil coming from the disposed
product may cause the pollution of soil or water. Thus, the wasted product must be
disposed lawfully, contact your authorized dealer nearby.
4. Modern lubricants contain additi es. Do not burn the disposed oil or fuel in con entional
heating systems.
5. When you drain or fill the fuel, lubricants oil and coolants, do not left to be absorbed into the
ground. They must be collected and disposed in a suitable manner.
6. Do not adjust the setting of the fuel deli ery system. This will alter the emission of exhaust
fumes.

Gear Neutral
The followings show the symbols and its meaning used for the tractor.
1-5. Symbols
Low speed
High speed
Engine speed
control (throttle)
Engine speed
control (throttle)
Forward/Rearward
Forward
Backward
4WD disconnection
4WD connection
Quick turn
(Optional)
Turn signal
light
Light switch
Fuel le el
Refer to User’s
Manual.
Fuel filter
Battery charging
Caution!
Transmission
oil pressure
Engine coolant
temperature
Direction
indicating light
1
11
1 - 15
Position control
(Up)
Position control
(Down)
Draft control
(Deep)
Draft control
(Shallow)
Parking brake
Headlights
(downward)
Side lights
Headlights
(upward)
Work light
Emergency lights
Cylinder rod
(shorten)
Cylinder rod
(extend)
Cylinder rod
(floating)
Window wiper
Window wiper
/ Washer (front)
Window wiper
/ Washer (rear)
Cruise dri e
(Optional)
Cruise dri e release
(optional)
Engine oil pressure
Diesel engine
preheat
Differential lock
de ice
horn
Engine stop
PTO in operation
PTO stop
Engine start
One side brake
light (option)
